Titan EZM-1500 Instruction manual

INSTALLATION, OPERATION
& MAINTENANCE MANUAL
FOLLOW THIS MANUAL CAREFULLY TO ENSURE THE EQUIPMENT WILL
FUNCTION CORRECTLY AND PROVIDE MANY YEARS OF DEPENDABLE SERVICE.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND SAFETY WARNINGS MAY
RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE. KEEP THIS MANUAL IN A
SAFE DRY PLACE FOR FUTURE REFERENCE.
MODEL:
EZM-1500
1,500 LB CAPACITY MECHANICAL VEHICLE POSITIONING JACKS
®

PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
®
To Our Valued Customers:
Thank you for purchasing a Titan Lifts®product. We hope this high quality equipment provides you with years of
dependable service.
It is unfortunate that rare situations may occur with the products you purchase from Titan Lifts®. We value your
business as well as the trust you have and need to maintain your relationship with us. Titan Lifts®carries liability
coverage that may protect our customers if a situation does occur. However, as in all accidents there must be
proof of liability for a claim to be made. Our insurance company requires the following procedures be observed in
order to consider a claim:
A. The claimant must contact the Titan Lifts®distributor immediately with the facts of the situation.
B. If any equipment is damaged, including vehicles or shop equipment, Titan Lifts®must be given the
opportunity to send an impartial representative to the site for proper assessment of the situation.
C. The Vehicle cannot be moved until either an impartial representative has reviewed the accident or clear
and precise pictures are taken that reect all the pertinent information for an impartial representative to be able
to access the information from a distance. Titan Lifts®or its representatives must approve the pictures before
anything can be moved.
D. If any potential liability is determined on behalf of Titan Lifts®, two estimates must be submitted for
damages to be reimbursed.
It is imperative that the claimant complies with these procedures, because without proper assessment of the
situation a claim will be denied.
ARBITRATION NOTICE
The installation or use of this equipment shall constitute an acknowledgement that the user agrees to resolve any
and all disputes or claims of any kind whatsoever, which relate in any way to the equipment, by way of binding
arbitration, not litigation. No suit or legal action may be led in any state or federal court. Any arbitration shall be
governed by the Federal Arbitration Act, and administered by the American Mediation Association, Indianapolis
Indiana. The maximum amount that an arbitrator may award and all damages shall not exceed the retail value of
this equipment.
WARRANTY NOTICE
This equipment must be assembled and used in the manner according to the documentation provided to be
covered by warranty.
Damaged or missing components must be reported within 72 hours of receipt to your freight carrier and to the
distributor. Claims must be led to cover cost.
If you have any questions or if we can be of any further assistance, please don’t hesitate to contact a Titan Lifts®
representative at 1-888-908-4826. Thank you for the opportunity to continue to serve your lift equipment needs.

1
INSTRUCTIONS
WARNING: READ ENTIRE MANUAL AND COMPLY WITH ALL SAFETY AND
SERVICE PRECAUTIONS. DEATH, PERSONAL INJURY AND / OR PROPERTY DAMAGE MAY
OCCUR IF INSTRUCTIONS ARE NOT FOLLOWED CAREFULLY.
WARNING: BEFORE OPERATING THE POSITIONING JACK, MAKE SURE THAT ALL
THE HARDWARE IS SECURE AND THAT EACH UNIT HAS BEEN TESTED PROPERLY.
1. Make sure that the vehicle being lifted is located on a solid at surface.
2. Slide the positioning jack around the tire so that the rollers (C) are perpendicular to the
tire. Make sure that each tire has a positioning jack around it before raising.
3. To raise each tire, pump each foot pedal (D) so that the rollers (C) move together and lift
the tire off the ground.
4. IMPORTANT: Once raised to the desired height, press the foot pedal (D) down and
swing the pedal latch (A) up to secure the foot pedal (D) in place.
5. Once all four tires are resting on the positioning jacks, the vehicle can be pushed into the
desired location.
6. To lower the vehicle, ip lever (B) down and pump foot pedal (D) until the weight of the
vehicle begins to spread the rollers (C) apart allowing the tire to rest on the ground.
7. Remove the positioning jacks from each tire and secure the foot pedal (D) with the pedal
latch (B).
OPERATION - REFER TO PARTS DIAGRAM (SIMPLE)

