TOPP C20 Operating and maintenance manual

C20
COD. 0P5186
VER.0.0 REV.09.13
INSTALLATION AND USE INSTRUCTIONS
CHAIN ACTUATOR FOR
WINDOW AUTOMATION
PATENTED
BEFORE INSTALLING AND USING THE ACTUATOR, IT IS
COMPULSORY FOR THE INSTALLER AND THE USER TO READ
AND UNDERSTAND THIS MANUAL IN ALL ITS PARTS.
THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR
AND MUST BE PRESERVED FOR FUTURE REFERENCE
UNTIL DEMOLITION OF THE SAME.
ORIGINAL

1- DECLARATION OF “CE” CONFORMITY
........................................................................................................................page 04
2- GENERAL REMARKS
2.1- General instructions..........................................................................................page 05
2.2- Installer and user..............................................................................................page 05
2.3- Warranty ...........................................................................................................page 05
2.4- Technical assistance.........................................................................................page 05
2.5- Reserved rights ................................................................................................page 05
2.6- Description of personnel...................................................................................page 06
3- TECHNICAL DESCRIPTION
3.1- Rating plate and “CE” marking .........................................................................page 07
3.2- Denomination of the components and dimensions ..........................................page 08
3.3- Technical data...................................................................................................page 10
3.4- Formulas for the calculation of thrust force or tractive force.............................page 11
3.5- Destination of use.............................................................................................page 11
3.6- Use Limits.........................................................................................................page 12
3.7- Package ...........................................................................................................page 12
4- SAFETY
4.1- General instructions .........................................................................................page 14
4.2- Safety Devices .................................................................................................page 14
4.2.1- Protections against electric hazard .......................................................page 14
4.3- Safety plates.....................................................................................................page 15
4.4- Residual risks ...................................................................................................page 15
5- INSTALLATION
5.1- General instructions .........................................................................................page 16
5.2- Top hung windows............................................................................................page 20
5.3- Bottom hung windows ......................................................................................page 21
5.4- .................................................................................................page 22
5.5- Electrical Connections......................................................................................page 24
5.6- Control devices.................................................................................................page 24
5.7- Correct assembly of the actuator on the window frame ...................................page 25
5.8- Emergency procedures ....................................................................................page 26
6- USE AND OPERATION
6.1- Use of the actuator ...........................................................................................page 27
7- MAINTENANCE
7.1- General instructions .........................................................................................page 28
8- DEMOLITION
8.1- General instructions .........................................................................................page 28
9- SPARE PARTS AND ACCESSORIES UPON REQUEST
9.1- General instructions .........................................................................................page 29
9.2- Brackets for vertical assembly..........................................................................page 29
9.3- “ ”..............................page 30
9.3.1- ......................................................................................page 30
9.3.2- Emergency procedures .........................................................................page 31
FIGURES
........................................................................................................................page 32
CERTIFICATE OF GUARANTEE
........................................................................................................................page 39
Dome windows
Quick coupling with integrated release push-button ARP
Dome windows
3
INDEX
INSTALLATION AND USE ISTRUCTIONS
C20
VER.0.0
REV.09.13

4
C20
VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
1- DECLARATION OF “CE” CONFORMITY
declares that the electrical device
Serial n° and year of manufacture: see data plate and CE marking applied to
the device
complies with the requirements of the following directives:
2006/95/CE
Low Voltage Directive: electrical material for use within certain voltage limits.
2004/108/CE
Electromagnetic Compatibility Directive - Concerning the approximation of the laws of
Member States relating to electromagnetic compatibility.
and also declares that the following harmonised standards have been applied:
called: CHAIN ACTUATOR FOR WINDOW AUTOMATION
type: C20
models: C20/230V - C20/24V
EN55014-1
EN55014-2
EN61000-6-3
EN61000-6-2
EN50366
EN60335-1
Date: Sandrigo, 10/01/2008
Matteo Cavalcante .....................................................
TOPP S.p.A.
via L. Galvani, 59
36066 Sandrigo (VI)
ITALIA

