Thermopatch NL-15 R/SQR MAMMOTH User manual

NL-15 R/SQR MAMMOTH
thermopatch.com
V. 3.0 ENG
Jan2014
thermopatch.com
User manual
CATTENTION!
All persons involved in installation, commissioning,
operation, maintenance and repair of this product
should be made available to these instructions.
V. 4.0 ENG
Sep2018

thermopatch.com
V. 3.0 ENG
Jan2014
2
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
Copyrights © 2017, Thermopatch bv, Almere, The Netherlands.
No part of this publication may be reproduced by any means
without the prior written permission of Thermopatch bv,
The Netherlands.
Thermopatch and the Thermopatch logo, Thermoseal and
Thermocrest are registered trademarks of Thermopatch.

thermopatch.com
V. 3.0 ENG
Jan2014
3
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
Introduction Dear User,
Welcome to the growing group of Thermopatch users. Your
purchase has been manufactured with the utmost care
to ensure that you benet as long as possible from your
Thermopatch product.
The products by Thermopatch are designed with special
attention to your convenience. Should you discover any fault
or damage upon receipt of this product, please contact your
local Thermopatch vendor.
The manual has been prepared in accordance with NEN 5509
and in conformity with the Machinery Directive 2006/42/EC.
This user manual is intended not only for all users of the
machine, but also for those who install and maintain the NL-
15 R / SQR. The goal is to familiarize you with the operation,
to provide for safe working instructions and guidelines for
periodical maintenance.
This manual applies to machines NL-15 R / SQR from
serialnumbers for type R: M14-03-0420 and for type SQR:
SQR13-0456.
CATTENTION!
In order to make safe and optimal use of the NL-15 R / SQR, it is important to take note of
and understand the contents of this manual.

thermopatch.com
V. 3.0 ENG
Jan2014
4
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
Contents
Copyrights 2
Introduction 3
Contents 4
DECLARATION OF CONFORMITY 5
1. General description 6
1.1 Delivery 6
1.2 Conditions of warranty 6
2. Intended use 7
3. Technical specications 8
3.1 Specications of the NL-15 R / SQR 8
4. Overview of safety measures and warnings 9
4.1 Safety 9
5. Transport and storage 11
5.1 Transport 11
5.2 Storage 11
6. Operating instruction 12
6.1 Operating the NL-15 R / SQR 12
6.2 Automatic mode 12
6.3 Safety Frame 12
6.4 The control panel 13
6.5 Change settings 14
6.5.1 Temperature settings 14
6.5.2 Pressure settings 16
6.5.3 Time settings 16
6.5.4 Power save 16
6.5.5 Dierent seal times left and right (optional) 16
6.5.6 Second sealing cycle 16
6.5.7 Interrupting the sealing cycle 17
6.5.8 Messages in the display 17
6.5.10 Preprogrammed settings 18
7. Assembly and installation 19
7.1 Assembly 19
7.2 Installation 19
8. Maintenance instructions 20
8.1 Daily maintenance 20
8.2 Periodic maintenance 20
8.3 Parts for regular replacement for maintenance: 20
9. Technical annexes 21
Parts list 01 21
Drawing 01 22
Parts list 02 23
Drawing 02 24
Parts list 03 for NL-15 R 25
Drawing 03 for NL-15 R 26
Parts list 03 for NL-15 SQR 27
Drawing 03 for NL-15 SQR 28
Drawing 03A for NL-15 and NL-15 SQR, SAFETY FRAME UPGRADE February 2017 29
Parts list 04 30
Drawing 04 31
Parts list 05 32
Drawing 05 33
Parts list 06 for pneumatic parts 34
Drawing 06 pneumatic diagram with parts 35
Drawing 07 Electrical wiring diagram 36
10. Faults 37
11. End of life 38
12. Disclaimer 38

