Tenda O6 User manual


-i-
Copyright Statement
© 2016 Shenzhen Tenda Technology Co., Ltd. All rights reserved.
is a registered trademark legally held by Shenzhen Tenda Technology Co., Ltd. Other brand and
product names mentioned herein are trademarks or registered trademarks of their respective holders. Copyright
of the whole product as integration, including its accessories and software, belongs to Shenzhen Tenda Technology
Co., Ltd. No part of this publication can be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language in any form or by any means without the prior written permission of Shenzhen Tenda
Technology Co., Ltd.
Disclaimer
Pictures, images and product specifications herein are for references only. To improve internal design, operational
function, and/or reliability, Tenda reserves the right to make changes to the products without obligation to notify
any person or organization of such revisions or changes. Tenda does not assume any liability that may occur due to
the use or application of the product described herein. Every effort has been made in the preparation of this
document to ensure accuracy of the contents, but all statements, information and recommendations in this
document do not constitute the warranty of any kind, express or implied.

-ii -
Preface
Conventions
If not specifically indicated, “the device” or “the AP” mentioned in this document stands for the Long Range
Outdoor Point To Point CPE O6.
Typographical conventions in this document:
Item
Presentation
Example
Menu
Bold
The menu "System Tool" will be simplified as System Tool.
Continuous
Menus
>
Go to System Tool > Diagnosis Tool.
Symbols in this document:
Item
Meaning
Note
This format is used to highlight information of importance or special interest.
Ignoring this type of note may result in ineffective configurations, loss of data or
damage to device.
Tip
This format is used to highlight a procedure that will save time or resources.
How to download documents
Besides this document, other documents are updated on our website. To download them, please do as follows:
1. Go to our website http://www.tendacn.com.
2. Search for the appropriate product model.
3. Download the correct documents.
Technical support
For more help, please contact us with any of the following ways.
Global Hotline:(86)755-27657180
United States Hotline: 1-800-570-5892
Technical Support: support@tenda.com.cn
HongKong Hotline: 00852-81931998
Canada Hotline: 1-888-998-8966
Email: support@tenda.com.cn
Website: http://www.tendacn.com
Skype: tendasz

Get to Know the Device
-1-
Table of contents
1 Get to know the device .........................................................................................3
1.1 Features ............................................................................................................................................................. 3
1.2 Package contents ............................................................................................................................................... 4
1.3 Hardware descriptions....................................................................................................................................... 5
1.3.1 Front panel.................................................................................................................................................. 5
1.3.2 Rear panel................................................................................................................................................... 6
1.3.3 Label............................................................................................................................................................ 7
2 Device installation ................................................................................................8
2.1 Installation preparations.................................................................................................................................... 8
2.1.1 Environment requirements......................................................................................................................... 8
2.1.2 Check your device....................................................................................................................................... 8
2.2 Installation steps................................................................................................................................................ 9
Step 1: Install the device...................................................................................................................................... 9
Step 2: Connect the device to a network........................................................................................................... 10
3 Web UI login ....................................................................................................... 11
3.1 Login ................................................................................................................................................................ 11
3.2 Layout of web UI.............................................................................................................................................. 13
4 Web UI functions ................................................................................................ 14
4.1 Status............................................................................................................................................................... 14
4.2 Quick setup...................................................................................................................................................... 17
4.2.1 AP mode.................................................................................................................................................... 18
4.2.2 Station (Client) mode................................................................................................................................ 20
4.2.3 Universal Repeater mode ......................................................................................................................... 23
4.2.4 WISP Mode ............................................................................................................................................... 25
4.2.5 Router Mode............................................................................................................................................. 28
4.3 Network........................................................................................................................................................... 30
4.3.1 LAN Settings.............................................................................................................................................. 31
4.3.2 DHCP Server.............................................................................................................................................. 34
4.3.3 DHCP Client............................................................................................................................................... 36
4.3.4 VLAN Settings ........................................................................................................................................... 36
4.4 Wireless ........................................................................................................................................................... 39

