Thermon Terminator DP/FAK-2 Reference guide

Terminator DP/FAK-2 and FAK-2L
Elbow Splice Kit for
Electrically Heated
TubeTrace® Bundles
INSTALLATION PROCEDURES

2
Tools Required
PETK Power and End Terminaon Kits (per heater)
PETK-1D for BSX, RSX, VSX-HT
PETK-2D for KSX, HTSX
PETK-3D for FP, HPT
Required: Order Separately for each heater to be fabricated
Dimensions
A
mm (inch)
B
mm (inch)
C
mm (inch)
Terminator DP/
FAK-2 187 mm (7-3/8”) 277 mm (11-7/8”) 187 mm (7-3/8”)
Terminator DP/
FAK-2L 328 mm (12-7/8”) 321 mm (12-5/8”) 328 mm (12-7/8”)
C
B
A
The following installaon procedures are suggested guidelines
for the installaon of the Terminator DP/FAK-2 and FAK-2L Kit.
Receiving, Storing and Handling
1. Inspect materials for damage incurred during shipping.
2. Report damages to the carrier for selement.
3. Idenfy parts against the packing list to ensure the proper
type and quanty has been received.
4. Store in a dry locaon.
Terminator DP/FAK-2 and FAK-2L
8
7
Terminator DP/FAK-2 and 2L Kit Contents
Item Quanty Descripon
1 1
Expediter Assembly: Flat Mount Base, Grommet,
Threaded Grommet Compressor, and Support Cap
with O-Ring
2 1 Juncon Box Lid
3 1 Juncon Box Base with O-Ring
4 1 Nut
5 1 Terminal Blocks with DIN Rail (Refer to terminal
specicaons for maximum allowable wire size)
6 1 Juncon Box Cord
7 1 90° Elbow Splice Cover (Top)
8 1 90° Elbow Splice Cover (Boom)
9 1 Heat Reecve Tape
10 2 (FAK-2)
3 (FAK-2L) RTV Sealant Tube
11 1 Glass Fiber Tape
12 1 Silicone Gasket
13 1 Self-Vulcanizing Tape
1 2 4
3 6
5
9 10
11 12
13

3
2. Trim tubing to within 38 mm (1-1/2”) of the end
of the insulaon. If self regulang heat trace
proceed to step 3. For Zone-type heat trace
connue with idencaon of bus connecon
on step 2a.
1. Remove outer jacket and insulaon from tubing
bundle approximately 457 mm (18”) from end
of the tubing bundle.
457 mm
(18”)
Tubing
Bundle
TubeTrace
Heat Tracing
Heat Tracing
Trim Tubing
457 mm
(18”) Tubing
2a. Strip back bundle insulaon 38 mm (1 1/2”) to
76 mm (3”) beyond bus connecon indentaon
of each heat trace. If bus connecon indentaon
is less than 305 mm (12”)- 381 mm (15”) from
end of the heat tracing, proceed stripping the
bundle insulaon to the next indentaon.
38 mm
(1 1/2”)
Bus Connecon
Indentaons
Heat Tracing
305 mm-381 mm
(12”- 15”)
Heat Reecve
Tape
Tubing
Glass Fiber
Tape
4. Wrap tube and heat trace with 1 pass of
reecve tape (25% overlap), then wrap with 3
passes of glass ber tape (50% overlap), or unl
ber tape is equal to original bundle insulaon
thickness.
3. Make 90˚ elbow union connections (fitting
provided by others). Test ng for leaks before
proceeding.
90˚ Elbow Union Fing
(Provided by Others)
Terminator DP Cercaons/Approvals
The Terminator DP/FAK-2 and FAK-2L In-Line Splice Kit is designed
to make a waterproof seal over the end of TubeTrace at the splice
connecons. Review instrucons prior to installaon. Kit will make
one splice connecon (tube ngs not included). See separate
instrucons for details on splicing heat tracing.
IP66 NEMA/Type 4X -60°C ≤ Ta ≤ +55°C
Ordinary & Hazardous Locaons
Class I, Division 2, Groups A, B, C, & D, Zone 2 IIC
Class II, Division 2, Groups F & G, Class III
Listed Heat Tracing System 137M
Installaon Precauons
• To minimize the potenal for arcing and ground-fault protecon.
The Naonal Electrical Code (NEC) and Canadian Electrical Code
(CEC) require ground-fault protecon of equipment for each
branch circuit supplying electric heat tracing.
• Installaon must comply with Thermon requirements and
be installed in accordance with the NEC, CEC, or any other
applicable naonal and local codes.
• Component approvals and performance rangs are based on
the use of Thermon specied parts only. User supplied power
connecon ngs must be listed or cered for intended use.
• De-energize all power sources before opening enclosure.
• Keep ends of heang cable and kit components dry before and
during installaon.
• Individuals installing these products are responsible for
complying with all applicable safety and health guidelines.
Proper personal protecve equipment, or PPE, should be
ulized during installaon. Contact Thermon if you have any
addional quesons.
5. Complete with additional passes of heat
reecve tape.
Heat Reecve
Tape
CAUTION (Found on TubeTrace SE/ME bundles)
Do not cut or damage the heat
trace or sampling tube.
Self-Regulang
Heat Tracing
Zone Type
Heat Tracing
INSTALLATION PROCEDURES

