TiCad TANGO Manual

READ ME FIRST
TiCad®TANGO/
TANGO CLASSIC
Read me first 1-1

2
YOUR TICAD®TANGO IN DETAIL
1 Umbrella adapter
2 Control handle
3 Drawbar handle
4 Single button (concealed)
5 Drawbar
6 Drawbar adjuster
7 Top bag holder
8 Fastening straps
9 Centre bar
10 Motor bar
11 Sliding sleeve
12 GRP* drive wheel
13 Bottom bar
14 Battery connection (concealed)
15 Battery holder (concealed)
16 Bottom bag holder (concealed)
17 Knurled sleeve
18 Front shaft
19 Front GRP* wheel
1
2
34
5
6
18
7
9
15
13
11
10
11
19
12
12
16
17
14
8
8
Removing and attaching
the drive wheels
Removing and attaching
the front wheel
SETTING UP YOUR TROLLEY
Attaching the wheels:
The drive wheels can be attached and removed with a quick re-
lease fastener and by pushing back the sliding sleeve at the wheel
hub (see arrow), attaching the drive wheels to the drive pins, and
making sure they engage.
Always make sure that no dirt gets into the hub. The hubs
must not be oiled or greased.
The front wheel can be fitted and removed by pulling back the
knurled sleeve. When attaching the wheels, slightly turning the
sleeve can make it easier for the wheels to engage.
Image:
TiCad®Tango with GRP* wheels, also available as
TiCad®Tango Classic with titanium wheels
READ ME FIRST
TiCad®TANGO/ TANGO CLASSIC
*Glass-fibre reinforced plastic (PA 6 GF 30)
Congratulations!
You have chosen an excellent product manufactured by TiCad®!
All of our high-quality products are carefully handmade at our
production facility in Altenstadt (Hessen, Germany).
To ensure that you will be able to enjoy your trolley for a very
long time, please take some time to carefully read through these
operating instructions, which contain important information that
will make using your trolley a lot easier.
If you have any further questions regarding the use or care of your
trolley, please contact your TiCad®dealer.
We would like to wish you many an enjoyable game
of golf and a lot of success! Your TiCad®team

3
Setting up your trolley:
The frame of your TiCad®trolley is easy to set up and fold together.
To do so, push the lower bar right down until it reaches the bottom
limit stop and the centre bar right up until it reaches the top limit
stop.
Pull the top bag holder down and turn it until it reaches its end
position and you can hear it engage.
To release the locking pin, pull the bag holder up and then fold
it down.
Attaching the golf bag:
Put your golf bag onto the trolley before fitting the drawbar, i.e.
while it is hanging loose. To fasten the golf bag, insert one of the
round fasteners into the strap of the opposite fastening strap.
When doing so, make sure not to flick the fasteners, as this may
cause injury. To undo the fastening straps, hold on to the bottom
strap an then pull out the top fastening strap with your other hand.
Attaching the golf bag des Golfbags
Connecting/removing the battery:
Insert the battery into the supplied battery holder. Connect the
battery before placing the golf bag onto the trolley. Do not let the
battery connector drop onto the ground. To unplug the connec-
tor, hold on to the knurl (not the cable) and pull the connector out
horizontally.
1 Battery inside plastic housing
2 Cable
3 Connector, 10-pin
4 Knurl for removing the connector
2
3
4
1
Adjusting the drawbar:
As soon as the golf bag has been attached to the TiCad®trol-
ley, you can adjust the drawbar to a comfortable height for you.
You can loosen the drawbar by turning the black handle coun-
ter-clockwise 3 to 4 times. Only start moving the drawbar into
the right position once it has been completely freed and moves
without resistance. To fasten the drawbar, turn the black handle in
the opposite direction. When doing so, move the drawbar slight-
ly up and down to allow the fastening mechanism‘s teeth to fully
engage with one another and to prevent them from becoming
damaged.
Adjusting the drawbar
Top bag holderFolding principle
We recommend adjusting the drawbar only once the golf
bag has been attached to prevent the trolley from tipping
over.

