TOPP ACK4S Series Operating and maintenance manual

PATENTED
BEFORE INSTALLING AND USING THE ACTUATOR, IT IS
COMPULSORY FOR THE INSTALLER AND THE USER TO READ
AND UNDERSTAND THIS MANUAL IN ALL ITS PARTS.
THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR
AND MUST BE PRESERVED FOR FUTURE REFERENCE
UNTIL DEMOLITION OF THE SAME.
ACK4S
INSTALLATION AND USE INSTRUCTIONS
CHAIN ACTUATOR FOR
WINDOW AUTOMATION
COD. 0P5301
VER.0.0 REV.06.19
original instructions

3
1- EC DECLARATION OF INCORPORATION OF PARTLY COMPLETED
MACHINERY
2- GENERAL REMARKS
2.2- Installer and user ...............................................................................................page 05
2.4- Reserved rights ................................................................................................page 06
2.1- General instructions ..........................................................................................page 05
2.3- Technical assistance .........................................................................................page 05
2.5- Description of personnel ...................................................................................page 06
...................................................................................................................................page 04
7.1- General instructions ..........................................................................................page 23
..................................................................................................................................page 25
5.1- General instructions ..........................................................................................page 15
6.1- Use of the actuator............................................................................................page 22
3.5- Destination of use .............................................................................................page 10
3.2- Denomination of the components and dimensions............................................page 08
3.3- Technical data ...................................................................................................page 09
3.7- Package.............................................................................................................page 11
3.4- Formulas for the calculation of thrust force or tractive force.............................page 10
4- SAFETY
4.2- Safety devices ...................................................................................................page 13
4.2.1- Protections against electric hazard ................................................................page 13
3- TECHNICAL DESCRIPTION
5- INSTALLATION
5.5- Control devices..................................................................................................page 20
3.6- Use Limits..........................................................................................................page 11
4.1- General instructions ..........................................................................................page 13
5.4- Electric connections ..........................................................................................page 19
5.6- Emergency procedures .....................................................................................page 21
4.4- Residual risks ....................................................................................................page 14
6.2- ...............................................................................page 23Smart Reset System (SAI)
7- MAINTENANCE
8.1- General instructions ..........................................................................................page 24
3.1- Rating plate and "CE" marking .........................................................................page 07
9- SPARE PARTS AND ACCESSORIES UPON REQUEST
5.3- Bottom hung windows .......................................................................................page 17
4.3- Safety plates......................................................................................................page 14
5.2- Top hung windows.............................................................................................page 16
8- DEMOLITION
9.1- General instructions ..........................................................................................page 24
6- USE AND OPERATION
FIGURES
INDEXACK4S
INSTALLATION AND USE ISTRUCTIONS

4
1- EC DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY ACK4S
INSTALLATION AND USE ISTRUCTIONS
ORIGINAL
EMC Directive 2014/30/EU
EN 55014-2:2015
EN 55014-1:2006 + A1:2009 + A2:2011
EN 61000-6-2:2005.
This declaration of conformity is issued under the sole responsibility of the manufacturer.
RoHS II Directive 2011/65/EU
the following essential requisites of the
Date: Sandrigo01/02/2018 Signature: Matteo Cavalcante
Model: ACK4S/230V - ACK4S/24V
have been applied and fulfilled: Enclosure I: 1.5.1; 1.5.2; 1.5.10; 1.5.11
The following harmonised standards have been applied:
and the following technical documents:
EN 62233:2008
2006/42/EC Machinery Directive (including all applicable amendments)
EN 50581:2012
EN 60335-2-103:2015 (applicable parts)
that the relevant technical documentation is compiled in accordance with part B of Annex VII of the above
mentioned Machinery Directive..
The above identified partly completed machinery must not be put into service until the final machinery
into which it is to be incorporated has been declared in conformity with the provisions of the above
mentioned Machinery Directive.
Type: ACK4S
The undersigned also undertakes the obligation, in response to a duly reasoned request by the national
market surveillance authorities, to transmit to the a.m. authorities, in electronic or paper format, the
relevant technical documentation on the partly completed machinery.
EN 61000-6-3:2007 + A1:2011 + AC:2012.
Amministratore ................................................................
The above identified partly completed machinery is also in conformity with the all the relevant provisions
of the following directives (including all applicable amendments)
behalf of the following company
Italia
36066 Sandrigo (VI)
herewith declares that the person authorised to compile the technical file is
Name: Bettiati Roberto - Topp S.r.l.
The undersigned, in the name of and
Address: via Galvani,59 36066 Sandrigo (VI)
Topp S.r.l.
and that to the partly completed machinery
Via Galvani, 59
CHAIN ACTUATOR FOR WINDOW AUTOMATION

