Televes DTKom Series User manual

CATV/SMATV/MATV
Broadband Indoor Distribution Amplier / Central Amplicadora - DTKom Series
Refs. 451280, 451281
Descripción
Características y VentajasFeatures & Benets
Description
La Serie Amplicadores DTKOM contiene centrales profesionales de calidad,
en las que se combinan dos amplicadores de banda ancha independientes
para una distribución interior. Esta Serie ha sido diseñada para sistemas de
distribución multicanal RF, en los que la entrada puede ser la bajante princi-
pal de cable o la salida de una cabecera MATV/SMATV/CATV. La ref. 451280
es un amplicador de gran potencia y alto nivel de salida con un ancho de
banda RF de 1002MHz, con capacidad para funcionar en dos bandas sepa-
radas en 42/54MHz. El retorno es congurable, pudiendo ser activo o pasivo.
Las ref. 451280 y 481281 ofrece una ganancia de 30dB-40dB, seleccionable
por el usuario. Dispone de atenuador-ecualizador 20dB, y de regulador-pre-
acentuador 10dB.
El canal de retorno gana 28dB en modo activo. Dispone de atenuador 20dB.
Los controles y switches están situados en la parte frontal del amplicador,
fácilmente accesibles. Se dispone de test entrada-salida a -20dB para testear
el equipo en funcionamiento.
Los amplicadores de la Serie DTKOM integran una fuente de alimentación
conmutada de 120/230V~ de bajo consumo que alarga la vida útil del equi-
po. El chasis, realizado en Zamak, resulta muy compacto y fácilmente insta-
lable. Además, proporciona una excelente disipación de calor, permitiendo
su funcionamiento en entornos con temperaturas elevadas sin que su rendi-
miento o abilidad se vean degradados.
Front panel variable reg. and tilt controls (10dB) for easy adjustment.
Two-way capability with a user selectable active/passive return path.
Power doubling technology for distortion-free, high output level
operation.
Externally accessible -20 dB input/output test ports provide
convenient in-service performance monitoring.
Optimized consumption: Approx. 20% less when congured as 30dB
FWD/-3dB RET for cost-eective and trouble-free operation.
Cast Zamak chassis with large heat sinks providing exceptional heat
dissipation.
Exceptional conducted and radiated interference performance at
full output level.
Enclosure provides excellent shielding performance, reducing
leakage and ingress.
Built-in, high quality switched power supply.
Controles de regulación y preacentuación (10dB) situados en el panel frontal
para un ajuste sencillo.
Canal de retorno activo o pasivo, seleccionable por el usuario.
Tecnología “power doubling” de potencia mejorada que genera altos niveles
de salida sin distorsión.
Puntos de entrada/salida TEST a -20dB, accesibles externamente, que permi-
ten controlar el rendimiento del servicio sin interrumpirlo.
Consumo optimizado: aprox. 20% menor en conguración 30dB FWD/-3dB
RET para un funcionamiento más eciente y seguro.
Chasis en Zamak con ranuras amplias que favorecen una buena disipación
de calor.
Comportamiento excepcional en términos de interferencias radiadas, funcio-
nando al máximo nivel de salida.
La carcasa proporciona un blindaje excelente, reduciendo las fugas y radia-
ción.
Fuente de alimentación conmutada de alta calidad integrada en la central.
The DTKom Series Ampliers are professional quality, completely self-
contained, two way broadband indoor distribution ampliers designed
for multi-channel RF distribution systems where the input source is a
cable drop or the output of a MATV/SMATV/CATV headend. The Ref.
451280 is a high output level, power doubling amplier, with an RF
bandwidth of 1002MHz, equipped for 2-way operation with a 42/54MHz
split that can operate in passive or active return congurations.
The ref. 451280 and 451280 have an user selectable gain of 30dB or 40
dB. It has 20dB attenuator-slope control and 10dB regulator-tilt control.
It has a return gain of 28dB when in active mode and 10dB attenuator.
The gain and slope controls are located on the front panel for easy set-
up and adjustment with the provided tool. Two -20dB test points are
provided to permit testing without interruption of service.
