Texas Instruments TAS5805M User manual

System
Processor
Digital
Audio
Source
ADR/FAULT
PDN
SDOUT
SDA
SCL
SDIN
SCLK (BCLK)
LRCLK
BST_A+
OUT_A+
BST_A-
OUT_A-
BST_B+
OUT_B+
BST_B-
OUT_B-
Speaker
L Channel Speaker R Channel
DVDD
Copyright © 2018, Texas Instruments Incorporated
Product
Folder
Order
Now
Technical
Documents
Tools &
Software
Support &
Community
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018
TAS5805M 23-W, Inductor-Less, Digital Input, Stereo, Closed-Loop Class-D Audio
Amplifier with Enhanced Processing and Low Idle Power Dissipation
1
1 Features
1• Supports Multiple Output Configurations
– 2 × 23 W in 2.0 Mode (8-Ω, 21 V, THD+N=1%)
– 45 W in Mono Mode (4-Ω, 21 V, THD+N=1%)
• Excellent Audio Performance
– THD+N ≤0.03% at 1 W, 1 kHz, PVDD = 12 V
– SNR ≥107 dB (A-weighted), Noise Level < 40
µVRMS
• Low Quiescent Current with Hybrid Modulation
– 16.5 mA at PVDD = 13.5 V , 22 µH + 0.68 µF
Filter
• Flexible Power Supply Configurations
– PVDD: 4.5 V to 26.4 V
– DVDD and I/O: 1.8 V or 3.3 V
• Flexible Audio I/O
– I2S, LJ, RJ, TDM, 3-Wire Digital Audio
Interface (No MCLK Required)
– Supports 32, 44.1, 48, 88.2, 96 kHz Sample
Rates
– SDOUT for Audio Monitoring, Sub-Channel or
Echo Cancellation
• Enhanced Audio Processing
– Multi-Band Advanced DRC and AGL
– 2×15 BQs, Thermal Foldback, DC Blocking
– Input Mixer, Output Crossbar, Level Meter
– 5 BQs + 1 Band DRC +THD Manager for the
Subwoofer Channel
• Integrated Self-Protection
– Adjacent Pin to Pin Short Without Device
Damage
– Over-Current Error (OCE)
– Over-Temperature Warning (OTW)
– Over-Temperature Error (OTE)
– Under/Over-Voltage Lock-out (UVLO/OVLO)
• Easy System Integration
– I2C Software Control
– Reduced Solution Size
– Fewer Passives Required Compared to
Open-Loop Devices
– Inductor-less Operation (Ferrite Bead) for
most cases where PVDD ≤14V
2 Applications
• LCD TV, OLED TV
• Wireless Speaker, Smart Speaker with Voice
Assistant
• Soundbar, Wired Speaker , Bookshelf Stereo
System
• Desktop PC, Notebook PC
• AV Receiver, Smart Home and IoT Appliance
3 Description
The TAS5805M is a high-efficiency, stereo, closed-
loop Class-D amplifier offering a cost effective digital-
input solution with low power dissipation and sound
enrichment. The device’s integrated audio processor
and 96 kHz architecture supports advanced audio
process flow, including SRC, 15 BQs per channel,
volume control, audio mixing, 3-band 4th order DRC,
full-band AGL, THD managing and level meter.
Featuring TI's proprietary Hybrid Modulation scheme,
the TAS5805M consumes very-low quiescent current
(<16.5 mA at 13.5V PVDD), extending battery life in
portable audio applications. With advanced EMI
suppression technology, designers can leverage
inexpensive ferrite bead filters to reduced board
space and system cost.
Device Information(1)
PART NUMBER PACKAGE BODY SIZE (NOM)
TAS5805M TSSOP (28) PWP 9.7 mm × 4.4 mm
(1) For all available packages, see the orderable addendum at
the end of the data sheet.
Simplified Block Diagram

2
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Table of Contents
1 Features.................................................................. 1
2 Applications ........................................................... 1
3 Description............................................................. 1
4 Revision History..................................................... 2
5 Device Comparison Table..................................... 3
6 Pin Configuration and Functions......................... 3
7 Specifications......................................................... 5
7.1 Absolute Maximum Ratings ...................................... 5
7.2 ESD Ratings ............................................................ 5
7.3 Recommended Operating Conditions....................... 5
7.4 Thermal Information.................................................. 5
7.5 Electrical Characteristics........................................... 6
7.6 Timing Requirements ............................................... 9
7.7 Typical Characteristics............................................ 10
8 Parameter Measurement Information ................ 19
9 Detailed Description............................................ 20
9.1 Overview................................................................. 20
9.2 Functional Block Diagram....................................... 20
9.3 Feature Description................................................. 21
9.4 Device Functional Modes........................................ 25
9.5 Programming and Control....................................... 30
9.6 Register Maps......................................................... 34
10 Application and Implementation........................ 65
10.1 Application Information.......................................... 65
10.2 Typical Applications ............................................. 65
11 Power Supply Recommendations ..................... 74
11.1 DVDD Supply........................................................ 74
11.2 PVDD Supply........................................................ 74
12 Layout................................................................... 76
12.1 Layout Guidelines ................................................. 76
12.2 Layout Example .................................................... 78
13 Device and Documentation Support................. 79
13.1 Device Support...................................................... 79
13.2 Receiving Notification of Documentation Updates 79
13.3 Community Resources.......................................... 80
13.4 Trademarks........................................................... 80
13.5 Electrostatic Discharge Caution............................ 80
13.6 Glossary................................................................ 80
14 Mechanical, Packaging, and Orderable
Information........................................................... 80
4 Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Original (May 2018) to Revision A Page
• Released as Production Data................................................................................................................................................. 1