THE MANUFACTURER HAS NO LIABILITY FOR ANY EVENTUAL DAMAGE TO
PERSONS, ANIMALS AND THINGS DUE TO THE INOBSERVANCE OF THE
PRESCRIPTIONS DESCRIBED IN THIS MANUAL.
BEFORE INSTALLING AND USING THE ACTUATOR, IT IS COMPULSORY THAT THE
INSTALLER AND THE USER CAREFULLY READ AND UNDERSTAND THIS MANUAL
IN ALL ITS PARTS.
2.1- GENERAL INSTRUCTIONS
THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR AND MUST COMPULSORILY
BE PRESERVED FOR FUTURE REFERENCE.
IN ORDER FOR THE AUTOMATION UNIT TO OPERATE CORRECTLY, WE
RECOMMEND CARRYING OUT PERIODICAL MAINTENANCE ON IT, AS INDICATED IN
PAR. 7.1 OF THIS MANUAL.
2.2- INSTALLER AND USER
THE ACTUATOR INSTALLATION CAN BE PERFORMED EXCLUSIVELY BY
COMPETENT AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE
PROFESSIONAL AND TECHNICAL REQUIREMENTS FORESEEN BY THE LAWS IN
FORCE IN THE COUNTRY OF INSTALLATION.
THE WARRANTY ON THE ACTUATOR WILL NOT BE HONORED IF PRODUCT IS NOT
INSTALLED AND USED ACCORDING TO THE INSTRUCTIONS PROVIDED AND THE
REGULATIONS SHOWN IN THIS INSTRUCTION MANUAL AND IF IT IS USED WITH NON-
GENUINE PARTS, ACCESSORIES, SPARE PARTS AND/OR CONTROL/FEEDING UNITS.
THE ACTUATOR CAN BE USED EXCLUSIVELY BY A USER ACTING IN COMPLIANCE
WITH THE INSTRUCTIONS CONTAINED IN THIS MANUAL AND/OR IN THE MANUAL
OF THE ACTUATOR CONTROL DEVICE (e.g.: CONTROL UNIT).
THE INSTALLATION TECHNICIAN SHALL ACCEPT FULL RESPONSIBILITY FOR ANY
INS TALLATION ERRO RS AND FOR ANY FAILUR E TO ADHERE TO THE
INSTRUCTIONS PROVIDED IN THIS MANUAL. THE INSTALLATION TECHNICIAN
SHALL THEREFORE BE EXCLUSIVELY LIABLE FOR ANY DAMAGES CAUSED TO
USERS AND/OR THIRD PARTIES THAT MAY ARISE AS A RESULT OF INCORRECT
INSTALLATION.
2.3- TECHNICAL ASSISTANCE
Contact the installation technician or retailer for assistance.
5
GENERAL REMARKS -2
ACK4S
INSTALLATION AND USE ISTRUCTIONS

User:
2.5- DESCRIPTION OF PERSONNEL
specialised person capable of operating the actuator under normal conditions by using
the relative controls. He/she must also be able to operate with the actuator under
“maintenance” in order to perform simple routine maintenance operations (cleaning),
and start or reset the actuator following an unscheduled stop.
Each information herein contained (text, drawings, diagrams, etc.) is reserved.
A specialised electrician must be able to install the actuator, start it and operate it both
in normal conditions and in the maintenance mode; he/she is qualified to perform all
electrical and mechanical adjustment and maintenance operations. He/she is allowed
to work on live electrical cabinets and junction boxes.
USERS MUST NEVER PERFORM OPERATIONS RESERVED FOR MAINTENANCE
PEOPLE OR SPECIALISED TECHNICIANS. THE MANUFACTURER DECLINES ALL
LIABILITY FOR DAMAGE DERIVING FROM FAILURE TO OBSERVE THE ABOVE
REQUIREMENTS.
None part of this manual can be reproduced and disclosed (totally or partially) by any
reproduction means (photocopies, microfilms or other) without written authorization of
the Manufacturer.
2.4- RESERVED RIGHTS
The reserved rights on this manual "Installation and use instructions" remain property of
the Manufacturer.
Specialised electrician:
6
2- GENERAL REMARKS ACK4S
INSTALLATION AND USE ISTRUCTIONS

• "CE" marking
• voltage and intensity of power supply (V - A)
The rating plate is an adhesive plate in polyester, silk-screen printed in black, having the
following size: L= 50 mm - H= 36 mm.
• thrust and tractive force F (N)
3.1- RATING PLATE AND "CE" MARKING
• type and model
• absorbed electric power P (W)
• logo and address of the manufacturer
The "CE" marking certifies the compliance of the machine with the essential safety and
health requirements foreseen by the product European Directives.
It is applied externally on the actuator. The plate bears in readable and indelible way the
following data:
• type of service S (min)
2
• idle translation speed (mm/s)
• protection degree (IP)
• symbol of double insulation (only for mod. ACK42)
• serial number
• symbol of “WEEE” Directive 2002/96/CE
7
ACK4S TECHNICAL DESCRIPTION -3
INSTALLATION AND USE ISTRUCTIONS