The DTKom Series ampliers incorporate a built in switched 120/230V~
power supply and are characterized by their exceptionally low power
consumption for a long and trouble-free operating life. The cast Zamak
chassis has been optimized to be compact and easy to install, while at
the same time providing excellent heat dissipation, allowing operation
at high ambient temperatures with no degradation of performance/
reliability.

Important safety instruccions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplugthis apparatusduring lightningstorms orwhen unusedfor long periods
of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Warning
Reduce the risk of re or electric shock, do not expose this apparatus to rain or
moisture.
Apparatus shall not be exposed to dripping or splashing and no objects lled with
liquids, such as glasses, shall be placed on the apparatus.
Safe operation
Power requirements for this product are 120/230V~ 50/60 Hz.
Should any liquid or object fall into the equipment, please refer to qualied
personnel for service.
To disconnect the equipment from the mains pull the plug never the cable.
It is strongly recommended not to connect the equipment to the mains until all
connections have been done.
The socket outlet shall be installed near the equipment and shall be easily
accessible.
Do not take the cover o the equipment without disconnecting it from the mains.
Safe installation
Ambient temperature should not be higher than 113°F.
Do not place the equipment near heat sources or in a highly humid environment.
Do not place the equipment in a place where it can suer vibrations or shocks.
Please allow air circulation around the equipment.
Do not place naked ames, such as lighted candles on or near the product.
Class B equipment
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Simbology
Equipment designed for indoor use.
The equipment meets the safety requirements specied for
Class II equipment.
To avoid the risk of electric shock, do not open
the equipment.
This symbol indicates that the product displays “dangerous
voltage”with a risk of electric shock or personal harm.
This symbol indicates that this product possesses important
instructions for use.
This symbol indicates this product has been safety tested
and meets UL requirements. The cULus Listed Mark indicates
compliance with Canadian and U.S. Safety standards.
The equipment complies with the CE mark requirements.
ES Importantes instrucciones de seguridad
EN Important Safety Instructions
Televes S.A guarantees this product as per legislation applicable
for this type of product at the time and in the country of purchase.
(A) Televes warrants, only to the original Purchaser,
all Products be free from any defect in materials or
workmanship for a period of two (2) years from the date
of original purchase, unless otherwise specied.
(B) Televes shall, free of charge and in its sole discretion,
either repair, replace with a new or factory
reconditioned equivalent, or refund the purchase price
of the Product(s), that has been determined by Televes
to be defective in material or workmanship, subject to
the limits of this warranty.
(C) This warranty excludes any damage or inoperability
resulting from:
(I) use or installation that is not in strict compliance with
the written instructions and specications;
(II) any modication or alteration performed by any third
party not authorized in writing by Televes;
(III) service or repair performed by any third party not
authorized in writing by Televes;
(IV) misuse, abuse, intentional harm, or lack of
reasonable care;
(V) re, ice, snow, rain, wind, water, volcano, excessive
heat or cold, lightning, ood, power surge,
earthquake, or any other acts of God;
(VI) war, crime, strike, riot, electro-magnetic pulse, or any
other acts beyond the control of Televes;
(VII) shipping.
(D) All claims under the terms of this warranty must be
made in writing, by the original Purchaser, within
fourteen (14) days of the defect being known to the
Purchaser. Such claims shall be accompanied by a
description of any material facts related to the claimed
defect and the invoice or other proof of original
purchase date and price. If Televes so requests, the
Purchaser shall, at Purchaser’s expense, deliver the
claimed Product(s) to Televes, within 14 days of the date
of the return authorization. Under no circumstances
shall the Product(s) be returned to Televes without a
return authorization.
(E) Any refund to the Purchaser, shall be limited to the
purchase price of the Product(s), excluding any
applicable taxes, duties, freight costs, removal costs,
installation costs, or any other charges incident to the
purchase of the product.
(F) Any damage caused by shipper shall be claimed with
the shipper in accordance with the shipper’s policies
and procedures.
(G) Televes shall in no event and under no circumstances
be liable or responsible for any consequential, indirect,
incidental, punitive, direct or special damages
based upon breach of warranty, breach of contract,
negligence, strict tort liability or otherwise or any other
legal theory, arising directly or indirectly from the sale,
use, installation or failure of any product acquired by
Purchaser from Televes.
