TPS23523EVM-863 Evaluation Module
User's Guide
SLVUBC9–December 2017
TPS23523EVM-863 Evaluation Module
This user’s guide describes the TPS23523 evaluation module (TPS23523EVM-863). The TPS23523EVM-
863 contains evaluation and reference circuitry for the TPS23523, which is a low-side Hot Swap and
ORing controller targeted at telecom applications. In addition, this EVM contains an INA226 to
demonstrate how telemetry can easily be added to this solution.
Contents
1 Introduction ................................................................................................................... 2
2 Schematic..................................................................................................................... 5
3 General Configuration and Description ................................................................................... 5
4 Test Results .................................................................................................................. 7
5 Bill of Materials ............................................................................................................. 16
List of Figures
1 TPS23523-863 Typical Configuration..................................................................................... 3
2 TPS23523-863 Advanced Configuration ................................................................................. 3
3 TPS23523EVM-863 Schematic............................................................................................ 5
4 Start Up (VIN = 54 V)......................................................................................................... 7
5 Start Up (VIN = 54 V)......................................................................................................... 7
6 Start Up (VIN = 38 V)......................................................................................................... 7
7 Start Up (VIN = 60 V)......................................................................................................... 7
8 Hot Plug Channel A and B Together...................................................................................... 7
9 Hot Plug Channel A and B Together...................................................................................... 7
10 Hot Plug A after B ........................................................................................................... 8
11 Hot Plug A after B ........................................................................................................... 8
12 Hot Plug A after B ........................................................................................................... 8
13 Hot Plug A after B ........................................................................................................... 8
14 Output Hot Short (VINB = 54 V) ............................................................................................ 8
15 Output Hot Short (VINB = 54 V) ............................................................................................ 8
16 Output Hot Short (VINB = 54 V) ............................................................................................ 9
17 Output Hot Short (VINB = 60 V) ............................................................................................ 9
18 Output Hot Short (VINB = 60 V) ............................................................................................ 9
19 Gradual Over Current (VINA = 54 V)....................................................................................... 9
20 Load Step Overcurrent...................................................................................................... 9
21 Start Into Short............................................................................................................... 9
22 Start Into Short ............................................................................................................. 10
23 Apply Short and Remove Short .......................................................................................... 10
24 1-ms Brown Out............................................................................................................ 10
25 1-ms Brown Out............................................................................................................ 10
26 Supply Switch Over (Raise VINA)......................................................................................... 10
27 Supply Switch Over (Zoomed in)......................................................................................... 10
28 VINA Short ................................................................................................................... 11
29 VINA Short ................................................................................................................... 11

Introduction www.ti.com
2SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
30 Unplug VINA................................................................................................................. 11
31 Plug in VINA Backwards ................................................................................................... 11
32 Plug in VINA Backwards ................................................................................................... 11
33 Undervoltage and Overvoltage (Rising)................................................................................. 11
34 Undervoltage and Overvoltage (Falling) ................................................................................ 12
35 –2-kV (2 Ω) Lightning Surge.............................................................................................. 12
36 –2-kV (2 Ω) Lightning Surge (Zoomed in) .............................................................................. 12
37 2-kV (2 Ω) Lightning Surge (Zoomed in)................................................................................ 12
38 2-kV (2 Ω) Lightning Surge (Zoomed in)................................................................................ 12
39 Start-Up (VIN = 54 V)....................................................................................................... 12
40 Hot Short (VIN = 54 V)...................................................................................................... 13
41 Hot Short (VIN = 38 V)...................................................................................................... 13
42 Load Step (0 A–11 A) ..................................................................................................... 13
43 Load Step Into Overcurrent............................................................................................... 13
44 Start Into Short ............................................................................................................. 13
45 1-ms Brown Out............................................................................................................ 13
46 Effective Circuit for Voltage Monitoring.................................................................................. 15
List of Tables
1 TPS23523 Electrical and Performance Specifications at 25°C........................................................ 4
2 Connector Functionality..................................................................................................... 5
3 Test Points.................................................................................................................... 6
4 Jumper Descriptions......................................................................................................... 6
5 TPS23523 EVM – Measured Voltage Monitoring Accuracy.......................................................... 14
6 TPS23523 EVM, Measured Current Monitoring Accuracy............................................................ 15
7 Bill of Materials ............................................................................................................. 16
Trademarks
All trademarks are the property of their respective owners.
1 Introduction
The TPS23523 EVM is meant to give a jump start to anyone designing a –48-V system with a single
supply that needs to support supply dips and other transients. It includes input clamping to support
lightning surge (up to 2 kV), various FET placeholders to support various power levels, and an output
inductor to mimic any EMI filter before the DC/DC converter. The EVM can be configured in two ways (via
jumpers) to evaluate 2 common architectures seen in the –48-V telecommunication space.
Figure 1 shows a block diagram for the first configuration of the EVM. The TPS23523 provides inrush
control, short circuit protection, reverse current protection, and reverse hookup protection. The INA226
provides current, voltage, and power monitoring. If the downstream DC/DC is isolated and powers the
microcontroller, an isolator is required to communicate between the microcontroller and the INA226. Thus,
the ISO1541 is added to provide this functionality. Also note that the TPS23523 helps to create a bias rail
to power both the INA226 and ISO1541. For detailed operation of the INA226, consult INA226EVM
Evaluation Board and Software Tutorial .

