Titan FJ2T Instruction manual

INSTALLATION, OPERATION
& MAINTENANCE MANUAL
FOLLOW THIS MANUAL CAREFULLY TO ENSURE THE EQUIPMENT WILL
FUNCTION CORRECTLY AND PROVIDE MANY YEARS OF DEPENDABLE SERVICE.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND SAFETY WARNINGS MAY
RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE. KEEP THIS MANUAL IN A
SAFE DRY PLACE FOR FUTURE REFERENCE.
MODEL:
FJ2T
2 TON (4,000 LB) CAPACITY HYDRAULIC FLOOR JACK
®

Products May Be
Upgraded Without Notice
Please Visit
WWW.TITANLIFTS.COM
For The Latest Version Of
This Manual
P.O. Box 7069 • Greenwood, IN 46142 • Ph. 888-908-4826 • Fx. 317-215-2770 • www.titanlifts.com

PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
®
To Our Valued Customers:
Thank you for purchasing a Titan Lifts®product. We hope this high quality equipment provides you with years of
dependable service.
It is unfortunate that rare situations may occur with the products you purchase from Titan Lifts®. We value your
business as well as the trust you have and need to maintain your relationship with us. Titan Lifts®carries liability
coverage that may protect our customers if a situation does occur. However, as in all accidents there must be
proof of liability for a claim to be made. Our insurance company requires the following procedures be observed in
order to consider a claim:
A. The claimant must contact the Titan Lifts®distributor immediately with the facts of the situation.
B. If any equipment is damaged, including vehicles or shop equipment, Titan Lifts®must be given the
opportunity to send an impartial representative to the site for proper assessment of the situation.
C. The Vehicle cannot be moved until either an impartial representative has reviewed the accident or clear
and precise pictures are taken that reect all the pertinent information for an impartial representative to be able
to access the information from a distance. Titan Lifts®or its representatives must approve the pictures before
anything can be moved.
D. If any potential liability is determined on behalf of Titan Lifts®, two estimates must be submitted for
damages to be reimbursed.
It is imperative that the claimant complies with these procedures, because without proper assessment of the
situation a claim will be denied.
ARBITRATION NOTICE
The installation or use of this equipment shall constitute an acknowledgement that the user agrees to resolve any
and all disputes or claims of any kind whatsoever, which relate in any way to the equipment, by way of binding
arbitration, not litigation. No suit or legal action may be led in any state or federal court. Any arbitration shall be
governed by the Federal Arbitration Act, and administered by the American Mediation Association, Indianapolis
Indiana. The maximum amount that an arbitrator may award and all damages shall not exceed the retail value of
this equipment.
WARRANTY NOTICE
This equipment must be assembled and used in the manner according to the documentation provided to be
covered by warranty.
Damaged or missing components must be reported within 72 hours of receipt to your freight carrier and to the
distributor. Claims must be led to cover cost.
If you have any questions or if we can be of any further assistance, please don’t hesitate to contact a Titan Lifts®
representative at 1-888-908-4826. Thank you for the opportunity to continue to serve your lift equipment needs.