3.2- DENOMINATION OF THE COMPONENTS AND DIMENSIONS
LEGEND:
1) Power supply cable
2) Support heads
3) Support
4) Opening stroke adjustment on both sides
5) Actuator
6) Chain pin
7) Bracket for bottom hung opening
8) Window frame connection bracket
1
4
5
3
2
6
8
7
Dimensions in mm
8
ACK4S
3- TECHNICAL DESCRIPTION
INSTALLATION AND USE ISTRUCTIONS
Fig. 1

3.3- TECHNICAL DATA
Tab. 1 contains the technical data characterising the actuators.
9
ACK4S TECHNICAL DESCRIPTION -3
INSTALLATION AND USE ISTRUCTIONS
MAXIMUM APPLICABLE THRUST LOAD 300 N 250 N
MAXIMUM APPLICABLE TRACTIVE LOAD 300 N 250 N
MAXIMUM THRUST LOAD APPLICABLE ON
TWO SYNCHRONIZED AUTOMATIONS.
500 N
450 N
MAXIMUM TRACTIVE LOAD APPLICABLE ON
TWO SYNCHRONIZED AUTOMATIONS
500 N 450 N
IDLE TRANSLATIO N SPEED 8,7 mm/s 8,7 mm/s
DURATION OF THE IDLE S TROKE 46 s 46 s
TYPE OF SERVICE S2 (1)
2
min 2 min
ADJUSTABLE STROKES ON OUTLET (2) 100-150-200-250-300-350-400 mm
ADJUSTMENT OF THE WINDOW FRAME CONNECTION
AUTOMATIC
MAX. OVERLAPPED PART “D” 50 mm
OPERATING TEMPERATURE -5°C ÷ 50°C
ACTUATOR WEIGHT WITH BRACKETS 1,1 kg
GROSS WEIGHT 1,5 kg
SYNCHRONIZ. TWO ACTUATORS ON THE SAME WINDOW Yes
MINIMUM DISTANCE BETWEEN ACTUATOR 60 mm
POWER SUPPLY VOLTAGE 230 V ~ 50 Hz 24 V ± 10%
ABSORBED CURRENT 0,20 A 1,0 A
ABSORBED POWER WITH LOAD 32 W 24 W
PROTECTION AGAINST ELECTRIC SHOCKS Class II Class III
PROTECTION DEGREE OF ELECTRIC DEVICES IP55
PARALLEL CONNECTION OF MORE THAN ONE ACTUATOR
Yes
(See wiring diagram)
ACK4S/230V
ACK4S/24V
(1)
Service of limited duration according to EN 60034
(2) Tolerance on the precision of the output limit switch tripping: +/- 10mm
Tab. 1

3.5- DESTINATION OF USE
THE ACTUATOR HAS BEEN DESIGNED AND MANUFACTURED TO PERFORM, BY
MEANS OF A CONTROL DEVICE, THE OPENING AND CLOSING OF TOP HUNG
WINDOWS, BOTTOM HUNG WINDOWS, PIVOT WINDOWS, AND SKYLIGHTS.
3.4- FORMULAS FOR THE CALCULATION OF THRUST AND
TRACTIVE
bottom hung windows (B)
F = Force necessary for opening or
(N)
C = Window opening stroke
(mm)
Top hung windows (A) or
closing
P = Weight of the window
(N)
(only movable part)
H = Window height
(mm)
F = (0,54 x P) x ( )
C
H
P
F
H
C
B
P
F
H
C
A
F
P
P = Weight of the skylight or dome
(N)
closing
Horizontal domes or skylights
F = Force necessary for opening or
(N)
(Only movable part)
F = 0,54 x P
10
3- TECHNICAL DESCRIPTION ACK4S
INSTALLATION AND USE ISTRUCTIONS
Fig. 2
Fig. 3
The ACK4S Chain actuator is equipped with the latest TOPP system for the coordinated
synchronization of the chain movement. The electronic speed control is fully automatic and
requires no external control unit; just connect the yellow/white/blue cables as per wiring diagram at
the back of the manual to achieve the synchronized mode. The Smart Reset System (SAI) has
also been included which adjusts the closure of the window in an optimum manner.
The ACK4S chain actuator is mounted when you need two or more attachment points because
the window is particularly heavy or wide and only one actuator would not allow perfect closure of
the window. It should be remembered that the force exerted by the actuators individually is the
same as a similar ACK4 actuator; for example, by mounting two actuators the force applied to the
window is, therefore, doubled. The window is moved in a uniform, synchronized and coordinated
manner with no interruptions and/or speed changes in the actuators' operation. In the event of any
failure of one of the actuators due to a mechanical or electrical fault, the others also stop operating,
guaranteeing that the window remains intact.