www.ti.com Introduction
3
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Figure 1. TPS23523-863 Typical Configuration
As Figure 2 shows, the TPS23523 EVM can also be configured to implement a more sophisticated
architecture. In this architecture there is a common 48-V input that is used to power both the load on the
board and the mid plane. The ORing and current monitoring is performed on the 48-V input. Then the hot-
swap function is performed on just the load present on the board. The remaining current powers the mid
plane, which has its own plug-in cards with hot swap on them.
Figure 2. TPS23523-863 Advanced Configuration
1.1 Features
This EVM has the following features:
• Inrush current control
• Hot-swap output short-circuit protection
• Reverse current protection
• Reverse hookup protection

Introduction www.ti.com
4SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
1.2 Applications
This EVM is used in the following applications:
• Wireless infrastructure
• Telecom infrastructure
• –48-V interface
1.3 Electrical Specifications
Table 1 lists the TPS23523 electrical and performance specifications at 25°C.
Table 1. TPS23523 Electrical and Performance Specifications at 25°C
Characteristic TPS23523EVM-PWR863
Input voltage range (recommended) 38 V to 60 V
Input voltage range (absolute maximum) 0 V to 150 V
Load power 400 W
Load output capacitance 500 µF
Current limit (normal) 12.5 A
Current limit (high FET VDS) 1.5 A
Typical inrush current 0.4 A
Hot-Swap FET VDS when current transitions from high to low 20.2 V
Time out (VDS,HS < 10 V) 2.25 ms
Time out (10 V < VDS,HS < 20 V) 1.12 ms
Time out (VDS,HS > 20 V) 0.23 ms
Undervoltage threshold (rising) 36.6 V
Undervoltage threshold (falling) 34.6 V
Overvoltage (OV) threshold (rising) 64.4 V
Overvoltage threshold (falling) 61.4 V

www.ti.com Schematic
5
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
2 Schematic
Figure 3 illustrates the EVM schematic.
Figure 3. TPS23523EVM-863 Schematic
3 General Configuration and Description
3.1 Physical Access
Table 2 lists the TPS23523EVM connector and functionality, Table 3 describes the test point availability,
and Table 4 describes the default jumper configuration.
Table 2. Connector Functionality
Connector Label Description
J1, J2 RTN Power bus input – tie the high side of the power-supply inputs and outputs
here.
J3 Overvoltage jumper – shorts OV to GND disabling OV.
J4 Neg48V Neg48V input – tie the low side of the input supply here.
J5 Vout_FLTD Output bus – low-side output after EMI inductor.
J6 VEE_PWR Tie Extra loads here to test advanced configuration.
J7 Jumper selects current monitoring between R20 and R21.
J8 Jumper selects current monitoring between R20 and R21.
J9 Connector for the INA dongle.

