Toa VX-3000 SERIES User manual

INSTALLATION MANUAL
INTEGRATED VOICE EVACUATION SYSTEM
VX-3000 SERIES
Thank you for purchasing TOA’s Integrated Voice Evacuation System.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1134
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg, Germany
1134-CPR-195
EN 54-16: 2008
Fire Detection and fire alarm systems - part 16: Voice alarm control and
indication system for fire detection and fire alarm systems for buildings
Options:
Manual silencing of voice alarm condition
manual reset of voice alarm condition
voice alarm condition output
indication of a fault related to voice alarm zones
voice alarm manual control
emergency microphones
redundant power amplifiers
16
DOP 16-004
When an EN 54-16 compliant VX-3000 system has to be installed, then carefully read the separate manual
titled "APPENDIX: ADDITIONAL INSTALLATION INSTRUCTIONS FOR AN EN 54-16 COMPLIANT
SYSTEM" and follow up the installation and configuration requirements explained therein. This APPENDIX
contains the basic description of settings and installations, so please refer to the general instruction
sections in this document for more details.

2
TABLE OF CONTENTS
Chapter 1 : NOTE
1. SAFETY PRECAUTIONS .......................................................................... 1-2
2. GENERAL DESCRIPTION ....................................................................... 1-6
3. SYSTEM FEATURES ................................................................................... 1-6
4. SYSTEM EXAMPLE ..................................................................................... 1-6
Chapter 2 : NOMENCLATURE AND FUNCTIONS
1. VX-3004F/3008F/VX-3016F
VOICE EVACUATION FRAME ............................................................... 2-2
2. VX-015DA/030DA/050DA
DIGITAL POWER AMPLIFIER MODULE ....................................... 2-9
3. VX-300LO LINE OUTPUT MODULE ................................................ 2-11
4. VX-3000PM PREAMP MATRIX PANEL ......................................... 2-12
5. VX-3000CT CONTROL PANEL ........................................................... 2-16
6. RM-200SF FIREMAN'S MICROPHONE ........................................ 2-18
7. RM-320F FIREMAN'S MICROPHONE EXTENSION ............. 2-21
8. RM-300X REMOTE MICROPHONE ................................................. 2-22
9. RM-210F REMOTE MICROPHONE EXTENSION ................... 2-25
10. RM-200RJ TERMINAL UNIT .............................................................. 2-26
11. RM-500 REMOTE MICROPHONE .................................................. 2-27
12. SX-200EL END OF LINE UNIT ........................................................ 2-30
13. VM-300SV END OF LINE UNIT ....................................................... 2-30
Chapter 3 : INSTALLATION AND SETTING PROCEDURES
(HARDWARE)
1. VX-015DA, VX-030DA, AND VX-050DA
DIGITAL POWER AMPLIFIER MODULE ....................................... 3-2
1.1. Changing the Speaker Line Voltage .................................................................. 3-2
1.2. Replacing the Blade Fuse ................................................................................. 3-2

