Thermo Scientific DensityPRO+ User manual

Part of Thermo Fisher Scientific
DensityPRO+
Gamma Density System with Remote Transmitter
Installation Guide
P/N 717818
Revision F

DensityPRO+
Gamma Density System with Remote Transmitter
Installation Guide
P/N 717818
Revision F

© 2011 Thermo Fisher Scientific Inc. All rights reserved.
“Microsoft” and “Windows” are either trademarks or registered trademarks of Microsoft Corporation in
the United States and/or other countries.
“HART” is a registered trademark of the HART Communication Foundation.
All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
Thermo Fisher Scientific Inc. (Thermo Fisher) makes every effort to ensure the accuracy and completeness
of this manual. However, we cannot be responsible for errors, omissions, or any loss of data as the result of
errors or omissions. Thermo Fisher reserves the right to make changes to the manual or improvements to
the product at any time without notice.
The material in this manual is proprietary and cannot be reproduced in any form without expressed
written consent from Thermo Fisher.

This page intentionally left blank.

Revision History
Revision Level Date Comments
1.0 07-2001 Initial release.
A 03-2005 Name change.
B 07-2007 Per ECO 5804.
C 03-2008 Per ECO 5835.
D 12-2008 Per ECO 5930.
E 11-2009 Per ECO 7168.
F 06-2011 Per ECO 7705.
Thermo Fisher Scientific DensityPRO+ Installation Guide v

This page intentionally left blank.

Contents
Safety Information & Guidelines ..................................................................... ix
Safety Considerations.............................................................................ix
Warnings, Cautions, & Notes................................................................ix
Chapter 1 Introduction........................................................................................................ 1-1
Associated Documentation.................................................................. 1-1
Handling & Storage .......................................................................................... 2-1
Chapter 2
ESD Procedures .................................................................................. 2-1
Unpacking, Inspection, & Storage ...................................................... 2-2
Installation ......................................................................................................... 3-1
Chapter 3
General ............................................................................................... 3-1
Licensing............................................................................................. 3-2
Guidelines........................................................................................... 3-2
General ............................................................................................ 3-2
Power Options ................................................................................. 3-3
The Transmitter.................................................................................. 3-4
Installing Transmitter Boards........................................................... 3-5
AC Power Supply............................................................................. 3-6
The Gauge Head................................................................................. 3-7
Mounting Configurations ................................................................ 3-7
Mounting Instructions ..................................................................... 3-9
Dual Chain Mount ....................................................................... 3-9
Pipe Saddle (Cradle) Mount........................................................ 3-12
Pipe Spool Mount....................................................................... 3-14
Wiring.................................................................................................................. 4-1
Chapter 4
Preparation.......................................................................................... 4-1
General Wiring Procedures ................................................................. 4-2
For Scintillation Detectors ............................................................... 4-2
For Ion Chamber Detectors ............................................................. 4-4
For the Transmitter.......................................................................... 4-5
EMC Requirement for ATEX Version of 1400S Transmitters ...... 4-5
Procedure...................................................................................... 4-6
Detector Type Selection................................................................ 4-7
Power Supply Wiring.......................................................................... 4-7
Power to the Scintillation Detector .................................................. 4-7
Thermo Fisher Scientific DensityPRO+ Installation Guide vii

