3
www.topvehicletech.com
๎ฆ๎ฏ๎ค๎ค๎ฏ๎
๎ง๎๎ง๎จ๎ฏ๎๎
3. With the bo๎ฉom panels now removed, you will have access to the side of the radio. From here, you
need to remove a 10mm bolt located right on the side of the stereo.
1. Open the passenger side door and proceed to pull away the door trim from the pillar.
๎๎ค๎๎๎๎๎๎๎๎๎๎ณ๎๎พ
๎๎๎๎๎๎
๎ค๎๎
๎
๎๎๎ฏ๎
๎๎ค๎๎พ๎พ๎๎ค๎ฏ๎๎
2. Using a set of panel removal tools, begin to pry away the pillar casing.
4. The DAB antenna not only has a self adhesive backing, but also features a black earth sheet. When
placing the DAB antenna, the earth sheet MUST be placed onto the metal part of the pillar. The antenna
itself must be located roughly 15cm from the top of the windscreen.
๎
๎ฝ๎๎๎ฅ๎๎๎๎๎๎๎๎ถ๎๎๎ถ๎ถ๎๎๎ต๎ต๎๎๎๎ถ๎ฝ๎๎๎๎๎๎๎ฏ๎๎๎๎๎๎๎๎ฝ๎๎๎๎ถ๎๎๎ฌ๎๎ถ๎๎๎ฝ๎จ๎๎๎๎๎๎ถ๎๎๎๎ฏ๎๎ต๎๎ถ๎๎๎ฅ๎๎๎๎๎๎๎๎๎ฏ๎ฏ๎๎๎ถ๎๎๎๎จ๎๎๎๎๎๎๎๎๎๎๎๎๎
๎๎ถ๎๎๎ถ๎ถ๎๎ฅ๎๎๎๎๎๎ถ๎๎ฏ๎ฅ
5. Once happy with the placement, take the 3m of wiring extension and feed it down through to the
stereoโs opening. With the wiring adjusted to the appropriate length, feel free to re-install the glovebox.
3. The glovebox will need to be made accessible to route the antennas wiring. To do this open the glove-
box and unclip the damper, once unclipped, push either side inwards and pull the glovebox down and
leave in the footwell.
4. Using a bojo tool, unclip both the le๎ and right bo๎ฉom panels that surround the main fascia.
๎ฆ๎๎๎๎ฏ๎๎๎๎พ๎๎ค๎๎๎๎๎ค๎ฅณ๎จ๎
1. Take the OEM fascia and undo the 4x screws that hold the air control panel in place. Once free, relocate
this to the new fascia and screw into place using the factory screws.
4. With the cage/brackets con๎ฎgured correctly, and the โStereo Installa๎onโ process complete, simply
install the stereo and proceed to re-assemble the dashboard.
2. Take the pocket slide it into the bo๎ฉom por๎on of the new fascia, clipping it into place in the process.
1. Begin by pulling o๎ซ the kick panel that surround the bo๎ฉom of the steering wheel.
2. Once o๎ซ, undo the 4x screws holding the metal panel to the underneath of the steering wheel.
5. With these side panels removed, you will need to undo 2x screws located on either side of the main
radio. Once all of the above screws are undone, pull the radio out of the dashboard and disconnect all of
the wiring.
3. This fascia allows for the installa๎on of a single DIN stereo via means of cage or brackets. If using the
brackets, these must be a๎ฉached to the stereo prior to installa๎on.
Please note: this kit also allows the installa๎on of a double DIN stereo. For double DIN installa๎on, use the
bigger set of brackets.