Get to Know the Device
-2-
4.4.1 Basic.......................................................................................................................................................... 39
4.4.2 Advanced .................................................................................................................................................. 44
4.4.3 Access control........................................................................................................................................... 46
4.5 Advanced Setting ............................................................................................................................................. 48
4.5.1 LAN Rate ................................................................................................................................................... 49
4.5.2 Diagnose ................................................................................................................................................... 49
4.5.3 Network Service........................................................................................................................................ 53
4.6 Tools................................................................................................................................................................. 58
4.6.1 Date & Time.............................................................................................................................................. 59
4.6.2 Maintenance............................................................................................................................................. 60
4.6.3 Administrator............................................................................................................................................ 63
4.6.4 System Log................................................................................................................................................ 64
4.7 Other Functions in Router Mode..................................................................................................................... 65
4.7.1 MAC Clone ................................................................................................................................................ 65
4.7.2 Traffic Control ........................................................................................................................................... 67
4.7.3 Port Forwarding........................................................................................................................................ 69
4.7.4 DMZ .......................................................................................................................................................... 73
4.7.5 MAC Filter................................................................................................................................................. 74
4.7.6 DDNS......................................................................................................................................................... 76
4.7.7 Remote Web Access.................................................................................................................................. 79
Appendix ............................................................................................................... 83
Configure your computer ...................................................................................................................................... 83
Safety and emission statement.............................................................................................................................. 85

Get to Know the Device
-3-
1 Get to know the device
Tenda O6 is an advanced and high-performanced long-range wireless access point which is suitable for long-range
data transmission and video surveillance, especially in WISP CPE solutions. It features with an external power
amplifier and a built-in 16dBi directional antenna to provide an efficient way to pick up and maintains a stable
signal for a wireless network connection range up to 10 kilometers. With waterproof cover and flexible mounting
design, it applies to different harsh environments and provides reliable, secure and wide wireless coverage.
1.1 Features
Works at 5GHz band and the wireless rate is up to 433Mbps.
Provide a 16dBi high power directional antenna and the transmission power is up to 400mW.
Provide a LAN port and its transmission rate is up to 1000Mbps.
Provide a DHCP server.
Support WEP, WPA-PSK, WPA2-PSK, WPA-PSK&WPA2-PSK, WPA and WPA2 encryption methods.
Support AP mode, Station mode, Universal Repeater mode, WISP mode and Router mode.
Provide network diagnose tools, including signal scan, Ping, and traceroute.
In router mode, the device supports extra functions, including MAC Clone, Traffic Control, Port Forwarding,
MAC Filter, DDNS and Remote Web Access.
Support IP64 dust and water proof level.

Get to Know the Device
-4-
1.2 Package contents
Unpack the package. Your box should contain the following items:
If any item is incorrect, missing or damaged, please keep the original package and contact the vendor for
replacement immediately.

Get to Know the Device
-5-
1.3 Hardware descriptions
1.3.1 Front panel
Item
Port / Button
Description
①
GND
Used to protect the device from surge and lightning. To achieve that, please connect
the GND port to the grounding bar of a building with a grounding cable and the
included grounding screw.
②
OFF/STA/AP
Used to adjust operation mode of the device.
OFF: the default position. When it is on OFF position, you can change
operation mode through web UI.
STA: When it is on STA position, the device only works at station mode and you
can't change the operation mode through web UI.
AP: When it is on AP position, the device only works at AP mode and you can't
change the operation mode through web UI.
③
Bridge/RST
Used to bridge two devices or reset the device.
To bridge two devices:
1. Press and hold this button for 3~7 seconds on an O6 that works in AP
mode. When you release the button, LED1/LED2/LED3 starts blinking.
2. Within two minutes, press and hold this button for 3~7 seconds on
another O6 that works in Station mode. When you release the button,
LED1/LED2/LED3 starts blinking and the two devices start to bridge.
LED1/LED2/LED3 of the two devices will light off and when they light and keep
solid, it indicates that the two deivces bridge successfully.
To reset the device:
Press and hold this button for over 15 seconds to restore the device to factory
default.

Get to Know the Device
-6-
Item
Port / Button
Description
④
PoE
LAN/WAN
This port can connect to a PoE power adapter to provide power for the device
and can transmit data.
It works interchangeably as a WAN port in router mode and a LAN port in
other modes.
⑤
Ethernet slot
It is used for an Ethernet cable to get through so that the device cover can be firmly
fixed.
1.3.2 Rear panel
LED
Status
Description
LAN/WAN
(PoE LAN/WAN)
Off
The device is powered off.
Solid
The device is powered on and is not transmitting data.
Blinking
The device is powered on and is transmitting data.
LED1, LED2,LED3
(Signal Threshhold LED)
Off
The device does not bridge to another device.
Blinking
The bridging between two devices is in progress.
Solid
When two devices bridge successfully, LED1/LED2/LED3 keeps solid.
The three LEDs indicate the signal strength of the other bridged
device. By default, the relations between the signal strength and LEDs
are shown below, and you can modify each LED’s threshold on the
web UI.
-90 dBm < signal strength < -80dBm: LED1 turns green.
-80 dBm < signal strength < -70dBm: LED1 and LED2 turn green.
-70 dBm < signal strength: All the three LEDs turn green.