(H) This limited warranty extends to the original Purchaser
and cannot be assigned or transferred to any other
party without the prior express written permission of
Televes, which permission Televes may withhold for any
reason or for no reason at all.
(I) Televes will not assume any liabilities for any other
warranties, whether statutory, express or implied, made
by any other person.
(J) Televes reserves the right to modify or discontinue this
warranty at Televes’ sole discretion without notication.
No other warrantees are expressed or implied.
Televes Limited Warranty
Condiciones generales de instalación
1. Lea las instrucciones.
2. Conserve estas instrucciones.
3. Preste atención a todas las advertencias.
4. Siga todas las instrucciones.
5. No utilice este aparato cerca del agua.
6. Limpie la unidad sólo con un paño seco.
7. No bloqueelas aberturas deventilación. Realizarla instalaciónde acuerdocon las
instrucciones del fabricante.
8. No la instale cerca de fuentes de calor tales como radiadores, registros de calor,
estufas u otros aparatos (incluyendo amplicadores) que produzcan calor.
9.
No anule la característica de seguridad del enchufe polarizado o con conexión a
tierra. Un enchufe polarizado tiene dos patillas planas, una más ancha que la otra.
Un enchufe con toma de tierra tiene dos patillas planas y una tercera de conexión
a tierra.La patillaancha ola tercera patilla,están pensadaspara su seguridad. Siel
enchufe suministrado no encaja en su toma, consulte con un electricista para que
reemplace la toma corriente obsoleta.
10. No pise ni pellizque el cable de red; tenga especial cuidado con las clavijas, tomas de
corriente y en el punto del cual salen del aparato.
11. Utilice solamente los aditamentos/accesorios especicados por el fabricante.
12. Use únicamente la carretilla, plataforma, trípode, soporte o tableros
especicados por el fabricante, o vendidos con el aparato. Cuando se usa una
carretilla, tenga cuidado al mover el conjunto carretilla/aparatos para evitar
lesiones en caso de vuelco.
13. Desenchufe este aparato durante las tormentas eléctricas o cuando no lo utilice
durante largos períodos de tiempo.
14. Solicite todas las reparaciones a personal de servicio cualicado. Solicite una
reparación cuando el aparato se haya dañado de cualquiera forma, como
cuando el cable de red o el enchufe están dañados, se ha derramado líquido
o han caído objetos dentro del aparato, el aparato ha sido expuesto a la lluvia o
humedad, no funciona normalmente, o haya sufrido una caída.
Atención
Para reducir el riesgo de fuego o choque eléctrico, no exponer el equipo a la lluvia
o a la humedad.
El aparato no debe ser expuesto a caídas o salpicaduras de agua. No situar objetos
o recipientes llenos de líquidos, como vasos, sobre o cerca del aparato.
Cómo utilizar el equipo de forma segura
La tensión de red de este producto ha de ser: 120/230V~ 50/60Hz.
En el caso de que cualquier líquido u objeto caigan dentro del aparato, debe de
ponerse en contacto con el servicio técnico.
Para desenchufar el equipo de la red, tire siempre de la clavija, nunca del cable.
No enchufe el equipo a la red eléctrica hasta que todas las demás conexiones
hayan sido realizadas.
La toma de red eléctrica debe estar cerca del equipo y ser fácilmente accesible.
No quitar la tapa del equipo sin desconectarlo de la red.
Instalación segura
La temperatura ambiente no debe superar los 45°C.
Nosituar elequipo cercade fuentesde caloro enambientes dehumedad elevada.
Nosituar elequipo dondepuedaestar sometidoa fuertes vibracioneso sacudidas.
Deje un espacio libre alrededor del aparato para proporcionar una ventilación
adecuada.
Nosituar sobreel aparatofuentesde llamadesnuda,tales comovelasencendidas.
Simbología
Equipo diseñado para uso en interiores.
Este símbolo indica que el equipo cumple los requerimientos
de seguridad para equipos de Clase II.
Para evitar el riesgo de choque eléctrico. no abrir
el equipo
Este símbolo indica “voltaje peligroso”dentro del producto
que puede presentar un riesgo de descarga eléctrica o daños
personales.