3
2. VX-3004F, VX-3008F, AND VX-3016F
VOICE EVACUATION FRAME .............................................................. 3-3
2.1. Installing VX-015DA/030DA/050DA Digital Power Amplifier Module ................ 3-3
2.2. The Zones Allocation Setting ............................................................................ 3-5
3. VX-300LO LINE OUTPUT MODULE .................................................. 3-7
3.1. The ID Number Setting ...................................................................................... 3-9
3.2. Setting the IP Address ..................................................................................... 3-10
4. VX-3000PM PREAMP MATRIX PANEL ......................................... 3-11
4.1. Setting the IP Address ...................................................................................... 3-11
5. VX-3000CT CONTROL PANEL ........................................................... 3-14
5.1. Setting the IP Address ...................................................................................... 3-14
6. RM-200SF, RM-300X, AND RM-500 MICROPHONES ........ 3-19
6.1. The ID Number Settings (RM-200F and RM-300X: Switches 1 – 3 operation
or RM-500: Switches 2 – 4 operation) .............................................................. 3-19
6.2. Adjusting Microphone Sensitivity .................................................................... 3-22
6.3. Setting The RM-500's Menu ............................................................................ 3-24
6.4. CPU Off Function (All-Zone Emergency Broadcast) Settings
(RM-200SF: Switch 6 operation or RM-300X: Switch 5 operation) ................ 3-30
6.5. Termination Setting
(RM-200SF, RM-500: Switch 8 operation) ...................................................... 3-31
6.6. Using an External Microphone (RM-300X Only) ............................................ 3-32
6.7. Setting the Level of the AUX Input Terminal (RM-500 Only) ........................... 3-33
6.8. Setting for using the direct selection mode (RM-500 Only) ............................ 3-33
6.9. Using an Auxiliary Input (RM-300X Only) ....................................................... 3-34
6.10. Compressor Function Setting (RM-200SF and RM-300X only) .................... 3-36
6.11. Microphone Fault Detection Function Setting (RM-300X Only) .................... 3-38
6.12. Installing the RM-200SF on a Wall ................................................................ 3-39
6.13. Installing the RM-320F on a Wall (RM-200SF only) ...................................... 3-43
6.14. RM-300X Extension with the Addition of the RM-210F
(Installed on a Flat Surface) .......................................................................... 3-45
6.15. Installing the RM-300X on a Wall .................................................................. 3-46
6.16. Installing the RM-210F on a Wall (RM-300X Only) ....................................... 3-47
6.17. Installing the RM-500 on a Wall ..................................................................... 3-49
6.18. Creating Remote Microphone Name Labels
(RM-200SF, RM-320F, RM-300X, and RM-210F only) .................................... 3-52
7. RACK MOUNTING ...................................................................................... 3-55
7.1. Affixing Declaration of Compliance (EN 54-16 Standard) ................................ 3-56
8. CONNECTIONS ........................................................................................... 3-57
8.1. Removable Terminal Plug Connection ............................................................ 3-57
8.2. Connecting the Cable to the Push-in Terminal Block ..................................... 3-58
8.3. Input Equipment Connections ......................................................................... 3-59
8.4. Speaker Connection ........................................................................................ 3-77
8.5. Control Output Terminal Connections ............................................................. 3-80
8.6. Control Input Terminal Connections ............................................................... 3-81
8.7. Emergency Control Input Terminal Connections ............................................. 3-82
8.8. VX-3000 Unit's LAN Link Connector Connection ........................................... 3-83
8.9. Sharing Standby Amplifier .............................................................................. 3-89

4
8.10. Speaker Selector Extension .......................................................................... 3-90
8.11. Analog Link Terminal Connections ................................................................ 3-91
8.12. Preamp Matrix Panel Connection .................................................................. 3-92
8.13. Control Panel Connections ............................................................................ 3-95
9. SPEAKER LINE INITIAL SETTING ................................................. 3-96
9.1. Setting Items .................................................................................................... 3-96
9.2. OPEN/SHORT Criterion by Comparing the Current Value
with the Initial Value ........................................................................................ 3-96
9.3. Setting Procedures ......................................................................................... 3-97
Chapter 4 : APPENDIX
1. THE FIRMWARE VERSION CONFIRMATION ............................ 4-2
2. SPECIFICATIONS ......................................................................................... 4-4
2.1. VX-3004F Voice Evacuation Frame 4AB .......................................................... 4-4
2.2. VX-3008F Voice Evacuation Frame 8SS ........................................................... 4-7
2.3. VX-3016F Voice Evacuation Frame 16SS ....................................................... 4-10
2.4. VX-015DA Digital Power Amplifier Module 150 W ........................................... 4-13
2.5. VX-030DA Digital Power Amplifier Module 300 W .......................................... 4-14
2.6. VX-050DA Digital Power Amplifier Module 500 W .......................................... 4-15
2.7. VX-300LO Line Output Module ........................................................................ 4-16
2.8. VX-3000PM Preamp Matrix Panel ................................................................... 4-17
2.9. VX-3000CT Control Panel ............................................................................... 4-18
2.10. RM-200SF Fireman's Microphone ................................................................. 4-19
2.11. RM-320F Fireman's Microphone Extension .................................................. 4-20
2.12. RM-300X Remote Microphone ...................................................................... 4-21
2.13. RM-210F Remote Microphone Extension ..................................................... 4-22
2.14. RM-200RJ Terminal Unit ............................................................................... 4-22
2.15. RM-500 Remote Microphone ....................................................................... 4-23
2.16. WB-RM500 Wall Mounting Bracket ................................................................ 4-24
2.17. VM-300SV End Of Line Unit ........................................................................... 4-24

