Terasic SFP HSMC User manual

Terasic THDB-SUM
SFP HSMC
Terasic SFP HSMC Board
User Manual
Document Version 1.00 AUG 12, 2009 by Terasic

Introduction
ii
Page Index
INTRODUCTION................................................................................................................................................................................. 1
1.1 1.1 FEATURES..................................................................................................................................................................... 1
1.2 1.2ABOUT THE KIT ............................................................................................................................................................ 2
1.3 1.3ASSEMBLE THE SFP HSMC BOARD ........................................................................................................................... 3
1.4 1.4 GETTING HELP ............................................................................................................................................................. 5
ARCHITECTURE................................................................................................................................................................................ 6
2.1 2.1 LAYOUT AND COMPONETS............................................................................................................................................ 6
2.2 2.2 BLOCK DIAGRAM .......................................................................................................................................................... 8
BOARD COMPONENTS................................................................................................................................................................... 9
3.1 3.1THE SFPHSMC CONNECTOR.................................................................................................................................... 9
3.2 3.2 CLOCK CIRCUITRY...................................................................................................................................................... 15
3.3 3.3 POWER SUPPLY.......................................................................................................................................................... 17
DEMONSTRATION .......................................................................................................................................................................... 18
4.1 4.1 INTRODUCTION ........................................................................................................................................................... 18
4.2 4.2 SYSTEM REQUIREMENTS........................................................................................................................................... 18
4.3 4.3 SETUP THE DEMONSTRATION .................................................................................................................................... 18
4.4 4.4 DEMO OPERATION...................................................................................................................................................... 20
4.5 4.5 OVERVIEW.................................................................................................................................................................. 21
APPENDIX......................................................................................................................................................................................... 23
5.1 5.1 REVISION HISTORY..................................................................................................................................................... 23
5.2 5.2ALWAYS VISIT SFPHSMC WEBPAGE FOR NEW MAIN BOARD................................................................................. 23

Introduction
1
1
Introduction
The Small Form-Factor Pluggable (SFP) HSMC board is a hardware platform for evaluating the interoperation
of Altera FPGA, specifically Stratix IV GX, Arria GX, and Arria II GX, with generic SFP modules. The optical
modules that are of particular importance are SGMII Ethernet, Fiber channel, CPRI/OBSAI and SONET.
Furthermore, the SFP HSMC board is intended for customers to implement both telecommunication and data
communications applications.
1.11.1 Features
Figure 1.1 shows the photo of the SFP HSMC board. The important features are listed below:
8 SFP Connectors
4 Transceiver Based SFPs
4 LVDS Bases SFPs
8 SMAs
2 Transceiver Receive SMAs
2 Transceiver Transmit SMAs
1 LVDS Clock Input SMA pair (2 SMAs)
2 Single-ended Clock Outputs SMAs
1 LVDS Clock Output SMApair (2 SMAs)
1 LVPECL Clock Output SMA pair (2 SMAs)
Power
12V to 4V
4V to 3.3V
Clocks
61.44 MHz
125 MHz
155.52 MHz
156.25 MHz
Differential SMA
High Speed Mezzanine Card (HSMC)

Introduction
2
Figure 1.1. The SFP HSMC Board
1.21.2 About the KIT
This section describes the package content
SFP HSMC Board x 1
System CD-ROM x 1
The CD contains technical documents of the SFP HSMC, and reference designs along with the source code.
Figure 1.2 SFP HSMC Package

Introduction
3
1.31.3 Assemble the SFP HSMC Board
This section describes how to connect the SFP HSMC board to a main board.
The SFP HSMC board connects withAltera DE3 Board

Introduction
4
The SFP HSMC connects to the Stratix IV GX FPGA Development Board
The SFP HSMC board connects withAltera Stratix III FPGADeveopment Kit
Note. Do not attempt to connect/remove the SFP HSMC daughter board to/from the main board when the
power is on, or else the hardware could be damaged.