3
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
5 Device Comparison Table
ORDERABLE PART
NUMBER RECOMMENDED PVDD RANGE Audio Process Flows RDS(ON)
TAS5805M 4.5 V to 26.4 V Enhanced Audio Process Flows with ROM Fixed 180 mΩ
TAS5707/TAS5711 8 V to 26 V Basic Audio Process Flow with ROM Fixed 180 mΩ
TAS5825M 4.5 V to 26.4 V Flexible Advanced Audio Process Flows with Smart-Amp
Features 90 mΩ
6 Pin Configuration and Functions
PWP Package
28-Pin TSSOP
(1) AI = Analog input, AO = Analog output, DI = Digital Input, DO = Digital Output, DI/O = Digital Bi-directional (input and output), P =
Power, G = Ground (0 V)
Pin Functions
PIN TYPE(1) DESCRIPTION
NAME NO.
DGND 1, 5 P Digital ground
DVDD 2 P 3.3-V or 1.8-V digital power supply
VR_DIG 4 P Internally regulated 1.5-V digital supply voltage. This pin must not be used to drive external devices
ADR/FAULT 3 DI/O Different I2C device address can be set by selecting different pull up resistor to DVDD, see Table 4 for details.
This pin can be programed by Register 0x60h and 0x61h after Power up bit. In this mode, the ADR/FAULT Is
redefined as FAULT
LRCLK 6 DI Word select clock for the digital signal that is active on the serial port's input data line. In I2S, LJ and RJ, this
corresponds to the left channel and right channel boundary. In TDM mode, this corresponds to the frame sync
boundary.
SCLK 7 DI Bit clock for the digital signal that is active on the input data line of the serial data port.
SDIN 8 DI Data line to the serial data port
SDOUT 9 DO Serial Audio data output. The source data can be Pre-DSP or Post DSP data, by setting the register 0x30h.
SDA 10 DI/O I2C serial control data interface input/output

4
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Pin Functions (continued)
PIN TYPE(1) DESCRIPTION
NAME NO.
SCL 11 DI I2C serial control clock input
PDN 12 DI Power Down, active-low.PDN place the amplifier in Shutdown, turn off all internal regulators. Low, Power Down
Device; High, Enable Device.
AVDD 13 P Internally regulated 5-V analog supply voltage. This pin must not be used to drive external devices
AGND 14 P Analog ground
PVDD 15,16,27,
28 P PVDD voltage input
PGND 19,24 P Ground reference for power device circuitry. Connect this pin to system ground.
OUT_A+ 26 O Positive pin for differential speaker amplifier output A+
BST_A+ 25 P Connection point for the OUT_A+ bootstrap capacitor which is used to create a power supply for the high-side
gate drive for OUT_A+
OUT_A- 23 O Negative pin for differential speaker amplifier output A-
BST_A- 22 P Connection point for the OUT_A- bootstrap capacitor which is used to create a power supply for the high-side gate
drive for OUT_A-
BST_B- 21 P Connection point for the OUT_B- bootstrap capacitor which is used to create a power supply for the high-side gate
drive for OUT_B-
OUT_B- 20 O Negative pin for differential speaker amplifier output B
BST_B+ 18 P Connection point for the OUT_B+ bootstrap capacitor which is used to create a power supply for the high-side
gate drive for OUT_B+
OUT_B+ 17 O Positive pin for differential speaker amplifier output B+
PowerPAD™ P Connect to the system Ground

