TOP VEHICLE TECH GRKFD02 User manual

www.topvehicletech.com
The informaon provided in this document is subject to change without noce due to changes and/or
improvements to the product/s.
V1.0521
GRKFD02
FORD FOCUS
2011-2015
INSTALLATION MANUAL
This dash image is a visual representaon for display purposes only.

2
www.topvehicletech.com
ABOUT THIS PRODUCT
The GRKFD02 installaon kit allows for the retenon of the vehicle’s steering wheel controls and helps maintain
the original aesthec of the interior when installing a new car stereo. The GRKFD02 gives you everything you
need for a complete install in one box. The components of this kit are compable for the Ford Focus (2011-
2015) with Visteon factory stereos. The wiring harness and interface will retain the steering wheel controls,
factory phone buons and parking sensor audio (if vehicle is equipped).
The interface supplied features a Ford OEM specic connector.
NB: this installaon kit works with vehicles that have an Advanced display only.
CUSTOMER SUPPORT
Installaons should be carried out by, or under the guidance of an experienced installer. If you do encounter any
problems during the installaon of this product, then please contact our dedicated customer service team at:
Phone: [phone] E-Mail: [e-mail]
CONTENTS
• 1x Fascia plate (with accessories)
• 1x Instrucon manual
• 1x Steering wheel control harness and interface
• 1x Antenna adapter
• 1x Stereo patch lead

3
www.topvehicletech.com
FITTING GUIDE
1. Unclip the small trim panel located directly underneath the main fascia panel. Further unclip another
plasc panel found underneath to uncover 2x torx screws.
STEREO REMOVAL
FASCIA PLATE SET-UP
1. Once you have taken the main fascia panel o, you will need to transfer the air vents to the new fascia.
To do this you will need to disengage the clips of each vent and when free, simply re-locate onto the new
fascia.
2. Take the new hazard switch that comes with the kit and place into the new fascia.
3. Aach the brackets to either side of the radio. When aached, roughly test t the radio and bracket
combinaon in relaon to the new fascia, doing this, you can best measure whether the brackets need
moving forwards/backwards.
2. Remove the 2x torx screws, and using a panel removal tool, pry away the enre main fascia panel,
disconnecng the hazard switch connector in the process.
3. Remove the 2x screws that hold the main radio in place and remove it from the dashboard, again,
disconnecng all the wiring in the process.
4. Aer the “Stereo Installaon” process is complete and you are re-assembling the vehicle, you will then
need to clip the trim frame around the display.

4
www.topvehicletech.com
FITTING GUIDE
7. Aach the addional wiring on the harness to the back of the stereo:
Pink - Speed Pulse Green - Park Brake Purple - Reverse Blue - Antenna Remote
8. When all the above wires (and any addional accessories) have been connected, nally make the power
connecons between the stereo and the vehicles pre-exisng connector.
4. Aach the 4-pin speaker module to the equivalent connector on the steering wheel harness.
5. Aach the red & white RCA connectors from the steering wheel harness to the back of the new stereo.
6. Aach the display connector from steering wheel harness to vehicles pre-exisng display. In turn,
connect the vehicles display connector to the steering wheel control interface.
1. Take the steering wheel control interface and aach the 14-way steering wheel harness connector to
the relevant side.
2. Take the patch lead and only aach ‘Key 1’, ‘Key 2’ and ‘Ground’ to the corresponding wires on the
stereo. When done, connect the 12-way connector to the steering wheel control interface.
STEREO INSTALLATION
3. Aach the antenna adapter to the vehicles pre-exisng connecon and the back of new stereo.

5
www.topvehicletech.com
Please note: conguraon layout may dier dependent on vehicle model.
STEERING WHEEL CONTROL FUNCTIONALITY
1
2
3
4
5
1. Volume +
2. Volume -
3. Track -
4. Track +
5. Mute
1. Volume +
2. Volume -
3. Track -
4. Track +
5. Speech
Original Buon New Funcon
1. Press Speech (5.) to turn on the vehicle display.
2. Press and hold Speech (5.) for 2x seconds to enable menu mode.
3. Press Volume +/- (1/2.) to navigate to the clock seng opon. Press Speech (5.) to conrm selecon.
4. Adjust the me using Volume +/- (1/2.) and press Speech (5.) to conrm.
5. Follow the same process to adjust the date.
6. Once me and date have been set, press Speech (5.) to conrm.
NB: the menu opon will me out aer 15-20 seconds of inacvity.
SETTING TIME/DATE

6
www.topvehicletech.com
WIRING DIAGRAM
Flying Wires
Pink - Speed Pulse
Green - Park Brake
Purple - Reverse Gear
Blue - Antenna Remote
ISO Connector
Connect to aftermarket stereo
Vehicle Specific Connector [OEM Specific]
Connect to OEM connector from vehicle
Main Wiring Loom
Connector [14 Pin]
Connect to
Interface Box
Interface Box
Vehicle Display Connector
Connect connection from
vehicle display to interface
Connect vehicle display
connector on harness to
vehicles connection
White/Red RCA Connectors (AUX)
Connect to aftermarket stereo
AUX
Speaker Module
Speaker Module
Connector [4-pin]
Connect connector
from harness to
speaker module.
Stereo Connection (Patch)
Lead Connector [12 Pin]
Connect to Interface Box
Note: Must be connected
first, before power
connection is made to the
interface

7
www.topvehicletech.com
NOTES

8
www.topvehicletech.com
If at any point you experience any problems and need any assistance before, during or aer the
installaon process, please contact us via :
Phone: [phone]
E-Mail: [e-mail]
Mon - Fri 9am - 5.30pm GMT
TECHNICAL ASSISTANCE
If you would like to download a digital copy of this manual, or any other product, then please
visit the www.topvehicletech.com website.
This manual is considered correct at the me of prinng but is subject to change. For the latest
manuals & updates, refer to our website.