General Configuration and Description www.ti.com
6SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Table 3. Test Points
Connector Label Description
TP1 VCC Clamped voltage supply
TP2 PGB_Col PGB test point
TP3 OV OV pin voltage
TP4 PGB Power good bar
TP5 VREF External voltage reference pin
TP6 SS Soft-start pin voltage
TP7 D D pin voltage
TP8 UVEN UV pin voltage
TP9 GATE2 Gate-drive output voltage for optional hot-swap FET Q5
TP10 GATE Gate-drive output voltage for hot-swap FET Q3
TP11 SNS Sense pin test point
TP12 GATEB Gate-drive output voltage for gate B ORing FET
TP13 TMR Timer capacitor voltage
TP14 VEE IC ground – place voltage probe ground at this pin
TP15 Neg48 Low-side input for power supply
TP16 OR_SRC Main power rail test point
TP17 VOUT_ Low side unfiltered output for load
TP18 VOUT_FLTD Low side filtered output for load
TP19 SNS- Negative side of Rsns
TP20 SNS+ Positive side of Rsns
TP21 VCC_EXT External bias voltage
TP22 VCC1 VCC from external connector J9 to DC/DC
TP23 VCC2 VCC between INA226 telemetry and DC/DC
TP24 SDA2 Data communication between INA226 telemetry and DC/DC
TP25 SDA1 Data communication between external connector J9 and DC/DC
TP26 VBUS Bus voltage input for INA226
TP27 SCL2 Serial bus clock line from DC/DC to INA226
TP28 SCL1 Serial bus clock line from external connector J9 to DC/DC
TP29 GND GND from external connector J9 to DC/DC
TP30 A0 Address pin – connect to GND, SCL, or SDA. Consult High-or Low-Side Measurement, Bi-Directional CURRENT/POWER MONITOR with I2C™
Interface for more information.
TP31 A1 Address pin – connect to GND, SCL, or SDA. Consult High-or Low-Side Measurement, Bi-Directional CURRENT/POWER MONITOR with I2C™
Interface for more information.
Table 4. Jumper Descriptions
Connector Description
J3 Overvoltage jumper – jump pins to short OV to GND, disabling OV.
J7 Jump pins 1-2 to enable R21, or jump pins 2-3 to enable R20.
J8 Jump pins 1-2 to enable R21, or jump pins 2-3 to enable R20.

www.ti.com General Configuration and Description
7
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
3.2 Equipment Setup
Use the following equipment list and setup steps to work with the EVM:
• 2× power supplies capable of ≥60 V and ≥15 A (preferred)
• Resistive or electronic load, only turn on the load after hot swap is up
Follow these steps to properly set-up the device:
1. Set the input power-supply voltage to the desired operating input voltage.
2. Turn the power supply off.
3. Jump pins on J7 and J8, depending on the desired resistor.
4. Leave pins 1-2 on J3 open.
5. Connect the positive voltage lead from the power supply to J1 (RTN). Connect the ground lead from
the power supply to J4 (Neg48V).
6. Make sure all voltmeter and oscilloscope GNDs are tied to VEE.
7. Turn the power supplies on.
3.3 Scope Considerations
Observe the following scope considerations:
• Most scopes have a 10-MΩresistance between scope GND and probe. If a scope GND is tied to RTN,
and a probe is placed on TMR that is approximately 5 µA of pullup current, this can overpower the
pulldown of the TMR pin and result in a time out.
• Scope GND is tied to Earth GND, which has some capacitance to supply (+) and (–) terminals. This
may cause system noise.
4 Test Results
This section provides typical performance waveforms for the TPS23523EVM-863. Actual performance
data is affected by measurement techniques and environmental variables; therefore, these curves are
presented for reference and may differ from actual results obtained.
No load, scope GND = –48V_A
Figure 4. Start Up (VIN = 54 V)
No load, scope GND = –48V_A
Figure 5. Start Up (VIN = 54 V)

Test Results www.ti.com
8SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
No load, scope GND = –48V_A
Figure 6. Start Up (VIN = 38 V)
No load, scope GND = –48V_A
Figure 7. Start Up (VIN = 60 V)
VINA = 54 V, VINB = 54 V, no load, scope GND = RTN
Figure 8. Hot Plug Channel A and B Together
VINA = 54.5 V, VINB = 54 V, no load, scope GND = RTN
Figure 9. Hot Plug Channel A and B Together
VINA = 54 V; VINB = 38 V, scope GND = RTN, Iload = 5 A
Figure 10. Hot Plug A after B
VINA = 54 V; VINB = 38 V, scope GND = RTN, Iload = 5 A
Figure 11. Hot Plug A after B

www.ti.com Test Results
9
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
VINA = 54 V; VINB = 38 V, scope GND = RTN, Iload = 5 A
Figure 12. Hot Plug A after B
VINA = 54.5 V; VINB = 54 V, scope GND = RTN, no load
Figure 13. Hot Plug A after B
Scope GND = –48V_B, no load, after inductor
Figure 14. Output Hot Short (VINB = 54 V)
Scope GND = –48V_B, 5-A load, after inductor
Figure 15. Output Hot Short (VINB = 54 V)
Scope GND = –48V_B, 5A load, zoomed in
Figure 16. Output Hot Short (VINB = 54 V)
Scope GND = –48V_B, 5-A load
Figure 17. Output Hot Short (VINB = 60 V)