Contents
viii DensityPRO+ Installation Guide Thermo Fisher Scientific
DC Power..................................................................................... 4-7
AC Power...................................................................................... 4-8
Power to the Ion Chamber Detector ................................................ 4-9
Power to the Transmitter ............................................................... 4-10
AC Power.................................................................................... 4-10
DC Power................................................................................... 4-10
Detector Signal Wiring ..................................................................... 4-11
Optional Wiring ............................................................................... 4-12
Relays............................................................................................. 4-12
Current Output ............................................................................. 4-12
Contact Closure (Switch) Inputs.................................................... 4-13
Temperature Compensation........................................................... 4-13
Flow Input ..................................................................................... 4-13
Serial Communications ..................................................................... 4-13
Optional RS485 Wiring................................................................. 4-14
RS485 Termination ....................................................................... 4-14
RS232 Wiring................................................................................ 4-14
HART Communications................................................................... 4-15
Getting Help........................................................................................................5-1
Chapter 5
Contact Information ........................................................................... 5-1
Returning Equipment for Service ........................................................ 5-1
Ordering Information .......................................................................................A-1
Appendix A
Appendix B Specifications...................................................................................................B-1
Drawings............................................................................................................ C-1
Appendix C
Adding Ferrite Clamps to 1400S Transmitter ..............................................D-1
Appendix D
Procedure........................................................................................... D-1
Index ..........................................................................................................INDEX-1

Safety Information & Guidelines
This section contains information that must be read and understood by all
persons installing, using, or maintaining this equipment.
Safety
Considerations
Failure to follow appropriate safety procedures or inappropriate use of the
equipment described in this manual can lead to equipment damage or
injury to personnel.
Any person working with or on the equipment described in this manual is
required to evaluate all functions and operations for potential safety hazards
before commencing work. Appropriate precautions must be taken as
necessary to prevent potential damage to equipment or injury to personnel.
The information in this manual is designed to aid personnel to correctly
and safely install, operate, and/or maintain the system described; however,
personnel are still responsible for considering all actions and procedures for
potential hazards or conditions that may not have been anticipated in the
written procedures. If a procedure cannot be performed safely, it must not
be performed until appropriate actions can be taken to ensure the safety
of the equipment and personnel. The procedures in this manual are not
designed to replace or supersede required or common sense safety practices.
All safety warnings listed in any documentation applicable to equipment
and parts used in or with the system described in this manual must be read
and understood prior to working on or with any part of the system.
Failure to correctly perform the instructions and procedures in this
manual or other documents pertaining to this system can result in
equipment malfunction, equipment damage, and/or injury to personnel.
W
arnings,
Cautions, &
Notes
arnings,
Cautions, &
Notes
Warnings, cautions, and notes are used throughout this manual to alert
users to potential hazards or important information. Failure to heed the
warnings and cautions in this manual can lead to injury or equipment
damage.
Warning Warnings notify users of procedures, practices, conditions, etc.
which may result in injury or death if not carefully observed or followed.
The triangular icon displayed with a warning depends on the type of hazard
(general, electrical, radiation). ▲
Thermo Fisher Scientific DensityPRO+ Installation Guide ix

Safety Information & Guidelines
Warnings, Cautions, & Notes
xDensityPRO+ Installation Guide Thermo Fisher Scientific
Caution Cautions notify users of operating procedures, practices,
conditions, etc. which may result in equipment damage if not carefully
observed or followed. ▲
Note Notes emphasize important or essential information or a statement of
company policy regarding an operating procedure, practice, condition,
etc. ▲
Tip Tips may also be used in this manual. They are suggestions or things to
consider that will help you use the instrument or this manual. ▲

Chapter 1
Introduction
Refer to the Density PRO+ User Guide (p/n 717819) for a description of
instrument functions and features, ordering information, and product
specifications.
Associated
Documentation
In addition to this guide, the following documents must be read and
understood by all persons installing, using, or maintaining this equipment:
●DensityPRO+ User Guide (p/n 717819)
●Gamma Radiation Safety (p/n 717904)
Thermo Fisher Scientific DensityPRO+ Installation Guide 1-1

This page intentionally left blank.