5
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
(1) Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings
only, which do not imply functional operation of the device at these or any other conditions beyond those indicated under Recommended
Operating Conditions. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) DVDD referenced digital pins include: ADR/FAULT, LRCLK, SCLK, SCL, SDA, SDIN,PDN
7 Specifications
7.1 Absolute Maximum Ratings
Free-air room temperature 25°C (unless otherwise noted) (1)
MIN MAX UNIT
DVDD Low-voltage digital supply –0.3 3.9 V
PVDD PVDD supply –0.3 30 V
VI(DigIn) DVDD referenced digital inputs(2) –0.5 VDVDD + 0.5 V
VI(SPK_OUTxx) Voltage at speaker output pins –0.3 32 V
TAAmbient operating temperature –25 85 °C
Tstg Storage temperature –40 125 °C
(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process.
7.2 ESD Ratings VALUE UNIT
V(ESD) Electrostatic discharge Human-body model (HBM), per ANSI/ESDA/JEDEC JS-001(1) ±2000 V
Charged-device model (CDM), per JEDEC specification JESD22-
C101(2) ±500
7.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted) MIN NOM MAX UNIT
V(POWER) Power supply inputs DVDD 1.62 3.63 V
PVDD 4.5 26.4
RSPK Minimum speaker load BTL Mode (4.5V≤PVDD≤16V) 3.2 Ω
BTL Mode (16V<PVDD≤24V) 4.8 Ω
RSPK Minimum speaker load PBTL Mode (4.5V≤PVDD≤16V) 1.6 Ω
PBLT Mode (16V<PVDD≤24V) 2.4 Ω
LOUT Minimum inductor value in LC filter under short-circuit condition 1 4.7 µH
(1) For more information about traditional and new thermal metrics, see the Semiconductor and IC Package Thermal Metrics application
report.
7.4 Thermal Information
THERMAL METRIC(1)
TAS5805M
TSSOP (PWP)
28 PINS UNIT
JEDEC
STANDARD
2-LAYER PCB
JEDEC
STANDARD
4-LAYER PCB
TAS5805MEVM-4
4-LAYER PCB
RθJA Junction-to-ambient thermal resistance N/A 29.1 24 °C/W
RθJC(top) Junction-to-case (top) thermal resistance N/A 21.8 N/A °C/W
RθJB Junction-to-board thermal resistance N/A 8.2 N/A °C/W
ψJT Junction-to-top characterization parameter N/A 0.3 1.5 °C/W
ψJB Junction-to-board characterization parameter N/A 8.1 7.6 °C/W
RθJC(bot) Junction-to-case (bottom) thermal resistance N/A 2.2 N/A °C/W

6
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
7.5 Electrical Characteristics
Free-air room temperature 25°C (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
DIGITAL I/O
|IIH| Input logic high current level for DVDD referenced digital
input pins VIN(DigIn) = VDVDD 10 µA
|IIL| Input logic low current level for DVDD referenced digital
input pins VIN(DigIn) = 0 V –10 µA
VIH(Digin) Input logic high threshold for DVDD referenced digital
inputs 70% VDVDD
VIL(Digin) Input logic low threshold for DVDD referenced digital
inputs 30% VDVDD
VOH(Digin) Output logic high voltage
level IOH = 2 mA 80% VDVDD
VOL(Digin) Output logic low voltage level IOH = –2 mA 20% VDVDD
I2C CONTROL PORT
CL(I2C) Allowable load capacitance
for each I2C line 400 pF
fSCL(fast) Support SCL frequency No wait states, fast mode 400 kHz
fSCL(slow) Support SCL frequency No wait states, slow mode 100 kHz
SERIAL AUDIO PORT
tDLY Required LRCLK/FS to SCLK
rising edge delay 5 ns
DSCLK Allowable SCLK duty cycle 40% 60%
fSSupported input sample rates 32 96 kHz
fSCLK Supported SCLK frequencies 32 64 fS
fSCLK SCLK frequency 24.576 MHz
SPEAKER AMPLIFIER (ALL OUTPUT CONFIGURATIONS)
Icc Quiescent supply current on
DVDD PDN=2V, DVDD=3.3V, Play mode 18 mA
Icc Quiescent supply current on
DVDD PDN=2V, DVDD=3.3V, Sleep mode 0.75 mA
Icc Quiescent supply current on
DVDD PDN=2V, DVDD=3.3V, Deep Sleep mode 0.75 mA
Icc Quiescent supply current on
DVDD PDN=0V, DVDD=3.3V, Shutdown mode 5.5 µA
Icc Quiescent supply current on
PVDD PDN=2V,, PVDD=13.5V, LC filter=10uH+0.68uF, Fsw=768kHz, BD Modulation, Play mode 32.5 mA
Icc Quiescent supply current on
PVDD PDN=2V,, PVDD=13.5V, LC filter=22uH+0.68uF, Fsw=384kHz, Hybrid Modulation, Play mode 16.5 mA
Icc Quiescent supply current on
PVDD PDN=2V, PVDD=13.5V, Output Hiz Mode 10.4 mA
Icc Quiescent supply current on
PVDD PDN=2V, PVDD=13.5V, Sleep Mode 7.2 mA
Icc Quiescent supply current on
PVDD PDN=2V, PVDD=13.5V, Deep Sleep Mode 120 µA
Icc Quiescent supply current on
PVDD PDN=0V, PVDD=13.5V, Shutdown Mode 7.2 µA
toff Turn-off Time Excluding volume ramp 10 ms
AV(SPK_AMP) Programmable Gain Value represents the "peak voltage" disregarding
clipping due to lower PVDD).
Measured at 0 dB input(1FS) 4.87 29.5 V
ΔAV(SPK_AMP) Amplifier gain error Gain = 29.5 Vp/FS 0.5 dB
fSPK_AMP Switching frequency of the
speaker amplifier 384 kHz
768 kHz
RDS(on) Drain-to-source on resistance of the individual output
MOSFETs FET + Metallization 180 mΩ

