Thermo Scientific 1371 User manual

Thermo Scientific Barnstead Nanopure™
TOC - Analytical Ultrapure Water System
Series 1371 and 1379
Operating Manual and Parts List LT1371X1 Rev. 1
_________________________________________________________________________________
Part of Thermo Fisher Scientific

Thermo Scientific
MANUAL NUMBER LT1371X1 (7007147)
1 26925 3/10/11 Decreased water pressure rating in Specifications from 100 to 80 psi ccs
0 -- 7/22/10 Transfer to Marietta (was LT1371X1 3/8/10) ccs
REV ECR/ECN DATE DESCRIPTION By
Preface
Nanopure TOC - Analytical i
Models covered in this manual
Model Number Voltage
D11941 (7147) 90-240V
D12411 (7151) 100-240V

Thermo Scientificii Nanopure TOC - Analytical
Preface
Important Read this instruction manual. Failure to read, understand and follow the instructions in this manual
may result in damage to the unit, injury to operating personnel, and poor equipment performance. s
Caution All internal adjustments and maintenance must be performed by qualified service personnel. s
Material in this manual is for information purposes only. The contents and the product it describes are subject to
change without notice. Thermo Fisher Scientific makes no representations or warranties with respect to this
manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising out of or related to
the use of this manual.
©2010 Thermo Fisher Scientific. All rights reserved.

Thermo Scientific Nanopure TOC - Analytical iii
Preface
Important operating and/or maintenance instructions. Read the accompanying text carefully.
Potential electrical hazards. Only qualified persons should perform procedures associated with this
symbol.
Equipment being maintained or serviced must be turned off and locked off to prevent possible injury.
Hot surface(s) present which may cause burns to unprotected skin, or to materials which may be
damaged by elevated temperatures.
Marking of electrical and electronic equipment, which applies to electrical and electronic equipment
falling under the Directive 2002/96/EC (WEEE) and the equipment that has been put on the market
after 13 August 2005.
This product is required to comply with the European Union’s Waste Electrical & Electronic
Equipment (WEEE) Directive 2002/96/EC. It is marked with the WEEE symbol. Thermo Fisher
Scientific has contracted with one or more recycling/disposal companies in each EU Member State
European Country, and this product should be disposed of or recycled through them. Further
information on Thermo’s compliance with this directive, the recyclers in your country and
information on Thermo products will be available at www.thermofisher.com.
4Always use the proper protective equipment (clothing, gloves, goggles, etc.)
4Always dissipate extreme cold or heat and wear protective clothing.
4Always follow good hygiene practices.
4Each individual is responsible for his or her own safety.

Thermo Scientificiv Nanopure TOC - Analytical
Preface
Do You Need Information or Assistance on
Thermo Scientific Products?
If you do, please contact us 8:00 a.m. to 6:00 p.m. (Eastern Time) at:
1-740-373-4763 Direct
1-800-438-4851 Toll Free, U.S. and Canada
1-877-213-8051 FAX
http://www.thermoscientific.com Internet Worldwide Web Home Page
Service E-Mail Address
Thermo Fisher Scientific
401 Millcreek Road, Box 649
Marietta, OH 45750
Our staff can provide information on pricing and give you quotations. We can
take your order and provide delivery information on major equipment items or make
arrangements to have your local sales representative contact you. Our products are listed on the
Internet and we can be contacted through our Internet home page.
Our staff can supply technical information about proper setup, operation or
troubleshooting of your equipment. We can fill your needs for spare or replacement parts or
provide you with on-site service. We can also provide you with a quotation on our Extended
Warranty for your Thermo Scientific products.
Whatever Thermo Scientific products you need or use, we will be happy to discuss your
applications. If you are experiencing technical problems, working together, we will help you
locate the problem and, chances are, correct it yourself...over the telephone without a service
call.
When more extensive service is necessary, we will assist you with direct factory trained
technicians or a qualified service organization for on-the-spot repair. If your service need is
covered by the warranty, we will arrange for the unit to be repaired at our expense and to your
satisfaction.
Regardless of your needs, our professional telephone technicians are available to assist you
Monday through Friday from 8:00 a.m. to 6:00 p.m. Eastern Time. Please contact us by
telephone or fax. If you wish to write, our mailing address is:
International customers, please contact your local Thermo Scientific distributor.
Sales Support
Service Support
[e-mail]