Chapter 2
Handling & Storage
This chapter addresses procedures for handling electrostatic discharge
(ESD) sensitive equipment, as well as procedures for unpacking, inspecting,
and storing of the system.
Caution This system is an ESD sensitive instrument. Use proper ESD
protective equipment and procedures. Failure to comply with ESD
procedures can result in circuit damage. ▲
ESD ProceduresSD Procedures The instrument contains electronic components that can be damaged from
discharges of static electricity. Ordinarily, handling the circuit boards by
their edges will not damage the circuits.
Caution Do not touch the circuit board components. ▲
Observe the following when installing, setting up, servicing,
troubleshooting, or repairing the instrument:
1. Use an antistatic bag. Most instrument subassemblies are shipped in a
special antistatic bag. When not installed, keep the assembly in the bag
as often as possible.
2. Remove ESD sensitive subassemblies only under the following
conditions:
a. When at a designated static-free workstation or when the bag is
grounded at a field site.
b. After the conductive area of the container has been neutralized.
c. After making firm contact with an antistatic mat and / or firmly
gripping a grounded individual.
3. Personnel handling ESD sensitive devices should be neutralized to a
static-free workstation by means of a grounding wrist strap that is
connected to the station or to a good grounding point at the field site.
Thermo Fisher Scientific DensityPRO+ Installation Guide 2-1

Handling & Storage
Unpacking, Inspection, & Storage
2-2 DensityPRO+ Installation Guide Thermo Fisher Scientific
4. Do not allow clothing to make contact with ESD sensitive devices.
5. Avoid touching edge connectors and components.
6. Avoid partially connecting ESD sensitive devices. These devices,
especially the power supply connector, can be damaged by floating
leads.
7. Ground test equipment.
8. Avoid static charges during troubleshooting.
Unpacking,
Inspection, &
Storage
All personnel involved in the packing, shipping, or receiving of hazardous
material must be trained in accordance with the United States Department
of Transportation (DOT) and OSHA hazardous materials regulations or in
accordance with the Canadian Nuclear Safety Commission (CNSC)
regulations.
Note Inspection, adjustment, installation, and maintenance of the
instrument must be performed by experienced personnel only. ▲
1. Upon receipt, inspect the instrument for damage that may have
occurred while in transit. If there is evidence of rough handling or
damage, file a damage claim with the transportation company
immediately. Notify Thermo Fisher and / or your sales representative as
soon as possible.
2. Carefully inspect the packing material prior to discarding it to ensure
that all equipment and instruction paperwork has been removed.
3. Use the original packing material and container for storage if necessary.
4. If storing the instrument, the storage environment should be protected,
free from extremes of temperatures and high humidity, and fall within
the environmental constraints listed in the specification appendix.

Chapter 3
Installation
Read Gamma Radiation Safety (p/n 717904) prior to installing the
equipment.
Tip Copies of the drawings referenced in this manual are provided in
Appendix C. ▲
Generaleneral The Thermo Scientific DensityPRO+ integrated gamma density system
consists of three components:
1. One of the following transmitter models:
Thermo Scientific 1400A transmitter with non-metallic enclosure
(NEMA 4X)
Thermo Scientific 1400A transmitter with cast aluminum enclosure
(NEMA 7/ NEMA 4)
Thermo Scientific 1400S transmitter with stainless steel enclosure
(NEMA 4X/IP65)
2. One of the following detector models:
Thermo Scientific 9701 or 9702 ion chamber detector
Thermo Scientific 9719B or 9720B scintillation detector
3. One of the following source head models:
Thermo Scientific 5190, 5191, 5176, 5200, 5201, 5202, 5203,
5204, or 5211
Note In this manual, the generic use of “transmitter” or “transmitters”
implies the 1400A and 1400S transmitters. The specific model name will
be used only when necessary. ▲
Note The combination of the detector and the source head is referred to as
the “gauge head”. ▲
Thermo Fisher Scientific DensityPRO+ Installation Guide 3-1