thermopatch.com
V. 3.0 ENG
Jan2014
5
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
DECLARATION OF CONFORMITY
We,
Thermopatch B.V.
Draaibrugweg 14
1332 Almere
The Netherlands
herewith declare, on our own responsibility, that the
machinery:
Thermopatch Thermoseal NL-15 R / SQR,
which this declaration refers to, is in accordance with the
conditions of the following Directive(s):
2006/42/EG (Machinery directive)
2004/108/EG (EMC directive)
Based on DEKRA IEC 610101-1 test report nr. 2166589.60-
PEP
The Netherlands, Almere, 21-01-2014
Jan Bausch,
Director

thermopatch.com
V. 3.0 ENG
Jan2014
6
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
1. General description
The pneumatic Mammoth is a practical and universal heat
seal press with two press pads for optimal use. Therefore,
you do not have to wait during the press cycle, but can
prepare the next article.
Textile labels, company emblems, repair patches, transfers,
in short all Thermopatch materials for marking and repair are
easily and permanently pressed on all types of fabric. The
machine is hand operated but can also be set to automatic
operation. In that case, the press cycle is performed
automatically when the swivelling arm comes in the end
position.
1.1 Delivery
The NL-15 R / SQR is mounted onto a pallet and xed with
straps, covered with a cardboard box.
The following articles can be found at:
• NL-15 R / SQR heat seal machine
• Power cord
• 6 mm air hose
• Quick installation guide
• quality checklist
• Manual on CD-ROM
• CE Declaration of Conformity
If one of these articles should be missing or faulty, please
contact your Thermopatch supplier.
1.2 Conditions of warranty
Thermopatch points to its warranty and product liability
conditions as laid down in our conditions of sales. These can
be obtained at your Thermopatch supplier.

thermopatch.com
V. 3.0 ENG
Jan2014
7
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
2. Intended useThe pneumatic NL-15 R / SQR is a heat seal machine that
is intended for the application of textile labelling, repair
patches and transfers. In short, all Thermopatch marking and
mending materials can be applied with the NL-15 R / SQR.
WARNING!
Any use other than described above can be dangerous and cause damage and thus qualies
as ‘misuse’ which excludes Thermopatch bv from any liability.

thermopatch.com
V. 3.0 ENG
Jan2014
8
NL-15 SQRNL-15 R
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
3. Technical specications
3.1 Specifications of the NL-15 R / SQR
NL-15 R
Power 800 Watts
Power supply 230 Volt
Operating temperature 204 °C
Temperature range 25-210 °C
Press Time range 1-60 sec.
Discharge pressure range 3-6 bar
Machine height (open) 470 mm
Machine width 540 mm
Machine depth 470 mm
Gross weight, including packaging 85 kg
Net weight 65 kg
Size sealing pads, round 160 mm
Fuses, slow 4.0 Ampere
A-weighted noise level <70 dB (A)
NL-15 SQR
Power 800 Watts
Power supply 230 Volt
Operating temperature 204 °C
Temperature range 25-210 °C
Press Time range 1-60 sec.
Discharge pressure range 3-6 bar
Machine height (open) 470 mm
Machine width 540 mm
Machine depth 470 mm
Gross weight, including packaging 85 kg
Net weight 65 kg
Size sealing pads, square 140 x 140 mm
Fuses, slow 4.0 Ampere
A-weighted noise level <70 dB (A)

thermopatch.com
V. 3.0 ENG
Jan2014
9
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
4. Overview of safety measures
and warnings
4.1 Safety
The NL-15 R / SQR has several features to ensure your
safety.
The safety frame
The press plate of the NL-15 R / SQR is provided with a
safety frame. When this is touched or rmly moved, the heat
sealing cycle is automatically interrupted.
To resume work, turn the machine o and on again.
The emergency stop button
In addition to the mandatory safety measures in conformity
with the Machinery Directive, from serial numbers:
Model R: M14-03-0420 and model SQR: SQR13-0456,
an emergency stop button has been provided to be able to
intervene even faster in case of unforeseen events.
The safety thermostat
The safety thermostat on the heating element will interrupt
the power supply when the temperature rises above 270°C.
CATTENTION!
Make sure you are informed about the contents of this manual before starting to work with
the NL-15 R / SQR. This ensures an optimal and safe use of the machine.
CATTENTION!
Always turn the power o (unplug it) when you need to carry out maintenance work or when
cleaning the machine.
CATTENTION!
In case of emergency, press the emergency stop button!
CATTENTION!
Take care that there is enough space around the machine. Cables and connections must not
get pinched. Although the heat radiation of the press is low, there should be
enough space for cooling down.
CATTENTION!
Avoid contact with the press element and the heating
element.
CATTENTION!
Pull the fabrics tight around the press pad and ensure that your hands are away from
the sealing pad before operating the machine.