Nanopure TOC - Analytical vThermo Scientific
Table of Contents
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1
General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Choosing a Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Bench Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Other Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Install Control Panel in a Remote Location . . . . . . . . . . . . . . . . . . . .5-3
Atmospheric Drain Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Feed Water Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5
Tubing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-7
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Main Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1
Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2
Initial Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1
Initial Rinse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
Cartridge Pack Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2
System Cleaning Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-3
Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1
Automatic Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2
Dispensing Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2
Section 1
Section 2
Section 3
Section 4
Section 5
Section 6
Section 7
Section 8

vi Nanopure TOC - Analytical Thermo Scientific
User Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1
Setting the Displayed Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1
Adjusting Display Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-1
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-2
Setting the Cell Constant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-3
Selecting the Setpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-4
Use of Standby Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-4
Resetting the TOC Lamp Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-5
Resetting the Cleaning Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-5
Using the TOC Analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-6
Setting Volumetric Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-6
Change Purity Units: factory set - “MΩ-cm” . . . . . . . . . . . . . . . . . .9-7
Performing a System Flush . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-7
Setting Timed Dispensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-7
Temperature Compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-8
Auto Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-8
Unit Under Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-9
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-1
Feed Water Float or Pressure Switch . . . . . . . . . . . . . . . . . . . . . . . . .10-1
Dispense Overflow Cutoff Float . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-2
Electronic Calibration w/ N.I.S.T. Cal Module . . . . . . . . . . . . . . . .10-3
Manual/Accudispense Remote Dispensers . . . . . . . . . . . . . . . . . . . .10-4
Computer/Printer Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1
RS-232 Capture Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1
Procomm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-2
Connecting and Starting the Printer . . . . . . . . . . . . . . . . . . . . . . . .11-3
Printer Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-3
Maintenance and Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-1
Cell Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-1
System Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-2
System Depressurization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-3
Cartridge Pack Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-4
0.2 Micron Filter Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-5
TOC Lamp Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-6
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-7
Fuse Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-7
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13-1
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-1
Recommended Spares . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-1
Ordering Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-3
Flow Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-4
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-5
Table of Contents
Section 11
Section 12
Section 13
Section 14
Section 9
Section 10

Nanopure TOC - Analytical 1-1Thermo Scientific
Section 1 Safety Information
Your Thermo Scientific Barnstead Nanopure TOC - Analytical ultrapure
water system has been designed with function, reliability, and safety in
mind. It is your responsibility to install it in conformance with local
electrical codes. This manual contains important operating and safety
information. You must carefully read and understand the contents of this
manual prior to the use of this equipment. For safe operation, pay
attention to Notes, Cautions, and Warnings throughout the manual.
Water purification technology employs one or more of the following:
chemicals, electrical devices, mercury vapor lamps, steam and heated
vessels. Care should be taken when installing, operating or servicing
Barnstead products. The specific safety notes pertinent to this product are
listed below.
Warnings
To avoid electrical shock, always:
1. Use a properly grounded electrical outlet of correct voltage and current
handling capacity.
2. Do not locate the Nanopure TOC - Analytical directly over equipment
that requires electrical service. Routine maintenance of this unit may
involve water spillage and subsequent electrical shock hazard if
improperly located.
3. Replace fuses with those of the same type and rating.
4. Disconnect from the power supply prior to maintenance and servicing.

1-2 Nanopure TOC - Analytical Thermo Scientific
Section 1
Safety Information
To avoid personal injury:
1. Do not use in the presence of flammable or combustible materials;
fire or explosion may result. This device contains components which
may ignite such materials.
2. Use this device with water feed only. Sanitizing/cleaning agents must
be used in compliance with the instructions in this manual. Failure to
comply could result in explosion and personal injury.
3. Avoid splashing cleaning solutions on clothing or skin.
4. Ensure all piping connections are tight to avoid chemical leakage.
5. Ensure adequate ventilation.
6. Carefully follow manufacturer’s safety instructions on labels of
chemical containers and material safety data sheets.
7. Depressurize system prior to removing the cartridge pack.
8. Refer servicing to qualified personnel.
9. A full cartridge pack may weigh about 20 lbs.

