Teledyne T3LCR1002 User manual

T3LCR1002, T3LCR1100, T3LCR1300
Precision LCR Meters
Quick Start Guide

This quick start guide contains proprietary information, which is
protected by copyright. All rights are reserved. No part of this manual
may be photocopied, reproduced or translated to another language
without prior written consent of Teledyne LeCroy company.
The information in this quick start guide was correct at the time of
printing. However, Teledyne LeCroy continues to improve products
and reserves the rights to change specification, equipment, and
maintenance procedures at any time without notice.

SAFETY INSTRUCTIONS
Safety Symbols
These safety symbols may appear in the quick start guide or on the
instrument.
WARNING
Warning: Identifies conditions or practices that
could result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that
could result in damage to the instrument or to
other properties.
When you notice any of the unusual conditions listed below,
immediately terminate operation and disconnect the power cable.
Please contact the Teledyne service center representative for repair
of the instrument. If you continue to operate without repairing the
instrument, there is a potential fire or shock hazard for operators.
The instrument is operating abnormally if:
•The instrument emits abnormal noise, smell, smoke, or a spark-
like light during the operation.
•The instrument generates high temperature or electrical shock
during operation.
•The power cable, plug, or receptacle on the instrument is
damaged.
•Foreign substances or liquid has fallen into the instrument.
The following general safety precautions must be observed during
all phases of operation, service, and repair of this instrument.
Failure to comply with these precautions or with specific
WARNINGS elsewhere in this manual may impair the protection
provided by the equipment. In addition it violates safety standards
of design, manufacture, and intended use of the instrument.
1

Disclaimer
Teledyne assumes no liability for the customer's
failure to comply with these requirements.
Ground The
Instrument
To avoid electric shock hazards, the instrument
chassis and cabinet must be connected to a safety
earth ground by the supplied power cable with
earth blade.
DO NOT Operate
In An Explosive
Atmosphere
Do not operate the instrument in the presence of
inflammable gasses or fumes. Operation of any
electrical instrument in such an environment
constitutes a definite safety hazard.
Keep Away From
Live Circuits
Operating personnel must not remove instrument
covers. Component replacement and internal
adjustments must be made by qualified
maintenance personnel. Do not replace
components with the power cable connected.
Under certain conditions, dangerous voltages may
exist even with the power cable is removed. To
avoid injuries, always disconnect the power and
discharge the circuits before touching them.
DO NOT Service
Or Adjust Alone
Do not attempt internal service or adjustment
unless another person, capable of rendering first
aid and resuscitation, is present.
DO NOT
Substitute Parts
Or Modify
Instrument
Because of the danger of introducing additional
hazards, do not install substitute parts or perform
unauthorized modifications to the instrument.
Return the instrument to a Teledyne authorized
service center for service and repair to ensure that
safety features are maintained.
2

GETTING STARTED
This chapter describes names and functions of the front panel, rear
panel, and screen display and provides the basic procedures for
operating the T3LCR series.
Overview
The Teledyne T3LCR series is a general-purpose LCR meter for
incoming inspection of components, quality control, and laboratory
use.
The T3LCR series is used for evaluating LCR components,
materials, and semiconductor devices over a wide range of
frequencies (10 Hz to 300 kHz) and test signal levels (10.00mV to
2.00V & 100.0uA to 20.00mA).
With its built-in comparator, the T3LCR series can output
comparison/decision results for sorting components into a
maximum of ten bins. Furthermore, by using the handler interface,
the T3LCR
Main Features
Correction
Function
•OPEN/SHORT correction
Eliminates measurement errors due to stray
parasitic impedance in the test fixtures.
Comparator
Function
(Sorting)
•Bin sort
The primary parameter can be sorted into
BIN1- BIN9, AUX, OUT and HI/IN/LO for
each of the primary measurement parameters.
The sequential mode or tolerance mode can be
selected as the sorting mode.
3
series can be easily combined with a component handler,
and a system controller to fully automate component testing,
sorting, and quality- control data processing.
The list Meas function permits entry of up to 10 frequencies or test
signal levels points to be automatically measured.