Test Results www.ti.com
10 SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Scope GND = –48V_B, 5-A load, zoomed in
Figure 18. Output Hot Short (VINB = 60 V)
Scope GND = –48V_A
Figure 19. Gradual Over Current (VINA = 54 V)
Scope GND = –48V_A
Figure 20. Load Step Overcurrent
Scope GND = –48V_A, VIN = 54 V
Figure 21. Start Into Short
Scope GND = –48V_A, VIN = 54 V
Figure 22. Start Into Short
Scope Gnd = –48V_A, VIN = 54 V
Figure 23. Apply Short and Remove Short

www.ti.com Test Results
11
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Scope GND = –48V_A, Iload = 5 A
Figure 24. 1-ms Brown Out
Scope GND = –48V_A, Iload = 5 A
Figure 25. 1-ms Brown Out
VINB = 53 V, Iload = 5 A, scope GND = RTN
Figure 26. Supply Switch Over (Raise VINA)
VINB = 53 V (raise VINA), scope GND = RTN, Iload = 5 A
Figure 27. Supply Switch Over (Zoomed in)
VINA = 54.5 V; VINB = 54 V, Iload = 5 A, scope GND = RTN
Figure 28. VINA Short
VINA = 54.5 V; VINB = 54 V, Iload = 5 A, scope GND=RTN
Figure 29. VINA Short

Test Results www.ti.com
12 SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
VINA = 54.5 V; VINB = 54 V, Iload = 5 A, scope GND=RTN
Figure 30. Unplug VINA
VINB = 60 V
Figure 31. Plug in VINA Backwards
VINB floating
Figure 32. Plug in VINA Backwards
Scope GND = –48V_A, no load
Figure 33. Undervoltage and Overvoltage (Rising)
Scope GND = –48V_A, no load
Figure 34. Undervoltage and Overvoltage (Falling)
Scope GND = RTN, 5-A load, Per IEC61000-4-5
Figure 35. –2-kV (2 Ω) Lightning Surge

www.ti.com Test Results
13
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Scope GND = RTN, 5-A load, Per IEC61000-4-5
Figure 36. –2-kV (2 Ω) Lightning Surge (Zoomed in)
Scope GND = RTN, 5-A load, Per IEC61000-4-5
Figure 37. 2-kV (2 Ω) Lightning Surge (Zoomed in)
Scope GND = RTN, 5-A load, Per IEC61000-4-5
Figure 38. 2-kV (2 Ω) Lightning Surge (Zoomed in)
Lin = 20 µH, scope GND = –48V_A
Figure 39. Start-Up (VIN = 54 V)
Lin = 20 µH, scope GND = –48V_A
Figure 40. Hot Short (VIN = 54 V)
Lin = 20 µH, scope GND = –48V_A
Figure 41. Hot Short (VIN = 38 V)

Test Results www.ti.com
14 SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Lin = 20 µH, scope GND = –48V_A,
Figure 42. Load Step (0 A–11 A)
Lin = 20 µH, scope GND = –48V_A
Figure 43. Load Step Into Overcurrent
Lin = 20 µH, scope GND = -48V_A
Figure 44. Start Into Short
Lin = 20 µH, scope GND = –48V_A
Figure 45. 1-ms Brown Out
The TPS23523 EVM – Measured Voltage Monitoring Accuracy table shows excellent voltage monitoring
accuracy was achieved.
Table 5. TPS23523 EVM – Measured Voltage Monitoring Accuracy
VIN, ACT(V) VBUS, ACT(V) VIN, MEAUS(V) Error
38.48 1.989 38.46 –0.05%
47.98 2.481 47.97 –0.02%
58.48 3.024 58.47 –0.02%