Nanopure TOC - Analytical 2-1Thermo Scientific
Section 2 Introduction
Congratulations on your purchase of a Thermo Scientific Barnstead
Nanopure TOC - Analytical ultrapure water system. This water
purification system is designed to provide low TOC, high resistivity,
reagent grade water that exceeds ASTM Type I, ISO 3696 and CLSI-
CLRW Type I standards. It uses a four-stage deionization process
combined with a 0.2 micron filter to polish suitable feed water (distilled,
deionized, or reverse osmosis) to produce low TOC (<10 ppb) water with a
resistivity of up to 18.2 megohmcm. Water resistivity is continuously
monitored by a resistivity cell and displayed on a digital display. Actual
system TOC values, obtained by an integrated TOC analyzer, can be
concurrently displayed with the resistivity.
The electronics can be verified and calibrated utilizing a N.I.S.T. Traceable
Calibration module. See accessory ordering information.
Read the instructions carefully to ensure that you receive maximum benefit
from the Nanopure TOC - Analytical. Also, fill out and return the
enclosed warranty registration card as it will help us assure you of proper
warranty coverage.
General Usage
Do not use this product for anything other than its intended usage.

Nanopure TOC - Analytical 3-1Thermo Scientific
Section 3 General Specifications
Dimensions
13.5” W x 19.5” H x 17.0” D (34.3 x 49.5 x 43.2 cm)
Clearance Requirements
Sides - 9” (22.9 cm) minimum for servicing.
Above - 3” (7.6 cm) minimum for removal of the top cover.
Front - 4.75” (12.1 cm) minimum for opening the front door.
Feed Water Requirements
Types . . . . . . . . . . . . . . . . . . . . .RO, DI, distilled.
TOC . . . . . . . . . . . . . . . . . . . .Less than 1.0 ppm.
Turbidity . . . . . . . . . . . . . .1.0 N.T.U. maximum.
Pressure Range . . . .Gravity feed to 80 psig (5.5bar, 5.6kg/cm2) max.
Temperature Range . . . . . .4°C - 40°C (40-104°F)
TDS (CaCO3) . . . . . . . . . . . . . . . . . . . .< 70 ppm
Silica . . . . . . . . . . . . . . . . . . . . . . . . . . . . .< 1 ppm
Silt . . . . . . . . . . . . . . . . . . . . . . . . . . . . .< 5% SDI
Product Water Quality
Resistivity . . . . . . . . . . . . . . . . . . . .> 18.2 mΩ-cm
TOC . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-10 ppb
Bacteria . . . . . . . . . . . . . . . . . . . .< 0.01 CFU/mL
Flow Rate
Up to 2 L/min maximum at minimum inlet feed water pressure 10 PSIG
with a new final filter.
Volumetric Dispense
Accuracy: . . . . . . . . . . . . . . . . . . . . . . . . . . . .± 5%
Repeatability: . . . . . . . . . . . . . . . . . . . . . . . .± 3%
TOC Analyzer
Range . . . . . . . . . . . . . . . . . . . . . . . .1 to 250 ppb
Accuracy . . .±1 ppb or ±15% (whichever is greater)
Cycle Time . . . . . . . . . . . . . . . . . . . .< 3.5 minutes
Water Consumption . . . . . . . . . .< 15 ml per cycle
Min. Water Resistivity . . . . . .> 10 MΩ for specified accuracy

3-2 Nanopure TOC - Analytical Thermo Scientific
Section 3
General Specifications
Electrical Requirements
The Nanopure TOC - Analytical is equipped with 2 power cords to be
plugged into an electrical outlet of the appropriate voltage.
U.K. customers use cord, CRX100 and fuses for 240V installation.
Model D11941, D12411 . . . 100-240VAC, 100 watts, 47-63 Hz, 1 phase
Environmental Conditions
Operating: 4°C - 40°C; 20% to 80% relative humidity, non-condensing.
Installation Category II (over-voltage) in accordance with IEC 664.
Pollution Degree 2 in accordance with IEC 664.
Altitude limit: 3,500 meters.
Storage: -25°C to 65°C; 10% to 85% relative humidity.
Declaration of Conformity
We hereby declare under our sole responsibility that this product conforms
with the technical requirements of the following standards:
EMC:
EN 61000-3-2 Limits for Harmonic Current Emissions
EN 61000-3-3 Limits for Voltage Fluctuations and Flicker
EN 61326-1 Electrical Equipment for Measurement, Control, and
Laboratory Use; Part I: General Requirements
Safety:
EN 61010-1 Safety Requirements for Electrical Equipment for
Measurement, Control and Laboratory Use; Part I: General
Requirements
per the provisions of the Electromagnetic Compatibility Directive
2004/108/EC, and per the provisions of the Low Voltage Directive
2006/95/EC.
Copies of the Declaration of Conformity are available upon request.

