Thermo Scientific BIOLiner Multifuge X3 User manual

Visit us online to register your warranty:
thermofisher.com/labwarranty
Thermo Scientific
BIOLiner™
Instruction Manual
50119954-e• 07/ 2020

WEEE Conformity
This product is subject to the regulations of the EU Waste Electrical & Electronic
Equipment (WEEE) Directive 2012/19/EU. It is marked by the following symbol:

Thermo Scientific 75003667 BIOLiner i
T
Chapter 1 Rotor Specifications ..............................................................................................................1-1
Technical Data ........................................................................................................1-2
Chapter 2 Accessories .............................................................................................................................2-1
Chapter 3 AutoLock™.............................................................................................................................3-1
Rotor Installation .....................................................................................................3-2
Removing the Rotor .................................................................................................3-3
Aerosol-tight Rotors .................................................................................................3-3
Chapter 4 Rotor Loading ..........................................................................................................................4-1
Before a Run ............................................................................................................4-2
Proper Loading .........................................................................................................4-2
Improper Loading ....................................................................................................4-3
Maximum Loading ...................................................................................................4-3
Cycle Counter ..........................................................................................................4-3
Chapter 5 Aerosol-tight Applications ...................................................................................................5-1
Basic Principles .........................................................................................................5-2
Fill Level ...................................................................................................................5-2
Checking the aerosol Tightness ................................................................................5-2
Table of Contents
Foreword ..................................................................................................................................iii
Scope of Supply ........................................................................................................................iii
Precautions ...............................................................................................................................iii
Autoclaving .............................................................................................................. 6-5
Service of Thermo Fisher Scientific .......................................................................... 6-5
RCF-Values .................................................................................................................A-1
RCF-Values BIOLiner bucket ..............................................................................A-1
RCF-Values Microplate Carrier ...........................................................................A-2
Chemical Compatibility Chart .......................................................................................B-1
Chapter 6 Maintenance and Care ..........................................................................................................6-1
Cleaning Intervals .....................................................................................................6-2
Cleaning ...................................................................................................................6-2
Disinfection ..............................................................................................................6-3
Decontamination .....................................................................................................6-4

Thermo Scientific 75003667 BIOLiner iii
F
Foreword
Before starting to use the rotor, read through this instruction manual carefully and follow the
instructions.
The information contained in this instruction manual is the property of Thermo Fisher Scientific; it
is forbidden to copy or pass on this information without explicit approval.
Failure to follow the instructions and safety information in this instruction manual will result in the
expiration of the seller’s warranty.
Scope of Supply
If any parts are missing, please contact the nearest Thermo Fisher Scientific representative.
Precautions
In order to ensure safe operation of the BIOLiner™, the following general safety regulations must be
followed:
•Do not use rotors which show any signs of corrosion and / or cracks. Do not touch the electronic
components of the rotor and do not make any changes to the electronic or mechanical
components.
•Use only with rotors which have been loaded properly.
•Never overload the rotor.
Article Number Quantity Check
75003602 BIOLiner™1
76003500 Rubber seal grease 1
70009824 Anti-corrosion oil 1
75003786 Bolt grease 1
50119954 Instruction Manual 1

Foreword
iv 75003667 BIOLiner Thermo Scientific
•Use only accessories which have been approved by Thermo Fisher Scientific. Exceptions to this
rule are commercially available glass or plastic centrifuge tubes, provided they have been approved
for the speed or the RCF value of the rotor.
•Please observe the safety instructions.
Please pay particular attention to the following aspects:
•Rotor installation: Check that the rotor is locked properly into place before operating the
centrifuge.
•Always balance the samples.
Maximum sample density at maximum speed: 1.2 g
cm3
-----------
This symbol refers to general hazards.
ATTENTION means that material damage could occur.
WARNING means that injuries or material damage or contamination could occur.
This symbol refers to biological hazards.
Observe the information contained in the instruction manual to keep yourself and your
environment safe.

Thermo Scientific 75003667 BIOLiner 1-1
1
Rotor Specifications
Contents
•“Technical Data” on page 1-2

1Rotor Specifications
Technical Data
1-2 75003667 BIOLiner Thermo Scientific
Technical Data
Table 1-1. 230 V, 50 / 60 Hz, Rectangular buckets 75003668
Centrifuge Multifuge X3 Multifuge X3 F Megafuge 40
Catalog # 75004500 75004530 75004503
Weight empty [kg] 7.3 7.3 7.3
Max. cycle number 55000 55000 55000
Maximum permissible load [g] 4 x 750 4 x 750 4 x 750
Maximum speed nmax [rpm] 3500 3500 3500
Maximum RCF value at nmax 2739 2739 2739
Max. / min. radius [cm] 20 / 10.5 20 / 10.5 20 / 10.5
Pitch angle [°] 90 90 90
Accel. / braking time [s] 55 / 55 55 / 55 55 / 55
Sample heating at nmax [°C] referred to
ambient temperature of 23-25 °C, running
time 120 minutes
888
Aerosol-tight*yes yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121 121
*Tested by HPA, Porton-down, UK
Centrifuge Multifuge X3R Multifuge X3 FR Megafuge 40R
Catalog # 75004515 75004536 75004518
Weight empty [kg] 7.3 7.3 7.3
Max. cycle number 55000 55000 55000
Maximum permissible load [g] 4 x 750 4 x 750 4 x 750
Maximum speed nmax [rpm] 3500 3500 3500
Maximum RCF value at nmax 2739 2739 2739
Max. / min. radius [cm] 20 / 10.5 20 / 10.5 20 / 10.5
Pitch angle [°] 90 90 90
Accel. / braking time [s] 55 / 55 55 / 55 55 / 55
Minimum temperature at nmax [°C] relating to
ambient temperature 23-25 °C
<0 <0 <0
Speed at 4 °C 3500 3500 3500
Aerosol-tight *yes yes yes
Permissible temperature range autoclavable
(cycle number) °C
121 121 121
*Tested by HPA, Porton-down, UK