Introduction
5
1.41.4 Getting Help
Here are some places to get help if you encounter any problem:
Email to [email protected]
Taiwan & China: [phone]
Korea : [phone]
Japan: [phone]

Architecture
6
2
Architecture
This Chapter covers the architecture of the SFP HSMC board including its PCB and block diagram.
2.1 2.1 Layout and Componets
The picture of the SFP HSMC board is shown in Figure 2.1 and Figure 2.2. It depicts the layout of the board
and indicates the location of the connectors and key components.
Figure 2.1. The SFP HSMC PCB and component diagram

Architecture
7
Figure 2.2. The SFP HSMC Back side – HSMC connector view
The following components are provided on the SFP HSMC board :
LVDS SFP[4-7] (J10), XCVR SFP Dip Switch (S5), XCVR LVDS Dip Switch (S4), CLK2_SMA_p
(J14), CLK2_SMA_n (J15), SMA_CLK1 (J9), PLL4:1 Input Multiplexer Dip Switch (S3), PLL 4:1 Input
Multiplexer Dip Switch (S2), SMA_REFCLK (J11), SMA_REFCLK_n (J8), SMA_REFCLK_p (J4),
CLOCK Dip Switch (S1), XCVR_TX4n (J5), XCVR_TX4p (J1), XCVR_TX4n (J6), XCVR_RX4p (J2),
SMA_CLK_n (J7), SMA_CLK_p (J3)
HSMC Connector (J17), XCVR SFP[0-3] (J16)

Architecture
8
2.2 2.2 Block Diagram
Figure 2.3 shows the block diagram of the SFP HSMC board
Figure 2.3. The block diagram of the SFP HSMC board

Board Components
9
3
Board Components
This section illustrates the detailed information of the components, connector interfaces, and the pin mapping
tables of the SFP HSMC board.
3.1 3.1 The SFP HSMC Connector
This section describes pin definition of the SFP HSMC interface onboard
All the control and data signals of the SFPs are connected to the HSMC connector, so users can fully control the
SFP HSMC daughter board through the HSMC interface. Power is derived from 3.3V and 12V of the HSMC
connector.

Board Components
10
Figure 3.1. The pin-outs on the HSMC connector

Board Components
11
The table 3.1 below lists the HSMC signal direction and description.
Pin
Numbers
Name Direction Description
1 N.C. N/A Not Connect
2 N.C. N/A Not Connect
3 N.C. N/A Not Connect
4 N.C. N/A Not Connect
5 N.C. N/A Not Connect
6 N.C. N/A Not Connect
7 N.C. N/A Not Connect
8 N.C. N/A Not Connect
9 N.C. N/A Not Connect
10 N.C. N/A Not Connect
11 N.C. N/A Not Connect
12 N.C. N/A Not Connect
13 XCVR_TX4p Output SMATransceiver Input
14 XCVR_RX4p Input SMA Transceiver Output
15 XCVR_TX4n Output SMATransceiver Input
16 XCVR_RX4n Input SMA Transceiver Output
17 SFP3_TDp Output Transmitter Non-Inverted Data Input
18 SFP3_RDp Input Receiver Non-Inverted Data Output
19 SFP3_TDn Output Transmitter Inverted Data Input
20 SFP3_RDn Input Receiver Inverted Data Output
21 SFP2_TDp Output Transmitter Non-Inverted Data Input
22 SFP2_RDp Input Receiver Non-Inverted Data Output
23 SFP2_TDn Output Transmitter Inverted Data Input
24 SFP2_RDn Input Receiver Inverted Data Output
25 SFP1_TDp Output Transmitter Non-Inverted Data Input
26 SFP1_RDp Input Receiver Non-Inverted Data Output
27 SFP1_TDn Output Transmitter Inverted Data Input
28 SFP1_RDn Input Receiver Inverted Data Output
29 SFP0_TDp Output Transmitter Non-Inverted Data Input
30 SFP0_RDp Input Receiver Non-Inverted Data Output
31 SFP0_TDn Output Transmitter Inverted Data Input
32 SFP0_RDn Input Receiver Inverted Data Output
33 N.C. N/A Not Connect
34 N.C. N/A Not Connect
35 N.C. N/A Not Connect