Get to Know the Device
-7-
1.3.3 Label
1IP Address:
When the device is in factory state, this IP address is used to log in to the device’s web UI.
2Username and Password:
When the device is in factory state, both the login username and password are admin.

Device Installation
-8-
2 Device installation
2.1 Installation preparations
2.1.1 Environment requirements
Item
Requirement
Temperature
-30℃~ 55℃
Humidity
10%~90%RH (non-condensing)
2.1.2 Check your device
To check whether the device works normally or not, please do as follows:
1. Connect the device to the PoE port of the power adapter with the included Ethernet cable.
2. Plug the power adapter to a power outlet with the included power cord.
If the device works normally, when the device is powered on, the LED status should be solid or blinking.
LED
Status
Description
LAN/WAN
(PoE LAN/WAN)
solid
The device is not transmitting data.
blinking
The device is transmitting data.

Device Installation
-9-
2.2 Installation steps
Step 1: Install the device
1. Choose a location to install the device.
We recommend that you install the device on a roof with a pole, or some locations like that.
2. Connect the cable to the AP.
1) Slide the bottom cover off.
2) Connect one end of an Ethernet cable to the PoE LAN/WAN port of the device.
The Ethernet cable should be a cat 5 Ethernet cable (or higher).
3) Connect one end of a grounding cable to the GND port and fix the grounding screw.
4) Gently replace the cover by sliding it up into the place.
5) Connect the other end of the grounding cable to the grounding bar of a building.
3. Mount the AP.
1) Place the back panel of the device to a pole.
2) Thread plastic straps through the grooves underneath the brackets.
3) Adjust the AP to get the best data transmission speed.
4) Attach the AP to the pole firmly by pulling the plastic straps.

Device Installation
-10 -
Step 2: Connect the device to a network
1. Connect the other end of the Ethernet cable to the PoE port of the power adapter.
2. Connect a computer, a switch or a router to the LAN port of the power adapter using an Ethernet cable.
3. Connect the power adapter to a power outlet using the power cord.

Web UI login
-11 -
3 Web UI login
3.1 Login
When using the device for the first time, you can log in to its web UI via a browser with default login information.
The default login information includes:
Item
Default Setting
IP Address
192.168.2.1
Username and Password
admin
To log in to this device:
(Assume that the AP is in factory default state and ensure that your PC is connected to the device.)
1. Set your PC’s IP address to 192.168.2.X (2~254).
>> Method 1: Set your PC to Obtain an IP address automatically.
>> Method 2: Manually set your PC to 192.168.2.X (2~254), with a subnet mask of 255.255.255.0. (If the
switch and AP are in the same IP segment, make sure that the switch, AP and PC have different IP addresses).
For detailed steps, see Appendix Configure your computer.
Tip
The AP’s DHCP server is enabled by default. Once you finished settings on Quick Setup page, the DHCP server
will be disabled automatically.
Or

Web UI login
-12 -
2. Launch a browser, such as Chrome , enter the AP’s default IP address 192.168.2.1 in the address bar, and
press Enter.
3. In the login page, enter admin (case sensitive) in both “Username” and “Password” box.
4. Click the dropdown list, select your country and click Login.
Then you come to the management page and can begin to configure the device.

Web UI login
-13 -
3.2 Layout of web UI
This web UI is divided into three parts: primary navigation bar, secondary navigation bar and configuration area,
described as follows.
Item
Name
Description
❶
Primary
Navigation
bar
The navigation bar organizes the device’s menu of all functions in the form of a
navigation tree. You can choose the function menu from the navigation bar with
selection result shown in the configuration area.
❷
Secondary
Navigation
bar
❸
Configuration
area
The area is used to configure and view settings.
The following table shows the commonly used buttons of the web UI.
Item
Description
Click the button to view the help info if you meet any problems during the setup.
Click the button to apply your settings.
Click the button to clear the settings you are editing.

Web UI Functions
-14-
4 Web UI functions
4.1 Status
This page displays system info, wireless info, and related statistics information of the device. Click Status to enter
the setup page, and pull the scroll bar to view more information.
Parameter Description (part of): (You can also click on the upper right page to get help.)
Parameter
Description
System Info
Running time: The duration of time that the device has been running from last reboot. It will be
reset when the device reboots.
System Time: The device’s current system time. To ensure that time-related functions work
properly, go to Tools > Date & Time to set up an appropriate system time.
LAN/WAN MAC: MAC address of PoE LAN/WAN port. In router mode, it is WAN MAC address
and in other modes, it is LAN MAC address. If you set up MAC Clone function in router mode,
you can check on this page whether it is successful.