1
SPECIFICATIONS
DESCRIPTION
Rated capacity 2 Ton (4,000 LB)
Min. Height 2-3/4”
Max. Height 23-1/2”
Length 32-5/8”
Net Weight 100 LB
1. Locate the jack in a suitable working area.
2. Inspect the jack before each use. Do not use jack if damaged, altered, modied, in poor
condition, leaking hydraulic uid, or unstable due to loose or missing hardware or parts.
Make corrections before using
3. Use jack on level and solid ground, preferably concrete. Avoid asphalt as jack may sink
in. Chock wheels of vehicle.
4. Ensure the vehicle parking brake is engaged, engine is switched off and transmission in
gear (or “PARK” if automatic).
5. Ensure minimum distance of 18” between vehicle and static objects such as doors,
walls, etc, to allow for vehicle tilting.
6. Ensure all non-essential persons keep a safe distance while the jack is in use.
7. Ensure there are no passengers in the vehicle.
8. Place jack under only those lifting points recommended by vehicle manufacturer (see
vehicle handbook)
9. Check that the lifting point is stable and centered on the jack saddle.
10. Ensure the jack wheels are free to move and that there are no obstructions.
11. Danger : Use the jack for lifting only
12. Ensure there are no persons or obstructions beneath the vehicle before lowering.
13. Use suitable jack stands under the vehicle before proceeding with any task.
14. Use a qualied person to lubricate and maintain the jack.
15. Wear ANSI-approved safety goggles and heavy-duty working gloves during use.
SAFETY PRECAUTIONS
This hydraulic oor jack is designed to lift, but not support, one end of a vehicle.
Immediately after lifting, load must be supported by at least two appropriately rated jack
stands.

2
ASSEMBLY
WARNING: READ ENTIRE MANUAL AND COMPLY WITH ALL SAFETY AND
SERVICE PRECAUTIONS. DEATH, PERSONAL INJURY AND / OR PROPERTY DAMAGE MAY
OCCUR IF INSTRUCTIONS ARE NOT FOLLOWED CAREFULLY.
WARNING: BEFORE OPERATING THE FLOOR JACK, MAKE SURE THAT ALL THE
HARDWARE IS SECURE AND THE UNIT HAS BEEN TESTED PROPERLY.
RECEIVING INSTRUCTIONS
16. Ensure that only hydraulic jack oil is used in the jack.
17. DO NOT operate the jack if damaged.
18. DO NOT allow untrained persons to operate the jack.
19. DO NOT exceed the rated capacity of the jack.
20. DO NOT allow the vehicle to move during lifting or lowering, or use the jack to move the
vehicle.
21. DO NOT jack vehicle if there is a risk of spillage of fuel, battery acid, or other dangerous
substances.
22. DO NOT work under the vehicle until appropriately rated jack stands have been correctly
placed under the vehicle.
23. DO NOT ll hydraulic system with brake uid, alcohol or transmission uid. Use
hydraulic jack oil only.
24. DO NOT adjust the safety overload valve
25. DO NOT use for aircraft purposes
26. When not in use store jack, fully lowered, in a safe, dry, childproof location.
27. The warnings, precautions, and instructions discussed in this manual cannot cover all
possible conditions and situations that may occur. The operator must understand that
common sense and caution are factors, which cannot be built into this product, but
must be supplied by the operator.
Visually inspect all components for shipping damage. If any shipping damage is found,
notify carrier at once. Shipping damage is NOT covered by warranty.
No. Description Qty
1 Handle Tube 1 1
2 Handle Tube 2 1
3 Jack Body 1
4 Instruction Manual 1
1
24
3

3
ASSEMBLY
1) The jack is comprised the following parts, Jack body, Two-part pumping handle.
2) Unscrew the bolt from handle tube 1, Insert the upper handle into the lower handle.
Secure the two pieces together with the bolt.
(1) Handle Tube 1
3) The handle socket is pressed down and supported by nylon
supporting block in the package during transportation. Before
assembling, please take out the nylon supporting block.
4) Undo the screw(B) in the handle socket, until it no longer
protrudes into the handle socket.
5) Insert the pump handle into the handle socket hole
completely.
6) Ensure that the handle is correctly inserted into the
socket, then tighten the handle socket screw (B). Please
make sure that the handle can be turned smoothly.
(2) Unscrew the bolt from
the handle
(3) Insert the upper tube (4) Tighten the bolt
B

