Thermaltake Pacific PR12-D5 Plus User manual

This product is intended for installation only by expert users. Please consult with a qualified technician for installation.
Improper installation may result in damage to your equipment.
1. Please carefully read the manual before beginning the installation process !
2. It is strongly recommended to use market proven pre-mix coolant, such as Thermaltake Coolant.
3. DO NOT USE any kind of alcohol or alcohol derivatives with this reservoir or the acrylic tube may crack and fail ! Do not clean it using alcohol either !
Installation Guide
Parts List
Pump & Reservoir
Bracket G1/4 Stop Plug Wrench
Clip Nuts Long Screws Short Screws
Ax 1
Bx 1 Cx 1 Gx 1 Hx 1
Lx 1 Mx 1 Nx 1I x 1 Jx 1 Kx 4
F
F
There are two types of mounting kits, please choose
the mounting kit you want to use.
Install your fittings and
tubes, remember to use
the bottom as an outlet
and top as an inlet. To control the lighting
effect by TT RGB PLUS
Software, please use
cable L to connect the
Pump & Reservoir
1 2 3
A
B
B
D
E
E
Support
16.8 Million Colors
Pump+Reservoir
L
Controller Power Cable Velcro Controller Cable Conversion cable Bridge Cable
Pacific PR12-D5 Plus
Ex 4 Fx 4Dx 4
or
D
C
CL-W338-PL00SW-A
1 0 5 G是X X 雙銅 單色 無無
其他特 殊處理效果表面處 理
2
厚度(g/m )
折數 材質雙面印 刷 印刷色彩單面印 刷
規格樣 式
單張 CHECK DESIGN
藍色線條為尺寸標示，請勿印刷上去！
210 mm
297 mm
刀模線
產品料號
C L - W 3 3 8 - P L 0 0 S W - A P a c i f i c P R 1 2 - D 5 P l u s 說明書 21/06/0 7 A
產品名稱 印刷項目 發稿日期 版本
Peipei
(21/06/07)
Leon
(21/06/07)

Installation Guide
4
6
5
J
Connect the reservoir cable onto the controller.
Set the DIP switch on the back side of the controller
to assign the number of the controller
7
123 45
J
NO.1
ON
1 2 3 4
NO.3
ON
1 2 3 4
NO.2
ON
1 2 3 4
NO.4
ON
1 2 3 4
NO.9
ON
1 2 3 4
NO.11
ON
1 2 3 4
NO.10
ON
1 2 3 4
NO.12
ON
1 2 3 4
NO.5
ON
1 2 3 4
NO.7
ON
1 2 3 4
NO.6
ON
1 2 3 4
NO.8
ON
1 2 3 4
NO.13
ON
1 2 3 4
NO.15
ON
1 2 3 4
NO.14
ON
1 2 3 4
NO.16
ON
1 2 3 4
Connect the controller cable onto the mainboard
(USB 2.0 9 pin) and controller.
9
10
8
If you want to connect two or more connectors,
you can use the bridge cable to connect the
controllers.
Connect the power cable to the 4pin Molex
connecter and controller.
K K
K
M M
© 2021 Thermaltake Technology Co., Ltd. All Rights Reserved.
After adding the recommended coolant, remember to
fill the reservoir to only 80% and leave the fill port cap
off. This will help stabilize your internal loop pressure
Keep the reservoir cap dry!
Do not allow coolant to
access the wire and
the LED module
Caution!
ON
1 2 3 4
I
Connect the Pump power cable to
the 4pin Molex connecter.