Este símbolo indica que existen instrucciones importantes
para este producto.
Este símbolo indica que este producto ha sido probado y
cumple con los requisitos de seguridad de UL.
La marca cULus indica el cumplimiento de las normas de
seguridad canadienses y estadounidenses.
El equipo cumple los requerimientos del marcado CE.

GAIN CONTROL
CONTROL DE GANANCIA
FWD. INPUT / RET OUTPUT
ENTRADA FWD / SALIDA RET
TEST (-20 dB)
FWD. OUTPUT / RET. INPUT
SALIDA FWD / ENTRADA RET
TEST (-20 dB)
FULL
MAX
AT T. AT T.
GAIN CONTROL
CONTROL DE GANANCIA
AMPLIFIER
AMPLIFICADOR
+10 dB
LOW GAIN
BAJA GANANCIA
RETURN PATH AMPLIFIER
AMP. CANAL DE RETORNO
PASSIVE RETURN PATH
CANAL DE RETORNO PASIVO
HYBRID PD AMPLIFIER
AMPLIFICADOR PD HÍBRIDO
GAIN CONTROL
CONTROL GANANCIA
SLOPE CONTROL
ECUALIZADOR
FULL
MAX FLAT
HPF 1
LPF 1
HPF 2
LPF 2
REG CONTROL
CONTROL REG
TILT CONTROL
PREACENT
FULL
MAX FLAT
Block diagram / Diagrama de bloques
Technical specications Características técnicas Units
Unidades
451280 451281
Forward path
Canal Directo
Return path
Canal de retorno
Forward path
Canal Directo
Return path
Canal de retorno
Frequency Range Margen de frecuencia MHz 54 ... 1002 5 ... 42 49 ... 1002 5 ... 36
Gain Ganancia dB 30 / 40 (selec.) 28 30 / 40 (selec.) 28
Flatness Planicidad dB ±1.5
Gain Control Range Atenuación entrada dB 20
Slope Control Range Ecualización entrada dB 20 - 20 -
Reg Control Range Regulación dB 10
Tilt Control Range Preacentuación dB 10
Noise Figure Figura de ruido dB 8 6 8 6
Channels (for CSO, CTB & XMOD) Canales (para CSO, CTB & XMOD) # 42 - 42 -
Output Level (42CH) Nivel de salida (42CH) dBmV
(dBµV)
52 (112) - 52 (112) -
Output Level Nivel de salida (DIN 45004B) 69 (129) 58 (118) 69 (129) 58 (118)
Composite Triple Beat (CTB) Composite Triple Beat (CTB) dB -60 - -60 -
Crossmodulation (XMOD) Modulación cruzada (XMOD) dB -60 - -60 -
2nd Order Composite (CSO) 2nd Order Composite (CSO) dB -60 - -60 -
Impedance Impedancia Ohm 75
Input/Output Test Port Level Atenuación Test Entrada/Salida dB -20 ( ±2)
Input/Output Test Port Return Loss Pérdidas retorno Entrada/Salida Test dB 18 12 18 12
Operating Temperature Range Temperatura de funcionamiento ºF (ºC) 14 - 113 (-10 ... 45)
Powering requirements Alimentación
V~ 120/230
mA 245/156
Hz 50/60
Consumption Consumo W 15.4
Size (LxWxH) Tamaño (LxAnxAl) in (mm) 11 x 5.6 x 1.9 (280 × 142 × 48)
Shipping Weight Peso lb (kg) 5.4 (2,4)
Total # of Channels
Nº total de canales
Input level / Nivel de entrada
dBmV / dBµV (Gain 40dB)
Output level / Nivel de salida
dBmV / dBµV
12 18 / 78 58 / 118
24 15 / 75 55 / 115
36 13 / 73 53 / 113
48 12 / 72 52 / 112
72 10 / 70 50 / 110
96 9 / 69 49 / 109
144 8 / 68 48 / 108
158 7 / 67 47 / 107
LPF (Low Pass Filter): Filtro Paso Bajo
HPF (High Pass Filter): Filtro Paso Alto
451280 451281
HPF1 54 49
HPF2 54 49
LPF1 42 36
LPF2 42 36

2018 © Copyright, Televés S.A.