•Limit Setup
Absolute value, deviation value, and %
deviation value can be used for setup.
•BIN count
Countable from 0 to 999999
Files
•Up to 10 setup conditions can be written
to/read from the built-in non-volatile memory.
Key Lock
•The front panel keys can be locked.
RS-232
•Complies with SCPI.
Front Panel







 
 
Description
1. LCD Display
2. Soft-key
3. Number Key
4. Cursor Key
5. Power Switch
6. Measure key
7. Setup Key
8. BNC Terminal
9. Trigger Key
10. ESC Key
11. USB Disk Port (USB-Host)
12. System Soft-key
4

Rear Panel
Power On
Press the power key for at least 2 seconds. Release power key when
the POWER LED is lit.
Power Off
Press the power key at least 2 seconds. LCR down when you
release the power key.
Description
1. Power Cable Receptacle(Outlet)
2. Frame Terminal
3. USB Interface (Type B)
4. RS-232 Interface
5. Handler Interface



5

Warm-up Time
T3LCR series is ready to be used as soon as the power-up sequence
has completed. However, to achieve the specification accuracy, first
warm up the instrument for 30 minutes.
Connect to the Device Under Test (DUT)
The T3LCR series uses a four terminal measurement configuration
that provides easy, accurate and stable measurements and avoids
mutual inductance, interference from measurement signals, noise
and other factors inherent with other types of connections.
Connect to DUT
WARNING
+
L Force L Sense H Sense H Force
-DUT+
+
-
6
Identifies conditions or practices that could result
in injury or loss of life. Do not apply DC voltage or
current to the UNKNOWN terminals. Applying a
DC voltage or current may lead to device failure.
Connect the measurement sample (DUT) to the
test port (or the test fixture, cables, etc. after the
DUT has been completely discharged.

SPECIFICATIONS
The following are the basic specifications for the T3LCR series. For
detailed specifications, please see the user manual
General Specification
Display
RGB color TFT-LCD, Size: 3.5” (320x240)
Test Function
Cs-Rs, Cs-D, Cp-Rp, Cp-D, Lp-Rp, Lp-Q, Ls-Rs,
Ls-Q, Rs-Q, Rp-Q, R-X, DCR, Z-θr, Z-θd, Z-D, Z-Q
Monitor
Parameter
Z, D, Q, Vac, Iac, Δ, Δ%, θr, θd, R, X, G, B, Y
(2 Parameter)
40 times/s, 10 times/s, 3 times/s
Test Frequency
T3LCR1300: 10Hz-300kHz
T3LCR1100: 10Hz-100kHz
T3LCR1002: 10Hz-2kHz
Frequency range and resolution
Frequency range(F)
Resolution
10.00Hz ≤F ≤99.99Hz
0.01Hz
100.0Hz ≤F ≤999.9Hz
0.1Hz
1.000Hz ≤F ≤9.999Hz
1Hz
10.00kHz ≤F ≤99.99kHz
10Hz
100.0kHz ≤F ≤300.0kHz
100Hz
Frequency Accuracy
Frequency range(F) ±0.01% 4 digit resolution
7

Display Range
Parameter
Resolution
L
0.00001uH-9999.99H
C
0.00001pF-9999.99mF
R, X, |Z|
0.00001Ω-99.9999MΩ
G, B, |Y|
0.01nS-999.999S
D
0.00001-9.99999
Q
0.00001-99999.9
θd
-179.999°-179.999°
θr
-3.14159-3.14159
DCR
0.00001Ω-99.9999MΩ
Δ %
-999999%-999999%
AC Test signal level
10.00mV-2.00V (±10%)
CV: 10.00mV-2.00V (±6%)
100.0uA-20.00mA (±10%)
CC: 100.0uA-20.00mA(±6%) (@2VMax)
DCR Test signal level
+2V, 0.066A(Max.), Output impedance fixed
30Ω
DC Bias: Internal
±2.5V (0.5%+0.005V)
List Test
10Step (Frequency/Voltage/Current)
Output impedance
30Ω, 50Ω and 100Ω
Ranging
Auto, Hold and Nominal range.
Total 9 Ranges.
Equivalent Circuit
Serial and Parallel
OPEN/SHORT Test
OPEN/SHORT Zeroing (ALL,SPOT)
Files
built-in 10 files and USB Disk 10 files, 9999 Log
File, 999 Picture File, 10000 Data (.csv)
Beep Feature
OFF/PASS/FAIL
Trigger Mode
Internal, Manual, External and Bus Trigger.
8

