Instruction #08409 (E1899 - Rev. 2/16/22)
Read and understand these instructions before using this product.
Keep these instructions for future reference.
Slab Gripper
Installation and Use
Model #14367
12”
12”
Nail Hole Nail Hole
Toe Board
The Tie Down Slab Gripper is the perfect solution for installing
guardrail systems on concrete decking. This OSHA compliant
guardrail system includes a quick adjustment handle which
guarantees the system’s integrity.
This guardrail system includes a quick adjustment handle and
a backup safety pin, which guarantees the system’s integrity.
These additional features allow compliance with all applicable
OSHA standards.
The Tie Down Slab Gripper installs easily and quickly and
adjusts to fit concrete slabs up to 27” thick. It is compatible
with 2” x 4” boards, as well as cable or snap-on metal railings.
The Slab Gripper can be adjusted to fit decking that does not
allow for slab attachment with the use of standard Hilti type
concrete anchor bolts. The Slab Gripper is resistant to corrosion
and damage because of the durable coating.
Features:
Ideal for concrete decking operations
Fast and easy setup
Adjusts up to a 27” slab
Meets OSHA standards
WARNING: This product can expose you
to chemicals including Nickel, which is
known to the State of California to
cause cancer. For more information
go to: www.P65Warnings.ca.gov
WARNING: This product can expose you
to chemicals including Nickel, which is
known to the State of California to
cause cancer. For more information
go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to
chemicals including Nickel, which is known to
the State of California to cause cancer. For more
information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
WARNING: This product can expose you to chemicals including Nickel, which is known to the
State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov

2TIE DOWN Safety Products Division
800-241-1806 • 404-344-0000 • www.tiedown.com
E1821 Rev. 2/16/22
Slab Gripper
Plan and implement a complete Fall Protection Plan prior to use. The Slab Gripper ONLY installs onto concrete or
compatible pan decking.
The Tie Down Slab Gripper MUST install evenly against the substrate and must allow guardrail posts to be
positioned perpendicular to the working surface. Concrete substrate MUST be deemed compatible with the Tie
Down Slab Gripper by a Competent Person.
1. Selected work area must be free of all hazards, including, but not limited to, debris, rot, decay,
cracking, and hazardous materials. NEVER install the Slab Gripper on gravel or other loose or slippery
surfaces. Guardrail systems must be installed a MINIMUM of 10’ from power lines and all other
electrical hazards.
2. All guardrails MUST be 2” x 4” construction grade lumber OR wire cabling with strength and installation
deemed compatible by a Competent Person. All other applicable equipment must be selected
and deemed compatible by a Competent Person.
3. Toprails must be 42” (+/- 3”) above the working surface or, if used in stilt work applications,
42” plus the height of stilts.
4. Midrails must be halfway between the top edge of the guardrail system and the working level
(not the toeboard).
5. Toeboards are REQUIRED on surfaces with slopes more than 4/12 (vertical/horizontal).
6. Toeboards are REQUIRED if a risk exists for tools, equipment, materials, or other substances to fall down
to a lower level.
7. Toeboards must be a minimum of 3-1/2” from their top edge to the work surface, and must not have
greater than 1/4” clearance between their bottom edge and the working surface.
8. Plan the layout by measuring and spacing the Slab Grippers on the working surface. Failure to properly
measure and plan ahead may result in having to move and reinstall system components.
MAXIMUM spacing between Slab Grippers is 8’.
Use these instructions as part of a training program as required by OSHA and any applicable state
agency. The user must understand how to safely use the Parapet Anchor and all safety equipment
used in combination with the Parapet Roof Anchor device.
A competent person who is highly trained and experienced, assigned by the employer, must be
responsible for all elements of a fall safety program, including the regulation, management, and
application as it relates to the use of the Parapet Anchor and related components.

3
TIE DOWN Safety Products Division
800-241-1806 • 404-344-0000 • www.tiedown.com E1821, Rev. 2/16/22
Slab Gripper Installation
12”
12”
Nail Hole Nail Hole
Toe Board
12”
12”
Nail Hole
Nail Hole
Toe Board
12”
12”
Nail Hole
Nail Hole
Toe Board
1. Place a1 ” socket and impact driver, over
the 1” nut on top of the Slab Gripper.
2. Adjust the opening of the Slab Gripper matching
the width of the slab/work surface.
3. Align the Slab Gripper perpendicular to the work
surface (90˚) making sure the inside extension
arm rest flush against the slab/work surface.
Guardrail rungs must always face towards
work surface
4. Using the impact driver tighten the nut on top of
the Slab Gripper to 30 ft. lbs.
5. Repeat steps #1-4 for the remaining Slab Grippers.
6. Install 2” x 4” guardrail boards in guardrail rungs.
Guardrails must overlap by a minimum of 12” at
each end.
7. Use nails, deemed compatible by a Competent
Person, to install nails through the guardrail rungs.
Nails must pass through the guardrail rung and
both 2x4’s.
8. Install toeboards - nail through the guardrail rung.
Nails must pass through the guardrail rung and
2x4.

Safety Products Division
605 Stonehill Drive SW, Atlanta, Georgia 30336
800-241-1806 • 404-344-0000 • www.tiedown.com
ISO 9001:2015 Certication
Intellectual property of TIE DOWN Inc. ©2018 TIE DOWN, Inc.
Instruction #08409 (E1899 Rev. 2/16/22)
Slab Gripper
12”
12”
Nail Hole Nail Hole
Toe Board
EFPS Panels
Slip EFPS panel (#14339) over the panel hook.
Over lap the panels to create a proper barrier.
Add a zip tie at the bottom to secure the base
of the panel.
Secondary Mounting Installation
In the event the floor slab excesses the 27” depth
the Slab Gripper can be modified to be installed
with concrete anchors.
1. Completely unscrew the clamp until it releases
from the Gripper post.
2. Rotate the clamp 180 degrees.
3. Insert the clamp into the Gripper post and
rewind until the clamp is fully retracted
within the Gripper post.
Concrete Installation is determined by your
choice of concrete anchors, recommendations
shown below.
Concrete Screw
KH-EZ CONCRETE SCREW ANCHOR
Anchor length: 5 inch
Nominal anchor diameter: 1/2 inch
Nominal embedment depth: 3 inch
Expansion Anchor
KWIK BOLT 1 CARBON STEEL WEDGE ANCHOR
Anchor length: 6 inch
Nominal anchor diameter: 1/2 inch
Nominal embedment depth: 3-5/8 inch
