TEUCER LR-4RGBW User manual

Teucer`s RGBW controller enables control of up to 4 zones.
As well as dimming this product this product can be used in
conjuncon with the LR-WTC receiver and paired with the
LR-WIFI trans and the Easy lighng app therefore allowing
any Android or Apple smartphone/ tablet to simultaneous
control the lighng wirelessly whilst maintaining synchro-
nous operaons.
Product Descripon
Technical Specicaon
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
Controller
Order Code LR-4RGBW
Type RF remote controller
Input Voltage 4.5VDC (3xAAA baery)
Operaon Frequency 434MHz / 869.5MHz / 916.5MHz
Dimension 55x120x17mm (WxLxH)
Operang temperature 0-40°C
Relave humidity 8% - 80%
Receiver
Order Code LRR-WTC
Type RF receiver
Input Voltage 12-36VDC
Current 4X5A
Output 4X(60-180)W
Note Constant voltage
Dimension 46x178x22mm (WxLxH)
• Control up to 4 zones independently or simultaneously
• Adjust colour and brightness
• Smartphone / tablet compable via Easy Lighng app
• Wireless RF range of 8-15 meters (depending on signal
obstacles within the installaon area)
• Save light funcons and preferences to each zone
• 5%-100% smooth dimming
Features
RF technology allows for greater exibility when it comes to
controlling simple or complex lighng installaons without
the need of addional cabling.
There are some limitaons where installaons have the
receivers enclosed in electrical boxes or hidden away in a
ceiling, reducing the RF signal strength and therefore the
communicaon range.
In order to overcome these RF Signal restricons we sug-
gest the following when synchronising our RF controllers
and receivers:
• Keep the distance within 10 meters from the controller
to the receiver
• When expanding your lighng, always try and use a
signal repeater (PR-RGB), where possible.
• If your installaon requires several RF receivers, ensure
the “master” receiver is posioned in the middle.
Recommendaon
LR-4RGBW and LRR-WTC
4 zone RF & WIFI controller and receiver for RGBW LED strip

Receiver wiring diagram
Controller layout
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
When wiring the receivers, it s mportant to make sure the total waage of the LED strips does not exceed the maximum
rated waage per channel of the receiver. Each chanel is rated at 5A, so the maximum waage per channel is 24x5A=120w.
The power supply has to match the rated voltage and be superior to the total LED strip waage by a remcommended 10%.
Bottom side
4.5V(3xAAA battery)
Front side
Indicator: indicate the
state of remote control
Color wheel
White channel: the 4th channel
Click to turn on/off,Press and hold
down to increase/decrease light
intensity of the W channel
Click to play / pause the 10
built-in effects, Press and hold
down to speed up/down the
running effect
Click to switch CW, NW, WW
mixed by RGB, double click to
turn off RGB channels
Press and hold down to decrease
light intensity of RGB channels
Press and hold down to increase
light intensity of RGB channels
Click to turn ON/OFF all zones
Press and hold down to save colors;
Click to recall the saved colors
Zone numbers:Click to choose
the zone/zones, Press and hold
down to turn on/off corresponding
zone
S1 S2
S3
W+
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
L
N
110V-230VACPower Supply
W
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
L
N
110V-230VACPower Supply
W
LR-4RGBW and LRR-WTC
4 zone RF & WIFI controller and receiver for RGBW LED strip

Synchronising the controller to receiver
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
1) Turn the controller ON. Red LED indicator will be light up.
3) Ensure the receiver has power. Press the learning key on the receiver.
4) Ensure the controller is turned ON (red light
indicator ON) and press the zone you which to
allocate to the receiver, than touch the colour
wheel. The LED strips will blink to conrm syn-
chronisaon has been successful.
6) To clear the receiver from a selected zone, simply press and hold the learning key for 5 or
more seconds. The receiver will be reset to the default factory sengs.
Learning key
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
W
2) Set the receiver LRR-WTC as a MASTER OR SLAVE.
Allocang the receiver as a master or slave is important to ensure your LED strip and receiv-
er are fully synchronised. There can be only 1 master receiver per zone.
close circuit for MASTER
open circtuit for SLAVE
1
23
LRR-WTC
Learning Key
4
MASTER SLAVE
W
1. Select your zone
2. Touch the colour wheel
The LED strip will flash
to confirm synchronisa�on.
S1 S2
S3
W+
5) Just repeat the learning process to synchronise several receivers to the same controller.
LR-4RGBW and LRR-WTC
4 zone RF & WIFI controller and receiver for RGBW LED strip

Teucer (UK) Ltd
Head oce
Bedford House, Fulham Green, Fulham High Street,
London, SW6 3JW, UK
Tel: [phone]
Fax: [phone]
www.teucerled.co.uk
[e-mail]
Logiscs Centre
Trident Court,
1 Oakcro Road,
Chessington,
Surrey, KT9 1BD, London, UK
Tel: [phone], extension: 401
[e-mail]
Controlling your LED strip
Brighter for longer
CONTROLLER AND RECEIVER
www.teucerled.co.uk
With LR-4RGBW one can adjust the brightness and colour temperature of the RGBW LED strip.
• Choose the zone(s) you wish to control.
Select as many zones as you wish.
• Touch the colour wheel to change colours.
• Choose one of 10 pre-set play modes.
• Speed up or slow down the play modes.
• Adjust the colour temperature from cool
white to warm white and neutral white.
Bottom side
4.5V(3xAAA battery)
Front side
Indicator: indicate the
state of remote control
Color wheel
White channel: the 4th channel
Click to turn on/off,Press and hold
down to increase/decrease light
intensity of the W channel
Click to play / pause the 10
built-in effects, Press and hold
down to speed up/down the
running effect
Click to switch CW, NW, WW
mixed by RGB, double click to
turn off RGB channels
Press and hold down to decrease
light intensity of RGB channels
Press and hold down to increase
light intensity of RGB channels
Click to turn ON/OFF all zones
Press and hold down to save colors;
Click to recall the saved colors
Zone numbers:Click to choose
the zone/zones, Press and hold
down to turn on/off corresponding
zone
S1 S2
S3
W+