Nanopure TOC - Analytical 4-1Thermo Scientific
Section 4 Unpacking
1. Remove the unit from its shipping container. Remove all contents
carefully. Ensure that the feed and drain tubing, cleaning cartridge,
wall bracket, accessory parts bag and power cords (see list below) are
removed from the packaging materials before discarding. Put the
Nanopure TOC - Analytical on a bench.
Cleaning Cartridge . . . . . . . . . . . . . . . . . . .CMX25
Wall Bracket (Unit) . . . . . . . . . . . . . . . .BC1190X12
Wall Bracket (Remote Display) . . . . . . .BC1190X10
Accessory Parts Bag Includes:
Feed Water Tube, 3/8” O.D. . . . . . . . . .TU1119X7
Drain Tube, 14” O.D. . . . . . . . . . . . . .TU1190X12
Display Cable . . . . . . . . . . . . . . . . . . . . . . .WHX20
Blank Display . . . . . . . . . . . . . . . . . . . .DL1190X18
Plug Adapter . . . . . . . . . . . . . . . . . . . . . . . . .CEX42
Power Cords
Also required for installation:
* Customer Supplied Fasteners to mount unit and remote display.

Nanopure TOC - Analytical 5-1Thermo Scientific
Section 5 Installation
The Nanopure TOC - Analytical features a removable control panel
display which allows the system to be mounted almost anywhere within
the laboratory. Use the wall bracket for wall mounted systems as a template
to drill mounting holes. (The Nanopure TOC - Analytical does not
include screws and fasteners for mounting.) Refer to the “General
Specifications” section for clearance requirements.
Caution Wall composition, condition and construction as well as fastener
type must be considered when mounting this unit. The mounting surface
and fasteners selected must be capable of supporting a minimum of 150
lbs.(68 kg). Inadequate support and/or fasteners may result in damage to
mounting surface and/or equipment. If you are unsure of mounting
surface composition, condition and construction or correct fasteners,
consult your building maintenance group or contractor. s
Warning Do not locate the Nanopure TOC - Analytical directly over
equipment that requires electrical service. Routine maintenance of this unit
may involve water spillage and subsequent electrical shock hazard if
improperly located. s
Do not use in the presence of flammable materials; fire or explosion
may result. This device contains components which may ignite such
materials.
Note The outlet of a gravity feed storage reservoir must be above or at
the same level as the inlet of the Nanopure TOC - Analytical. s
Choosing a Site

Other Accessories
5-2 Nanopure TOC - Analytical Thermo Scientific
Section 5
Installation
Optional accessories for this unit include a float switch, low pressure
switch, N.I.S.T. Traceable Calibration Module, standard remote dispenser,
Accudispense volumetric remote dispenser, dispense overflow cutoff float
and printer. If you purchased a float switch or low pressure switch, refer to
“User Settings’ in this manual. If you purchased a standard or
Accudispense volumetric remote dispenser, refer to their respective operator
manuals for installation instructions.
1. Place the Nanopure TOC - Analytical on a bench top that is accessible
to pretreated water, electricity and an atmospherically vented drain.
Note A bracket is available that will allow you to mount the control panel
on the bench, if bench mounting is desired, order bracket AY1367X2. s
Install the Nanopure TOC - Analytical on a wall in a convenient location
that is accessible to water, an atmospherically vented drain and electricity.
Caution Wall composition, condition and construction as well as fastener
type must be considered when mounting this unit. The mounting surface
and fasteners selected must be capable of supporting a minimum of 150
lbs.(68 kg). Inadequate support and/or fasteners may result in damage to
mounting surface and/or equipment. If you are unsure of mounting surface
composition, condition and construction or correct fasteners, consult your
building maintenance group or contractor. s
Warning Do not locate the Nanopure TOC - Analytical directly over
equipment that requires electrical service. Routine maintenance of this unit
may involve water spillage and subsequent electrical shock hazard if
improperly located. s
Note The outlet of a gravity feed storage reservoir must be above or at the
same level as the inlet of the Nanopure TOC - Analytical. s
Bench Mounting
Wall Mounting