4
12. For power connection applications: Use
dimple molded into side of juncon box base
to locate center hole, drill for user supplied
power connecon ng per manufacture’s
recommendaons.
13. Mount juncon box on expediter making sure
to align slots to properly orient juncon box
base.
Dimple for Center Line
Drilled thru (1) Wall
14. Install quick mount terminal blocks twist to
posion and ghten screws.
6. Cut splice cover top and splice cover boom to
match outside diameter of tubing bundle.
7. Mount expediter base with o-ring to splice
cover boom using (3) M5 mounng screws
and lock washers. Punch out weep hole.
O-Ring
Splice Cover
Boom
Expediter Base
Weep
Hole
9. Assemble splice cover top, tubing bundle, and
splice cover boom together as shown Snap
together rmly. Inspect ends of tubing splice
cover for snug t. Apply addional RTV sealant
where needed.
Align Slot
Terminal Blocks
(Typical)
Terminator DP/FAK-2 and FAK-2L
Cut and Remove
Ends to Fit
TubeTrace
Tubing Bundle
Field Drilled
(By Others)
8. Install the Silicone Gasket (cut o excess). Apply
RTV Sealant to both halves.
RTV
Sealant
Splice Cover Top
RTV Silicone
Gasket
Splice Cover
Boom
10. Apply self-vulcanizing tape around bundle jacket
and work up over FAK ends.
11. Terminate heat tracing with appropriate PETK
termination kit. Refer to PETK installation
instrucons (purchased separately) for details
not addressed here.
Power Connecon
Boot
Ground Braid
Heat Tracing
Conduit and Wire (By Others
For Power Connecon Applicaons)

Thermon • 100 Thermon Dr • PO Box 609 San Marcos, TX 78667-0609 • Phone: [phone] • 1-800-820-4328
For the Thermon oce nearest you visit us at . . . www.thermon.com
© Thermon, Inc. • Printed in U.S.A. • Informaon subject to change.
15. Complete system wiring between fabricated
heat tracing and power supply wiring. See
wiring diagram.
16. Install juncon box lid and twist hand ght.
Insert screwdriver into ratchet slot located
on side of juncon box base to ghten. Use
screwdriver ratchet on juncon box lid. Lid will
rotate 30°.
30°
17. Lid latch mechanism fully engaged. To remove
lid, repeat step 15 but in opposite direcon.
18. Completed Terminator DP/FAK-2/2L power
assembly for Electrically Heated TubeTrace
Bundles. (Installaon shown is to feed power
in the middle of a TubeTrace bundle. Many
installaons will be near the end of a TubeTrace
bundle.)
Tubing Bundle
Juncon Box Juncon Box
Lid
Form PN50059-1218
Heat Trace #1
Heat Trace #2
Terminal Block
In-Line Splice Power Connecon (2 Heat Tracers)
Heat Trace #1
Power Supply
Terminal Block
Heat Trace #2
Power Wiring &
Conduit By Others