MAKE SURE THAT THE ABOVE DESCRIBED COMPONENTS ARE CONTAINED IN
THE PACKAGE, AS WELL AS THAT THE ACTUATOR HAS NOT BEEN DAMAGED
DURING TRANSPORT.
SHOULD ANY ANOMALY BE DETECTED, IT IS FORBIDDEN TO INSTALL THE
ACTUATOR, AND IT IS COMPULSORY TO REQUIRE TECHNICAL ASSISTANCE FROM
YOUR DEALER OR THE MANUFACTURER.
THE USE OF THE ACTUATOR IN ENVIRONMENTS WITH POTENTIALLY EXPLOSIVE
ATMOSPHERE IS STRICTLY FORBIDDEN.
IT IS COMPULSORY TO KEEP THE PACKAGE AND THE ACTUATOR OUT OF REACH
OF CHILDREN.
3.7- PACKAGE
Check carefully all environmental conditions (temperature, humidity, wind, snow,
potential chemical agents, etc.) and installation settings (misaligned fitting of brackets
and attachment to the frame, frictions produced by hinges or gaskets, use of self-
balancing window stays, etc.) it is recommended that they not exceed the actuator
performances shown in the technical table. If they do, please find an alternative and
more suitable product for your application.
IT IS STRICTLY FORBIDDEN TO USE THE ACTUATOR FOR IMPROPER USES OTHER
THAN THE ONE FORESEEN BY THE MANUFACTURER (SEE PAR. 3.5).
IT IS STRICTLY FORBIDDEN TO INSTALL THE ACTUATOR ON THE EXTERNAL SIDE
OF THE WINDOW FRAME SUBJECT TO ATMOSPHERIC AGENTS (RAIN, SNOW,
ETC.).
Each standard package of the product (cardboard box) contains (Fig. 4):
• No. 1 Bracket for hopper opening (Ref. B);
• No. 1 Small parts package (window connection bracket, nuts, pin and fastening
screws for aluminium window frames) (Ref. C);
• No. 1 Adhesive drilling template (Ref. D);
3.6- USE LIMITS
The actuator has been designed and manufactured exclusively for the destination of
use given in par .3.5, therefore, any other type of use is strictly forbidden in order to
assure in any moment the safety of the installer and of the user, as well as the
efficiency of the actuator itself.
• No. 1 Actuator equipped with power supply cable;
• No. 1 Installation and use instructions (Ref. E);
• No.1 Safety Plate (Fig. 5).
• No. 1 Support (Ref. A);
THE PACKAGING (PAPER, PLASTIC, ETC.) HAS TO BE DISPOSED ACCORDING TO
THE LAWS IN FORCE.
EX
11
ACK4S TECHNICAL DESCRIPTION -3
INSTALLATION AND USE ISTRUCTIONS

A
C
B
ED
ISTRUZIONI PER L’INSTALLAZIONE E L'USO
ORIGINALI
BREVETTATO
PRIMA DI INSTALLARE E UTILIZZARE L’ATTUATORE È OBBLIGATORIO CHE
L’INSTALLATORE E L’UTILIZZATORE LEGGANO E COMPRENDANO
IN TUTTE LE SUE PARTI IL PRESENTE MANUALE.
IL PRESENTE MANUALE È PARTE I NTEGRANTE DELL’ATTUATORE E DEV E
OBBLIGATORIAME NTE ESSERE CONSERVATO
PER FUTURI RIFERIMEN TI FINO ALLA DEMOLIZIONE DELLO STESSO.
ATTUATORE A CATENA PER
AUTOMAZIONE FINESTREACK4S
COD. 0P5000
REV. 05/03
PATENTED
BEFORE INSTALLING AND USING THE ACTUATOR, IT IS
COMPULSORY FOR THE INSTALLER AND THE USER TO READ
AND UNDERSTAND THIS MANUAL IN ALL ITS PARTS.
THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR
AND MUST BE PRESERVED FOR FUTURE REFERENCE
UNTIL DEMOLITION OF THE SAME .
ACK4S
INSTALLATION AND USE INSTRUCTIONS
CHAIN ACTUATOR FO R
WINDOW AUTOMATION
P/N 0P5101
REV.11.07
12 INSTALLATION AND USE ISTRUCTIONS
3- TECHNICAL DESCRIPTION ACK4S
Fig.4