www.ti.com Test Results
15
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
The INA226 measures the voltage on the VBUS pin, which is tied to VIN through a resistor divider. Figure 46
illustrates a simplified diagram. Note that there is an 830-kΩresistor that must be accounted for. For this
EVM, R1= 100 kΩand R2= 5.49 kΩ. To compute VIN, MEAS from VBUS, MEAS measured, first compute RBOT
and then compute the resistor divider ration as follows:
(1)
(2)
Figure 46. Effective Circuit for Voltage Monitoring
Table 6 shows the current monitoring accuracy results. The VSNS was measured between TP19 and
TP7, which is before the RC filter going into the IC. The results show that the sense resistor is responsible
for the majority of the error and roughly equals 2%. Note that on this PCB, a simple two-terminal, 2-mΩ
resistor was used. If greater accuracy is desired, 4-terminal resistors or higher-accuracy resistors can be
used. Note that the IC + Other Error sources are 0.5% at 1 A and down to 0.1% at 10 A.
Table 6. TPS23523 EVM, Measured Current Monitoring Accuracy
IIN,
ACT VSNS, ACT (mV) VSNS, MEAS (mV) IIN, MEAS (A) RSNS, ERROR IC + Other Error Total Error
1 2.035 2.025 1.0125 1.8% -0.49% 1.25%
2 4.08 4.07 2.035 1.9% -0.25% 1.65%
3 6.125 6.11 3.055 2.1% -0.25% 1.83%%
4 8.17 8.153 4.0765 2.1% -0.21% 1.91%
5 10.21 10.19 5.095 2.1% -0.20% 1.90%
6 12.22 12.19 6.095 1.8% -0.25% 1.58%
7 14.27 14.25 7.125 1.9% -0.14% 1.79%
8 16.34 16.32 8.16 2.1% -0.12% 2.00%
9 18.38 18.36 9.18 2.1% -0.11% 2.00%
10 20.4 20.38 10.19 2.0% -0.10% 13.22%

Bill of Materials www.ti.com
16 SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
5 Bill of Materials
Table 7 lists the EVM BOM.
Table 7. Bill of Materials
Designator Qty Value Description Package
Reference Part Number Manufacturer
PCB 1 Printed Circuit Board PWR863 Any
C2 1 0.47uF CAP, CERM, 0.47 µF, 25 V, ±10%, X7R, AEC-Q200 Grade 1, 0603 0603 GCM188R71E474KA64D Murata
C3 1 0.15uF CAP, CERM, 0.15 µF, 25 V, ±10%, X7R, 0603 0603 GRM188R71E154KA01D Murata
C5, C20 2 0.1uF CAP, CERM, 0.1 µF, 100 V, ±10%, X7R, 0805 0805 C0805C104K1RACTU Kemet
C8, C9 2 330uF CAP, AL, 330 µF, 100 V, ±20%, 0.153 ohm, SMD SMT Radial
K16 EEV-FK2A331M Panasonic
C11 1 1uF CAP, CERM, 1 µF, 100 V, ±10%, X7R, 1206 1206 C3216X7R2A105K160AA TDK
C16 1 0.015uF CAP, CERM, 0.015 µF, 25 V, ±10%, X7R, 0603 0603 GRM188R71E153KA01D Murata
C17 1 0.033uF CAP, CERM, 0.033 µF, 100 V, ±10%, X7R, 0805 0805 08051C333KAT2A AVX
C18 1 0.01uF CAP, CERM, 0.01 µF, 100 V, ±5%, X7R, 0805 0805 08051C103JAT2A AVX
C21, C23 2 0.1uF CAP, CERM, 0.1 µF, 10 V, ±10%, X7R, 0603 0603 C0603C104K8RACTU Kemet
C22 1 1uF CAP, CERM, 1 µF, 10 V, +80/-20%, Y5V, 0603 0603 C0603C105Z8VACTU Kemet
D1 1 150V Diode, Schottky, 150 V, 1 A, SMA SMA STPS1150A STMicroelectroni
cs
D2 1 100V Diode, Switching, 100 V, 0.15 A, SOD-123 SOD-123 1N4148W-TP Micro
Commercial
Components
H1, H2, H3, H4 4 Machine Screw, Round, #4-40 x 1/4, Nylon, Philips panhead Screw NY PMS 440 0025 PH B&F Fastener
Supply
H5, H6, H7, H8 4 Standoff, Hex, 0.5"L #4-40 Nylon Standoff 1902C Keystone
J1 1 Standard Banana Jack, Uninsulated, 8.9mm Keystone575
-8 Keystone
J2, J4, J5, J6 4 Standard Banana Jack, Uninsulated, 8.9mm Keystone575
-8 575-8 Keystone
J3 1 Header, 100mil, 2x1, Gold, TH 2x1 Header TSW-102-07-G-S Samtec
J7, J8 2 Header, 100mil, 3x1, Gold, TH PBC03SAAN PBC03SAAN Sullins Connector
Solutions
J9 1 Receptacle, 50mil, 10x1, Gold, R/A, TH receptacle
10x1, 50mil 851-43-010-20-001000 Mill-Max
L1 1 5.6uH Inductor, Shielded Drum Core, Mn-Zn, 5.6 µH, 25 A, 0.00274 ohm, SMD 18.3x8.9x18.
2mm 7443557560 Wurth Elektronik
Q1 1 150 V Transistor, PNP, 150 V, 0.5 A, SOT-23 SOT-23 MMBT5401LT1G ON
Semiconductor
Q3 1 100V MOSFET, N-CH, 100 V, 197 A, TO-263-2 KTT0002A CSD19535KTT Texas
Instruments
Q7, Q11 2 200V MOSFET, N-CH, 200 V, 36 A, PG-TDSON-8 PG-TDSON-
8BSC320N20NS3GATMA1 Infineon Technologies