thermopatch.com
V. 3.0 ENG
Jan2014
10
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
Warning symbols
The following warning symbols have been mounted onto the
machine for added safety:
WARNING!
Hot surface
WARNING!
Electric tension
WARNING!
Pinching hazard

thermopatch.com
V. 3.0 ENG
Jan2014
11
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
5. Transport and storage
5.1 Transport
When the machine needs to be moved, Thermopatch advises
to use the original packaging. The machine has to be lifted by
the screw that is xing the swiveling arm and the handle on
the front of the machine.
5.2 Storage
When the machine needs to be stored, Thermopatch advises
to use the original packaging. The machine should be stored
on a pallet, o the oor, in dry conditions.

thermopatch.com
V. 3.0 ENG
Jan2014
12
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
6. Operating instruction
6.1 Operating the NL-15 R / SQR
You can work with the Mammoth when the machine is
connected to the mains.
• Set the airpressure
• See paragraph 6.8 for information regarding the pressure
settings required for the NL-15 R / SQR.
• Place the plug in the socket and turn on the NL-15 R /
SQR with the ON - OFF switch mounted on the back of the
machine.
• Wait until the factory set temperature is reached.
This will take approx 1 minute. The standard operating
temperature has been set to 204 °C.
The press can be operated now.
6.2 Automatic mode
You can use the NL-15 R / SQR in Auto mode by pressing the
AUTO -button The press cycle will automatically start when
the swivel arm is positioned above the press plate.The robot
symbol ( ) is shown in the display.
6.3 Safety Frame
The upper platen of the press head of the NL-15 R / SQR is
enclosed by a safety frame. This frame will react if it is moved
or touched and will interrupt the sealing cycle immediately.
Switch the machine o and on again to resume work.
CATTENTION!
The automatic mode ( ) should be switched o, when you wish to change the set values
for temperature, pressure and press time.
When the automatic mode is activated, the key board will not respond.

thermopatch.com
V. 3.0 ENG
Jan2014
13
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
6.4 The control panel
NL-15 R / SQR control panel
The pressure, temperature and time are shown on the
display.
The minimum, maximum and default values for temperature
and pressure have been set by the manufacturer. The
following icons are present on the display:
KEYS Temperature setting
Pressure setting
Time setting
+Plus (higher)
-Minus (lower)
AUTO Automatic mode on / o
SYMBOLS ON
SCREEN Automatic mode on
Power saving mode on
Next to time indicator
Second sealing cycle active
Interruption of the safety
circuit

thermopatch.com
V. 3.0 ENG
Jan2014
14
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
6.5 Change settings
6.5.1 Temperature settings
The default operating temperature of 204 °C has been set by
the manufacturer. In case you want to adjust the operating
temperature above or below the default temperature range,
please contact the service department of your supplier.
The default temperature range is: minimum 25 °C, maximum
210 °C.
Temperature change
You can change the temperature in steps of 1 degree by
pushing the -button 1 x pushing the + and the -.
You change from Celsius to Fahrenheit and vice versa by
pushing the -button for 3 seconds.
CATTENTION!
The NL-15-R / SQR has maximum a tolerance of 10 ° C above or below the set
temperature.
If the limit of + or - of 10 ° C is exceeded, the machine cannot be operated.
CATTENTION!
The automatic mode ( ) should be switched o, when you wish to change the set values
for temperature, pressure and press time.
When the automatic mode is activated, the key board will not respond.