Board Components
12
36 N.C. N/A Not Connect
37 JTAG_TDO_TDI Inout JTAG data loop through
38 JTAG_TDO_TDI Inout JTAG data loop through
39 N.C. N/A Not Connect
40 N.C. N/A Not Connect
41 SEL[0] Inout CLK 1 Select bit 0
42 SEL[1] Inout CLK 1 Select bit 1
43 SEL[2] Inout CLK 2 Select bit 2
44 SEL[3] Inout CLK 2 Select bit 3
45 3V3 Power Power 3.3V
46 12V Power Power 12V
47 SFP3_TXFAULT Input Module Transmitter Fault
48 SFP3_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output
49 SFP3_MOD2_SDA Input SDA Serial Data Signal
50 SFP3_MOD1_SCL Inout SCL Serial Clock Signal
51 3V3 Power Power 3.3V
52 12V Power Power 12V
53 SFP3_MOD0_PRSNTn Input LED indicator that the module is present
54 SFP3_RATESEL Output Rate Select
55 SFP3_LOS Input Receiver Loss of Signal Indication
56 SFP2_TXFAULT Input Module Transmitter Fault
57 3V3 Power Power 3.3V
58 12V Power Power 12V
59 SFP2_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output
60 SFP2_MOD2_SDA Inout SDA Serial Data Signal
61 SFP2_MOD1_SCL Output SCL Serial Clock Signal
62 SFP2_MOD0_PRSNTn Input LED indicator that the module is present
63 3V3 Power Power 3.3V
64 12V Power Power 12V
65 SFP2_RATESEL Output Rate Select
66 SFP2_LOS Input Receiver Loss of Signal Indication
67 SFP1_TXFAULT Input Module Transmitter Fault
68 SFP1_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output
69 3V3 Power Power 3.3V
70 12V Power Power 12V
71 SFP1_MOD2_SDA Inout SDA Serial Data Signal
72 SFP1_MOD1_SCL Output SCL Serial Clock Signal
73 SFP1_MOD0_PRSNTn Input LED indicator that the module is present

Board Components
13
74 SFP1_RATESEL Output Rate Select
75 3V3 Power Power 3.3V
76 12V Power Power 12V
77 SFP1_LOS Input Receiver Loss of Signal Indication
78 SFP0_TXFAULT Input Module Transmitter Fault
79 SFP0_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output
80 SFP0_MOD2_SDA Inout SDA Serial Data Signal
81 3V3 Power Power 3.3V
82 12V Power Power 12V
83 SFP0_MOD1_SCL Output SCL Serial Clock Signal
84 SFP0_MOD0_PRSNTn Input LED indicator that the module is present
85 SFP0_RATESEL Output Rate Select
86 SFP0_LOS Input Receiver Loss of Signal Indication
87 3V3 Power Power 3.3V
88 12V Power Power 12V
89 SFP4_TDp Output Transmitter Non-Inverted Data Input
90 SFP4_RDp Input Receiver Non-Inverted Data Output
91 SFP4_TDn Output Transmitter Inverted Data Input
92 SFP4_RDn Input Receiver Inverted Data Output
93 3V3 Power Power 3.3V
94 12V Power Power 12V
95 SFP4_TXFAULT Input Module Transmitter Fault
96 CLK1_p Input Differential Clock Input
97 SFP4_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output
98 CLK1_n Input Differential Clock Input
99 3V3 Power Power 3.3V
100 12V Power Power 12V
101 SFP4_MOD2_SDA Inout SDA Serial Data Signal
102 SFP4_MOD1_SCL Output SCL Serial Clock Signal
103 SFP4_MOD0_PRSNTn Input LED indicator that the module is present
104 SFP4_RATESEL Output Rate Select
105 3V3 Power Power 3.3V
106 12V Power Power 12V
107 SFP4_LOS Input Receiver Loss of Signal Indication
108 SFP5_TXFAULT Input Module Transmitter Fault
109 SFP5_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output
110 SFP5_MOD2_SDA Inout SDA Serial Data Signal
111 3V3 Power Power 3.3V