4
Control handle:
Start/Stop and speed control
Twisting the handle forward starts the trolley and increases its
speed. Twisting the handle backward decreases the trolley‘s
speed and twisting the handle right back to the mechanical limit
stop (to zero) will bring the trolley to a stop and activate the brake.
Memory function
If you do not want to use the control handle to bring the trolley to
a stop, you can also use the single button (3). Pressing the single
button (3) again will make the trolley start up again at the speed
that was used last.
Releasing and applying the electromagnetic parking brake
If you stopped your trolley by pressing the single button (3), you
can release the brake by twisting the control handle right back to
zero. The brake can be reactivated by pressing the single button
(3) again. To start the trolley up again, twist the control handle
forwards.
If you stopped your trolley by twisting the control handle until it
reached zero, you can release the brake by pressing the single
button (3). The brake can be reactivated by pressing the single
button (3) again. To start the trolley up again, twist the control
handle forwards.
All TiCad®Tango Classic‘s are equipped with an electromagnetic
parking as standard.
1 Twisting the handle forwards:
start + faster
2 Twisting the handle backwards:
slower + stop
3 Single button
Timer function (base setting):
Press the single button until the LED lights up. Your trolley will
now drive about 10 metres and then come to a stop. Press the
single button until the LED starts flashing. Your trolley will now
drive about 20 metres and then come to a stop. You can stop the
timer function at any time by pressing the single button again.
The relevant timer settings will be confirmed by the LED on the
battery.
10 metres - LED lights up
20 metres - LED flashes
Motor brake:
When moving downhill, you can use the trolley‘s drives as a motor
brake: To do so, set the speed to whichever low setting will make
your TiCad®generate the right level of resistance for you.
Electromagnetic parking brake:
The electromagnetic brake is automatically applied to the right
wheel when the trolley comes to a stop and will safely keep the
trolley in place. Please note that the parking brake needs a small
amount of current in order to work.
(Supplied as standard only on TiCad®Tango Classic.)
READ ME FIRST
TiCad®TANGO/ TANGO CLASSIC
3
1
2
USING YOUR TROLLEY
Always move your TiCad®trolley slowly and carefully when
moving over rough ground that contains stones or pot-
holes. Avoid kerb edges. Never tow your TiCad®trolley with
a buggy!

5
Shaft guard:
Your TiCad®trolley is supplied with a shaft guard for protecting
the drive shafts during transport. Please always use this guard
and do not allow the trolley to drop onto the shafts.
Shaft guard
Free-wheel function:
The wheels have a free-wheel function that we recommend using
when the battery is empty or if you chose to push or pull your golf
trolley yourself over longer distances. To do so, push back the
sliding sleeves on the wheels and arrest them about 5 mm from
the drive pin.
Drive wheel arrested
in free-wheel function
ELECTRONICS
Battery:
The battery will continue to discharge power while connected even
if the trolley is standing still. The control unit contains a number
of fuses to protect the drives from being overloaded and to pro-
tect the battery. These fuses are tripped: if the wheels are blocked,
if the trolley moves up excessively steep inclines, at slow speed
coupled with excessive resistance or if the battery is empty. In this
case, the golf trolley will come to a stop and the LED will flash fast.
Allen key in the umbrella adapter
Umbrella adapter
with TiCad®umbrella holder
Umbrella adapter:
The umbrella adapter is supplied ready-fitted at the end of the
drawbar‘s handle. To adjust the adapter to the drawbar‘s posi-
tion and to your body height, loosen the screw in the centre of the
adapter with the supplied Allen key and turn it into the required
position.
When doing so, the larger hole on the adapter always has to
point towards the top and the middle hole with the thread to
the bottom. Once you have adjusted the adapter, tighten the
screw again.
Screw the umbrella holder into the tapered adapter.
1 Battery inside plastic housing
2 Cable
3 Connector, 10-pin
2
3
1
Care:
The frame of your TiCad®trolley is made of a high-quality,
rust-proof material and has been sealed to keep out rain. The
frame can be cleaned with a conventional household cleaning
product – but not with abrasive cleaners. The titanium‘s shine
can be restored with a special cleaning oil available from TiCad®.
The hubs of the wheels and the couplings must not be oiled or
greased.
Never clean your trolley with a jet washer. Should your trolley
ever become briefly flooded with water, please send it to us im-
mediately!

