Thermon Terminator ZP Reference guide

For Power Connection, In-Line Splice Connection,
T-Splice Connection, or End Termination Applications
Terminator
TM ZP
Power Connection Kit
INSTALLATION PROCEDURES

2
IP66/Type 4X -60°C ≤Ta ≤+55°C
Listed Heat Tracing Cable System 137M
Ordinary & Hazardous Locations
Class I, Division 2, Groups A, B, C, & D
Class II, Division 2, Groups F & G, Class III
Class I, Zone 1, AEx eb IIC T4-T6
09.2238691,-G,-S, Ex e IIC T4-T6
Kit Contents . . .
Tools Required . . .
Receiving, Storing and Handling . . .
1. Inspect materials for damage incurred during shipping.
2. Report damages to the carrier for settlement.
3. Identify parts against the packing list to ensure the proper
type and quantity has been received.
4. Store in a dry location.
Dimensions . . .
Certifications/Approvals . . .
Installation Precautions . . .
• To minimize the potential for arcing and fire caused by product
damage or improper installation use ground-fault protection.
The National Electrical Code (NEC) and Canadian Electrical Code
(CEC) require ground-fault protection of equipment for each
branch circuit supplying electric heat tracing.
• Installation must comply with Thermon requirements and be
installed in accordance with the NEC, CEC, or any other applicable
national and local codes.
• Component approvals and performance ratings are based on
the use of Thermon specified parts only. User supplied power
connection fittings must be listed or certified for intended use.
• Avoid electrostatic charge. Clean only with a damp cloth.
• De-energize all power sources before opening enclosure.
• Keep ends of heating cable and kit components dry before and
during installation.
• Individuals installing these products are responsible for complying
with all applicable safety and health guidelines. Proper personal
protective equipment, or PPE, should be utilized during installation.
Contact Thermon if you have any additional questions.
TerminatorTM ZP INSTALLATION PROCEDURES
Item Quantity Description
1 1
Expediter Assembly
Support Cap with O-Ring
Threaded Grommet Compressor
Grommet
Support Base with O-Ring
2 1 Junction Box Lid
3 1 Junction Box Base with O-Ring
4 1 Nut
5 1 Banding
6 1 Banding Guide
7 1
Terminal Blocks with DIN Rail
(Refer to terminal specifications for maximum
allowable wire size)
8 1 Junction Box Cord
12
6
4
3
8
5
7
Order Separately . . .
PETK Power and End Termination Kits (per cable)
PETK-1 for BSX, RSX, VSX
PETK-2 for KSX, HTSX
PETK-3 for HPT, FP
Item Quantity Description
1 1 RTV Tube
2 1 Power Connection Boot
3 1 End Cap
4 1 Tape Strip 6" (PETK-3 only)
5 1 End Termination Caution Label
6 1 GRW-G Grommet (PETK-3 only)
7 1 Ground Sleeve
1
2 64
3 5
7
FMG 10.0022X Ex eb IIC T4-T6, Ex tb IIIC T135°C-T85°C
1725 II 2 GD Ex eb IIC T4-T6, Ex tb IIIC T135°C-T85°C FM 10ATEX0058X

3
TerminatorTM ZP INSTALLATION PROCEDURES
1. Locate bus connection (HPT and FP only) and
cable as shown. Cut end of cable at angle to aid
in piercing grommet. Leave additional cable for
expansion loop. See page 5 for multiple cable
installation tips.
4. Insert banding guide into expediter and snap into
place.
2. Insert cable into expediter. If mounted on
bottom or side of pipe, punch out weep hole.
Note: For HPT and FP cable, exchange grommet
in Terminator with GRW-G provided in PETK-3.
3. Slide expediter toward pipe and route cable
through support base entry.
7. Terminate cable with appropriate PETK termination
kit. Refer to PETK installation instructions.
8. Push excess cable back through expediter. Tighten
cap securely. Tape cable expansion loop to pipe.
5. Mount expediter to pipe using pipe band. Do not
band over cable.
6. Cut off end of cable.
9. For power connection applications: Use dimple
molded into side of junction box base to
locate center of hole, drill for user supplied
power connection fittings per manufacturer’s
recommendations.
HPT and FP Only
Bus
Connection

4
10. Mount junction box base on expediter. Make sure
to align slots to properly orient junction box base.
Tighten nut securely.
11. For power connection applications: Install power
connection fittings (user supplied) and pull in
power and ground wires.
12. Install quick mount terminal blocks.
13. Complete system wiring. Refer to typical wiring
details on page 5. Tighten terminal screws to a
minimum torque value of 1.5 Nm (13.3 lb-in).
15. Use screwdriver to ratchet on junction box lid. Lid
will rotate 30 degrees.
16. Lid latch mechanism fully engaged. To remove
lid, repeat steps 14 and 15 but in the opposite
direction.
TerminatorTM ZP INSTALLATION PROCEDURES
14. Install junction box lid and twist hand tight. Insert
screwdriver into ratchet slots located on side of
junction box base.

5
Power Connection (1 to 3 Cables). For 3 cable
power connections, additional terminal blocks will be
required when using 10mm2(#8 AWG) power supply
wiring.
In-Line Splice and T-Splice End Termination (1 to 2 Heating Cables) Remove
jumpers for 2 cable terminations.
Typical Wiring Details
Locate bus connection (HPT and FP only) and cable
as shown. Cut end of cable at angle to aid in piercing
grommet. Leave additional cable for expansion loop.
Two Cable Layout Tips
Insert two cables into expediter.
Note: For HPT and FP cable, exchange grommet
in Terminator with GRW-G provided in PETK-3.
Three Cable Layout Tips
Locate bus connection (HPT and FP only) and cable
as shown. Cut end of cable at angle to aid in piercing
grommet. Leave additional cable for expansion loop.
Insert three cables into expediter.
Note: For HPT and FP cable, exchange grommet
in Terminator with GRW-G provided in PETK-3.
Mount expediter with three cables. Do not band over cable.
TerminatorTM ZP INSTALLATION PROCEDURES
