TOP VEHICLE TECH KWFOR2 User manual

www.topvehicletech.com
The informaon provided in this document is subject to change without noce due to changes and/or
improvements to the product/s.
V1.0321
KWFOR2
FORD FOCUS
2011-2015
INSTALLATION MANUAL
This dash image is a visual representaon for display purposes only.

2
www.topvehicletech.com
ABOUT THIS PRODUCT
The KWFOR2 installaon kit allows for the retenon of the vehicle’s steering wheel controls and helps maintain
the original aesthec of the interior when installing a new car stereo. The KWFOR2 gives you everything you
need for a complete install in one box. The components of this kit are compable for the Ford Focus (2011-
2015) with Visteon factory stereos. The wiring harness and interface will retain the steering wheel controls,
factory phone buons and parking sensor audio (if vehicle is equipped).
The interface supplied features a Ford OEM specic connector.
NB: this installaon kit works with vehicles that have an Advanced display only.
CUSTOMER SUPPORT
Installaons should be carried out by, or under the guidance of an experienced installer. If you do encounter any
problems during the installaon of this product, then please contact our dedicated customer service team at:
Phone: [phone] E-Mail: [e-mail]
CONTENTS
• 1x Fascia plate (with accessories)
• 1x Instrucon manual
• 1x Steering wheel control harness and interface
• 1x Antenna adapter
• 1x DAB antenna adapter
• 1x Stereo patch lead

3
www.topvehicletech.com
FITTING GUIDE
1. Unclip the small trim panel located directly underneath the main fascia panel. Further unclip another
plasc panel found underneath to uncover 2x torx screws.
1. Open the passenger side door and proceed to pull away the door trim from the pillar.
STEREO REMOVAL
DAB ANTENNA INSTALLATION
2. Using a set of panel removal tools, begin to pry away the pillar casing.
4. The DAB antenna not only has a self adhesive backing, but also features a black earth sheet. When plac-
ing the DAB antenna, the earth sheet MUST be placed onto the metal part of the pillar. The antenna itself
must be located roughly 15cm from the top of the windscreen.
Note: this antenna must not be placed atop any kind of heang elements, this will interfere with the
antenna’s signal.
5. Once happy with the placement, take the 3m of wiring extension and feed it down through to the
stereo’s opening. With the wiring adjusted to the appropriate length, feel free to re-install the glovebox.
3. The glovebox will need to be dropped down to route the antennas wiring. To do this, take o the side
panel of the glovebox and remove the 1x screw located there. Then open the glovebox and undo 2x
screws located in the upper lip, and 2x screws located underneath at the far back of the glovebox. Once
free, pull the glovebox out and leave in the footwell.
FASCIA PLATE SET-UP
1. Once you have taken the main fascia panel o, you will need to transfer the air vents to the new fascia.
To do this you will need to disengage the clips of each vent and when free, simply re-locate onto the new
fascia.
2. Take the new hazard switch that comes with the kit and place into the new fascia.
3. Aach the brackets to either side of the radio. When aached, roughly test t the radio and bracket
combinaon in relaon to the new fascia, doing this, you can best measure whether the brackets need
moving forwards/backwards.
2. Remove the 2x torx screws, and using a panel removal tool, pry away the enre main fascia panel,
disconnecng the hazard switch connector in the process.
3. Remove the 2x screws that hold the main radio in place and remove it from the dashboard, again,
disconnecng all the wiring in the process.
4. Aer the “Stereo Installaon” process is complete and you are re-assembling the vehicle, you will then
need to clip the trim frame around the display.
1. Take the steering wheel control interface in hand and connect both the 12-way stereo patch lead and
the 14-way steering wheel harness connectors to the corresponding sides.
2. Connect the bullet connector from the stereo patch lead to the ‘steering wheel remote input’ on the
back of the new stereo.
STEREO INSTALLATION
3. Connect the DAB antenna’s SMB connector to the back of the new stereo.
4. Aach the antenna adapter to the vehicles pre-exisng connecon and the back of new stereo.

4
www.topvehicletech.com
Please note: conguraon layout may dier dependent on vehicle model.
FITTING GUIDE
STEREO INSTALLATION CONT’D.
8. Aach the addional wiring on the harness to the back of the stereo:
Pink - Speed Pulse Green - Park Brake Purple - Reverse Blue - Antenna Remote
9. When all the above wires (and any addional accessories) have been connected, nally make the
connecons between the stereo and the vehicles pre-exisng connector.
STEERING WHEEL CONTROL FUNCTIONALITY
1
2
3
4
5
1. Volume +
2. Volume -
3. Track -
4. Track +
5. Mute
1. Volume +
2. Volume -
3. Track -
4. Track +
5. Speech
Original Buon
New Funcon
5. Aach the 4-pin speaker module to the equivalent connector on the steering wheel harness.
6. Aach the red & white RCA connectors from the steering wheel harness to the back of the new stereo.
7. Aach the display connector from steering wheel harness to vehicles pre-exisng display. In turn,
connect the vehicles display connector to the steering wheel control interface.
1. Press Speech (5.) to turn on the vehicle display.
2. Press and hold Speech (5.) for 2x seconds to enable menu mode.
3. Press Volume +/- (1/2.) to navigate to the clock seng opon. Press Speech (5.) to conrm selecon.
4. Adjust the me using Volume +/- (1/2.) and press Speech (5.) to conrm.
5. Follow the same process to adjust the date.
6. Once me and date have been set, press Speech (5.) to conrm.
NB: the menu opon will me out aer 15-20 seconds of inacvity.
SETTING TIME/DATE

5
www.topvehicletech.com
WIRING DIAGRAM
Flying Wires
Pink - Speed Pulse
Green - Park Brake
Purple - Reverse Gear
Blue - Antenna Remote
ISO Connector
Connect to aftermarket stereo
Vehicle Specific Connector [OEM Specific]
Connect to OEM connector from vehicle
Main Wiring Loom
Connector [14 Pin]
Connect to
Interface Box
Interface Box
Vehicle Display Connector
Connect connection from
vehicle display to interface
Connect vehicle display
connector on harness to
vehicles connection
White/Red RCA Connectors (AUX)
Connect to aftermarket stereo
AUX
Speaker Module
Speaker Module
Connector [4-pin]
Connect connector
from harness to
speaker module.
Stereo Patch Lead Connector [12 Pin]
Connect to Interface Box
Note: Must be connected first, before power
connection is made to the interface
Stereo Patch Lead Bullet Connector
Connect to ‘Steering Wheel Remote Input’ on back
of the stereo.

6
www.topvehicletech.com
If at any point you experience any problems and need any assistance before, during or aer the
installaon process, please contact us via :
Phone: [phone]
E-Mail: [e-mail]
Mon - Fri 9am - 5.30pm GMT
TECHNICAL ASSISTANCE
If you would like to download a digital copy of this manual, or any other product, then please
visit the www.topvehicletech.com website.
This manual is considered correct at the me of prinng but is subject to change. For the latest
manuals & updates, refer to our website.