Chapter 1
NOTE

1-2
Chapter 1 NOTE
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe
operation.
• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or
cautions regarding safety.
• After reading, keep this manual handy for future reference.
• This equipment is not suitable for use in locations where children are likely to be present.
• An equipment installer and the person in charge of maintenance are required to fully understand the functions
and structure of this unit, then be aware of electrical and mechanical risks before work.
Before starting work, he or she should take possible measures to prevent occurrence of such risks.
Be sure to contact your nearest TOA dealer if you need to conrm unclear points about risk sources of this
unit.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property
damage which could result from mishandling. Before operating your product, read this manual rst and
understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.
When Installing the Unit
• (Except VX-300LO)
Do not expose the unit to rain or an environment where it may be splashed by water or other liquids, as doing
so may result in re or electric shock.
• (Applicable to VX-3004F, VX-3008F, VX-3016F, VX-015DA, VX-030DA, VX-050DA, VX-3000PM, VX-3000CT,
RM-200SF, RM-300X, RM-500, VX-3000DS, and VX-3150DS only)
Use the unit only with the voltage specied on the unit. Using a voltage higher than that which is specied
may result in re or electric shock.
• (Applicable to VX-3000DS and VX-3150DS only)
Do not cut, kink, otherwise damage nor modify the power supply cord. In addition, avoid using the power cord
in close proximity to heaters, and never place heavy objects -- including the unit itself -- on the power cord,
as doing so may result in re or electric shock.
• (Applicable to RM-200SF, RM-300X, RM-500, RM-320F, and RM-210F only)
Avoid installing or mounting the unit in unstable locations, such as on a rickety table or a slanted surface.
Doing so may result in the unit falling down and causing personal injury and/or property damage.
• (Applicable to RM-200SF, RM-300X, RM-500, RM-320F, and RM-210F only)
Install the unit only in a location that can structurally support the weight of the unit and the mounting bracket.
Doing otherwise may result in the unit falling down and causing personal injury and/or property damage.
• Since the unit is designed for indoor use, do not install it outdoors. If installed outdoors, the aging of parts
causes the unit to fall off, resulting in personal injury. Also, when it gets wet with rain, there is a danger of
electric shock.
When the Unit is in Use
• Should the following irregularity be found during use, immediately switch off the power, disconnect the power
supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the
unit in this condition as this may cause re or electric shock.
· If you detect smoke or a strange smell coming from the unit
· If water or any metallic object gets into the unit
· If the unit falls, or the unit case breaks
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
WARNING

1-3
Chapter 1 NOTE
· (Applicable to VX-3000DS and VX-3150DS only)
If the power supply cord is damaged (exposure of the core, disconnection, etc.)
· If it is malfunctioning (no tone sounds)
• To prevent a re or electric shock, never open nor remove the unit case as there are high voltage components
inside the unit.
Refer all servicing to qualied service personnel.
• Do not place cups, bowls, or other containers of liquid or metallic objects on top of the unit. If they accidentally
spill into the unit, this may cause a re or electric shock.
• (Applicable to VX-3004F, VX-3008F, VX-3016F, VX-015DA, VX-030DA, VX-050DA, VX-3000DS, and VX-
3150DS only)
Do not insert nor drop metallic objects or ammable materials in the ventilation slots of the unit’s cover, as this
may result in re or electric shock.
• (Applicable to VX-3000DS and VX-3150DS only)
Do not touch a power supply plug during thunder and lightning, as this may result in electric shock.
• When replacing the fuse, be sure to use the supplied one. Using any other fuse than supplied may cause re
or electric shock.
VX-015DA: Blade 10 A
VX-030DA: Blade 20 A
VX-050DA: Blade 30 A
VX-3000DS and VX-3150DS: AC T8A H, AC T6.3A L, and Blade 35 A
• Be sure to switch off the amplier's power when replacing the fuse.
Inserting or removing the fuse with the amplier's power on may cause personal injury.
• (Applicable to VX-3000DS and VX-3150DS only)
Handle or use the batteries properly.
Doing otherwise may cause leakage or explosion of the batteries, resulting in a re, personal injury, damage
to peripheral equipment, or contamination of environment.
When Installing the Unit
• (Applicable to VX-3000DS and VX-3150DS only)
Never plug in nor remove the power supply plug with wet hands, as doing so may cause electric shock.
• (Applicable to VX-3000DS and VX-3150DS only)
When unplugging the power supply cord, be sure to grasp the power supply plug; never pull on the cord itself.
Operating the unit with a damaged power supply cord may cause a re or electric shock.
• (Applicable to VX-3004F, VX-3008F, VX-3016F, VX-015DA, VX-030DA, VX-050DA, VX-3000DS, and VX-
3150DS only)
Do not block the ventilation slots in the unit’s cover. Doing so may cause heat to build up inside the unit and
result in re.
(Applicable to VX-015DA, VX-030DA, and VX-050DA only)
Also, periodically clean the ventilation slots of dust.
• Avoid installing the unit in humid or dusty locations, in locations exposed to the direct sunlight, near the
heaters, or in locations generating sooty smoke or steam as doing otherwise may result in re or electric
shock.
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
CAUTION