4.1- GENERAL INSTRUCTIONS
DURING HANDLING AND INSTALLATION OF THE PARTS, THE PERSONNEL SHALL
BE EQUIPPED WITH SUITABLE PERSONAL PROTECTION EQUIPMENT (PPE) SO AS
TO PERFORM THE WORKS REQUIRED UNDER SAFE CONDITIONS.
ANY TAMPERING WITH OR UNAUTHORISED REPLACEMENT OF ONE OR MORE
PARTS OR COMPONENTS OF THE ACTUATOR, OR THE USE OF UNORIGINAL
ACCESSORIES AND CONSUMABLES, MAY INCREASE THE RISK OF ACCIDENT
AND THUS RELIEVES THE MANUFACTURER OF ALL CIVIL AND PENAL LIABILITY.
THIS APPLIANCE MAY NOT BE USED BY PERSONS (CHILDREN INCLUDED) WITH
REDUCED PHYSICAL, SENSORIAL OR MENTAL CAPACITIES, OR INEXPERT
PEOPLE, UNLESS THEY ARE SUPERVISED AND TAUGHT HOW TO USE IT BY A
PERSON RESPONSIBLE FOR THEIR SAFETY. CHILDREN MUST BE CONTROLLED
TO MAKE SURE THEY DO NOT PLAY WITH THE APPLIANCE.
The protection measures against direct contacts aim at protecting people against
hazards due to contact with active parts, usually live parts; while the protection
measures against indirect contacts aim at protecting people against hazards due to
conducing part, which are usually insulated, but could become live in case of failure
(insulation failure).
IF THE WINDOW FRAME IS ACCESSIBLE FROM OR INSTALLED AT A HEIGHT OF
LESS THAN 2.5 m FROM THE GROUND, AND IF IT CAN BE COMMANDED BY AN
UNTRAINED USER OR WITH A REMOTE CONTROL DEVICE, FIT AN EMERGENCY
STOP SYSTEM WHICH AUTOMATICALLY CUTS IN TO PREVENT THE RISK OF
CRUSHING OR DRAGGING PARTS OF THE BODY INSERTED BETWEEN THE
MOVING AND FIXED PARTS OF THE WINDOW FRAME.
OPERATORS MUST BE INFORMED OF ACCIDENT RISKS, SAFETY DEVICES AND
THE GENERAL ACCIDENT PREVENTION REGULATIONS ESTABLISHED BY
INTERNATIONAL DIRECTIVES AND BY THE LAW IN FORCE IN THE COUNTRY OF
USE. ALL OPERATORS MUST STRICTLY COMPLY WITH THE ACCIDENT
PREVENTION REGULATIONS IN FORCE IN THE COUNTRY OF USE.
The adopted protection measures are the following:
DO NOT REMOVE OR ALTER THE PLATES PLACED ON THE ACTUATOR BY THE
MANUFACTURER.
4.2.1- PROTECTION AGAINST ELECTRIC HAZARD
4.2- SAFETY DEVICES
The actuator is protected against electric hazard due to direct and indirect contacts.
EXTRAORDINARY AND ROUTINE MAINTENANCE OPERATIONS INVOLVING THE
TOTAL OR PARTIAL DISMOUNTING OF THE ACTUATOR MAY ONLY BE PERFORMED
AFTER DISCONNECTING IT FROM THE POWER SUPPLY.
13
INSTALLATION AND USE ISTRUCTIONS
SAFETY -4ACK4S