2
1. Load should not exceed rated capacity for positioning jacks - 1500lbs per jack
2. A vehicle’s engine must be turned off and the parking brake must be set before lifting
3. Do not allow people in the vehicle when it is being lifted or moved.
4. Never work underneath the vehicle while it is resting on the positioning jacks.
5. Only trained people should operate the positioning jacks.
6. Indoor use recommended.
7. Keep hands, tools and other extremities away from moving parts.
8. Check for damaged or worn parts that may affect the operation of the jack and replace
immediately before use.
9. Maintain a safe working environment. The work area should be clean, dry, clutter free
and sufciently lit.
10. Wear proper safety attire. Do not wear loose tting clothing while operating lift. Long
hair and sleeves should be secured.
11. Keep children and bystanders away from work area. Do not let children operate or play
with the equipment.
12. Do not use if under the inuence of drugs or alcohol. Operator must be alert at all times
when using heavy lift equipment.
13. Use these jacks only for the work they are intended. Do not use this product for an
application for which it was not designed. Misuse can lead to personal injury and/or
property damage.
14. Have your positioning jacks serviced by a qualied repair person using only identical
Titan Lifts®replacement parts and attachments. This will ensure that the safety of the
jacks is maintained.
15. Lubricate the following parts of your jack once a week:
• Sides and bottom of telescoping shaft with bearing grease (DO NOT lubricate teeth)
• Inside of rollers with bearing grease
• All pivot pins with light oil
• Caster swivels with light oil
SAFETY PRECAUTIONS

3
PARTS DIAGRAM (SIMPLE)
NO. DESCRIPTION QTY
A Pedal Latch 1
B Lift/Release Lever 1
C Wheel Rollers 2
D Foot Pedal 1
E 5” Caster 2
F 4” Caster 2

4
PARTS DIAGRAM (FULL)

5
PARTS LIST
NO. DESCRIPTION QTY
1 5” Caster 2
2 Nut M16 2
3 Ratchet Assembly 1
4 Spring 1
5Washer Φ16 1
6 Cotter Pin 1
7 Pedal Latch 1
8 Lock Nut M6 1
9 Roller 2
10 Receiver Assembly 1
11 Roller Bearing 2
12 Screw M8×20 2
13 Foot Pedal 1
14 Pin 1
15 Spring 1
16 Front Pawl 1
17 Back Pawl 1
18 Pin 1
19 Plate 1
20 Retainer 1
21 Lever 1
22 Spring Pad 1
23 Bolt M8×20 1
24 Nut M12 2
25 4” Caster 2
26 Nut M8 1
27 Lock Nut M8 1
28 Insurance Rod 1
29 Cap Nut M8 1