1-4
Chapter 1 NOTE
• (Applicable to VX-3004F, VX-3008F, VX-3016F, VX-015DA, VX-030DA, VX-050DA, VX-3000PM, VX-3000CT,
RM-200SF, RM-300X, VX-3000DS, and VX-3150DS only)
Note correct polarity (positive and negative orientation) when connecting the power supply cord. Reversed
polarity connections will cause damage to the unit.
• (Applicable to VX-015DA, VX-030DA, and VX-050DA only)
To avoid electric shocks, be sure to switch off the VX-3000F’s power when connecting the unit.
• (Applicable to VX-3004F, VX-3008F, VX-3016F, VX-3000PM, VX-3000CT, VX-3000DS, and VX-3150DS
only)
System units (except remote microphones) are designed exclusively to be mounted in an equipment rack.
Be sure observe the following instructions when rack-mounting the unit. Failure to do so may cause a re or
personal injury.
· Install the equipment rack on a stable, hard oor. Fix it with anchor bolts or take other arrangements to
prevent it from falling down.
· (Applicable to VX-3004F, VX-3008F, VX-3016F, VX-3000PM, and VX-3000CT only)
The supplied rack-mounting screws can be used for the TOA equipment rack only. Do not use them for other
racks.
· (Applicable to VX-3000DS and VX-3150DS only)
Rack-mounting screws are not supplied with the unit. Prepare them that are appropriate for the equipment rack .
· (Applicable to VX-3000DS and VX-3150DS only)
When connecting the unit’s power cord to an AC outlet, use the AC outlet with current capacity allowable to
the unit.
• (Applicable to VX-3000DS and VX-3150DS only)
When connecting multiple appliances to a single power socket through a multi-outlet power strip, a total
current consumption of the appliances must not exceed the allowable current capacity of the power socket.
Failure to observe this instruction may result in a re or electric shock.
• (Applicable to VX-3000DS and VX-3150DS only)
When 2 or more AC power cords are connected to a multi-outlet power strip, never remove the power strip
from a power source.
When the Unit is in Use
• (Applicable to VX-3004F, VX-3008F, VX-3016F, VX-015DA, VX-030DA, VX-050DA, and VX-3000PM only)
Do not operate the unit for an extended period of time with the sound distorting. Doing so may cause the
connected speakers to heat, resulting in a re.
• (Applicable to RM-200SF, RM-300X, and RM-500 only)
Use the specied AC adapter for the unit. Note that the use of other adapter may cause a re.
• (Applicable to VX-015DA, VX-030DA, and VX-050DA only)
Contact your TOA dealer as to the cleaning. If dust is allowed to accumulate in the unit over a long period of
time, a re or damage to the unit may result.
• (Applicable to VX-3000DS and VX-3150DS only)
Make sure to observe the following handling precautions so that a re or personal injury does not result from
leakage or explosion of the battery.
· Do not short, disassemble, heat nor put the battery into a re.
· Avoid using both new and old batteries together.
· Never charge batteries of the type which are not rechargeable.
· Do not solder a battery directly.
· Be sure to use the specied type of batteries.
· Note correct polarity (positive and negative orientation) when connecting a battery to the unit.
· Avoid locations exposed to the direct sunlight, high temperature and high humidity when storing batteries.
• (Applicable to RM-200SF, RM-300X, RM-500, RM-320F, and RM-210F only)
Have the unit checked periodically by the shop from where it was purchased. Failure to do so may result
in corrosion or damage to the unit or its mounting bracket that could cause the unit to fall, possibly causing
personal injury.