Fig. 5 illustrates the safety plate: this must applied directly to the outside of the actuator
or near it and always in a position where it can be seen by the installer and/or operator.
4.4- RESIDUAL RISKS
1) Insulation of live parts by means of a plastic material body;
4.3- SAFETY PLATES
2) Enclosure with suitable protection degree;
3) Only for the mod. ACK4S/230V provided with protection against electric
shocks: Protection of passive type given by the use of components with double
insulation, also called components of class II or with equivalent insulation.
IT IS FORBIDDEN TO REMOVE, MOVE, SPOIL OR IN ANYWAY REDUCE THE
VISIBILITY OF THE SAFETY PLATES. FAILURE TO OBSERVE THE ABOVE MAY
CAUSE SERIOUS HARM TO PEOPLE AND DAMAGE TO PROPERTY. THE
MANUFACTURER DECLINES ALL LIABILITY FOR ANY DAMAGE CAUSED BY THE
FAILURE TO OBSERVE THE ABOVE REQUIREMENT.
The installer and the user are herewith informed that after the actuator has been
installed on the window, the actuator drive can accidentally generate the following
residual risk:
Exposure frequency: Accidental and when the installer or the user decides to perform
a wrong voluntary action.
Severity of the damage:Light lesions (usually reversible).
Residual risk:Hazard of squashing or dragging of body parts inserted between the
movable and the fix part of the window frame.
Adopted measures:Before enabling the device, it is compulsory to verify that near the
window there are not persons, animals or things whose safety may be accidentally
jeopardized. During actuator operation, it is compulsory to be in a safe control position
assuring visual control on the window movement (see par. 6.1).
4- SAFETY ACK4S
Fig. 5
14 INSTALLATION AND USE ISTRUCTIONS
ATTENTION! AUTOMATIC MACHINE WITH REMOTE CONTROL DEVICE
ATTENZIONE MACCHINA AD AVVIAMENTO AUTOMATICO CON COMANDO A DISTANZA
MACCHINA AD AVVIAMENTO AUTOMATICO
AUTOMATIC MACHINE
PRIMA DI INSTALLARE E UTILIZZARE L'ATTUATORE È OBBLIGATORIO CHE L'INSTALLATORE E
L'UTILIZZATORE LEGGANO E COMPRENDANO IN TUTTE LE SUE PARTI IL MANUALE
PERICOLO ATTENZIONE ALLE MANI
THE INSTALLER AND USER MUST READ AND UNDERSTAND ALL PARTS OF THIS MANUAL BEFORE
INSTALLING AND USING THE ACTUATOR.
BEWARE OF YOUR HANDS
IT
EN

5.1- GENERAL INSTRUCTIONS
CHECK THE ADEQUACY OF THE WINDOW AND THE SUITABILITY OF THE MATERIALS
OF THE WINDOW AND/OR FRAME ON WHICH THE ACTUATOR WILL BE FASTENED. AND
IT MUST ENSURE A GOOD SUPPORT OF THE ACTUATOR-WINDOW ASSEMBLY DURING
THE MOVEMENT.
FOR CORRECT OPERATION OF THE ACTUATOR, THE WINDOW MUST HAVE A
MINIMUM HEIGHT H See Tab.2. OTHERWISE, ASK YOUR DEALER OR THE
MANUFACTURER FOR THE NECESSARY ACCESSORIES FOR A CORRECT
INSTALLATION.
THE ACTUATOR PERFORMANCE MUST BE SUFFICIENT TO ASSURE THE
CORRECT MOVEMENT OF THE WINDOW. IT IS COMPULSORY TO VERIFY THE
THRUST OR TRACTIVE FORCE ACCORDING TO THE TYPE AND WEIGHT OF THE
WINDOW (PAR. 3.4). IT IS FORBIDDEN TO EXCEED THE LIMITS GIVEN IN TAB. 1
CONCERNING THE TECHNICAL DATA (PAR. 3.3).
THE ACTUATOR INSTALLATION CAN BE PERFORMED EXCLUSIVELY BY
COMPETENT AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE
PROFESSIONAL AND TECHNICAL REQUIREMENTS FORESEEN BY THE LAWS IN
FORCE IN THE COUNTRY OF INSTALLATION.
THE ACTUATOR INSTALLATION MUST BE PERFORMED EXCLUSIVELY WITH
CLOSED WINDOW OR SKYLIGHT.
BEFORE PERFORMING THE INSTALLATION OF THE ACTUATOR ON HOPPER
WINDOWS, VERIFY THAT ON BOTH SIDES OF THE WINDOW TWO COMPASS
STROKE LIMIT DEVICES ARE INSTALLED IN ORDER TO AVOID THE ACCIDENTAL
FALL OF THE WINDOW.
15
ACK4S INSTALLATION -5
INSTALLATION AND USE ISTRUCTIONS