www.ti.com Bill of Materials
17
SLVUBC9–December 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Table 7. Bill of Materials (continued)
Designator Qty Value Description Package
Reference Part Number Manufacturer
Q8 1 140 V Transistor, NPN, 140 V, 0.6 A, SOT-23 SOT-23 MMBT5550LT1G ON
Semiconductor
R1 1 49.9k RES, 49.9 k, 0.1%, 0.1 W, 0603 0603 RT0603BRD0749K9L Yageo America
R3 1 301k RES, 301 k, 1%, 0.125 W, 0805 0805 ERJ-6ENF3013V Panasonic
R4 1 200k RES, 200 k, 1%, 0.125 W, 0805 0805 CRCW0805200KFKEA Vishay-Dale
R5 1 15.0k RES, 15.0 k, 1%, 0.75 W, AEC-Q200 Grade 0, 2010 2010 CRCW201015K0FKEF Vishay-Dale
R6 1 499k RES, 499 k, 1%, 0.125 W, 0805 0805 CRCW0805499KFKEA Vishay-Dale
R7 1 10.0 RES, 10.0, 1%, 0.25 W, 1206 1206 RC1206FR-0710RL Yageo America
R8 1 100 RES, 100, 1%, 0.1 W, 0603 0603 CRCW0603100RFKEA Vishay-Dale
R10 1 374k RES, 374 k, 1%, 0.1 W, 0603 0603 RC0603FR-07374KL Yageo America
R11 1 1.00k RES, 1.00 k, 1%, 0.1 W, 0603 0603 CRCW06031K00FKEA Vishay-Dale
R13 1 4.75k RES, 4.75 k, 1%, 0.1 W, 0603 0603 CRCW06034K75FKEA Vishay-Dale
R14, R23, R25 3 10.0 RES, 10.0 ohm, 1%, 0.1W, 0603 0603 CRCW060310R0FKEA Vishay-Dale
R16 1 5.62k RES, 5.62 k, 1%, 0.1 W, 0603 0603 CRCW06035K62FKEA Vishay-Dale
R17, R27, R28 3 10.0 RES, 10.0, 1%, 0.1 W, 0603 0603 CRCW060310R0FKEA Vishay-Dale
R20 1 0.001 RES, 0.001, 1%, 1 W, 2512 2512 ERJ-M1WTF1M0U Panasonic
R21 1 0.002 RES, 0.002, 1%, 1 W, 2512 2512 ERJ-M1WTF2M0U Panasonic
R31 1 4.75k RES, 4.75 k, 1%, 0.25 W, 1206 1206 ERJ-8ENF4751V Panasonic
R32, R40, R41 3 0 RES, 0, 5%, 0.1 W, 0603 0603 ERJ-3GEY0R00V Panasonic
R33 1 100k RES, 100 k, 0.1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 ERA-3AEB104V Panasonic
R34, R35, R36, R37,
R38 5 10.0k RES, 10.0 k, 1%, 0.1 W, 0603 0603 CRCW060310K0FKEA Vishay-Dale
R39 1 5.49k RES, 5.49 k, 0.1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 ERA-3AEB5491V Panasonic
RV1, RV2 2 Ceramic transient voltage suppressor, 2220_250 B72540T6500S162 TDK
SH-J1, SH-J2, SH-J3 3 1x2 Shunt, 100mil, Gold plated, Black Shunt 969102-0000-DA 3M
TP1, TP2, TP3, TP4,
TP5, TP6, TP7, TP8,
TP9, TP10, TP11,
TP12, TP13, TP14,
TP15, TP16, TP17,
TP18, TP19, TP20,
TP21, TP22, TP23,
TP24, TP25, TP26,
TP27, TP28, TP29,
TP30, TP31
31 Test Point, Miniature, SMT Testpoint_Ke
ystone_Minia
ture
5015 Keystone
U1 1 TPS2352x Family, PW0016A PW0016A TPS23523PW Texas
Instruments
U2 1 Low-Power Bidirectional I2C Isolators, D0008A D0008A ISO1541DR Texas
Instruments
U3 1 High-or Low-Side Measurement, Bi-Directional CURRENT/POWER MONITOR with
I2C(TM) Interface, DGS0010A DGS0010A INA226AIDGSR Texas Instruments