1-5
Chapter 1 NOTE
Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment
may cause radio interference.

1-6
Chapter 1 NOTE
2. GENERAL DESCRIPTION
The TOA VX-3000 Series Integrated Voice Evacuation System is designed for both general and emergency
purpose broadcasts.
It is comprised of the Voice Evacuation Frame, Digital Power Amplier modules, Line Output module, Preamp
Matrix Panel, Control Panel, Power Supply unit, Emergency Power Supply, and a user-specied number of
Remote Microphones.
The system complies with the EN54-16 Standard and its failure detection circuitry operates continuously to
check components and speaker lines for any irregularities. If detected, failure warnings are provided by way of
an LED indicator and a buzzer.
The VX-3000 system allows 4 types of broadcasts to be made: General-purpose broadcast such as general
paging and BGM, Emergency warning broadcast that can be broadcast with priority over the Emergency
broadcast, Emergency broadcast that the emergency messages are to be broadcast by an automatic
announcement device or remote microphone, All-zone emergency broadcast* that is to be made available even
during system malfunctions or failures.
Two patterns of the Emergency broadcast can be activated simultaneously.
The dedicated software is used to perform all necessary settings related to the entire system operation and
functions including system congurations, input-to-output signal routing, function assignment to the operation
keys, operation of the control terminals, and selection of the failure detection points.
* Available when an analog link is connected.
3. SYSTEM FEATURES
• VX-3000 system is a voice evacuation system.
• Decentralized conguration is possible via network.
• VX-3000 system is constructed up to 160 AB zones or 640 zones as system.
• Speaker Selector function is implemented, then VX-3000 system is able to cover many zones.
• A general broadcast for a sound quality regulating function is possible to digitalize all sound.
• A general broadcasting is possible by latitude setting of control input/output and priorities.
4. SYSTEM EXAMPLE
LAN
VX-3000 System
VX-3000 System
1A
1B
4A
4B
VX-3004F
BGM unit
RM-300X
RM-500
RM-210F RM-200SF RM-320F
VX-3000PM
VX-3000CT VX-015DA/030DA/050DA/300LO
VX-3000DS or VX-3150DS

Chapter 2
NOMENCLATURE AND FUNCTIONS

2-2
Chapter 2 NOMENCLATURE AND FUNCTIONS
1. VX-3004F/3008F/VX-3016F VOICE EVACUATION FRAME
VX-3004F, VX-3008F, and VX-3016F are collectively referred to as "VX-3000F" in this manual.
• The VX-3000F is a unit designed to control the Voice evacuation announcements of the VX-3000 series voice
evacuation system.
• The VX-3000F is equipped with the audio input terminals and has the module slots for optionally accommodating
3 kinds of digital power amplier modules and a line output module.
• Compatible with network, the system can be congured in distributed arrangement.
[Front]
Amplifier section Fault status section
[Amplifier section] [Fault status section]
9
10
11
12
13
14
15
16
17
18
19
20 21 22 23
1
2
3
5
6
7
8
4
VX-3004F
VX-3008F
Amplifier section Fault status section
1
2
3
5
6
7
8
[Amplifier section] [Fault status section]
9
10
11
12
13 14
15
16
17
18
19
20 21 22 23
4