Board Components
14
112 12V Power Power 12V
113 SFP5_TDp Output Transmitter Non-Inverted Data Input
114 SFP5_RDp Input Receiver Non-Inverted Data Output
115 SFP5_TDn Output Transmitter Inverted Data Input
116 SFP5_RDn Input Receiver Inverted Data Output
117 3V3 Power Power 3.3V
118 12V Power Power 12V
119 SFP5_MOD1_SCL Output SCL Serial Clock Signal
120 SFP5_MOD0_PRSNTn Input Not Connect
121 SFP5_RATESEL Output Rate Select
122 SFP5_LOS. Input Receiver Loss of Signal Indication
123 3V3 Power Power 3.3V
124 12V Power Power 12V
125 SFP6_TDp Output Transmitter Non-Inverted Data Input
126 SFP6_RDp Input Receiver Non-Inverted Data Output
127 SFP6_TDn Output Transmitter Inverted Data Input
128 SFP6_RDn Input Receiver Inverted Data Output
129 3V3 Power Power 3.3V
130 12V Power Power 12V
131 SFP6_TXFAULT Input Module Transmitter Fault
132 SFP6_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output
133 SFP6_MOD2_SDA Inout SDA Serial Data Signal
134 SFP6_MOD1_SCL Output SCL Serial Clock Signal
135 3V3 Power Power 3.3V
136 12V Power Power 12V
137 SFP6_MOD0_PRSNTn Input LED indicator that the module is present
138 SFP6_RATESEL Output Rate Select
139 SFP6_LOS Input Receiver Loss of Signal Indication
140 SFP7_TXFAULT Input Module Transmitter Fault
141 3V3 Power Power 3.3V
142 12V Power Power 12V
143 SFP7_TDp Output Transmitter Non-Inverted Data Input
144 SFP7_RDp Input Receiver Non-Inverted Data Output
145 SFP7_TDn Output Transmitter Inverted Data Input
146 SFP7_RDn Input Receiver Inverted Data Output
147 3V3 Power Power 3.3V
148 12V Power Power 12V
149 SFP7_TXDISABLE Output Transmitter Disable, Turns off transmitter laser output

Board Components
15
150 SFP7_MOD2_SDA Inout SDA Serial Data Signal
151 SFP7_MOD1_SCL Output SCL Serial Clock Signal
152 SFP7_MOD0_PRSNTn Input LED indicator that the module is present
153 3V3 Power Power 3.3V
154 12V Power Power 12V
155 SFP7_RATESEL Output Rate Select
156 CLK2_p Input Differential Clock Input
157 SFP7_LOS Input Receiver Loss of Signal Indication
158 CLK2_n Input Differential Clock Input
159 N.C. N/A Not Connect
160 GND Power Power Ground
3.2 3.2 Clock Circuitry
This section describes the board’s clock inputs and outputs
LVDS clock frequencies of 61.44MHz, 125MHz, 155.52MHz, or 156.25MHz can be selected for HSMC
CLK1p/CLK1n. CLK1p/CLk1n will be converted to a single-ended clock signal and output to an SMA.
LVDS clock frequencies of 125MHz, 155.52MHz, 156.25MHz, or SMA_CLKp/n can be selected for HSMC
CLK2p/CLK2n pins. CLK2p/CLK2n will also be output directly to SMAs.
CLK_IN is a single-ended CMOS signal received by the daughter card from the FPGA and is cleaned-up with
a frequency synthesizer. The cleaned-up clock is output to an LVPECL SMA pair.

Board Components
16
Figure 3.2 Clock Diagram
Table 3.2 CLK1 Settings
SEL [1:0] CLK1p/CLK1n Frequency
11 125.00 MHz (Default)
10 155.52 MHz
01 156.25 MHz
00 61.44 MHz
Table 3.3 CLK2 Settings
SEL [3:2] CLK2p/CLK2n Frequency
11 125.00 MHz (Default)
10 155.52 MHz
01 156.25 MHz
00 SMA_CLK_p/n

Board Components
17
3.3 3.3 Power Supply
This section describes the power supply on the SFI HSMC board
The SFP HSMC is powered through the HSMC connector’s 3.3V and 12V pins. The SFP and clocking
circuitry requires 3.3V. A switching regulator powered from the 12 HSMC input produces 4V. Three linear
regulators powered from 4V will produce the 3.3V. The switching frequency is set to 1MHz. The power
distribution network is shown in the figure below. Max power consumption is estimated at 1A on 12V.
Typical power consumption is considerably less than this.
Figure 3.3 Power distribution on the SFP HSMC board

Demonstration
18
4
Demonstration
This Chapter illustrates the reference designs for the SFP HSMC board
4.1 4.1 Introduction
This section describes the functionality of the demonstration briefly.
The demonstration shows how to run the SFP HSMC loopback test for both Transceiver/LVDS based
channels using the SFP HSMC daughter board and the Stratix IV GX FPGA Development board. The
demonstration is intended for users to provide a basic introduction to the SFP HSMC daughter board with the
procedure to control different hardware and software settings.
4.2 4.2 System Requirements
The following items are required for the HSMC-DVI Server demonstration.
SFP HSMC x 1
Stratix IV GX FPGA Development Board x 1
SFP Loopback Connectors x 4
4.3 4.3 Setup the Demonstration
Figure 4.3 and 4.4 shows how to setup hardware for the SFP HSMC demonstration.