Web UI Functions
-15-
WLAN MAC: MAC address of the wireless interface of the device.
LAN/WAN: Indicates the connection status of PoE LAN/WAN port.This can indicate that a cable
is not plugged into a device, there is no active Ethernet connection, or the current rate of PoE
LAN/WAN port. (In router mode, PoE LAN/WAN port works as a WAN port. In other modes, it
works as LAN port.)
Wireless Info
Working mode: Current operation mode of the device. For the working modes supported by the
device, please see Operation mode description.
SSID: Current wireless network name of the device.
Security Mode: Current wireless encryption mode of the device. For detailed encryption
information, please see Encryption method description.
Channel/Bandwidth: Current working channel and bandwidth of the device.
Wireless Clients: Number of wireless clients currently connected to SSID of the device.
AP MAC: Wireless MAC address of this device or a remote AP.
In AP mode and router mode, it is the wireless MAC address of this device.
In other modes, if this device is connected to another AP wirelessly, AP MAC address is the
wireless MAC address of that remote AP.
Signal strength: Wireless signal strength of the connected device.
If this device is connected to another AP wirelessly, it is the wireless signal strength of that
remote AP.
In AP mode and router mode, it is the wireless signal strength of the wireless client that is
first connected to this device.
Noise Floor: Background noise of the current environment. The greater the absolute value, the
less the interference.
TX/RX link: The number of independent spatial data streams that the device is transmitting (TX)
and receiving (RX). This device is Single-Input Single-Output.
TX/RX rate: (Available in Station/Universal Repeater/WISP mode.) Displays the current 802.11
data transmission (TX) and data reception (RX) rates.
Statistics
Throughput: The current data traffic on wireless interface and LAN port in both graphical and
numerical form.The chart scale and throughput dimension (Bps, Kbps, Mbps) change
dynamically depending on the mean throughput value.The statistics are updated automatically.

Web UI Functions
-16-
Clients: Available in AP mode and router mode.
IP address: IP address of a wireless client.
MAC address: MAC address of a wireless client.
Signal/Noise: Wireless signal strength from the device to a client and noise floor of the
current environment.
TX/RX Rate: Current TX/RX rate of a client.
CCQ: Link quality of the clients. The higher the percentage, the better the network
transmission quality.
Connection time: Duration of a client that is connected to the SSID of the device.
Statistics
Upper AP: Available in Station/Universal Repeater/WISP mode.
IP address: IP address of the upper AP.
MAC address: MAC address of the upper AP.
Signal/Noise: Wireless signal strength from this device to the upper AP and noise floor of the
current environment.
TX/RX Rate: Current TX/RX rate of this device.
CCQ: Link quality of this device to the upper AP. The higher the percentage, the better the
network transmission quality.
Connection time: Duration that this device is connected to the upper AP.
Interface: The information of LAN port and bridge interface, including IP address, MAC address,
RX packets, RX errors, TX packets and TX errors.
ARP table: Current ARP table of the device.
IP address: IP address of a host in the ARP table.
MAC address: MAC address that corresponds to the IP address of a host.
Interface: Interface that is used to communicate with a host.
Routing table: Target network the device can reach currently.
Destination Segment: IP address or IP network of the destination.
Subnet Mask: Subnet mask of the destination.
Next hop: Next hop is where the packets are forwarded to first.
Interface: Interface is where the packets are forwarded from this device.

Web UI Functions
-17-
When the device works in router mode, the system info is displayed as follows:
Parameter Description (part of): (You can also click on the upper right page to get help.)
Parameter
Description
System Info
WAN IP: WAN IP address obtained from the upper DHCP server. When the device works in
router mode, the PoE LAN/WAN port works as WAN port.
WAN Gateway: Gateway address of the device. When the device accesses to an external
network, its data packets are forwarded by this gateway.
Connection Status: Current network connection status of the device.
Connection Type: Current connection type of the device. The device supports three connection
types, as follows:
DHCP: WAN port of the device obtains an IP address from the upper DHCP server.
Static IP: WAN port is connected through fixed IP address, subnet mask, default gateway, and
DNS server information.
PPPoE: WAN port is dialed up through user name and password.
4.2 Quick setup
This device supports the following operation modes and the default operation mode is AP mode.
AP Mode
Station (Client) Mode
Universal Repeater Mode
WISP Mode
Router Mode
Table of contents
Other Tenda Wireless Access Point manuals
Popular Wireless Access Point manuals by other brands

D-Link
D-Link nuclias connect DAP-2662 Quick installation guide

Moxa Technologies
Moxa Technologies AirWorks AWK-5222 user manual

APM
APM ABR-1A+3G Specification sheet

Encore
Encore ENRXWI-G user guide

D-Link
D-Link DAP-1665 Quick installation guide

Moxa Technologies
Moxa Technologies AirWorksAWK-6232-M12 Hardware installation guide