5
INSTALLATION AND USE INSTRUCTIONS
C20
VER.0.0
REV.09.13
GENERAL REMARKS -2
2.1- GENERAL INSTRUCTIONS
BEFORE INSTALLING AND USING THE ACTUATOR, IT IS COMPULSORY THAT THE
INSTALLER AND THE USER CAREFULLY READ AND UNDERSTAND THIS MANUAL IN
ALL ITS PARTS.
THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR AND MUST COMPULSORILY BE
PRESERVED FOR FUTURE REFERENCE.
THE MANUFACTURER HAS NO LIABILITY FOR ANY EVENTUAL DAMAGE TO PERSONS,
ANIMALS AND THINGS DUE TO THE INOBSERVANCE OF THE PRESCRIPTIONS
DESCRIBED IN THIS MANUAL.
2.2- INSTALLERAND USER
THE ACTUATOR INSTALLATION CAN BE PERFORMED EXCLUSIVELY BY COMPETENT
AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE PROFESSIONAL AND
TECHNICAL REQUIREMENTS FORESEEN BY THE LAWS IN FORCE IN THE COUNTRY OF
INSTALLATION.
THEACTUATOR CAN BE USED EXCLUSIVELY BYAUSERACTING IN COMPLIANCE WITH
THE INSTRUCTIONS CONTAINED IN THIS MANUAL AND/OR IN THE MANUAL OF THE
ACTUATOR CONTROL DEVICE (E.G.: CONTROL UNIT).
2.3- WARRANTY
THE ACTUATOR WARRANTY EXPIRES, IF ITS USE DOES NOT COMPLY WITH THE
INSTRUCTIONS AND PRESCRIPTIONS DESCRIBED IN THIS MANUAL, AS WELL AS IF
NON-ORIGINAL COMPONENTS, ACCESSORIES, SPARE PARTS, AND CONTROL
SYSTEMSARE USED.
2.4- TECHNICALASSISTANCE
For the technical assistance apply to your Dealer or to the Manufacturer.
2.5- RESERVED RIGHTS
The reserved rights on this manual "Installation and use instructions" remain property of
the Manufacturer.
Each information herein contained (text, drawings, diagrams, etc.) is reserved.
None part of this manual can be reproduced and disclosed (totally or partially) by any
reproduction means (photocopies, microfilms or other) without written authorization of
the Manufacturer.

2.6- DESCRIPTION OF PERSONNEL
USERS MUST NEVER PERFORM OPERATIONS RESERVED FOR MAINTENANCE
PEOPLE OR SPECIALISED TECHNICIANS. THE MANUFACTURER DECLINES ALL
LIABILITY FOR DAMAGE DERIVING FROM FAILURE TO OBSERVE THE ABOVE
REQUIREMENTS.
Specialised electrician:
A specialised electrician must be able to install the actuator, start it and operate it both
in normal conditions and in the maintenance mode; he/she is qualified to perform all
electrical and mechanical adjustment and maintenance operations. He/she is allowed
to work on live electrical cabinets and junction boxes.
User:
specialised person capable of operating the actuator under normal conditions by using
the relative controls. He/she must also be able to operate with the actuator under
“maintenance” in order to perform simple routine maintenance operations (cleaning),
and start or reset the actuator following an unscheduled stop.
6
2- GENERAL REMARKS
INSTALLATION AND USE ISTRUCTIONS
C20
VER.0.0
REV.09.13