thermopatch.com
V. 3.0 ENG
Jan2014
15
thermopatch.com
7
:K\FKHFNWKHWHPSHUDWXUH"
For optimal sealing results, the temperature, pressure and
WLPHPXVWEHVHWDFFRUGLQJWRWKHVSHFL¿FDWLRQVWKDWFRPH
with the product to be applied.
When one or more parameters are not set correctly, the label,
patch, emblem or transfer will not perform as designed and
this will bring unneeded cost.
The Temperature Indicator Labels are available
in four ranges:
• 93 °C – 132 °C • 121 °C – 160 °C
• 143 °C – 182 °C • 188 °C – 232 °C
40 labels per bag.
With both ranges the temperature is showed over eight
intervals, this gives a very accurate readout of the actual
interplaten temperature.
+RZLWZRUNV"
For optimal results place a temperature indication label with
the yellow side upwards on the lower platen of the heat seal
press and close the press for 7 seconds.
When a temperature is reached within the range of the labels,
depending on the temperature, you will see one or more
ER[HVFRORUFKDQJHGWREODFN7KHER[FORVHVWWRWKHDFWXDO
temperature changes to grey.
$VVRUWPHQW
Temperature Indication Labels are available in 4 temperature
ranges.
3DFNLQJ
Temperature Indication Labels come in a paper bag with 40
measuring strips.
6WRUDJHLQVWUXFWLRQV
Temperature Indication Labels must be stored in a cool, dry
& dark place. It is obvious that the labels must be stored at
lower temperature than the range they are for.
7HPSHUDWXUH,QGLFDWLRQ/DEHOV
5DQJH
&±&
5DQJH
&±&
5DQJH
&±&
5DQJH
&±&
([DPSOHRIXQXVHGODEHO
VKRZLQJWHPSHUDWXUH
Thermopatch
°C
°
C
93
99
104
110
116
121
127
132
Thermopatch
°C
°
C
121
127
132
138
143
149
154
160
Thermopatch
°C
°
C
143
149
154
160
166
171
177
182
Thermopatch
°C
°
C
188
193
199
204
210
216
224
232
Thermopatch
°C
°
C
143
149
154
160
166
171
177
182
Thermopatch
°C
°
C
188
193
199
204
210
216
224
232
([DPSOHRIXVHGODEHO
VKRZLQJWHPSHUDWXUH
Temperature
ranging between
>149 °C and
<154 °C
Temperature
ranging between
>204 °C and
<210 °C
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
Temperature check
The temperature is displayed digitally by pressing one key. An additional check of the
temperature between the press plates can be performed by means of temperature indication
labels.
• To check the temperature, do the following:
• Let the machine heat up for about 1 minute.
• Set the time to 12 seconds and close the machine.
• After opening the machine again, put the Thermolabel on the press pad and close the
machine again.
• 4.Take the label away immediately after opening the machine.

thermopatch.com
V. 3.0 ENG
Jan2014
16
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
6.5.2 Pressure settings
The working pressure of the machine has been set to 5 bar.
The pressure regulator on the machine only inuences the
pressure on the press cylinder. The opening and closing of the
NL-15 R / SQR is done with the pressure that is supplied by
the machine.
The NL-15 R / SQR has a pressure safety range; this means
that a maximum pressure of about 6 Bar and a minimum
pressure of 4 Bar is allowed. When the air pressure exceeds
these limits, the machine cannot be operated.
You can set the pressure with the control panel.
Change pressure
You set the minimum pressure range in steps of 0,1 Bar by
pushing the -button and then the + or - button once.
You set the maximum pressure range in steps of 0,1 Bar by
pushing the -button and then push the + or – button
twice (2x).
The standard working pressure for textile repair and marking
is 5 Bar.
6.5.3 Time settings
The default sealing time setting of the NL-15 R / SQR is 12
seconds. Adjusting the settings can be done with the control
panel.
Change time
Push the -button once. Change the time setting in steps of
1 second by pushing the - or + button. The range is 1 - 60
seconds.
6.5.4 Power save
When you want the machine to switch to a lower energy level
when you are not working, you can use the power save
mode.
Push the -button twice.
Set the power save mode in steps of 1 minute by pushing the
+ or – button.
Power save ranges from 1-60 minutes. If it is set to 0 the
power save mode is not active and the machine will be
heated continuously.
6.5.5 Dierent seal times left and right (optional)
To enable sealing 2 dierent products in a short time, the
seal time for the left and the right sealing pad can be set on a
dierent parameter
Push the -button three times. Change the time for the
left sealing pad in steps of 1 second by pushing the + or –
button.
If the time is set on 0 seconds the seal time left and right are
equal.

