ELECTRONIC THERMOSTAT – INSTRUCTIONS
OPERATION
1. Open window function button
2. Display (shows the desired room temperature by default)
3. Power button
4. Control button (+) (increase temperature/Increase timer)
5. Heating indicator light
6. Open window function indicator light
7. Timer function button
8. WIFI connection/delete button
9. Control button (–) (reduce temperature/Decrease timer)
10. Timer indicator light
11. WIFI indictor light
Control panel for electronic thermostat:
Before the heater is turned on, it must be attached to a wall or stand. If the
heater is not installed correctly or is installed askew, this may cause the heater to
malfunction or in the worst case, be damaged.
If the temperature sensor is not functioning properly, you will see the symbol
below on the display. Please contact the dealer or importer .
1. Turn on:
Plug in the heater. After “BI” voice, the heater enter into standby mode and show OF icon on display. Press
button to turn on the heater, and display show room temperature.
2. Temperature setting:
A. Temperature setting range is 5~35ºC.
B. Default temperature setting is 22ºC.
C. Press or button to set temperature, icon flash, the temperature will increase or decrease by
1ºC after each pressing and save in 3 seconds if no action. The display will show room temperature after
setting.
D. If room temperature is 1ºC higher than setting temperature, it will stop heating; if room temperature is
2ºC lower than setting temperature, it will start heating.
3. Timer
A. Under turn on mode, press button to enter into 24 hours turn off timer setting, and icon flash,
then press or button to set timer, the timer will increase or decrease by 1 hour after each pressing
and save in 3 seconds if no action and timer indicator light shows on display. Timer setting range is
0~24 hours.
4. Open window function
The heater has open window function. Pres button to enter the setting, and Pre or button to turn
on or turn off the function. When screen show “OF”, The function turns off. When screen shows ON, The
function turns on.
If you open a window widely in the space where the heater is located and the temperature drop 2ºC or
more than 2ºC in two minutes, a sensor will detect the sharp drop in temperature. The heater will switch out
automatically and “FO” flash in display.
CAUTION!