6
To start the trolley again, press the single button. If the trol-
ley comes to a stop after a sudden impact with an obstacle
(e.g. pot-hole or kerb stone), disconnect the battery connec-
tor and reconnect it after 5 seconds. If the battery has suffi-
cient charge, you can then start the trolley again. A standard
battery generally holds sufficient charge for an average of
27 holes and an additional trolley weight of approx. 16 kg.
READ ME FIRST
TiCad®TANGO/ TANGO CLASSIC
1 Charger
2 Charger cable
3 10-pin connector
4 Mains cable
3
2
1
4
your battery to always be ready for use, fully charge the battery
before storing it and then to-up its charge the day before you are
playing golf.
For over-winter storage, disconnect the battery from the charger
and store it fully charged in a cool and dry room at an ambient
temperature of less than 20°C. We recommend storing the bat-
tery at as low a temperature as possible, and ideally at 8°C! Avoid
using the battery in high temperatures (> 50°C), as this could
cause irreversible damage.
If the battery is not used for a long period of time, fully charge it
at the latest every 8-12 weeks to prevent it from becoming dam-
aged. Avoid causing mechanical damage to the battery case and
the cable. The battery case‘s seal is rainwater-proof and must not
be opened. If the battery has been submerged in water or is dam-
aged during a fall, please send it immediately to TiCad®GmbH &
Co. KG. Do not attempt to open or repair the battery yourself. The
battery must only be opened and repaired by trained, specialist
personnel. Doing so yourself will void the warranty and may make
the battery unsafe.
Caring for the battery:
Your TiCad®trolley is fitted with a rechargeable lithium-ion bat-
tery. Please fully charge the battery before using the trolley for
the first time.
ATTENTION! Lithium-ion batteries are considered
hazardous goods. The lithium-ion battery supplied with the
trolley contains a protective circuit that protects the battery
from incorrect use. However, the instructions on the bat-
tery‘s use and care still have to be strictly followed, and the
battery treated with care, as non-observance and improper
use can increase the risk of fire. Never expose the battery to
mechanical stress or manually manipulate it. Always make
sure to carefully wrap and store the battery! The battery
must only be charged with the supplied charger.
8 hours to fully charge and be ready for operation again. If you
are playing a lot of golf, you can leave the lithium battery con-
stantly connected to the charger during the season. However, it
is still recommended to disconnect the battery from the charger
once it is fully charged. If you only play golf occasionally and want
Charger:
Only ever charge the battery with the supplied charger. The char-
ger has been configured to carefully charge the battery. The char-
ger must only be used in a dry environment and is not suitable for
outdoor use. The charger must not be covered. Avoid using the
charger in temperatures above 35°C and below 5°C!
The charger‘s status is shown by the LED:
LED GREEN = Battery is fully charged
LED GREEN & flashing = Battery is charging
LED RED = Error
The charger can also be used to check the battery‘s charge: If
the LED stays green when connecting the battery, it is fully
charged.

7
WARRANTY
Your TiCad®trolley has been designed and built with great care.
Please get in touch with your TiCad®dealer if you notice anything
unusual. The provision of spare parts or repairs performed under
warranty do not extend the warranty period. The warranty does
not apply to damage caused by carelessness or rough handling,
overloading the trolley, inappropriate operation, external force,
submersion in water and unauthorised persons‘ actions. The
warranty only applies if the enclosed operating instructions have
been observed and the trolley is being appropriately used and
cared for, and used with the battery pack and charger supplied by
TiCad®. Technical changes and new developments do not entitle
warranty holders to upgrades.
The warranty period for the titanium frame and the wheels is 5
years, and for the electronic components 2 years from the date
of purchase. The warranty does not cover any damage to the
wheel coating and wear parts such as, e.g. tyres, leather handle.
Loss of battery performance does not constitute a manufac-
turing fault. Batteries are wear parts and are therefore subject
to ageing. Ageing is furthermore affected by factors such as e.g.
operating and storage temperature and level of charge during
storage. Amongst others, one of the signs of battery ageing is an
irreversible loss of capacity.
SERVICE
If you experience any problems with your TiCad®trolley, please
first contact your TiCad®dealer, one of our service centres or get
in touch with us at our office in Altenstadt, Germany.
We will then arrange for your TiCad®trolley to be collected and
returned to us and help you with the packaging material. If you
want us to perform an inspection or repair, there is no need to
contact your TiCad®dealer.
For trolleys located outside Germany, please always first contact
your local service staff.
Postal address: TiCad®GmbH & Co. KG
Heegwaldstr. 5
D-63674 Altenstadt -Waldsiedlung
Phone: [phone]
Fax: [phone]
E-Mail: [e-mail]
Model TiCad®Tango
Weight of frame + wheels 6.4 kg
Battery weight 1.5 kg
Nominal battery 21.6 V
Battery capacity 224 Wh
Motor capacity 2x90 W
Dimensions when folded 66x65x11
Technical data and dimensions
This device has been labelled in accordance with EU
Directive 2012/19/EC on Waste Electrical and Elec-
tronic Equipment (WEEE).
This directive provides the framework for the recovery,
reuse and recycling of electrical and electronic pro-
ducts across Europe. WEEE-Reg.-Nr.: DE 11192197
PUBLISHER
TiCad®GmbH & Co. KG, Heegwaldstr. 5, D-63674 Altenstadt
www.ticad.de
The above information, wording and images have been largely
standardised and are primarily intended to describe the trolley‘s
basic functions. For this reason, the product supplied to you may
slightly differ from the above descriptions, in particular if your
trolley is a new version. This „Read Me First“ manual must not be
copied or used otherwise in whole or part without TiCad®GmbH
& Co. KG‘s consent.
Please carefully retain your Read Me First manual and the origi-
nal packaging.
Please read our General Terms and Conditions of Business www.
ticad.de.
Graphic design and layout: www.bild-satz-und-sieg.de

8
YOUR NOTES
READ ME FIRST
TiCad®TANGO/ TANGO CLASSIC
©2014 TiCad®GmbH & Co. KG - All rights reserved.