thermopatch.com
V. 3.0 ENG
Jan2014
17
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
6.5.6 Second sealing cycle
In some cases it is desirable to seal a second time.
Push the AUTO button during three seconds. A second seal
cycle of 2 seconds takes place.
You can switch this option o by pushing the button for
three seconds once more.
CATTENTION!
If the rst sealing cycle has been interrupted, the second cycle will not start.
CATTENTION!
If the rst sealing cycle has been interrupted, the second cycle will not start.
6.5.7 Interrupting the sealing cycle
There are various means to interrupt the sealing cycle of the
machine. You can interrupt the operation by:
• 1. Pushing a button of the display randomly.
• 2. Turning the on/o switch on the front.
• 3. Stir the safety bar.
• 4. Push the emergency stop button, pull out and switch
on the machine again.
6.5.8 Messages in the display
A description is given below of the messages in the display
which appear immediately after turning on the machine.
Further, we will discuss some failure codes that can be
displayed on the control panel display.
• During heating up of the machine the temperature,
pressure and time are displayed.
• During the press cycle the press time is displayed from
0 to the programmed sealing time
• Automatic mode ON/OFF is displayed with the Robot-
icon( ).
• is displayed during POWER SAVE MODE.
6.5.9 Error codes
There are 6 dierent failure codes that can be displayed;
contact your Thermopatch supplier.
01 Sensor defective or broken sensor cable
02 Sensor short cut
03 Element defective or broken element cable
04 Pressure set too low
05 Pressure set too high
06 Safety switch interrupted or defective

thermopatch.com
V. 3.0 ENG
Jan2014
18
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
6.5.10 Preprogrammed settings
The setting of the heat sealing time and temperature is dependant on the labour that has to
be executed and the materials to be marked. These can be adjusted by the operator.
By pressing the “AUTO” button the NL-15 R/SQR can be entered into () and taken out of
() operational mode. Only when the NL-15 R/SQR is taken out of oprational mode ()
parameters can be altered and presets can be chosen (nr. 1 - 5) by pressing the button.
The NL-15 R/SQR has been provided with following 5 preprogrammed presets:
Preset 1, for Thermopatch label products for high temperature applications (up to 95 °C
washing):
• Sealing time: 14 seconds
• Temperature: 204 °C
• Energy saving mode: 15 minutes
• Minimum - Maximum pressure: 2.0 - 6.0 bar (0.5 kg cm² minimum)
• Set pressure: 5.0 bar
Preset 2, for emblems and transfers for high temperature applications (up to 95 °C washing)
• Sealing time: 14 seconds
• Temperature: 195 °C
• Energy saving mode: 15 minutes
• Minimum - Maximum pressure: 2.0 - 6.0 bar (0.5 kg cm² minimum)
• Set pressure: 5.0 bar
Preset 3: for emblems and transfers for high temperature applications (up to 95 °C washing)
• Sealing time: 12 seconds
• Temperature: 185 °C
• Energy saving mode: 15 minutes
• Minimum - Maximum pressure: 2.0 - 6.0 bar (0.5 kg cm² minimum)
• Set pressure: 5.0 bar
Preset 4: for emblems and transfers for medium to low temperature applications (tot 60 °C
washing)
• Sealing time: 15 seconds
• Temperature: 150 °C
• Energy saving mode: 15 minutes
• Minimum - Maximum pressure: 2.0 - 6.0 bar (0.5 kg cm² minimum)
• Set pressure: 5.0 bar
Preset 5: for emblems and transfers for low temperature applications (up to 40 °C washing)
• Sealing time: 15 seconds
• Temperature: 130 °C
• Energy saving mode: 15 minutes
• Minimum - Maximum pressure: 2.0 - 6.0 bar (0.5 kg cm² minimum)
• Set pressure: 5.0 bar
Presented in the display:
• The set temperature: see preset in °C
• The supplied air pressure: 5 bar
• The set time: see preset in seconds
• Day counter: 001
• Machine in operational mode: Locked
Unlock the settings screen
with the 'AUTO' -button Select the required preset by
pushing the button