HDTV ENCODER/MODULATOR - Dual HDMI Component to QAM
HDTV ENCODER/MODULATOR - Dual Component to QAM HDTV ENCODER/MODULATOR - Dual Component to QAM HDTV ENCODER/MODULATOR - Dual Component to QAM HDTV ENCODER/MODULATOR - Dual Component to QAM HDTV ENCODER/MODULATOR - Dual Component to QAM
HDTV ENCODER/MODULATOR - Dual Component to QAM (EAS)
HDTV ENCODER/MODULATOR - Dual Component to QAM
HDTV ENCODER/MODULATOR - Dual Component to QAM HDTV ENCODER/MODULATOR - Dual Component to QAM HDTV ENCODER/MODULATOR - Dual Component to QAM HDTV ENCODER/MODULATOR - Dual Component to QAM
HDTV ENCODER/MODULATOR - Dual Component to QAM (EAS)
HD RECEIVERS
(up to 1080p)
SECURITY CAMERAS
DIGITAL SIGNALS PLAYERS
Component
24
4
4
2
10
14
1234567
8 9 10 11 12 13 14
Composite
Unencrypted HDMI
COAX
DISTRIBUTION
EXISTING
ANALOG
CHANNELS
-20 dB
Test
FWD.
INPUT
OK - Return
20 dB
20 dB
-20 dB
Test INPUT
+10 dB
Passive Return Path
On
20 dB
GAIN SLOPE
FULL FLAT
GAIN
FULL
RET.
OUTPUT
FWD.
OUTPUT
RET.
REG TILT
FULL FLAT
10 dB 10 dB
OK -
FORWARD
Designed& manufactured in Spain
P.max 15.4W
I.max 245mA
120/230V~ 50/60Hz
Fuse:T2A L 250V
USOEXCLUSIVO EN INTERIOR
FORINDOOR USE ONLY
AUDIO/VIDEO
APPARATUS
19XG
Typical Application / Aplicación típica
1 ... 12: Dual Component to QAM / 13: QUAD Composite to QAM / 14: Dual HDMI to QAM
Additional information / Información adicional
SLOPE
1002 MHz
SLOPE
750 MHz
Gain
1002 MHz
Gain
750 MHz
TILT
1002 MHz
Gain
750 MHz
Gain
750 MHz
Gain
750 MHz
0 0 40 40 0 0 40 40
2 1,5 40 39,5 2 1,5 40 39,5
4 3 40 38,9 4 3 40 38,9
6 4,4 40 38,4 6 4,4 40 38,4
8 5,9 40 37,9 8 5,9 40 37,9
10 7,4 40 37,4 10 7,4 40 37,4
12 8,9 40 36,9
14 10,3 40 36,3
16 11,8 40 35,8
18 13,3 40 35,3
20 14,8 40 34,8
Recomm, Max. Amp. Cascade 1 2 3 4 5 6 7 8 9 10
Gain 40 dB X X X
Gain 35 dB X X X X X
Gain 30 dB X X X X X X X X X X
Adjust for replacement 750 MHz units ( all in dB): Max. Slope: 14,8 Máx Tilt 7,4 / Ajuste para sustitución de 750 MHz (todo en dB): Máx. Pendiente: 14,8 Máx
inclinación7,4.
Cascadable ampliers, 42CH, see table below / Amplicadores en cascada, 42CH, ver la siguiente tabla:
Installation and level setting / Instalación y ajustes de nivel
* Plastic accessory included / Incluye accesorio de plástico.
*
DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY DECLARAÇÃO DE CONFORMIDADE DECLARATION DE CONFORMITE DICHIARAZIONE
DI CONFORMITÀ DEKLARACJA ZGODNOŚCI KONFORMITÄTSERKLÄRUNG ΠΙΣΤΟΠΟΙΗΤΙΚΟ ΣΥΜΜΟΡΦΩΣΗΣ FÖRSÄKRAN OM ÖVERENSSTÄMMELSE
ДЕКЛАРАЦИЯ СООТВЕТСТВИЯ https://doc.televes.com