Interface
Handler interface and RS232/USB interface.
Environment
Specification Conditions
Temperature: 23˚C±5˚C,
Relative Humidity: < 70%RH
Operating Environment
Temperature: 0~50˚C,
Relative Humidity: <70%RH
(Indoor use only, Altitude: 2000 meters)
Storage Conditions
Temperature: -10~70˚C,
Relative Humidity: <80%RH
Power Source
AC 100V-240V, 50Hz-60Hz
Fuse
2A Slow-Blow
Maximum rated power
30W
Weight
3kg, net
9

DIMENSIONS
264.4
231
107
99
291.6
308.6
311.1
10

Teledyne LeCroy certifies compliance to the following standards as
of the time of publication. Please see the EC Declaration of
Conformity document shipped with your product for current
certifications.
EMC Compliance
EC DECLARATION OF CONFORMITY - EMC
The instrument meets intent of EC Directive 2014/30/EU for
Electromagnetic Compatibility. Compliance was demonstrated to
the following specifications listed in the Official Journal of the
European Communities:
EN 61326-1:2013, EN 61326-2-1:2013 EMC requirements for
electrical equipment for measurement, control, and laboratory use.1
Electromagnetic Emissions:
EN 55011:2016+A1:2017, Radiated and Conducted Emissions
Group 1, Class A 2 3
EN 61000-3-2:2014 Harmonic Current Emissions, Class A
EN 61000-3-3:2013 Voltage Fluctuations and Flickers, Pst = 1
Electromagnetic Immunity:
EN 61000-4-2:2009 Electrostatic Discharge, 4 kV contact, 8 kV air, 4
kV vertical/horizontal coupling planes 4
EN 61000-4-3:2006+ A2:2010 RF Radiated Electromagnetic Field,
3 V/m, 80-1000 MHz; 3 V/m, 1400 MHz - 2 GHz; 1 V/m, 2 GHz -
2.7 GHz
CERTIFICATIONS
11

EN 61000-4-4:2012 Electrical Fast Transient/Burst, 1 kV on power
supply lines, 0.5 kV on I/O signal data and control lines 4
EN 61000-4-5:2014+A1:2017 Power Line Surge, 1 kV AC Mains, L-N,
L-PE, N-PE4
EN 61000-4-6:2014 RF Conducted Electromagnetic Field, 3 Vrms,
0.15 MHz - 80 MHz
EN 61000-4-11:2004+A1:2017 Mains Dips and Interruptions, 0%/1
cycle, 70%/25 cycles, 0%/250 cycles 4 5
1To ensure compliance with all applicable EMC standards, use high-
quality shielded interface cables.
2Emissions which exceed the levels required by this standard may occur when the
instrument is connected to a test object.
3This product is intended for use in nonresidential areas only. Use in residential
areas may cause electromagnetic interference.
4Meets Performance Criteria “B” limits of the respective standard: during the
disturbance, product undergoes a temporary degradation or loss of function or
performance which is self-recoverable.
5Performance Criteria “C” applied for 70%/25 cycle voltage dips and for 0%/250
cycle voltage interruption test levels per EN61000-4-11.
European Contact:*
Teledyne GmbH, European Division
Im Breitspiel 11c
D-69126 Heidelberg
Germany
Tel: + 49 6221 82700
AUSTRALIA & NEW ZEALAND DECLARATION OF
CONFORMITY –EMC
The instrument complies with the EMC provision of the Radio
Communications Act per the following standards, in accordance
with requirements imposed by Australian Communication and
Media Authority (ACMA):
12