4
HYDRAULIC SYSTEM PURGING
1. Open the release valve by turning it two full turns counter-clockwise.
2. Pump the handle four full strokes quickly.
3. Close the release valve by turning it clockwise.
4. Pump the handle with full strokes to check if it can reach the maximum height within
ten pumps.
If it can’t reach the maximum height within ten pumps, please refer to the following special
purging process:
5. Open the release valve by turning counter-clockwise and lower the lifting arm to the
minimum height.
6. Put the jack on a at working table, lift the front part of
the jack to make sure the front part is at least 18” higher
than the back part of the jack. See the following photo.
7. Pump the handle four full strokes quickly.
8. Put the jack on a at surface and close the release valve
by turning it clockwise.
9. Pumping the handle with full strokes to check if it can
reach the maximum height within ten pumps. If not
please repeat the special purging process again.
OPERATING INSTRUCTIONS
WARNING: ENSURE THAT YOU READ, UNDERSTAND AND APPLY THE SAFETY
INSTRUCTIONS AND WARNINGS BEFORE USE. FAILURE TO HEED THESE INSTRUCTIONS
MAY RESULT IN PROPERTY DAMAGE AND/OR PERSONAL INJURY.
RAISING A VEHICLE
1. Ensure that the jack and the vehicle are on a hard, level surface.
2. Always ensure that the vehicle parking brake is engaged and that the vehicle wheels are
chocked.
3. Consult the vehicle manual to determine the location of jacking points. Position the jack
under a suitable lifting point.
4. Turn the handle clockwise, to close release valve. DO NOT over-tighten.
5. Raise the vehicle to the desired height by pumping the handle up and down.
6. Place jack stands beneath the locations recommended by the vehicle manufacturer.
7. Turn the release valve slowly counter-clockwise to lower the vehicle on to the jack
stands.

5
1. Lubricate the linkages, the saddle, and pump mechanism with light oil.
2. Grease the wheel bearing and axles.
3. Keep all jack surfaces and warning labels clean.
4. Check the pump for any signs of rust or corrosion. Clean the pump as required.
MAINTENANCE
MONTHLY MAINTENANCE
Lubrication is critical to jacks, since they support heavy loads. Any restriction due to dirt
or rust can cause slow jack movement or extremely rapid jerks, causing damage to the
internal components. To keep the jack well lubricated, carry out the following steps.
LOWERING A VEHICLE
1. Turn the release valve clockwise to close it.
2. Pump the handle to raise the vehicle off the jack stands.
3. Remove the jack stands from beneath the vehicle.
4. Turn the release valve slowly counter-clockwise to lower the vehicle to the ground.
NOTE: When the jack is not in use, ALWAYS leave the saddle and ram fully retracted.
CAUTION: Keep hands and feet away from the hinge mechanism of the jack
IMPORTANT: Only fully qualied personnel should attempt maintenance or repair.
Linkage (1)
Roller Pin (right) Roller Pin (left) Lifting Arm
Linkage (2)

6
TROUBLESHOOTING
Problem Cause Solution
Jack will not lift to full height 1. Oil level low
2. Release valve not closing
1. Check / add oil
2. Close the release valve
Jack will not hold the load 1. Hydraulic oil is contaminated
2. Pump leaking
1. Contact authorized service
agent
Lift arm will not lower
1. Pump cylinder binding
2. Parts worn
3. Internal component damage
4. Return spring broken or
unhooked
5. Lift arm linkage bent or
binding
6. Air in the hydraulic system
1. Contact authorized service
agent
After hydraulic purging, the jack
cannot reach the maximum
height within 10 pumps
1. Follow all the purge
instructions on page 4
Poor lift performance 1. Fluid level low
2. Hydraulic unit malfunction
1. Ensure proper uid level
2. Discontinue use, contact
authorized service agent