thermopatch.com
V. 3.0 ENG
Jan2014
19
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
7. Assembly and installation
7.1 Assembly
To work seamlessly with the NL-15 R / SQR, it is very
important that the machine can dispose of supply
of clean, dry air. The water condenser is an additional
safety measure. Provide pressure of 4-6 bar from the
compressor or its own air supply.
Attach a tube with a diameter of 6 mm at the
compressor or own air supply and the air regulator of the NL-
15 R / SQR.
7.2 Installation
Upon delivery, the NL-15 R / SQR is fastened with straps
to a pallet. The arm of the machine is locked
with a bolt (M12). Lift the machine out of the box holding
it by this bolt and the handle.
Put the machine on a work table near an earthed socket.
Remove the bolt.
Take care that there is enough free space around the
machine.
Also take care that there are no items near the machine that
are sensitive to heat radiation.
If you have to move the machine at a later time, it is
recommended to pack it in a similar way. Let the press cool
down before you pack it.
7.3 Electrical requirements
The Mammoth should be connected to the electricity grid
(230 V alternating current). Use the machine’s power cable
to provide current. The Mammoth is an earthed machine and
has been provided with two fuses of 4.0 amps.

thermopatch.com
V. 3.0 ENG
Jan2014
20
thermopatch.com
Manual NL-15 R / SQR V.4.0 ENG translation from Original Version NL-15 R / SQR V.4.0 NL September 2018
8. Maintenance instructions
8.1 Daily maintenance
Clean the outside of the machine regularly with a clean,
moist cloth. First switch o the machine, let it cool down and
pull the plug out of the socket. The inner part of the press
must also be cleaned from dust now and then. First switch o
the current before performing this operation and remove the
bottom plate.
For good press results it is important to keep the press
surfaces clean. Therefore, clean the coating of the upper
plate with a clean, dry cloth. Do not touch the heating
element!
Also clean the rubber of the press shoe daily with a dry cloth.
Do not use solvents or other chemical substances to remove
impurities. Do not let buttons, zips, etc. come between the
plates. In this way, the silicone rubber will remain intact for a
long time.
8.2 Periodic maintenance
The mechanism of the NL-16 R / SQR needs no maintenance.
Run water from the separator at least once a week.
The rubber pad and the upper plate must be cleaned once
or several times daily. Clean them with a clean and dry
cloth when they have cooled down. They must be absolutely
smooth and clean.
Both the and the lower press pad should be replaced
regularly.
In order to replace the adhesive, the press machine must
be warm. Remove the old pad and carefully remove all
glue residues from the metal surface. The surface must be
absolutely clean and smooth, so that the new sticks well.
Teon replacement
In order to be able to replace the teon of the upper platen,
the press needs to be warmed up until 80 °C. Remove the
worn teon sheet and remove glue residue carefully from the
metal surface by using a scraper or a putty knife.
After this, brush the surface with with a copper wire brush.
Finally clean the upper platen with a soft cloth. The newly
applied teon will only adhere well when the surface is com-
pletely clean.
8.3 Parts for regular replacement for maintenance:
• Sealing pads Art.nr.
for type R: 160 mm round SPAMA-01-04
for type SQR: 140 x 140 mm SPAMA-01-04 VA
• Self adhesive teon sheet
for type R: 160 mm, round SPAMA-03-21
for type SQR: 150 x 150 mm SPAMA-03-21 V
• Fuse
4 A TR SPAMA-04-10