AS/NZS CISPR 11:2015 Radiated and Conducted Emissions, Group
1, Class A.
Australia / New Zealand Contacts:*
RS Components Pty Ltd.
RS Components Ltd.
Suite 326 The Parade West
Units 30 & 31 Warehouse World
Kent Town, South Australia 5067
761 Great South Road
Penrose, Auckland, New Zealand
* Visit teledynelecroy.com/support/contact for the latest contact information.
Safety Compliance
EC DECLARATION OF CONFORMITY –LOW VOLTAGE
The instrument meets intent of EC Directive 2014/35/EU for
Product Safety. Compliance was demonstrated to the following
specifications as listed in the Official Journal of the European
Communities:
EN 61010-1:2010 Safety requirements for electrical equipment for
measurement, control, and laboratory use –
Part 1: General requirements
EN 61010-2:030:2010 Safety requirements for electrical equipment
for measurement, control, and laboratory use –
Part 2-030: Particular requirements for testing and measuring
circuits
The design of the instrument has been verified to conform to the
following limits put forth by these standards:
• Mains Supply Connector: Overvoltage Category II, instrument
intended to be supplied from the building wiring at utilization
points (socket outlets and similar).
• Measuring Circuit Terminals: No rated measurement category.
Terminals not intended to be connected directly to the mains
supply.
13

• Unit: Pollution Degree 2, operating environment where
normally only dry, non-conductive pollution occurs. Temporary
conductivity caused by condensation should be expected.
Environmental Compliance
END-OF-LIFE HANDLING
The instrument is marked with this symbol to indicate
that it complies with the applicable European Union
requirements of Directives 2012/19/EU and 2006/66/EC
on Waste Electrical and Electronic Equipment (WEEE)
and Batteries.
The instrument is subject to disposal and recycling regulations that
vary by country and region. Many countries prohibit the disposal
of waste electronic equipment in standard waste receptacles. For
more information about proper disposal and recycling of your
Teledyne LeCroy product, please visit teledynelecroy.com/recycle.
RESTRICTION OF HAZARDOUS
SUBSTANCES (RoHS)
EC DECLARATION OF CONFORMITY –RoHS
Unless otherwise specified, all the materials and processes are
compliant with RoHS Directive 2011/65/EU in its entirety,
inclusive of any further amendments or modifications of said
Directive.
CHINA RoHS 2
Unless otherwise specified, all the materials and processes are
compliant with the latest requirements of China RoHS 2. The
hazardous substances contained in the instrument are disclosed in
accordance with the standards SJ/T 11364-2014 (Marking for the
restricted use of hazardous substances in electronic and electrical
products) and GB/T 26572-2011 (Requirements on concentration
14

limits for certain restricted substances in electrical and electronic
products). The instrument is marked with an appropriate
Environmental Friendly Use Period (EFUP) symbol. The packaging
materials include the appropriate recycling labels. The below
substance disclosure tables (in Chinese and English languages)
provide the required compliance information.
部件名称
有毒有害物质和元素
铅
汞
镉
六价铬
多溴联苯
多溴二苯醚
(Pb)
(Hg)
(Cd)
(Cr6+)
(PBB)
(PBDE)
PCBAs
X
O
O
O
O
O
机械硬件
O
O
O
O
O
O
金属片
O
O
O
O
O
O
塑料部件
O
O
O
O
O
O
电缆组件
X
O
O
O
O
O
显示器
O
O
O
O
O
O
电源
O
O
O
O
O
O
风扇
O
O
O
O
O
O
电池
O
O
O
O
O
O
电源线
O
O
O
O
O
O
外部电源(如有)
X
O
O
O
O
O
探头(如有)
X
O
O
O
O
O
熔丝(如有)
O
O
O
O
O
O
产品外壳(如有)
O
O
O
O
O
O
适配器/模块(如有)
O
O
O
O
O
O
鼠标(如有)
O
O
O
O
O
O
O: 表明该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T11364-2014 标准规定的限量要求
之下。
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 标准规定的限
量要求。
EFUP (对环境友好的使用时间): 30 年。
使用条件：参阅用户手册“环境条件”部分的规定。
探头 EFUP: 10 年。
15