7
PARTS DIAGRAMS & LISTS
DIAGRAM 1

8
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
1 UPPER HANDLE SECTION 1 23 LOCK WASHER 4
2 BOLT 1 24 C-CLIP 2
3 LOWER HANDLE SECTION 1 25 NUT 2
4 FOAM HANDLE SLEEVE 1 26 FRAME BASE 1
5 C-CLIP 2 27 ADJUSTMENT SCREW 2
6 C-CLIP 1 28 RIGHT ADJUST PLATE 1
7 FOOT PEDAL 1 29 C-CLIP 2
8 PIN 1 30 FLAT WASHER 2
9 PUMP SPINDLE 1 31 FRONT WHEEL 2
10 LOCK WASHER 2 32 COVER PLATE 1
11 BOLT 2 33 SCREW 4
12 HANDLE SOCKET 1 34 LEFT ADJUST PLATE 1
13 BOLT 1 35 ZERK FITTING 1
14 LIMITING BAR 2 36 LIFT ARM ASSEMBLY 1
15 SPRING 1 37 LIFT ARM SHAFT 1
16 WASHER 2 38 SADDLE BOLT 1
17 LOCK WASHER 4 39 SADDLE 1
18 BOLT 4 40 C-CLIP 2
19 NUT 2 41 PUMP ASSEMBLY 1
20 LOCK WASHER 4 42 SPRING 2
21 REAR CASTER 2 43 ROLL PIN 1
22 BOLT 4 44 ROD ASSEMBLY 1
PARTS LIST 1

NOTES

10
EQUIPMENT MODEL:
TYPE OF POWER UNIT:
DATE OF PURCHASE:
PLACE PURCHASED:
NAME:
STREET:
CITY, STATE, ZIP:
PHONE:
EMAIL:
SERIAL NUMBER:
SERIAL NUMBER:
WARRANTY REGISTRATION
OPT OUT OF PROMOTIONS
In order to utilize the warranty on this Titan Lifts product, you must register your product with us. The
simplest way to do this is to visit TITANLIFTS.COM/WARRANTIES and submit your information online. If you
prefer to send your information through the mail, please ll out the form below and send this page to us at :
Titan Lifts
PO Box 7069
Greenwood, IN 46142
In order to receive your warranty, return this card
or visit TITANLIFTS.COM/WARRANTIES within 30 days.