(Fig. 6 and 13 ÷ 23)
CAUTION: FOR NON-COPLANAR WINDOW FRAMES, IT IS NECESSARY TO CUT THE
TEMPLATE CONCERNED PART AND TO APPLY IT ON THE WINDOW FRAME PAYING
ATTENTION TO KEEP IT IN THE SAME REFERENCE POSITION.
1) Open the package (par. 3.7) and extract the
various components;
4) Fig. 16- Insert the two nuts "D1" on the support
"SA" and mount the head "T1" by fixing it using
screw "V1";
7) Fig. 18- Mount the support "SA" on the fix window frame with the screws "V2"; Check
the perfect horizontal and vertical alignment with the window frame;
5.2- TOP HUNG WINDOWS
2) Fig. 14- With a pencil draw the centre line "X" of
the window frame;
3) Fig. 15- Select the following components:
bracket "S1", support "SA", two nuts "D1", two
screws "V1", heads "T1" and “T2";
5) Fig. 17- Cut out the adhesive template "DS" and
apply it on the window frame centring it on the previously drawn centre line "X";
6) With a suitable drill, create on the window frame holes having the related diameter,
given on the adhesive template "DS";
8) Mount the bracket "S1" on the movable window frame with the screws "V2";
9) Fig. 19- Use a screwdriver or coin to adjust selector “SR” to the desired opening
stroke (both actuators must have the same stroke in tandem installations).
CAUTION: VERIFY THAT THE SELECTED STROKE IS SOME CENTIMETRES LOWER
THAN THE STROKE EFFECTIVELY ALLOWED BY MECHANICAL LOCKS, COMPASS
STROKE LIMIT DEVICES, OR WING OPENING HINDRANCES.
10)Hook the system up electrically as indicated in par. 5.4 and the wiring diagram (for
tandem installations, complete the hookup per the wiring diagram before running the
chain out). Run the chain out for at least 10cm, then disconnect the actuator from its
power supply.
11) Fig. 20- Mount the actuator on the support "SA", place the head "T2" and tighten the
screw "V1;
VERIFY THAT THE CHAIN END "TC" IS ON THE SAME AXIS OF THE BRACKET "S1".
OTHERWISE, LOOSEN THE FIXING SCREWS AND POSITION IT CORRECTLY. WHEN
THE DEVICES ARE NOT COAXIAL, THIS MAY DAMAGE THE ACTUATOR AND THE
WINDOW FRAME (FIG. 7).
16
ACK4S
5- IINSTALLATION
INSTALLATION AND USE ISTRUCTIONS
Fig. 6

17
INSTALLATION -5
ACK4S
12) Fig.20a- Unscrew and remove the screw and washer mounted at the factory on the
chain ending"TC";
CAUTION: FOR NON-COPLANAR WINDOW FRAMES, IT IS NECESSARY TO CUT THE
TEMPLATE CONCERNED PART AND TO APPLY IT ON THE WINDOW FRAME PAYING
ATTENTION TO KEEP IT IN THE SAME REFERENCE POSITION.
(Fig. 8 and 24 ÷ 34)
Fig. 21- Mount the nut "D2" on the hole head screw "V3" and then it on the chain
ending "TC";
Fig. 22- Connect the bracket "S1" to the screw "V3" by means of the pin "P";
14) Power up the actuators.
13) Repeat with the second actuator;
15) Fig. 23- Perform a test of complete window frame opening and closing. After the
closing phase, verify that the chain end "TC" is completely returned in its seat ;
16) Fix the screw "V3" with the nut "D2" and the pin "P".
5.3- BOTTOM HUNG WINDOWS
2) Fig. 25- With a pencil draw the centre line "Y" of
the window frame;
3) Fig. 26- Select the following components:
bracket "S2" and "S3", support "SA", two nuts
"D1", two screws "V1", screw "V4", heads "T1"
and "T2";
4) Fig. 27- Insert the two nuts "D1" on the support
"SA" and mount the head "T2" by fixing it using
screw "V1";
1) Open the package (par. 3.7) and extract the
various components;
5) Fig. 28- Cut out the adhesive template "DV" and apply it on the window frame
centring it on the previously drawn centre line "Y";
INSTALLATION AND USE ISTRUCTIONS
Fig. 8
Fig. 7
TC TC
S1 S1
NO
YES

18
ACK4S
5- INSTALLATION
9) Fig. 30- Use a screwdriver or coin to adjust selector “SR” to the desired opening
stroke (both actuators must have the same stroke in tandem installations).
11) Fig. 31- Mount the actuator on the support "SA", place the head "T1" and tighten the
screw "V1;
6) With a suitable drill, create on the window frame holes given on the adhesive
template "DV";
7) Fig. 29- Mount the support "SA" on the fix window frame with the screws "V2"; check
the perfect horizontal and vertical alignment with the window frame;
8) Mount the bracket "S2" on the movable window frame with the screws "V2";
CAUTION: VERIFY THAT THE SELECTED STROKE IS SOME CENTIMETRES LOWER
THAN THE STROKE EFFECTIVELY ALLOWED BY MECHANICAL LOCKS, COMPASS
STROKE LIMIT DEVICES, OR WING OPENING HINDRANCES.
10) Hook the system up electrically as indicated in par. 5.4 and the wiring diagram (for
tandem installations, complete the hookup per the wiring diagram before running the
chain out). Run the chain out for at least 10 cm, then disconnect the actuator from its
power supply.
12) Fig. 31a- Unscrew and remove the screw and washer mounted at the factory on the
chain ending "TC";
Fig.32- Mount the nut "D2" on the hole head screw "V3" and then it on the chain end
"TC";
16) Fix the screw "V3" with the nut "D2" and the pin "P".
14) Power up the actuators.
Fig.33- Connect the bracket "S3" to bracket "S2" and fix it with the screw "V4".
Connect the bracket "S3" with the screw "V3" by means of the pin "P";
13) Repeat with the second actuator;
15) Fig. 34- Perform a test of complete window frame opening and closing. After the
closing phase, verify that the chain end "TC" is completely returned in its seat;
INSTALLATION AND USE ISTRUCTIONS