2-3
Chapter 2 NOMENCLATURE AND FUNCTIONS
1. Power indicator (Green)
Lights when the power is supplied.
Flashes in standby state.
2. RUN indicator (Green)
Normally ashes continuously. Goes off while in
a CPU off state (p. 3-30). Also goes off while in
standby state*1.
*1 A state during power failures or a state that the
unit is internally initialized after power-on
3. Emergency indicator (Red)
Lights when the VX-3000 system is in an
emergency condition or while in a CPU off state
(p. 3-30).
4. CPU off indicator (Red)
Lights while in a CPU off state (p. 3-30).
5. LAN A indicator (Green)
Lights when the LAN link A connector (49) on the
rear panel is connected, and ashes during LAN
communications.
6. LAN B indicator (Green)
Lights when the LAN link B connector (49) on the
rear panel is connected, and ashes during LAN
communications.
7. RS link A indicator (Green)
Lights when the RS link A connector (50) on
the rear panel is connected, and ashes while
communications are being performed via the RS
link A connector.
8. RS link B indicator (Green)
Lights when the RS link B connector (50) on
the rear panel is connected, and ashes while
communications are being performed via the RS
link B connector.
 9.Amplierpeakindicators(Red)
Show the input signal state to the power amplier
when the module is installed.
The indicator corresponding to the module slot
port will light if the input signal level exceeds +0.5
dB*2.
It remains unlit when no module is installed.
10.Ampliersignalindicators(Green)
Show the input signal state to the power amplier
when the module is installed.
The indicator corresponding to the module slot
port will light if the input signal level exceeds - 25
dB*2.
It remains unlit when no module is installed.
VX-3016F
[Amplifier section] [Fault status section]
9
10
11
12
13
14
15
16
17
18
19
20 21 22 23
1
2
3
5
6
7
8
4
Amplifier section Fault status section
*2 0 dB = 1 V

2-4
Chapter 2 NOMENCLATURE AND FUNCTIONS
11.Amplieroperateindicators(Green)
The indicator corresponding to the module slot
port will light or go off depending on the operation
state of the power amplier when the power
amplier module is installed.
Operating status Indicator status
In-use Lit
Standby Unlit
DC fuse blowout Unlit
Protection* activated Unlit
* The built-in protection circuit operates if some
irregularities occur inside the amplier such as
abnormal temperature rise or fan failure.
It remains unlit when the line output module is
installed.
It remains unlit when no module is installed.
12.Amplierpowerindicators(Green)
The indicator corresponding to the module slot
port will light or go off depending on the operation
state of the power amplier when the power
amplier module is installed.
Operating status Indicator status
In-use Lit
Standby Lit
DC fuse blowout Unlit
Protection* activated Lit
* The built-in protection circuit operates if some
irregularities occur inside the amplier such as
abnormal temperature rise or fan failure.
It remains unlit when the line output module is
installed.
It remains unlit when no module is installed.
13. Zone fault indicators (Yellow)
Lights or ashes when the speaker line surveillance
function detects 3 types of failures: poor insulation
(ground fault), overload (line short), and cable
disconnection.
14. Fuse fault indicator (Yellow)
Lights or ashes when DC fuse blowout are
detected.
15. Power fault indicator (Yellow)
Lights or ashes when failures are detected in
Power Supply Manager.
16. CPU fault indicator (Yellow)
Lights while in a CPU off state (p. 3-30) or when a
failure is detected in the VX-3000F.
17. General fault indicator (Yellow)
Lights while in a CPU off state (p. 3-30) Lights or
ashes when a failure is detected in the system.
18. Unit fault indicator (Yellow)
Lights or ashes when a failure is detected in the
unit.
19. Network fault indicator (Yellow)
Lights or ashes when failures are detected in
communications with the other VX-3000F.
It also ashes or lights at network setting and
when a conguration error occurs.
20.
Emergency microphone fault indicator (Yellow)
Lights or ashes when failures are detected in
Emergency Microphone.
21. Fault ACK key
The buzzer will sound and Fault indicator will
ashes when a failure is detected in the system.
Press this key to stop the buzzer and switches the
Fault indicator from ashing to steady on.
22. Fault reset key
Pressing this key resets the failure information
(the buzzer and fault indicators) for the system.
23. Lamp test key
Used to test each indicator on the front panel of
the VX-3000F Voice Evacuation Frame.
All indicators remain lit and the buzzer sounds as
long as this key is pressed.