Installation
Licensing
Licensing
Warning The instrument is a nuclear device regulated by federal and / or
state authorities. You are responsible for knowing and following the
pertinent safety and regulatory requirements. Refer to Gamma Radiation
Safety (p/n 717904) for a summary of these requirements. ▲
Warning Moving or removing an installed source housing or any assembly
that includes a source housing requires a person who is specifically licensed
to install and commission Thermo Scientific source heads. ▲
In the United States, your general license permits you to own and install all
of the instrument’s components, including the source head. However, you
may not commission the instrument (remove the lock and open the source
housing shutter for the first time) without a specific license authorizing
radiation commissioning of the instrument. In Canada, you are only
allowed to remove the instrument from the shipping container if your
CNSC license has a condition authorizing mounting / dismounting of
devices. For assistance obtaining a license or commissioning /
decommissioning the instrument, contact Thermo Fisher.
Guidelines
Warning Do not install the system in any hazardous area other than those
approved. Refer to the equipment tag for the specific approvals applicable
to the configuration of your instrument. ▲
Warning Do not apply power to the instrument in any hazardous area
unless the safety ground is properly wired inside the instrument and the
cover is properly installed. ▲
Generaleneral Review the following guidelines when planning gauge installation. Also
refer to the installation layout drawing 868695 in the drawing appendix.
1. Correct power source is available. See “Power Options” later in this
chapter.
2. Operating temperature range:
a. Transmitter: -40°C to +60°C (-40°F to +140°F)
b. Scintillation or ion chamber detector: -30°C to +60°C (-20°F to
+140°F)
3-2 DensityPRO+ Installation Guide Thermo Fisher Scientific

Installation
Guidelines
3. The transmitter should be mounted so that the display is easily seen
and the keypad on the transmitter (if applicable) is easily accessible.
4. The transmitter should not be mounted near high voltage, high
current, corrosive vapors, corrosive liquids, or corrosive esters.
5. There should be enough clearance to install and service the gauge head.
Refer to the appropriate drawings for your type of gauge and mount
(Appendix C).
6. The source housing should be positioned so that the radioactive source
identification tag is visible. The source housing tag should be upright.
7. The gauge should not be mounted where process overflow or other
material can collect in the beam path. The source shutter mechanism
must be kept free of debris.
8. The maximum cable length between the transmitter and the detector
varies with the gauge of the wire, but should not exceed 5000 feet
(1525 m) for an ion chamber detector or 1000 feet (300 m) for a
scintillation detector.
Power Options 1400A/1400S transmitters
●115/230 Vac (100–240 Vac), 50/60 Hz, 12 VA
●24 Vdc (20–28 Vdc), 12 VA
9701/9702 ion chamber detector
●115/230 Vac ± 10%, 50/60 Hz, 500 VA
9719B/9720B scintillation detector
●24 Vdc ± 20%, 12 VA, at detector input
●115/230 Vac ± 15%, 50/60 Hz, 12 VA
Thermo Fisher Scientific DensityPRO+ Installation Guide 3-3

Installation
The Transmitter
The Transmitter
Warning Do not install the unit in any hazardous area other than those
approved. Refer to the equipment tag for the specific approvals applicable
to the configuration of your instrument. Follow all instructions on the
installation drawings. ▲
Warning Do not apply power to the unit in any hazardous area unless the
safety ground is properly wired inside the unit and the cover is properly
installed. ▲
Warning Use proper lifting procedures during installation to avoid
injury. ▲
Refer to the proper dimensional drawing for the transmitter mounting
dimensions:
●868212: 1400A transmitter with non-metallic enclosure (NEMA
4X)
●868214: 1400A transmitter with cast aluminum enclosure (NEMA
7/ NEMA 4)
●208-140002: 1400S transmitter with stainless steel enclosure
(NEMA 4X/IP65)
Mount the transmitter in one of the following two ways:
●With four screws: Place one screw through each of the four holes in
the transmitter enclosure’s flange and tighten.
●With four nuts, four bolts, and eight washers: Place one bolt
through each of the four holes in the transmitter enclosure’s flange,
with one washer on each side. Screw on the nuts, and tighten the
bolts.
3-4 DensityPRO+ Installation Guide Thermo Fisher Scientific