Bill of Materials www.ti.com
18 SLVUBC9–December 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
TPS23523EVM-863 Evaluation Module
Table 7. Bill of Materials (continued)
Designator Qty Value Description Package
Reference Part Number Manufacturer
C1 0 0.47uF CAP, CERM, 0.47 µF, 250 V, ±10%, X7R, 1812 1812 GRM43DR72E474KW01L Murata
C4 0 0.1uF CAP, CERM, 0.1 µF, 250 V, ±10%, X7T, 0805 0805 C2012X7T2E104K125AA TDK
C6, C7 0 330uF CAP, AL, 330 µF, 100 V, ±20%, 0.153 ohm, SMD SMT Radial
K16 EEV-FK2A331M Panasonic
C10 0 0.068uF CAP, CERM, 0.068 µF, 50 V, ±10%, X7R, 0603 0603 GRM188R71H683KA93D Murata
C12 0 10uF CAP, CERM, 10 µF, 6.3 V, ±20%, X5R, 0603 0603 C0603C106M9PACTU Kemet
C13 0 0.01uF CAP, CERM, 0.01 µF, 250 V, ±10%, X7R, 0805 0805 QMK212B7103KG-T Taiyo Yuden
C14 0 0.01uF CAP, CERM, 0.01 µF, 50 V, ±5%, X7R, 0603 0603 C0603C103J5RACTU Kemet
C15 0 0.1uF CAP, CERM, 0.1uF, 16V, ±5%, X7R, 0603 0603 0603YC104JAT2A AVX
C19 0 0.01uF CAP, CERM, 0.01 µF, 25 V, ±10%, X7R, 0603 0603 GRM188R71E103KA01D Murata
FID1, FID2, FID3, FID4,
FID5, FID6 0 Fiducial mark. There is nothing to buy or mount. Fiducial N/A N/A
Q2, Q4 0 200V MOSFET, N-CH, 200 V, 62 A, DDPAK DDPAK IRFS4227PBF International
Rectifier
Q5, Q6, Q10 0 100V MOSFET, N-CH, 100 V, 17 A, SON 5x6mm SON 5x6mm CSD19532Q5B Texas
Instruments
Q9, Q12 0 200V MOSFET, N-CH, 200 V, 36 A, PG-TDSON-8 PG-TDSON-
8BSC320N20NS3GATMA1 Infineon Technologies
R2 0 10.0 RES, 10.0, 1%, 0.25 W, 1206 1206 RC1206FR-0710RL Yageo America
R9 0 0 RES, 0, 5%, 0.1 W, 0603 0603 ERJ-3GEY0R00V Panasonic
R12 0 100 RES, 100, 1%, 0.1 W, 0603 0603 CRCW0603100RFKEA Vishay-Dale
R15, R18, R19, R22,
R24, R26, R30 0 10.0 RES, 10.0 ohm, 1%, 0.1W, 0603 0603 CRCW060310R0FKEA Vishay-Dale
R29 0 499 RES, 499, 1%, 0.1 W, 0603 0603 RC0603FR-07499RL Yageo America

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.

FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