7
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
Electrical Characteristics (continued)
Free-air room temperature 25°C (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
OCETHRES Over-Current Error Threshold OUTxx Overcurrent Error Threshold 5 A
OVETHRES(PVDD PVDD over voltage error
threshold 28 V
UVETHRES(PVDD PVDD under voltage error
threshold 4.2 V
OTETHRES Over temperature error
threshold 160 °C
OTEHystersis Over temperature error
hysteresis 10 °C
OTWTHRES Over temperature warning
level Read by register 0x73 bit3 135 °C
SPEAKER AMPLIFIER (STEREO BTL)
|VOS| Amplifier offset voltage Measured differentially with zero input data, programmable gain configured with 29.5 Vp gain,
VPVDD = 12 V, BD Mode –6.5 6.5 mV
PO(SPK) Continuous Output power
(per channel)
VPVDD = 21V, SPK_GAIN = 24.8 Vp/FS, RSPK = 8
Ω, f = 1 kHz, THD+N = 1%, 1SPW Mode 23 W
VPVDD = 21 V, SPK_GAIN = 24.8 Vp/FS, RSPK = 8
Ω, f = 1 kHz, THD+N = 10%, 1SPW Mode 27.5 W
VPVDD = 18 V, SPK_GAIN = 20.8 Vp/FS, RSPK = 6
Ω, f = 1 kHz, THD+N = 1%, BD Mode 21 W
VPVDD = 18 V, SPK_GAIN = 20.8 Vp/FS, RSPK = 6
Ω, f = 1 kHz, THD+N = 10%, BD Mode 25 W
VPVDD = 12 V, SPK_GAIN = 13.9 Vp/FS, RSPK = 6
Ω, f = 1 kHz THD+N = 1%, BD Mode 9.9 W
VPVDD = 12 V, SPK_GAIN = 13.9 Vp/FS, RSPK = 6
Ω, f = 1 kHz THD+N = 10%, BD Mode 12 W
VPVDD = 13.5 V, SPK_GAIN = 15.6 Vp/FS, RSPK
= 6 Ω, f = 1 kHz THD+N = 1%, BD Mode 12 W
VPVDD = 13.5 V, SPK_GAIN = 15.6 Vp/FS, RSPK
= 6 Ω, f = 1 kHz THD+N = 10%, BD Mode 15 W
THD+NSPK
Total harmonic distortion and
noise
(PO= 1 W, f = 1 KHz, RSPK =
6Ω)
VPVDD = 12 V, Fsw=768kHz, SPK_GAIN = 13.9
Vp/FS, LC-filter, BD Mode 0.03%
VPVDD = 18 V, Fsw=768kHz, SPK_GAIN = 20.8
Vp/FS, LC-filter, BD Mode 0.03%
ICN(SPK) Idle channel noise(A-
weighted) VPVDD = 12 V, Fsw=768kHz, LC-filter, Load=6 Ω37 µVrms
VPVDD = 18 V, Fsw=768kHz, LC-filter, Load=6 Ω38
DR Dynamic range A-Weighted, -60 dBFS method. PVDD = 24 V,
SPK_GAIN = 29.5 Vp/FS 106 dB
SNR Signal-to-noise ratio
A-Weighted, referenced to 1% THD+N output
level, PVDD=24V 111 dB
A-Weighted, referenced to 1% THD+N output
level, PVDD=13.5V 107.5 dB
KSVR Power supply rejection ratio Injected Noise = 1 KHz, 1 Vrms, PVDD = 12 V,
input audio signal = digital zero 72 dB
X-talkSPK Cross-talk (worst case between left-to-right and
right-to-left coupling) f = 1 kHz 100 dB
SPEAKER AMPLIFIER (MONO PBTL)
PO(SPK) Continuous Output Power
VPVDD = 12 V, SPK_GAIN = 13.9 Vp/FS, RSPK = 4
Ω, f = 1kHz, THD+N = 1%, BD Mode 15.4 W
VPVDD = 12 V, SPK_GAIN = 13.9 Vp/FS, RSPK = 4
Ω, f = 1kHz, THD+N = 10%, BD Mode 18.5 W
VPVDD = 18V, SPK_GAIN = 22.1 Vp/FS, RSPK = 4
Ω, f = 1kHz, THD+N = 1%, BD Mode 33.6 W
VPVDD = 18 V, SPK_GAIN = 22.1 Vp/FS, RSPK = 4
Ω, f = 1kHz, THD+N = 10%, BD Mode 41 W

8
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Electrical Characteristics (continued)
Free-air room temperature 25°C (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
THD+NSPK
Total harmonic distortion and
noise
(PO= 1 W, f = 1 kHz)
VPVDD = 12 V, SPK_GAIN = 16.5 Vp/FS, 4.7uH +
0.68uF filter, RSPK = 4 Ω, BD Mode 0.06%
VPVDD = 24 V, SPK_GAIN = 29.5 Vp/FS, 4.7uH +
0.68uF filter, RSPK = 4 Ω, 1SPW Mode 0.07%
DR Dynamic range A-Weighted, -60 dBFS method, PVDD = 24V,
SPK_GAIN = 29.5 Vp/FS 106 dB
SNR Signal-to-noise ratio
A-Weighted, referenced to 1% THD+N output
level, PVDD=13.5V 107.7 dB
A-Weighted, referenced to 1% THD+N output
level, PVDD=24V 111 dB
KSVR Power supply rejection ratio Injected Noise = 1 KHz, 1 Vrms, PVDD = 19 V, input
audio signal = digital zero 72 dB

9
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
7.6 Timing Requirements MIN NOM MAX UNIT
Serial Audio Port Timing
fSCLK SCLK frequency 1.024 MHz
tSCLK SCLK period 40 ns
tSCLKL SCLK pulse width, low 16 ns
tSCLKH SCLK pulse width, high 16 ns
tSL SCLK rising to LRCK/FS edge 8 ns
tLS LRCK/FS Edge to SCLK rising edge 8 ns
tSU Data setup time, before SCLK rising edge 8 ns
tDH Data hold time, after SCLK rising edge 8 ns
tDFS Data delay time from SCLK falling edge 15 ns
I2C Bus Timing – Standard
fSCL SCL clock frequency 100 kHz
tBUF Bus free time between a STOP and START condition 4.7 µs
tLOW Low period of the SCL clock 4.7 µs
tHI High period of the SCL clock 4 µs
tRS-SU Setup time for (repeated) START condition 4.7 µs
tS-HD Hold time for (repeated) START condition 4 µs
tD-SU Data setup time 250 ns
tD-HD Data hold time 0 900 ns
tSCL-R Rise time of SCL signal 20 + 0.1CB1000 ns
tSCL-R1 Rise time of SCL signal after a repeated START condition and
after an acknowledge bit 20 + 0.1CB1000 ns
tSCL-F Fall time of SCL signal 20 + 0.1CB1000 ns
tSDA-R Rise time of SDA signal 20 + 0.1CB1000 ns
tSDA-F Fall time of SDA signal 20 + 0.1CB1000 ns
tP-SU Setup time for STOP condition 4 µs
I2C Bus Timing –
Fast
fSCL SCL clock frequency 400 kHz
tBUF Bus free time between a STOP and START condition 1.3 µs
tLOW Low period of the SCL clock 1.3 µs
tHI High period of the SCL clock 600 ns
tRS-SU Setup time for (repeated)START condition 600 ns
tRS-HD Hold time for (repeated)START condition 600 ns
tD-SU Data setup time 100 ns
tD-HD Data hold time 0 900 ns
tSCL-R Rise time of SCL signal 20 + 0.1CB300 ns
tSCL-R1 Rise time of SCL signal after a repeated START condition and
after an acknowledge bit 20 + 0.1CB300 ns
tSCL-F Fall time of SCL signal 20 + 0.1CB300 ns
tSDA-R Rise time of SDA signal 20 + 0.1CB300 ns
tSDA-F Fall time of SDA signal 20 + 0.1CB300 ns
tP-SU Setup time for STOP condition 600 ns
tSP Pulse width of spike suppressed 50 ns

Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=18V
TA=25qC
RL=6:
D104
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=24V
TA=25qC
RL=6:
D105
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=12V
TA=25qC
RL=4:
D109
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=12V
TA=25qC
RL=6:
D103
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=5V
TA=25qC
RL=4:
D102
P O=0.5W
PO=1W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D003D004D002
PVcc=7.4V
TA=25qC
RL=4:
D101
P O=0.5W
PO=1W
PO=2.5W
10
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
7.7 Typical Characteristics
7.7.1 Bridge Tied Load (BTL) Configuration Curves
Free-air room temperature 25°C (unless otherwise noted) Measurements were made using TAS5805MEVM
board and Audio Precision System 2722 with Analog Analyzer filter set to 20-kHz brickwall filter. All
measurements taken with audio frequency set to 1 kHz and device PWM Modulation mode set to 1SPW mode
unless otherwise noted.
PVDD = 5 V 4.7uH+0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 1. THD+N vs Frequency-BTL
PVDD = 7.4 V 4.7uH+0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 2. THD+N vs Frequency-BTL
PVDD = 12 V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 4Ω
Figure 3. THD+N vs Frequency-BTL
PVDD = 12 V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 4. THD+N vs Frequency-BTL
PVDD = 18 V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 5. THD+N vs Frequency-BTL
PVDD = 24 V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 6. THD+N vs Frequency-BTL

Supply Voltage (V)
Output Power (W)
4.5 6.5 8.5 10.5 12.5 14.5 16
0
5
10
15
20
25
30
D014
D037
BTL Mode
TA=25qC
D120
THD+N=1%, R L=4:
THD+N=10%, R L=4:
Supply Voltage (V)
Output Power (W)
4.5 6.5 8.5 10.5 12.5 14.5 16.5 18.5 20.5 22.5 24
0
5
10
15
20
25
30
35
40
45
D014
D037
BTL Mode
TA=25qC
D121
THD+N=1%, R L=6:
THD+N=10%, R L=6:
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=24V
TA=25qC
RL=8:
D108
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=19V
TA=25qC
RL=6:
D110
BD Mode
1SPW Mode
Hybrid Mode
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=12V
TA=25qC
RL=8:
D106
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=18V
TA=25qC
RL=8:
D107
P O=1W
PO=2.5W
PO=5W
11
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 12 V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 7. THD+N vs Frequency-BTL
PVDD = 18 V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 8. THD+N vs Frequency-BTL
PVDD = 24 V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 9. THD+N vs Frequency-BTL
PVDD = 19 V 10uH+0.68uF POUT = 5W
FSW = 384 kHz BD/1SPW/Hybrid Load = 6Ω
Figure 10. THD+N vs Frequency-BTL
NOTE: Dashed lines represent thermally limited region for the
continuous output power.
PVDD = 4.5 V~16V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 4Ω
Figure 11. Output Power vs Supply Voltage-BTL
NOTE: Dashed lines represent thermally limited region for the
continuous output power.
PVDD = 4.5 V~24V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 12. Output Power vs Supply Voltage-BTL

Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10 20
D007
PVCC=18V
TA=25qC
RL=6:
D115
f=20Hz
f=1kHz
f=10kHz
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10 20
D007
PVCC=24V
TA=25qC
RL=6:
D116
f=20Hz
f=1kHz
f=10kHz
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=12V
TA=25qC
RL=4:
D113
f=20Hz
f=1kHz
f= 10kHz
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=12V
TA=25qC
RL=6:
D114
f=20Hz
f=1kHz
f=10kHz
Supply Voltage (V)
Output Power (W)
4.5 6.5 8.5 10.5 12.5 14.5 16.5 18.5 20.5 22.5 24
0
5
10
15
20
25
30
35
40
D014
D037
BTL Mode
TA=25qC
D122
THD+N=1%, R L=8:
THD+N=10%, R L=8:
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=5V
TA=25qC
RL=4:
D112
f=20Hz
f=1kHz
f= 10KHz
12
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 4.5 V~24V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 13. Output Power vs Supply Voltage-BTL
PVDD = 5V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 4Ω
Figure 14. THD+N vs Output Power-BTL
PVDD = 12V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 4Ω
Figure 15. THD+N vs Output Power-BTL
PVDD = 12V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 16. THD+N vs Output Power-BTL
PVDD = 18V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 17. THD+N vs Output Power-BTL
PVDD = 24V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 18. THD+N vs Output Power-BTL

Frequency (Hz)
Crosstalk (dB)
-120
-100
-80
-60
-40
-20
0
100 1k 10k20 20k
D003D001D128
PVDD=12V, LC filter=4.7uH+0.68uF
Ch A to Ch B
Ch B to Ch A
Frequency (Hz)
Crosstalk (dB)
-120
-100
-80
-60
-40
-20
0
100 1k 10k20 20k
D003D001D129
PVcc=18V, LC filter=10uH+0.68uF
Ch 1 to Ch 2
Ch 2 to Ch 1
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10 20
D007
PVCC=24V
TA=25qC
RL=8:
D119
f=20Hz
f=1kHz
f=10kHz
Supply Voltage (V)
Idle Channel Noise (PVrms)
0
20
40
60
80
205 15 1810 20
D007D030D126
Fsw=768kHz, Channel A
Fsw=768kHz, Channel B
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=12V
TA=25qC
RL=8:
D117
f=20Hz
f=1kHz
f=10kHz
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10 20
D007
PVCC=18V
TA=25qC
RL=8:
D118
f=20Hz
f=1kHz
f=10kHz
13
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 12V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 19. THD+N vs Output Power-BTL
PVDD = 18V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 20. THD+N vs Output Power-BTL
PVDD = 24V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 21. THD+N vs Output Power-BTL
PVDD = 4.5V~24V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 22. Idle Channel Noise vs PVDD-BTL
PVDD = 12V 4.7uH+0.68uF Pout=1W
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 23. Crosstalk
PVDD = 18V 10uH+0.68uF Pout=1W
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 24. Crosstalk

Output Power (W)
Efficiency (%)
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30
D024
TA=25qC
RL=4:
BTL Mode
D123
PVDD = 4.5V
PVDD = 7.4 V
PVDD = 12 V
Output Power (W)
Efficiency (%)
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40 50
D024
TA=25qC
RL=6:
BTL Mode
D124
PVDD = 7.4V
PVDD = 12 V
PVDD = 18 V
PVDD = 24 V
Frequency (Hz)
Crosstalk (dB)
-120
-100
-80
-60
-40
-20
0
100 1k 10k20 20k
D003D001D132
PVDD=18V, LC filter=10uH+0.68uF
Ch 1 to Ch 2
Ch 2 to Ch 1
Frequency (Hz)
Crosstalk (dB)
-120
-100
-80
-60
-40
-20
0
100 1k 10k20 20k
D003D001D133
PVDD=24V, LC filter=10uH+0.68uF
Ch 1 to Ch 2
Ch 2 to Ch 1
Frequency (Hz)
Crosstalk (dB)
-120
-100
-80
-60
-40
-20
0
100 1k 10k20 20k
D003D001D130
PVDD=24V, LC filter=10uH+0.68uF
Ch 1 to Ch 2
Ch 2 to Ch 1
Frequency (Hz)
Crosstalk (dB)
-120
-100
-80
-60
-40
-20
0
100 1k 10k20 20k
D003D001D131
PVDD=12V, LC filter=4.7uH+0.68uF
Ch A to Ch B
Ch B to Ch A
14
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 24V 10uH+0.68uF Pout=1W
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 25. Crosstalk
PVDD = 12V 4.7uH+0.68uF Pout=1W
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 26. Crosstalk
PVDD = 18V 10uH+0.68uF Pout=1W
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 27. Crosstalk
PVDD = 24V 10uH+0.68uF Pout=1W
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 28. Crosstalk
PVDD =
4.5V/7.4V/12V 4.7uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 4Ω
Figure 29. Efficiency vs Output Power-BTL
PVDD =
7.4V/12V/18V/24V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 6Ω
Figure 30. Efficiency vs Output Power-BTL

Supply Voltage (V)
Output Power (W)
4.5 6.5 8.5 10.5 12.5 14.5 16
0
5
10
15
20
D014
D037
BTL Mode
TA=25qC
D137
THD+N=1%, R L=8:
THD+N=10%, R L=8:
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=7.4V
TA=25qC
RL=4:
D138
f=20Hz
f=1kHz
f=10kHz
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=12V
TA=25qC
RL=6:
D135
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=12V
TA=25qC
RL=8:
D136
P O=1W
PO=2.5W
PO=5W
Output Power (W)
Power Efficiency (%)
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40 50 60
D024
TA=25qC
RL=8:
BTL Mode
D125
PVCC = 7.4V
PVCC = 12 V
PVCC = 18 V
PVCC = 24 V
15
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 7.4V/12V/18V/24V 10uH+0.68uF
FSW = 768 kHz 1SPW Modulation Load = 8Ω
Figure 31. Efficiency vs Output Power-BTL
7.7.2 Bridge Tied Load (BTL) Configuration Curves
Free-air room temperature 25°C (unless otherwise noted) Measurements were made using TAS805MEVM board
and Audio Precision System 2722 with Analog Analyzer filter set to 20-kHz brickwall filter. All measurements
taken with audio frequency set to 1 kHz and device PWM frequency set to 384 kHz, Spread Spectrum Enable,
Ferrite bead + Capacitor as the output filter, BD Modulation, unless otherwise noted.
PVDD = 12V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 6Ω
Figure 32. THD+N vs Frequency-BTL
PVDD = 12V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 8Ω
Figure 33. THD+N vs Frequency-BTL
PVDD = 4.5V~16V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 8Ω
Figure 34. Output Power vs Supply Voltage-BTL
PVDD = 7.4V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 4Ω
Figure 35. THD+N vs Output Power-BTL

Output Power (W)
Efficiency (%)
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40
D024
TA=25qC
RL=8:
BTL Mode
D144
PVDD = 7.4V
PVDD = 12 V
Output Power (W)
Efficiency (%)
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40
D024
TA=25qC
RL=6:
D145
PVDD = 7.4V
PVDD = 12 V
Frequency (Hz)
Crosstalk (dB)
-120
-100
-80
-60
-40
-20
0
100 1k 10k20 20k
D003D001D141
PVDD=12V, Ferrite Bead + Capacitor
Ch 1 to Ch 2
Ch 2 to Ch 1
Output Power (W)
Efficiency (%)
0
10
20
30
40
50
60
70
80
90
100
0 10 20
D024
TA=25qC
RL=4:
BTL Mode
D143
PVDD = 5V
PVDD = 7.4 V
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=12V
TA=25qC
RL=6:
D139
f=20Hz
f=1kHz
f=10kHz
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=12V
TA=25qC
RL=8:
D140
f=20Hz
f=1kHz
f=10kHz
16
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 12V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 6Ω
Figure 36. THD+N vs Output Power-BTL
PVDD = 12V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 8Ω
Figure 37. THD+N vs Output Power-BTL
PVDD = 12V,
Pout=1W Ferrite Bead + Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 6Ω
Figure 38. Crosstalk
PVDD = 5V/7.4V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 4Ω
Figure 39. Efficiency vs Output Power-BTL
PVDD = 7.4V/12V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 8Ω
Figure 40. Efficiency vs Output Power-BTL
PVDD = 7.4V/12V Ferrite Bead +
Capacitor Spread Spectrum Enable
FSW = 384 kHz BD Modulation Load = 6Ω
Figure 41. Efficiency vs Output Power-BTL
7.7.3 Parallel Bridge Tied Load (PBTL) Configuration
Free-air room temperature 25°C (unless otherwise noted) Measurements were made using TAS5805MEVM
board and Audio Precision System 2722 with Analog Analyzer filter set to 20-kHz brickwall filter. All
measurements taken with audio frequency set to 1 kHz and device PWM frequency set to 576 kHz, the LC filter
used was 4.7 μH / 0.68 μF, unless otherwise noted.

Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=5V
TA=25qC
RL=4:
D150
f=20Hz
f=1kHz
f=10kHz
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10 20
D007
PVCC=12V
TA=25qC
RL=4:
D151
f=20Hz
f=1kHz
f=10kHz
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=24V
TA=25qC
RL=4:
D148
P O=1W
PO=2.5W
PO=5W
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10
D007
PVCC=5V
TA=25qC
RL=2:
D149
f=20Hz
f=1kHz
f=10kHz
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=7.4V
TA=25qC
RL=4:
D146
P O=1W
PO=2.5W
PO=5W
Frequency (Hz)
THD+N(%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
100 1k 10k20 20k
D002
PVcc=12V
TA=25qC
RL=4:
D147
P O=1W
PO=2.5W
PO=5W
17
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 7.4V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 42. THD+N vs Frequency-PBTL
PVDD = 12V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 43. THD+N vs Frequency-PBTL
PVDD = 24V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 44. THD+N vs Frequency-PBTL
PVDD = 5V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 2Ω
Figure 45. THD+N vs Output Power-PBTL
PVDD = 5V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 46. THD+N vs Output Power-PBTL
PVDD = 12V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 47. THD+N vs Output Power-PBTL

Output Power (W)
Efficiency (%)
0
10
20
30
40
50
60
70
80
90
100
0 60403020
D043D156
PVDD = 5 V
PVDD = 7.4 V
PVDD = 12 V
PVDD = 18 V
PVDD = 24 V
Supply Voltage (V)
Output Power (W)
4.5 6.5 8.5 10.5 12.5 14.5 16.5 18.5 20.5 22.5 24
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
D014
D037
PBTL Mode
TA=25qC
D154
THD+N=1%, R L=4:
THD+N=10%, R L=4:
Supply Voltage (V)
Idle Channel Noise (PVrms)
0
20
40
60
205 15 1810 20
D007D030D155
Fsw=576kHz, PBTL Mode
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10 20
D007
PVCC=18V
TA=25qC
RL=4:
D152
f=20Hz
f=1kHz
f=10kHz
Output Power (W)
THD+N (%)
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
10
0.01 0.1 1 10 20
D007
PVCC=24V
TA=25qC
RL=4:
D153
f=20Hz
f=1kHz
f=10kHz
18
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
Typical Characteristics (continued)
PVDD = 18V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 48. THD+N vs Output Power-PBTL
PVDD = 24V 4.7uH + 0.68uF
FSW = 576kHz 1SPW Modulation Load = 4Ω
Figure 49. THD+N vs Output Power-PBTL
PVDD = 4.5V~24V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 50. Output Power vs Supply Voltage-PBTL
PVDD = 4.5V~24V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 51. Idle Channel Noise vs Supply Voltage-PBTL
PVDD = 5V/7.4V/12V/18V/24V 4.7uH + 0.68uF
FSW = 576 kHz 1SPW Modulation Load = 4Ω
Figure 52. Efficiency vs Output Power

SDA
SCL
START Repeated
START STOP
tD-SU
tLOW.
tSCL-R.
tHI.
tS-HD.
tBUF.
tSCL-F.
tD-HD
tRS-HD
tRS-SU
tSDA-R tSDA-F tP-SU
tSP
SCLK
(Input)
0.5 × DVDD
tSCLKH
0.5 × DVDD
tSCLKL
tSCLK tSL
tSU tDH
0.5 × DVDD
0.5 × DVDD
tDFS
tLS
LRCK/FS
(Input)
DATA
(Input)
DATA
(Output)
19
TAS5805M
www.ti.com SLASEH5A –MAY 2018–REVISED JULY 2018
Product Folder Links: TAS5805M
Submit Documentation FeedbackCopyright © 2018, Texas Instruments Incorporated
8 Parameter Measurement Information
Figure 53. Serial Audio Port Timing in Slave Mode
Figure 54. I2C Communication Port Timing Diagram

IO
IO
I2S/TDM
Audio DSP
Subsystem
PDM
Modulator
PLL & OSC
LDO 1.5V
ADR/
PDN
FAULT
SDA
SCL
SDIN
LRCLK
SCLK
LDO 5V
Digital to PWM
Conversion
H Bridge
&
Gate Driver
&
OC/DC Protect
DVDD VR_DIG AVDD PVDD1/2/3/4
AGND PGND 1/2
DGND
3.3/1.8V
4.5-26.4V
BST_A+
OUT_A+
OUT_A-
BST_A-
BST_B-
OUT_B-
BST_B+
OUT_B+
Closed-Loop Feedback
Closed-Loop Feedback
SDOUT
20
TAS5805M
SLASEH5A –MAY 2018–REVISED JULY 2018 www.ti.com
Product Folder Links: TAS5805M
Submit Documentation Feedback Copyright © 2018, Texas Instruments Incorporated
9 Detailed Description
9.1 Overview
The TAS5805M device integrates 4 main building blocks together into a single cohesive device that maximizes
sound quality, flexibility, and ease of use. The 4 main building blocks are listed as follows:
• A stereo audio DAC.
• An Audio DSP subsystem.
• A flexible closed-loop amplifier capable of operating in stereo or mono, at different switching frequencies, and
supporting a variety of output voltages and loads.
• An I2C control port for communication with the device
The device requires only two power supplies for proper operation. A DVDD supply is required to power the low
voltage digital circuitry. Another supply, called PVDD, is required to provide power to the output stage of the
audio amplifier. Two internal LDOs convert PVDD to 5 V for GVDD and AVDD and to 1.5V for DVDD
respectively.
9.2 Functional Block Diagram
