Preface
About This Guide Welcome to the Thermo Electron MS/ETD System. The MS/ETD System is a
member of Thermo Electron family of mass spectrometer (MS) detectors.
This manual describes how to upgrade an LTQ mass spectrometer to an LTQ XL
mass spectrometer, how to connect the ETD Module to the mass spectrometer, and
how to connect the MS/ETD System (consisting of the ETD Module and the LTQ
XL MS detector) to hook-ups in your laboratory.
This manual is intended to be used by Thermo Electron Service Engineers only.
Related
Documentation
In addition to this guide, Thermo Electron provides the following documents for
the MS/ETD System as PDF files:
• MS/ETD System Preinstallation Guide
• MS/ETD System Getting Started
•MS/ETD Module Hardware Manual
• LTQ XL manual set
Help is also available from within the software.
Safety and Special
Notices
Make sure you follow the precautionary statements presented in this guide. The
safety and other special notices appear in boxes.
Safety and special notices include the following:
CAUTION Highlights laser-related hazards to human beings. It includes
information specific to the class of laser involved. Each DANGER notice is
accompanied by the international laser radiation symbol.
CAUTION Highlights hazards to humans. Each CAUTION notice is
accompanied by an appropriate CAUTION symbol.

Preface
xMS/ETD Getting Connected Guide Thermo Electron Corporation
Contacting Us There are several ways to contact Thermo Electron.
Assistance For new product updates, technical support, and ordering information, contact us
in one of the following ways:
Visit Us on the Web
www.thermo.com/finnigan
Contact Technical Support
Phone: [phone]
Fax: [phone]
[email protected]
Contact Customer Service
In the US and Canada for ordering information:
Phone: [phone]
Fax: [phone]
International contacts for ordering information:
Visit www.thermo.com/finnigan for the current listing,
CAUTION Highlights electric shock related hazards to human beings. Each
electric shock notice is accompanied by the international High Voltage symbol.
CAUTION Highlights heat-related hazards to human beings. Each Heat notice is
accompanied by the international Heat symbol.
IMPORTANT Highlights information necessary to avoid damage to software, loss
of data, invalid test results, or information critical for optimal performance of the
system.
Note Highlights information of general interest.
Note Helpful information that can make a task easier.

Preface
Thermo Electron Corporation MS/ETD Getting Connected Guide xi
Changes to the Manual
and Online Help
To suggest changes to this guide or to the online Help, use either of the following
methods:
• Fill out a reader survey online at www.thermo.com/lcms-techpubs
• Send an e-mail message to the Technical Publications Editor at
[email protected]

Thermo Electron Corporation MS/ETD Getting Connected Guide 1
Chapter 1 Making the External
Connections
This chapter explains the external connections that are made to the MS/ETD
system. External connections consist of connections to vacuum pumps, gases and
sources of electricity.
This chapter contains the following sections:
•Vacuum and Gas Connections
•Electrical Connections

1Making the External Connections
Vacuum and Gas Connections
2MS/ETD Getting Connected Guide Thermo Electron Corporation
Vacuum and Gas
Connections
This section describes how to make the vacuum and gas connections to the
MS/ETD system.
To connect the vacuum hoses and gas lines to the MS/ETD system
1. To connect the vacuum hose to the forepump port for the MS detector
a. Attach the forepump O-ring to the MS forepump port on the back of the
ETD module as shown in Figure 1.
Figure 2 shows the forepump ports on the back of the ETD module.
Figure 1. Attaching the O-ring to the forepump port for the MS detector
Figure 2. Forepump ports
MS Detector
Forepump Port
ETD Module
Forepump Port

1 Making the External Connections
Vacuum and Gas Connections
Thermo Electron Corporation MS/ETD Getting Connected Guide 3
b. Place the forepump hose clamp on the end of the vacuum hose, and then
attach the hose to the forepump port for the MS detector.
c. Tighten the hose clamp around the vacuum hose and port as shown in
Figure 3.
Figure 3. Tightening the forepump hose clamp to the forepump port of the MS
detector
2. Attach the ETD helium line to the helium port on the back of the ETD
module as shown in Figure 4.
.
Figure 4. ETD helium line attached to the helium port
Helium Line

1Making the External Connections
Vacuum and Gas Connections
4MS/ETD Getting Connected Guide Thermo Electron Corporation
3. To connect the vacuum hose to the forepump port for the ETD module
a. Attach the O-ring to the forepump port for the ETD module as shown in
Figure 5.
Figure 5. Attaching the O-ring to the forepump port for the ETD module
b. Place the forepump hose clamp for the ETD module on the end of the
hose that will attach to the port and then attach the hose to the forepump
port of the ETD module.
c. Tighten the forepump hose clamp for the ETD module around the hose
and port as shown in Figure 6.

1 Making the External Connections
Vacuum and Gas Connections
Thermo Electron Corporation MS/ETD Getting Connected Guide 5
Figure 6. Tightening the forepump hose clamp to the forepump port for the ETD
module
4. Insert the MS/ETD system nitrogen line (friction fit) into its fitting as shown
in Figure 7.
Figure 7. Insert the nitrogen line into its fitting
Nitrogen Line

1Making the External Connections
Electrical Connections
6MS/ETD Getting Connected Guide Thermo Electron Corporation
Electrical
Connections
This section describes how to make the electrical connections to the MS/ETD
system. Do not plug the electrical cords into their wall outlets until you read the
instructions in Chapter 2, “Powering Up.”
To make electrical connections to the MS/ETD System
1. Ensure that the power cords for the ETD module and MS detector are not
connected to line power.
2. Connect the forepump for the ETD module to its electrical cord as shown in
Figure 8.
Figure 8. ETD forepump electrical connection
3. Plug the forepump electrical cord into the Forepump receptacle on the ETD
module power panel as shown in Figure 9. The Main Power and Service Mode
switches for the MS detector must be in the Off position. The ETD module
power and service switches can be in the On and Operating Mode positions
respectively.
CAUTION Be sure that the forepump electrical switch is in the Off position
before you plug it in.
CAUTION Power to the ETD module is controlled by the Main Power switch
on the Power Entry Module of the MS detector. Be sure that the Main Power
and Service Mode switches on the MS detector are in the Off position before
connecting power cords to the ETD module and the MS detector. See
Figure 10.

1 Making the External Connections
Electrical Connections
Thermo Electron Corporation MS/ETD Getting Connected Guide 7
Figure 9. ETD power cords plugged in to the ETD module Power Panel
4. Plug the power cord into the Power In receptacle on the Power Entry Module
of the ETD module (see Figure 9).
Service Switch
Power Switch
Forepump
Receptacle Power
Receptacle
CAUTION Be sure that the MS Main Power and Service Mode switches are in
their Off positions before connecting power cords to the MS detector.

1Making the External Connections
Electrical Connections
8MS/ETD Getting Connected Guide Thermo Electron Corporation
5. Ensure that the Main Power and Service Mode switches for the MS detector
are in the Off position, and then plug the power cords from the two forepumps
into the Mechanical Pumps/Accessory receptacles on the Power Entry Module
of the MS detector (see Figure 10 and Figure 11).
Figure 10. Main Power switch of the MS detector in the Off position and the power
cords are plugged in to their receptacles on the Power Entry Module
Figure 11. Service Mode switch for the MS detector in the Off position
The system is ready to be powered up as discussed in Chapter 2, “Powering Up.”