3.1- RATING PLATE AND “CE” MARKING
The “CE” marking certifies the compliance of the machine with the essential safety and
health requirements foreseen by the product European Directives.
The rating plate is an adhesive plate in polyester, silk-screen printed in black, having the
following size: L=36 mm - H=50 mm.
It is applied externally on the actuator. The plate (Fig. 1) bears in readable and indelible
way the following data:
• logo and address of the manufacturer
• type and model
• voltage and intensity of power supply (V -A)
• absorbed electric power P (W)
• thrust and tractive force F (N)
• type of service S (min)
2
• idle translation speed (mm/s)
• protection degree (IP)
• “CE” marking
• symbol of WEEE Directive 2002/96/CE
• symbol of double insulation (only for mod. C20/230V)
• serial number
7
C20
VER.0.0
REV.09.13 INSTALLATION AND USE ISTRUCTIONS
TECHNICAL DESCRIPTION -3
Fig. 1
Sandrigo - made in Italy
N:0910TA12000
C20
230V~ 50Hz
I = 0,12A
P = 25W
F = 300N
S2= 4min
8 mm/s
IP30
Sandrigo - made in Italy
N:0910TA12000
C20
24V
I = 0,43A
P = 9W
F = 300N
S2= 4min
7,5 mm/s
IP30

Fig. 2a
48
34
286
342
15.1
362
10.3
64.5
4
2
1
3
5
Dimensions in mm
3.2- DENOMINATION OF THE COMPONENTSAND DIMENSIONS
LEGEND:
1) Power supply cable
2) Window frame connection brackets (right-left)
3) Actuator
4) Chain end
5) Electric connector
6) Switch I=240 mm; II=360 mm
C20
3- TECHNICAL DESCRIPTION
8VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
6
-
+
7
Min
(-)
Max
(+)
150 N 100 N
200 N
300 N
7) Dip switch power Thrust
force
Tractive
force

Fig. 2b
(43)
30
15
2.5
85
22
19.5
16.8
3
35
17.5
(4)
24±0,1
80
10.5
42
11
14
8.4
15
11
27
42
51.8
13.313
36
17
9.5
2
1
4
5
16
8615
3
Dimensions in mm
LEGEND:
1) Bracket for bottom hung opening
2)
3) Release side indicator
4) Bracket for vertical assembly “A”
5) Bracket for vertical assembly “B”
Quick coupling to the window frame “ARS”
9
C20
VER.0.0
REV.09.13 INSTALLATION AND USE ISTRUCTIONS
TECHNICAL DESCRIPTION -3

Gross weight
Dome
Tab. 1
230 V - 50 Hz
C20/230V
0,12 A
25 W
300 N
200 N
240
250
500
360
360
900
8 mm/s
46 s
Classe II
4 min
- 5 + 50 ºCºC
IP 30
NO
NO
0,97 kg
1,15 kg
24 V
C20/24V
0,43 A
9 W
7,5 mm/s
48 s
Classe III
300 400
3.3- TECHNICAL DATA
Tab. 1 contains the technical data characterising the actuators.
Power supply voltage
Absorbed current
Absorbed power with load
Thrust force
Tractive force
Idle translation speed
Duration of the idle stroke (360 mm)
(1)
Operation stroke length (mm)
Limit switch: Electronic for opening - by amperometric absorption for closing.
Parallel electric connection of more
actuators on the same window
Parallel electric connection of more
actuators on different windows
(1) Tolerance on the precision of limit switch tripping at output: +/- 2 cm.
Minimum window
(2)
frame height (mm)
Top hung
Bottom hung
Protection against electric shock
(3)
Type of service S
2
Operating temperature
Protection degree of electric devices
Adjustment of the window frame connection
Yes
(see wiring diagram)
Actuator weight with brackets
(2) Actuator distance from the window frame opening hinge
(3) Service of limited duration according to EN 60034
C20
3- TECHNICAL DESCRIPTION
10 VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
Compatibility of actuators connected in parallel
ACK4 T50 C20 C25 C30 C40 SL60 T80 C240 C20T
C20