Part Name
Toxic or Hazardous Substances and Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr6+)
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCBAs
X
O
O
O
O
O
Mechanical
Hardware
O
O
O
O
O
O
Sheet Metal
O
O
O
O
O
O
Plastic Parts
O
O
O
O
O
O
Cable Assemblies
X
O
O
O
O
O
Display
O
O
O
O
O
O
Power Supply
O
O
O
O
O
O
Fans
O
O
O
O
O
O
Batteries
O
O
O
O
O
O
Power Cord
O
O
O
O
O
O
Ext Power Supply
(if present)
X
O
O
O
O
O
Probes (if present)
X
O
O
O
O
O
Fuse (if present)
O
O
O
O
O
O
Product Case
(if present)
O
O
O
O
O
O
Adapters/Modules
(if present)
O
O
O
O
O
O
Mouse (if present)
O
O
O
O
O
O
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials
for this part is below the limit requirement specified in SJ/T11364-2014.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogenous
materials used for this part is above the limit requirement specified in SJ/T11364-2014.
EFUP (Environmental Friendly Use Period): 30 years.
Use Conditions: Refer to the environmental conditions stated in the User Manual.
EFUP for Probes: 10 years.
16

©2020 Teledyne Test Tools is a brand and trademark of Teledyne LeCroy Inc. All rights reserved. Specifications, prices, availability and delivery subject to change without notice.
Product brand or brand names are trademarks or requested trademarks of their respective holders.
T3 stands for Teledyne Test Tools. 933555-00 RevA
teledynelecroy.com
Company Profile
Teledyne LeCroy is a leading provider of oscilloscopes, protocol
analyzers and related test and measurement solutions that
enable companies acrossawide range of industries to design
and test electronic devices of all types. Since our founding in
1964, we have focused on creating products that improve
productivity by helping engineers resolve design issues faster
and more effectively.Oscilloscopes are tools used by
designers and engineers to measure and analyze complex
electronic signals in order to develop high-performance
systems and to validate electronic designs in order to improve
time to market.
The Teledyne Test Tools brand extends the Teledyne LeCroy
product portfolio with a comprehensive range of test
equipment solutions. This new range of products delivers
a broad range of quality test solutions that enable engineers to
rapidly validate product and design and reduce time-to-
market. Designers, engineers and educators rely on Teledyne
Test Tools solutions to meet their most challenging needs for
testing, education and electronics validation.
Location and Facilities
Headquartered in Chestnut Ridge, New York, Teledyne Test
Tools and Teledyne LeCroy has sales, service and
development subsidiaries in the US and throughout Europe
and Asia. Teledyne Test Tools and Teledyne LeCroy products
are employed acrossawide variety of industries, including
semiconductor, computer, consumer electronics, education,
military/aerospace, automotive/industrial, and
telecommunications.
Teledyne LeCroy
(US Headquarters)
700 Chestnut Ridge Road
Chestnut Ridge, NY. USA 10977-6499
Phone: [phone] or 845-425-2000
Fax Sales: 845-578-5985
Phone Support: 1-800-553-2769
Email Sales: [e-mail]
Email Support: [e-mail]
Web Site: http://teledynelecroy.com/
Teledyne LeCroy
(European Headquarters)
Teledyne LeCroy GmbH
Im Breitspiel 11c
D-69126 Heidelberg, Germany
Phone: + 49 6221 82700
Fax: [phone]
Fax Sales: [phone]
Fax Service: [phone]
Email Sales: [email protected]
Email Service: [email protected]
Email Support: [email protected]
Web Site: http://teledynelecroy.com/germany
Phone Service: [phone]
Phone Support: [phone]
World wide support contacts can be found at:
hps://teledynelecroy.com/support/contact
ABOUT TELEDYNE TEST TOOLS
Distributed by:
