The Splash Lab TSL.C.050 Maintenance and service guide

TSL 050.C.
channel sensor faucet
installation + maintenance

contents
3 Safety and Warnings
4 Box Contents
5 Technical Data
6 BeforeYouInstall
8 HowtoInstall
10 The Complete System
11 Resetting the Sensor
13 Maintenance
13 Cleaning
14 Spare Parts
14
15
Product ldentification
Troubleshooting
16 Warranty
BackCover ContactDetails
2 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL

faucet
Read and save these instructions
WARNING !
General information
310 410 5008
Technical support
[e-mail]
For further contact information visit:
www.thesplashlabusa.com
Warehouse + Offices:
20809 Higgins Court, Torrance CA 90501
Showroom:
8745 Washington Boulevard, Studio D, Culver City CA 90232
TSL.C.050 channel sensor
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 3
To reduce the risk of fire, electric shock or injury to persons, observe the following:
+ Use this unit only in the manner intended by the manufacturer. If you have questions,
contactthemanufacturer.
+ This equipment should be installed in a way that ensures all electrical parts are
keptdry.
+ A means of electrical isolation must be incorporated in the fixed wiring, in
accordancewiththecurrentlocalregulationsinforce.
+ Disconnect the power supply before performing any maintenance on the product.
+ Children should not play with this equipment. Cleaning and maintenance shall not
beperformedbychildrenwithoutsupervision.
+ This equipment is designed to be used in commercial and public areas; it is not
intendedfordomesticorresidentialuse.
+ If in doubt, consult an electrician.
+ Not to be installed above such surfaces as china or chrome drain covers.
+ Ensurewiringisinstalledcorrectlybeforeconnectingtolivepower supply.

boxcontents
Channel sensor faucet head
B Mains power supply
C Solenoid valve
D Pad
E Gasket
F Washer
G Fixing nut
H Flow restrictor
I Flex hose - 300mm
A
AB
C
D
E
F
G
H
I
4 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL

Material (body) AISI316 Stainless steel
Operating pressure 7 - 87 psi dynamic pressure
Flow rate 0.5 GPM
(Other flow rates available upon request)
Weight 2lb 3oz
Power supply - Mains Input 100-240V ac; 50/60Hz
Output 6V DC, 0.5A, 3W max
Sensor range - Preset
Sensor range - Minimum
Sensor range - Maximum
5"
3"+/-20%
5.9"+/-20%
technical data
Finishes TSL.C.050.C Bright Polished
TSL.C.050.CS Brushed Stainless
TSL.C.050.CP Brushed Copper
TSL.C.050.BK Brushed Black
TSL.C.050.BR
Brushed Brass
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 5
Comfort delay 2 seconds
Security time 60 seconds
ApprovalsASME A112.18.1, CSA B125.1, NSF/ANSI/CAN 61,
WRAS, RoHS, ADA
Warranty1 year parts and labor
To flush 20 seconds after 24 hours of no usage

before you install
6 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL
FIXING
SIDEFRONT
Sensor
Range
3-15/16"
Sensor
wire
Flexi-hose
2 "
9-5/16"
1/2" PF
35-7/16"
21-5/8"21-5/8"

before you install
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 7
before you install
Flow Rates
Different flow rates may need to be achieved. The Splash Lab offers a number of
flow regulators which can be used in conjunction with the aucet. Contact Channel F
The Splash Lab for more information.
Water Temperature
The Faucet does not come equipped with temperature control. PremixedChannel
water must therefore be supplied separately.
Sinks
Use of a The Splash Lab sink is recommended when used in conjunction with any of
the The Splash Lab Channel fixtures.
When using other sinks, ensure that holes and appropriate mounting points are created
in accordance with the diagram below.
Spacing
If the Channel Faucet is installed with other units from the Channel System, it should be
installed in the center with the Soap Dispenser installed at 6" to the left and the
Hand Dryer installed at 8" to the right.

before you installbefore you install
The Splash Lab Monolith ( C or D) basin is recommended for use with the Series      Channel
range of products  . If an alternative basin is used, please confirm with The Splash Lab
that there will be no reflection or splash issue.
Basins
The Splash Lab offers an optional backplate
for the fixtures that means the fixtures can
be mounted from the front and have simpler
access.
Backplate
8 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL
6"8"
Back wall
Fixture insert
Washbasin
Front view
Ø 7/8"
Soap Faucet Dryer
Ø /"
1 3 16
Ø "
1 3/16
8"MIN
10"MAX
Distance between
the sensor and
the bottom of the basin

how to install
1
Drill hole 1 3 16" diameter in wall 8-10" - /
above the bottom of the basin.
2
Fit faucet body into the 1 3 16" hole in wall.- /
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 9
Ø -/"1 3 16

3
Thread the sensor wire and flexi-hose
through the gasket, washer and
fixing nut then tighten the nut
against the installation wall.
10 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL

Water Aerator
A Channel sensor faucet head
B Mains power supply
C Solenoid and cable
H Flow restrictor
the complete system
A
C
B
H
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 11

resetting the sensor
1 2
After connecting to power, immediately
place your hand at about 2 below the "
sensor on the tap head and keep it there
for 3 seconds.
First disconnect the Channel Tap head
from the Power unit. Wait a minimum of
4 seconds and reconnect the power.
solenoid cable
(Brown Orange wire)+
adapter cable
(Black Red )+ wire
12 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL

3 4
At the end of 3 seconds, move your hand
back to the original 2 position from the "
sensor and keep at the position for 3
seconds to complete setting up the
desired sensor range.
*Remove reflective clothing during
installation.
At the end of the 3 seconds, move
your hand away from the senor and
down towards the wash basin to set
the desired sensor range (max. 5.9 ) "
and keep your hand at the desired
position for 3 seconds.
max. 5.9"
resetting the sensor
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 13

Some of the components in the Channel System are consumable and may need
maintenance and replacing. The Channel System has been developed to accommodate
for this maintenance, yet all work should be done by a trained member of an approved
maintenance team. For more information, contact The Splash Lab.
maintenance
All grades of stainless steel will stain or discolor if due care and attention is not
taken. The surface must be regularly cleaned to ensure a long service life of the
sensor faucet.
Use a soft cloth or sponge with a mild solution of soapy water as part of the regular
washroom janitorial routine. Do not use abrasive or cream cleaners as these will
damage the surface finish.
If the sensor faucet is subjected to a highly chlorinated environment e.g. swimming
pools or marine coastal locations, a further treatment, in addition to the regular
cleaning as described above, is recommended to use a household cleaning product
containing silicone.
If further information is required, contact The Splash Lab Team for more detailed
stainless steel care guidelines. 
cleaning
+
+
+
+
14 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL

If a situation arises where you require replacement components outside of a
maintenance contract, there may be provision to obtain spare parts. Providing
the components are under warranty and the parts have become non-functioning
during normal use within their assumed usable life, they may be replaced. Should a
replacement mains power supply be required it is imperative that an identical type is
used. Contact The Splash Lab for further information. 
product identification
A unique product identification code can be found on the product tag attached to the
water hose.
spare parts
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 15

troubleshooting
Corrective Actions for Initial Installation Failures
Water does not flow / Cannot hear valve open
+ There is no power to valve or sensor
+ Check that cables are connected
+ Check that transformer is operating and supplying 6 volts
+ Sensor range is incorrect
+ Adjust sensor setting (see pages 11 and 12)
Water does not flow / Valve can be heard to open
+ Water supply is blocked to valve
+ Check and clean filter on solenoid valve
+ Check water supply for any blockages or restrictions
+ Water pressure is too low
+ Check pressure of water supply
Water does not flow / Sensor light is flashing all the time
+ Supply voltage has dropped below 5.4V
+ Check power supply and if necessary replace transformer
We are always looking to improve. If these steps
did not solve your problem please contact us
and we will endeavor to help.
Tel: [phone]
Email: [e-mail]
16 + TSL.C.050 CHANNEL SENSOR FAUCET MANUAL

The Channel Sensor Faucet will be warranted by The Splash Lab to be free of
     manufacturing and material defects during normal use and environmental conditions
as detailed below: 
2 year parts and 1 year labor.
If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide
         a replacement part or product, or make appropriate adjustments. Damage caused by
accident, misuse, or abuse is not covered by this warranty Improper care and cleaning         .   
will void the warranty.  
-Non operation of the product due to environmental conditions beyond our control,
          installation error, incorrect maintenance, water quality, fair wear and tear, incorrect or
inappropriate installation, misuse and abuse is not covered by the warranty.         
  (   )        Proof of purchase original sales receipt must be provided to The Splash Lab with all
warranty claims.
The above warranty is valid for goods supplied within North America.
            For goods supplied outside of North America, The Splash Lab will honor the above
     stated warranty periods for the parts only.
        THE SPLASH LAB DISCLAIM ANY LIABILITY FOR SPECIAL, INCIDENTAL OR
 CONSEQUENTIAL DAMAGES.
warranty
TSL.C.050 CHANNEL SENSOR FAUCET MANUAL + 17
+
+
+
+
+
+

TSL.C.050 (US) REV 2-16/06/21• •