2-5
Chapter 2 NOMENCLATURE AND FUNCTIONS
24. Audio input volume controls
Adjust the input volume of each input channel.
Rotating the control fully counterclockwise mutes
the input sound source connected to that channel.
25. Module slots
Accommodate the VX-015DA, VX-030DA, or VX-
050DA, Digital Power Amplier Module and VX-
300LO Line Output Module. The maximum number
of the connectable units is as follows.
VX-3004F: 4 units
VX-3008F: 3 units for the digital power amplier
module, and 2 units for the line output
module
VX-3016F: 2 units
26. Reset key
Pressing this key reactivates the VX-3000F.
27. ID switch
Sets the VX-3000F's ID number (device number).
28. DA control link connector
Connect this connector to the DA control link
connector of the installed digital power amplier
module or the line output module.
29. DIP switch
[VX-3004F]
• Switches 1 – 6
These switches are not used.
• Switch 7
Used when conrming the rmware version.
(See p. 4-2.)
• Switch 8
Used to set the IP address. (See p. 3-10.)
[VX-3008F]
• Switches 1 – 3
Used to allocate speaker lines. (See p. 3-5.)
• Switches 4 – 6
These switches are not used.
• Switch 7
Used when conrming the rmware version.
(See p. 4-2.)
• Switch 8
Used to set the IP address. (See p. 3-10.)
[VX-3016F]
• Switch 1
Used to place the unit in 2 channel mode
operation. (See p. 3-5.)
• Switches 2 – 6
These switches are not used.
• Switch 7
Used when conrming the rmware version.
(See p. 4-2.)
• Switch 8
Used to set the IP address. (See p. 3-10.)
Note
By default, switches 1 – 7 are set to OFF, and
switch 8 to ON.
30. Impedance initialize key
Press this key to acquire the initial value of the
speaker line impedance as failure detection is
executed on the basis of the impedance change.
31. DA output link connector
Connect this connector to the DA output link
connector of the installed digital power amplier
module.
This is an electric hazard mark.
There is the possibility of an electric shock when connecting cables.
Make connections when power is not supplied to the Digital Power
Amplifier Modules VX-015DA, VX-030DA, and VX-050DA.
24 25
26 27 28 28 28 2829 30 31 313131
[Front panel detached]

2-6
Chapter 2 NOMENCLATURE AND FUNCTIONS
[Rear]
VX-3004F
VX-3008F
VX-3016F
90 W
32 33 33 3334 34 34 343335 3535 35 36
37 38 39 40 41 4342
44 45 46
47 48 49 50
90 W
44
45
3632 33 35 33 35 33 3534 34 34
37 38 39
46
47 48 49 50 51 52
42
41 43 40
90 W
45
44
37 38 39 51 52
42 3632 33 35 33 3534 34
46
47 48 49 50
41 41 43
40

2-7
Chapter 2 NOMENCLATURE AND FUNCTIONS
32. DC power input terminal
Connect an optional DC power supply unit to
this terminal. Select the DC power supply source
with consideration given to the current power
consumption of the system the VX-3000F is to be
connected to.
(See the Instruction Manual attached to the VX-
3000DS or the VX-3150DS.)
33. Fuse
When an amplier module is installed, its fuse
can be checked.
You can replace the fuse with the amplier module
installed to the VX-3000F. (See p. 2-10.)
34.Ampliermodelnumberindicationwindow
When a power amplier module is installed, you
can check its model number.
35.AmplierDCpowerinputterminal
When a power amplier module is installed, you
can check its power input terminals. (See p. 2-10.)
36. Audio input terminals
Electronically-balanced 47 kΩ, –20 dB*/–60
dB*, Terminal connectors. LINE or MIC input
can be selected, and the phantom power supply
turned on and off. (See the separate Setting
Software Instructions, "UNIT CONFIGURATION
SETTINGS.")
* 0 dB = 1 V
37. Signal ground terminal
Hum noise may be generated when external
equipment is connected to the unit. Connecting
this terminal to the signal ground terminal of the
external equipment may reduce the hum noise.
Note: This terminal is not for protective ground.
38.Standbyamplieroutputconnector
When a standby amplier is shared by multiple VX-
3000F units, connect this connector to the standby
amplier input connector of other VX-3000F.
39.Standbyamplierinputconnector
When making the VX-3000F with no standby
amplier share the standby amplier installed to
other VX-3000F, connect this connector to other
VX-3000F's standby amplier output connector.
40. MAC address
This is the MAC address* for the unit. Since
the relationship of each unit location to its MAC
address is established when setting the network
attributes, keep track of this relationship for later
use.
* The unit’s MAC address consists of 12
hyphenated alphanumeric characters.
41. Speaker output terminals
Connect speakers to these outputs.
42. ATT/Control output terminals
These terminals permit the VX-3000 system to
control other connected external equipment.
Alternatively, these terminals become attenuator
control outputs by setting.
43. Emergency control input terminal
Connect to an automatic re alarm system and
activate emergency broadcasts, play back/stop
automatic emergency announcements and reset
emergency broadcasts.
Two isolated voltage inputs which activates when
the polarity of the applied voltage (24 V DC is kept
applied to this terminal under normal condition) is
reversed.
44. DS link connectors
Connects this connector to the DS LINK IN
connector of the VX-3000DS or the VX-3150DS.
45. Analog link output connector
Connect this connector to the analog link input
connector of the other VX-3000F.
46. Analog link input connector
Connect this connector to the analog link output
connector of the other VX-3000F.
47. Control output connectors
These RJ45 connectors permit the VX-3000
system to control other connected external
equipment.
48. Control input connectors
These RJ45 connectors receive activation signals
from external equipment to enable external VX-
3000 system control.
Alternatively, these connectors become EOL
inputs by setting.
33 34 35

