Timago TGR-R KP-U 3522L User manual

1
INSTRUCTIONS FOR USE
Shower chair with backrest and U-shape seat – tool free
Product code: TGR-R KP-U 3522L
1. Characteristics
Shower chair consists of aluminium frame and wide seat made of
durable PVC. The chair is equipped with height adjustable legs with
anti-sliding rubber tips and integrated handles which facilitate using
the product. Specially designed rubber tips prevent the chair from
sliding on wet surfaces. The chair is additionally equipped with Tool-
Free (TF) system facilitating the assembly.
The set includes:
•backrest – 1 pc
•backrest tubes – 2 pcs
•seat – 1 pc
•base tubes – 2 pcs
•height adjustable legs – 4 pcs
•mounting screws (wing screws) – 9 pcs
Elements of the shower chair:
a. backrest
b. backrest tubes
c. seat
d. base tubes
e. height adjustment – TF system
f. anti-sliding tips
2. Application
The shower chair is ancillary equipment which helps the user to
perform hygienic activities. The chair is recommended to people with
reduced mobility which prevents or hinders the unassisted
performance of daily living activities. The chair can be used in the
shower, in the bath, in bathrooms and other humid rooms at home and
in hospitals.

2
3. Assembly
ASSEMBLY
Step 1. Place the seat upside down on a flat surface.
Step 2. Fix crossed base tubes with seat in the middle using one screw
with washer.
Step 3. Join base tubes with legs.
Step 4. Screw backrest tubes to base tubes using four wing screws with
washers.
Step 5. Place shower chair with fixed seat and backrest tubes on the
legs and tighten the backrest using four wing screws with washers.
HEIGHT ADJUSTMENT
•To adjust the height of the shower chair, press metal pin, select
appropriate height of leg, and lock the position of the tubes
relative to each other with the use of metal pin. The legs are
adjustable in 2.5 cm increments.
Note! The pins must be set on the same level in each leg.
4. Technical data
Width 48 cm
Depth 40 cm
Seat height 35-52 cm
Overall height 70-87 cm
Seat dimensions 48 x 31 cm
Weight 2.8 kg
Maximum capacity 110 kg
5. Notes
Timago International Group does not bear responsibility of improper
use of the shower chair, failure to comply safety regulations and
misuse.

3
6. Maintenance
•Clean the shower chair regularly using only water, sponge and
mild detergents for plastic materials such as soap. Dry thoroughly.
•Do not use for cleaning: strong detergents, abrasive agents,
bleach, petrol or solvents (it may cause frame damage, visible
defects and in consequence – loss of warranty rights).
•Systematically check:
-tightening of wing screws
-condition of locking pins
-condition of tubes (if cracks)
It is recommended to check rubber tips regularly. In case of worn-
out, replace the tips with the new ones.
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained
9. Labels
Reference
number
Manufacturer
LOT number Manufacture date
Serial number Medical device
Note
Please read the
instruction

4
The manufacturer checked for compliance with
essential medical devices requirements.
Our complete line of products is available from our distributors.
Learn more at: www.timago.com. Thank you for choosing Timago!
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Polska
T.: [phone]
F.: [phone]
E.: [e-mail]
Rev. II, date 20.05.2021