THE ELECTRIC CONNECTION OF THE VERSION ACK4S 24V HAS TO BE CARRIED OUT
WITH A VERY LOW SAFETY VOLTAGE FEEDER PROTECTED AGAINST SHORT CIRCUITS.
5.4- ELECTRIC CONNECTIONS (Wiring diagram)
THE ELECTRIC CONNECTION OF THE ACTUATOR CAN BE PERFORMED ONLY BY
COMPETENT AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE
TECHNICAL AND PROFESSIONAL REQUIREMENTS FORESEEN BY THE LAW IN
FORCE IN THE COUNTRY OF INSTALLATION ISSUING TO THE CUSTOMER A
DECLARATION OF CONFORMITY FOR THE CONNECTION AND/OR THE PLANT
PERFORMED.
BEFORE PERFORMING THE ELECTRIC CONNECTION OF THE ACTUATOR, VERIFY
THE CORRECT INSTALLATION ON THE WINDOW.
THE ELECTRICAL CONNECTION OF THE VERSION ACK4S/230V MUST BE COMPLETED
INTO A SUITABLE AND APPROPRIATE JUNCTION BOX, THE COMMUNICATION CABLES
HAVE TO BE PLACED INTO THE SAME JUNCTION BOX WHERE ELECTRICAL CABLES
ARE.
THE MAINS TO WHICH THE ACTUATOR IS CONNECTED MUST COMPLY WITH THE
REQUIREMENTS OF THE LAWS IN FORCE IN THE COUNTRY OF INSTALLATION, AS
WELL AS SATISFY THE TECHNICAL FEATURES GIVEN IN TAB. 1 AND ON THE
RATING PLATE AND THE "CE" MARKING (PAR. 3.1).
THE SECTION OF THE MAINS CABLES MUST BE PROPERLY SIZED ACCORDING TO
THE ABSORBED ELECTRIC POWER (SEE RATING PLATE AND "CE" MARKING).
ANY TYPE OF ELECTRIC MATERIAL (PLUG, CABLE, TERMINALS, ETC.) USED FOR
THE CONNECTION MUST BE SUITABLE FOR THE USE, WITH "CE" MARKING AND
COMPLYING WITH THE REQUIREMENTS FORESEEN BY THE LAWS IN FORCE IN
THE COUNTRY OF INSTALLATION.
TO ASSURE EFFICIENT SEPARATION FROM THE MAINS, INSTALL AN APPROVED
TEMPORARY BIPOLAR SWITCH (PUSH-BUTTON) UPLINE OF THE DEVICE. FIT A
BIPOLAR MAIN SWITCH WITH CONTACT APERTURE OF AT LEAST 3 mm UP LONE
OF THE CONTROL LINE.
BEFORE PERFORMING THE ELECTRIC CONNECTION OF THE ACTUATOR, VERIFY
THAT THE POWER SUPPLY CABLE IS NOT DAMAGED. SHOULD IT BE DAMAGED, IT
MUST BE REPLACED BY THE MANUFACTURER OR BY THE TECHNICAL
ASSISTANCE SERVICE OR IN ANY CASE BY AUTHORIZED OPERATORS.
19
ACK4S INSTALLATION -5
INSTALLATION AND USE ISTRUCTIONS

To these control units, it is possible to connect the rain sensors (RDC -12V), the
windsensor (RW) and the brightness sensor;
1) MANUAL PUSH-BUTTON:
5.5- CONTROL DEVICES
2) OPTIONAL: CONTROL AND FEEDING UNIT:
TOPP Microprocessor control units (e.g.: Mod. TF44, etc.) controlling the single
actuator (ACK4S/230V) or more than one actuator simultaneously (ACK4S/230V)
or by means of one or more manual pushbuttons, an infrared remote control or a 433
Mhz radio control.
The electrical connection of the ACK4S/24V version must be made with a 24V power
supply / control units of appropriate power.
THE EVENTUALLY USED UNITS MUST SUPPLY A VOLTAGE TO ACK4S FOR MAX.
120s.
THE CONTROL DEVICES USED TO DRIVE THE ACTUATOR MUST ASSURE THE
SAFETY CONDITIONS FORESEEN BY THE LAWS IN FORCE IN THE COUNTRY OF
USE.
According to the different type of installations, the actuators can be driven by the
following control devices:
Bipolar switch button with central OFF position, with biased-off switch;
20
ACK4S
5- INSTALLATION
INSTALLATION AND USE ISTRUCTIONS