2-8
Chapter 2 NOMENCLATURE AND FUNCTIONS
49. LAN link connectors
Connect the VX-3000 system components or
switching hubs. (See p. 3-83 "VX-3000 Unit's
LAN Link Connector Connection.")
50. RS link connectors
Connect the RM-200SF Fireman's Microphone
or RM-300X/500 Remote Microphone to these
connectors.
Note
Only one RM-200SF can be connected to each
connector if the system is required to comply with
EN54-16.
51. Extension output connectors
Connect these connectors to the Extension input
connector of the VX-3000F in SS mode (with no
built-in Digital Power Amplier) for zone number
expansion by the VX-3008F or VX-3016F.
52. Extension input connectors
Connect these connectors of the VX-3008F or
VX-3016F set to SS mode to the Extension output
connector of the VX-3000F in normal mode.

2-9
Chapter 2 NOMENCLATURE AND FUNCTIONS
2. VX-015DA/030DA/050DA DIGITAL POWER AMPLIFIER MODULE
• The VX-015DA, VX-030DA, and VX-050DA are Digital power amplier modules used for the VX-3000 system.
• They are module types with 1 channel of class-D digital power amplier, which contributes to energy-saving
and light weight design.
• The VX-015DA, VX-030DA, and VX-050DA also feature standby mode to be set for reducing standby power
consumption.
• They require VX-3000F control unit and VX-3000DS or VX-3150DS power supply unit.
Module lineup includes the following 3 models different in rated output.
VX-015DA : 150 W
VX-030DA : 300 W
VX-050DA : 500 W
1. DA control link connector
Connect this connector to the DA control link
connector of the VX-3000F to which this module is
installed using the supplied harness.
2. Fixing screw
Fixes the module to the VX-3000F.
3. Model number indication
4. DA output link connector
Connect this connector to the DA output link
connector of the VX-3000F to which this module is
installed using the supplied harness.
5. Filter
Dustproof lter.
Remove and clean the lter periodically.
If the lter becomes clogged, heat will be trapped
inside the module.
1
234
Appearance with
a filter detached
Appearance with
a filter attached
5
This is an electric hazard mark.
There is the possibility of an electric shock when
connecting cables.
Make connections when power is not supplied to the
Digital Power Amplifier Modules VX-015DA,
VX-030DA, and VX-050DA.
[Front]

2-10
Chapter 2 NOMENCLATURE AND FUNCTIONS
[Left Side]
8
6. Fuse
Use a blade fuse described below depending on
the power amplier's rated output.
VX-015DA : 10 A
VX-030DA : 20 A
VX-050DA : 30 A
7. DC power input terminal
Connect an optional DC power supply unit to this
terminal. (See the Instruction Manual attached to
the VX-3000DS or the VX-3150DS.)
[Rear]
6 7
8. Output voltage selection switch
Used to select power amplier's rated output voltage.
