TiCad Andante Manual
READ ME FIRST
TiCadANDANTE®
Read me first 1-1
2
YOUR TICAD ANDANTE®IN DETAIL
1 Delta leather handle
2 Umbrella adapter
3 Drawbar
4 Top Fixfest coupling
5 Top bag holder
6 Fastening straps
7 Centre bar
8 Bottom Fixfest coupling
9 Shaft
10 Locking pin
11 Locking brake
12 Knurled sleeve
13 GRP* wheel
14 Bottom bar
15 Bottom bag holder
16 Front shaft
17 Front GRP* wheel
12
3
4
5
6
6
7
9
9
13
13
15
16
17
12
12
12 14
11
10
8
Image:
TiCad Andante® with GRP* wheels, also available as
TiCad Andante® Classic with titanium wheels
SETTING UP YOUR TROLLEY
Fitting the shaft:
Before fitting the shaft, pull back the locking pin (black round
handle) and turn it slightly to the right (about 45°). Next, insert
the shaft halfway into the frame with the brake on the left and
release the locking pin by turning the black handle back again
and allowing the locking pin to engage. You can now insert the
shaft fully into the frame until it engages. To lock the shaft into
place for the integrated locking brake, continue turning it until it
engages again.
Shaft with locking pin groove and arrester Locking pin
Removing and attaching the wheels
READ ME FIRST
TiCad ANDANTE®
*Glass-fibre reinforced plastic (PA 6 GF 30)
Congratulations!
You have chosen an excellent product manufactured by TiCad®!
All of our high-quality products are carefully handmade at our
production facility in Altenstadt (Hessen, Germany).
To ensure that you will be able to enjoy your trolley for a very
long time, please take some time to carefully read through these
operating instructions, which contain important information that
will make using your trolley a lot easier.
If you have any further questions regarding the use or care of your
trolley, please contact your TiCad®dealer.
We would like to wish you many an enjoyable game
of golf and a lot of success! Your TiCad®team
3
Attaching the golf bag
Frame connections (Fixfest couplings):
The frame sections of your TiCad®trolley are connected to one
another with Fixfest couplings. To connect the two frame sec-
tions, simply press them into one another and slightly turn one
of the sections to allow the coupling system to engage. It will have
engaged once the outer ring has slid over the joint. To open the
coupling, pull the outer ring back. 1
3
2
Engaging (1+2) and opening (3) the
Fixfest couplings
Bag holder:
The top bag holder is fitted into place with an expansion bolt.
The expansion bolt must not be turned in too far (see images),
because there has to be a gap between the expansion bolt and
the start of the thread. To fit the bag holder, insert it into the frame
and then align and fix it into place by tightening the bolt.
Expansion bolt turned in too far
Bag holder Expansion bolt in the correct position
Attaching the golf bag:
Put your golf back onto the trolley before attaching the drawbar.
To fasten the golf bag, insert one of the round fasteners into the
strap of the opposite fastening strap. When doing so, make sure
not to flick the fasteners, as this may cause injury. To undo the
fastening straps, hold on to the bottom strap and then pull out the
top fastening strap with your other hand.
We recommend fitting the drawbar only once the golf bag
has been attached to prevent the trolley from tipping over.
4
Umbrella adapter:
The umbrella adapter is located at the top end of the drawbar.
Screw the umbrella holder into the tapered adapter. The adapter
can only be used in the standard position on the drawbar.
TiCad®umbrella adapter with
umbrella holder
Locking brake:
The locking brake has to be fitted on the left wheel. To open and
apply the brake, simply move the locking lever back or forward.
Locking brake when open Locking brake when applied
READ ME FIRST
TiCad ANDANTE®
Care:
The frame of your TiCad®trolley is made of a high-quality,
rust-proof material and has been sealed to keep out rain. The
frame can be cleaned with a conventional household cleaning
product – but not with abrasive cleaners. The titanium‘s shine
can be restored with a special cleaning oil available from TiCad®.
The hubs of the wheels and the couplings must not be oiled or
greased.
USING YOUR TROLLEY
Always move your TiCad®trolley slowly and carefully when
moving over rough ground that contains stones or pot-
holes. Avoid kerb edges.
5
YOUR NOTES
Technical data and dimensions
Model TiCad Andante®
Weight of frame + wheels 4.4 kg
Dimensions when folded cm 65x26x13
WARRANTY
Your TiCad®trolley has been designed and built with great care.
Please get in touch with your TiCad®dealer if you notice anything
unusual. The provision of spare parts or repairs performed under
warranty do not extend the warranty period. The warranty does
not apply to damage caused by carelessness or rough handling,
overloading the trolley, inappropriate operation, external force,
submersion in water and unauthorised persons‘ actions. The
warranty only applies if the enclosed operating instructions have
been observed and the trolley is being appropriately used and
cared for. Technical changes and new developments do not enti-
tle warranty holders to upgrades.
The warranty period for the titanium frame and the wheels is 5
years from the date of purchase. The warranty does not apply to
wear parts such as e.g. tyres, leather handle.
SERVICE
If you experience any problems with your TiCad®trolley, please
first contact your TiCad®dealer, one of our service centres or get
in touch with us at our office in Altenstadt, Germany.
We will then arrange for your TiCad®trolley to be collected and
returned to us and help you with the packaging material. If you
want us to perform an inspection or repair, there is no need to
contact your TiCad®dealer.
For trolleys located outside Germany, please always first contact
your local service staff.
Postal address: TiCad®GmbH & Co. KG
Heegwaldstr. 5
D-63674 Altenstadt -Waldsiedlung
Phone: +49 (0)6047 / 987 90-14
Fax: +49 (0)6047 / 987 90-39
E-Mail: service@ticad.de
PUBLISHER
TiCad®GmbH & Co. KG, Heegwaldstr. 5, D-63674 Altenstadt
www.ticad.de
The above information, wording and images have been largely
standardised and are primarily intended to describe the trolley‘s
basic functions. For this reason, the product supplied to you may
slightly differ from the above descriptions, in particular if your
trolley is a new version. This „Read Me First“ manual must not be
copied or used otherwise in whole or part without TiCad®GmbH
& Co. KG‘s consent.
Please carefully retain your Read Me First manual and the origi-
nal packaging.
Please read our General Terms and Conditions of Business www.
ticad.de.
Graphic design and layout: www.bild-satz-und-sieg.de
6
YOUR NOTES
READ ME FIRST
TiCad ANDANTE®
©2014 TiCad®GmbH & Co. KG - All rights reserved.