1. Locate the wall bracket packed separately from the unit.
2. Using the wall bracket as a template, locate and drill the mounting
holes in the wall. A minimum of four (customer-supplied) fasteners
will be required — two on the top and two on the bottom.
3. Attach the wall bracket to the wall using the customer-supplied
fasteners.
4. Remove the locking screws on each side of the wall bracket.
5. Pull the two locking slides on each side of the wall bracket out as far as
they will go.
6. Hang the unit on the wall bracket by sliding the mounting pins into
the wall bracket slots.
7. Push locking slides on each side of wall bracket in as far as they will go.
8. Replace the locking screws.
For your convenience, the control panel can be removed from the unit and
mounted at a convenient location within 10 ft. (3.1 m.) of the unit.
Note The removable control panel was not designed to be repeatedly
removed from the unit, therefore, you may experience difficulty when
attempting to remove it. It is therefore recommended that the control
panel be permanently mounted in a remote location or remain intact with
the unit. s
Caution Repeated removal and replacement of the control panel from the
top cover may eventually cause it to become damaged.
Note The blank protective cover on the rear side panel display connector
should remain in place when the display is not remotely located.
To remove the control panel from the unit:
1. Turn the unit OFF and disconnect it from the power supply.
2. Slide the control panel upward about 1/4” (.64 cm) to 3/8” (.95 cm) -
(just enough to clear connector on top cover), pull forward, and
remove. (The control panel fits tightly in the unit so it may be difficult
to remove.)
Nanopure TOC - Analytical 5-3Thermo Scientific
Section 5
Installation
Wall Mounting
(continued)
Install Control Panel
in a Remote Location

5-4 Nanopure TOC - Analytical Thermo Scientific
Section 5
Installation
3. Replace the control panel with the blank panel provided with the unit
to protect the electrical connector.
4. Using the wall bracket as a template, locate and drill the mounting
holes in the wall. A minimum of two (customer-supplied) fasteners will
be required. Attach the wall bracket to the wall using the customer-
supplied fasteners.
5. Locate the 25-pin connector on the back top right of the unit. Remove
the protective black cover and store it for future use if the control panel
is returned to the top cover.
6. Locate the 10 ft. (3.1 m.) 25 pin M-F cable included with the unit;
attach the female end to the 25 pin connector on the back top right of
the unit, and the other end to the connector on the bottom of the
control panel.
7. Tighten the cable screws on each end to secure the cable to the unit
and control panel.
8. The control panel may now be mounted on the wall.
Install Control Panel
in Remote Loc. (cont.)
Blank
panel
Wall Mount
Bracket
Figure 5-2. Mounting the Control Panel Remotely

1. Locate the length of 3/8” O.D. tubing provided with the unit with a
quick disconnect insert on one end and a 3/8” (.95 cm) O.D. X 1/4”
(.64 cm) NPT tubing adapter on the other.
2. Install the tubing adapter onto your incoming water line. We
recommend a customer supplied shut off valve be installed in your feed
water line. Do not connect the feed water to your Nanopure TOC -
Analytical. You will connect the feedwater during the “Initial
Cleaning” procedure explained later in this manual.
Note The cartridge pack must be installed before connecting water line. s
3. If a pressure switch is to be used, see the “Installing a Float or Pressure
Switch” section for more information.
When the Nanopure TOC - Analytical flushes its membrane, the water
used is sent to drain through this connection. To install:
1. Locate the drain water tubing. This is the 1/4” (.64 cm) O.D. tubing
that is approximately 6 ft. (1.9 m.) long. The atmospheric drain fitting
is located on the lower left side of the Nanopure TOC - Analytical.
2. Route the other end of the drain water tubing to an atmospherically
vented drain and make a connection. Ensure there are no kinks in the
tubing and that it proceeds in a downward plane. Proceed to “Initial
Operation.”
Note To prevent leaking, push the tubing into the atmospheric drain
connection until it bottoms out. s
Nanopure TOC - Analytical 5-5Thermo Scientific
Section 5
Installation
Feed Water
Connection
Pump
Interlock
Remote 1
Remote 2
Feed
Water Inlet
Atmospheric
Drain
Accudispense
control cable
Overflow Float
Connection
Figure 5-3. Left Side View Figure 5-4. Right Side View
Atmospheric Drain
Connection