P.O. Box 7069 • Greenwood, IN 46142 • Ph. 888-908-4826 • Fx. 317-215-2770 • www.titanlifts.com
LIMITED WARRANTY
The Titan 2 Post lifts, 4 Post lifts and Bridge Jacks are backed by a standard 1-year replacement parts warranty and a 5-year
structural warranty from the date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers power
units, hydraulic cylinders, and all other assembly components such as, but not limited to: turn plates, slip plates, cables, chains,
valves, switches etc. This does not cover normal wear items such as, but not limited to: rubber lifting pads and nylon slide blocks.
Titan Elite model lifts have been discontinued but still qualify under the same terms as shown above.
Titan SL-6600 Scissor Lifts and PREMIER Series 2 Post Lifts are backed by a 2-year replacement parts warranty and a 5-year
structural warranty from the date of purchase, to the original purchaser only. The 2-year replacement parts warranty covers power
units, hydraulic cylinders, and all other assembly components such as, but not limited to: valves, switches, capacitors etc. This does
not cover normal wear items such as, but not limited to: rubber lifting pads, nylon slide blocks and rubber arm pads.
Titan MRL-6000 Scissor lifts are backed by a standard 1-year replacement parts warranty and a 5-year structural warranty from the
date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers power units, hydraulic cylinders, and
all other assembly components such as, but not limited to: valves, switches, capacitors etc. This does not cover normal wear items
such as but not limited to rubber lifting pads.
Titan ROT-4500 Rotisseries are backed by a standard 1-year replacement parts warranty from the date of purchase, to the original
purchaser only. The 1-year replacement parts warranty covers components such as, but not limited to: hydraulic cylinders, caster
assemblies, bearings etc. This does not cover normal wear items such as, but not limited to, mounting adapters.
Titan Standard Duty and Heavy Duty motorcycle lifts are backed by a standard 1-year replacement parts warranty from the date of
purchase, to the original purchaser only. The 1-year replacement parts warranty covers power units, hydraulic cylinders, pneumatic
cylinders, and all other assembly components such as, but not limited to: cables, caster wheels, valves, switches, wheel vises etc.
This does not cover normal wear items such as, but not limited to: rubber wheel vise pads.
Titan Light Duty motorcycle lifts are warrantied for replacement parts only to the original purchaser for a period of 90 days from the
date of purchase. This 90 day replacement parts warranty covers items such as, but not limited to: hydraulic cylinder, casters, pedal
assemblies, wheel vises etc. This does not cover normal wear items such as, but not limited to: rubber wheel vise pads.
Titan Bulldog Moto Cradle Wheel Chock is warrantied for replacement parts, only to the original purchaser, for a period of 2-years
from the date of purchase.
XL Tool by Titan Wheel Service Machines and Helper Arm Assemblies are backed by a standard 1-year replacement parts warranty
from the date of purchase, to the original purchaser only. The 1-year replacement parts warranty covers internal boards, motors,
pneumatic cylinders, and all other assembly components such as, but not limited to: cabinet, switches, valves, ttings etc. This does
not cover normal wear items such as but not limited to: rubber pads, jaw protectors, air hoses, quick nut assemblies.
Titan shop equipment products and accessories are warrantied for replacement parts only to the original purchaser for a period of
90 days from the date of purchase. This 90 day replacement parts warranty covers products such as but not limited to: EZ -Mover
Jacks, Mini Jacks, tie down products, wheel service accessories, Bulldog Moto Cradle Wheel Chock accessories, dollies, stands,
Multi-purpose Jacks, etc.
Titan TJ1T, FJ2T, and FJ3T are warrantied for replacement parts only to the original purchaser for a period of 1 year from the date of
purchase.
All non-serialized items will require proof of purchase in the form of a sales receipt from an authorized Titan Lifts dealer showing the
date of purchase for any warranty consideration.
For all warranty considerations, Titan Marketing, LLC will supply replacement parts only during the warranty period. The original
purchaser is responsible for all shipping, handling, and any labor charges incurred. Hydraulic/Pneumatic cylinders may qualify for
exchange under warranty if reported within the rst 30 days from date of sale. After the rst 30 days from date of sale, a seal kit and
installation instructions will be sent for cylinder repairs. All defective parts must be returned to Titan for inspection and examination.
Any parts that are found to be defective will be replaced or repaired to proper working order. Other items not listed above may be
considered general wear parts and therefore, will not be covered under warranty. These warranties do not extend to defects caused
by ordinary wear, abuse, misuse, shipping damage, improper installation, voltage or lack of required maintenance. Titan Marketing,
LLC is not to be held responsible for any failure that results from an accident, purchaser/operator abuse, neglect, or failure to operate
products in accordance with instructions provided in the owner’s manual(s) supplied. Damage caused by rain, excessive humidity,
corrosive environments or other contaminants are not covered under warranty. THESE WARRANTIES DO NOT EXTEND TO ANY
COSMETIC DEFECT NOT INTERFERING WITH EQUIPMENT FUNCTIONALITY OR ANY INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY DEFECT, FAILURE OR MALFUNCTION OF A TITAN MARKETING LLC
PRODUCT OR THE BREACH OR DELAY IN PERFORMANCE OF THE WARRANTY.

WARNING
The warnings, precautions and instructions in this manual cannot
cover all possible conditions and situations that may occur. The
operator must understand that the operator must supply common
sense and examine caution factors when using this product to
determine safety in all circumstances being used.
®
PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
Copyright © 2019 by Titan Marketing, LLC. All rights reserved. No portion of this manual or any artwork contained herein may be
reproduced in any shape or form without the express consent of Titan Marketing, LLC. Diagrams within this manual may not be
drawn proportionally. Due to continuing improvements, actual product may di󰀨er slightly from the product described herein. Tools
required for assembly and service may not be included.
Patent No.: US 8,104,588 B2
CA 2,729,670 4/30/19