6
P.O. Box 7069 • Greenwood, IN 46142 • Ph. 888-908-4826 • Fx. 317-215-2770 • www.titanlifts.com
LIMITED WARRANTY
The Titan 2 Post lifts, 4 Post lifts and Bridge Jacks are backed by a standard 1-year replacement parts warranty and a 5-year
structural warranty from the date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers power
units, hydraulic cylinders, and all other assembly components such as, but not limited to: turn plates, slip plates, cables, chains,
valves, switches etc. This does not cover normal wear items such as, but not limited to: rubber lifting pads and nylon slide blocks.
Titan Elite model lifts have been discontinued but still qualify under the same terms as shown above.
Titan SL-6600 Scissor Lifts and PREMIER Series 2 Post Lifts are backed by a 2-year replacement parts warranty and a 5-year
structural warranty from the date of purchase, to the original purchaser only. The 2-year replacement parts warranty covers power
units, hydraulic cylinders, and all other assembly components such as, but not limited to: valves, switches, capacitors etc. This does
not cover normal wear items such as, but not limited to: rubber lifting pads, nylon slide blocks and rubber arm pads.
Titan MRL-6000 Scissor lifts are backed by a standard 1-year replacement parts warranty and a 5-year structural warranty from the
date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers power units, hydraulic cylinders, and
all other assembly components such as, but not limited to: valves, switches, capacitors etc. This does not cover normal wear items
such as but not limited to rubber lifting pads.
Titan ROT-4500 Rotisseries are backed by a standard 1-year replacement parts warranty from the date of purchase, to the original
purchaser only. The 1-year replacement parts warranty covers components such as, but not limited to: hydraulic cylinders, caster
assemblies, bearings etc. This does not cover normal wear items such as, but not limited to, mounting adapters.
Titan Standard Duty and Heavy Duty motorcycle lifts are backed by a standard 1-year replacement parts warranty from the date of
purchase, to the original purchaser only. The 1-year replacement parts warranty covers power units, hydraulic cylinders, pneumatic
cylinders, and all other assembly components such as, but not limited to: cables, caster wheels, valves, switches, wheel vises etc.
This does not cover normal wear items such as, but not limited to: rubber wheel vise pads.
Titan Light Duty motorcycle lifts are warrantied for replacement parts only to the original purchaser for a period of 90 days from the
date of purchase. This 90 day replacement parts warranty covers items such as, but not limited to: hydraulic cylinder, casters, pedal
assemblies, wheel vises etc. This does not cover normal wear items such as, but not limited to: rubber wheel vise pads.
Titan Bulldog Moto Cradle Wheel Chock is warrantied for replacement parts, only to the original purchaser, for a period of 2-years
from the date of purchase.
XL Tool by Titan Wheel Service Machines and Helper Arm Assemblies are backed by a standard 1-year replacement parts warranty
from the date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers internal boards, motors,
pneumatic cylinders, and all other assembly components such as, but not limited to: cabinet, switches, valves, ttings etc. This does
not cover normal wear items such as but not limited to: rubber pads, jaw protectors, air hoses, quick nut assemblies.
Titan shop equipment products and accessories are warrantied for replacement parts only to the original purchaser for a period of
90 days from the date of purchase. This 90 day replacement parts warranty covers products such as but not limited to: EZ -Mover
Jacks, Mini Jacks, tie down products, wheel service accessories, Bulldog Moto Cradle Wheel Chock accessories, dollies, stands,
Multi-purpose Jacks, etc.
Titan TJ1T, FJ2T, and FJ3T are warrantied for replacement parts only to the original purchaser for a period of 1 year from the date of
purchase.
All non-serialized items will require proof of purchase in the form of a sales receipt from an authorized Titan Lifts dealer showing the
date of purchase for any warranty consideration.
For all warranty considerations, Titan Marketing, LLC will supply replacement parts only during the warranty period. The original
purchaser is responsible for all shipping, handling, and any labor charges incurred. Hydraulic/Pneumatic cylinders may qualify for
exchange under warranty if reported within the rst 30 days from date of sale. After the rst 30 days from date of sale, a seal kit and
installation instructions will be sent for cylinder repairs. All defective parts must be returned to Titan for inspection and examination.
Any parts that are found to be defective will be replaced or repaired to proper working order. Other items not listed above may be
considered general wear parts and therefore, will not be covered under warranty. These warranties do not extend to defects caused
by ordinary wear, abuse, misuse, shipping damage, improper installation, voltage or lack of required maintenance. Titan Marketing,
LLC is not to be held responsible for any failure that results from an accident, purchaser/operator abuse, neglect, or failure to operate
products in accordance with instructions provided in the owner’s manual(s) supplied. Damage caused by rain, excessive humidity,
corrosive environments or other contaminants are not covered under warranty. THESE WARRANTIES DO NOT EXTEND TO ANY
COSMETIC DEFECT NOT INTERFERING WITH EQUIPMENT FUNCTIONALITY OR ANY INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY DEFECT, FAILURE OR MALFUNCTION OF A TITAN MARKETING LLC
PRODUCT OR THE BREACH OR DELAY IN PERFORMANCE OF THE WARRANTY.

EQUIPMENT MODEL:
TYPE OF POWER UNIT:
DATE OF PURCHASE:
PLACE PURCHASED:
NAME:
STREET:
CITY, STATE, ZIP:
PHONE:
EMAIL:
SERIAL NUMBER:
SERIAL NUMBER:
WARRANTY REGISTRATION
OPT OUT OF PROMOTIONS
In order to utilize the warranty on this Titan Lifts product, you must register your product with us. The
simplest way to do this is to visit TITANLIFTS.COM/WARRANTIES and submit your information online. If you
prefer to send your information through the mail, please ll out the form below and send this page to us at :
Titan Lifts
PO Box 7069
Greenwood, IN 46142
In order to receive your warranty, return this card
or visit TITANLIFTS.COM/WARRANTIES within 30 days.

NOTES

WARNING
The warnings, precautions and instructions in this manual cannot
cover all possible conditions and situations that may occur. The
operator must understand that the operator must supply common
sense and examine caution factors when using this product to
determine safety in all circumstances being used.
®
PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
Copyright © 2022 by Titan Marketing, LLC. All rights reserved. No portion of this manual or any artwork contained herein may be
reproduced in any shape or form without the express consent of Titan Marketing, LLC. Diagrams within this manual may not be
drawn proportionally. Due to continuing improvements, actual product may di󰀨er slightly from the product described herein. Tools
required for assembly and service may not be included.
Patent No.: US 8,104,588 B2
CA 2,729,670 5/11/22