3.5- DESTINATION OF USE
THE ACTUATOR HAS BEEN DESIGNED AND MANUFACTURED TO PERFORM
AUTOMATICALLY, BY MEANS OF A COMMAND DEVICE, THE OPENING AND CLOSING
OF TOP HUNG WINDOWS, BOTTOM HUNG WINDOWS, PIVOT WINDOWS, AND
SKYLIGHTS.
P
F
H
C
B
P
F
H
C
A
Fig. 3
Fig. 4
F
P
Top hung windows (A) or
bottom hung windows (B)
F = Force necessary for opening or
closing
P = Weight of the window
(Only movable part)
C = Window opening stroke
H = Window height (Only movable part)
F = (0.54 x P) x ( )
C
H
Horizontal domes or skylights
F= Force necessary for opening or
closing
P= Weight of the skylight or dome
(Only movable part)
F = 0.54 x P
3.4- FORMULAS FOR THE CALCULATION OF THRUSTAND TRACTIVE
FORCE
C20 TECHNICAL DESCRIPTION -3
11
VER.0.0
REV.09.13 INSTALLATION AND USE ISTRUCTIONS

3.6- USE LIMITS
The actuator has been designed and manufactured exclusively for the destination of
use given in par. 3.5, therefore, any other type of use is strictly forbidden in order to
assure in any moment the safety of the installer and of the user, as well as the efficiency
of the actuator itself.
IT IS STRICTLY FORBIDDEN TO USE THE ACTUATOR FOR IMPROPER USES, I.E. OTHER
THAN THE ONE FORESEEN BY THE MANUFACTURER (SEE PAR. 3.5).
IT IS STRICTLY FORBIDDEN TO INSTALL THE ACTUATOR ON THE EXTERNAL SIDE OF
THE WINDOW FRAME SUBJECT TOATMOSPHERICAGENTS (RAIN, SNOW, ETC.).
THE USE OF THE ACTUATOR IN ENVIRONMENTS WITH POTENTIALLY EXPLOSIVE
ATMOSPHERE IS STRICTLY FORBIDDEN.
IT IS COMPULSORY TO KEEP THE PACKAGE AND THE ACTUATOR OUT OF REACH OF
CHILDREN.
3.7- PACKAGE
Each package of the product (cardboard box) contains (Fig. 5):
• No. 1Actuator equipped with power supply cable (with electric connector);
• No. 2 Window frame connection brackets (right-left) (Ref. A);
• No. 1 Bracket for bottom hung opening (Ref. B);
• No. 1Adhesive drilling template (Ref. C);
• No. 1 Installation and use instructions (Ref. E);
• No. 1 Safety plate (Fig. 6);
MAKE SURE THAT THE ABOVE DESCRIBED COMPONENTS ARE CONTAINED IN THE
PACKAGE, AS WELL AS THAT THE ACTUATOR HAS NOT BEEN DAMAGED DURING
TRANSPORT.
SHOULD ANY ANOMALY BE DETECTED, IT IS FORBIDDEN TO INSTALL THE ACTUATOR,
AND IT IS COMPULSORY TO REQUIRE TECHNICAL ASSISTANCE FROM YOUR DEALER
OR THE MANUFACTURER.
THE PACKAGING (PAPER, PLASTIC, ETC.) HAS TO BE DISPOSED ACCORDING TO THE
LAWS IN FORCE.
• No. 1 Small parts package for aluminum windows (No. 2 screws for lateral fastening of
connection brackets to the window, No. 7 screws AF Ø 4,8 x 16 mm and No. 2 screws
AF Ø 4,2 x 19 mm for the fastening of the brackets to the window frame and for ARS
coupling fastening) (Ref. D);
• No. 1 ARS coupling release tool (Ref. D-1);
• No. 1 ARS coupling (Ref. D-2);
EX
C20
3- TECHNICAL DESCRIPTION
12 VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS

C20
COD. 0P5152
VER.0.0 REV.09.13
INSTALLATION AND USE INSTRUCTIONS
CHAIN ACTUATOR FOR
WINDOW AUTOMATION
PATENTED
BEFORE INSTALLINGAND USING THE ACTUATOR, IT IS
COMPULSORYFOR THE INSTALLER AND THE USER TO READ
AND UNDERSTANDTHIS MANUAL IN ALL ITS PARTS.
THIS MANUAL IS INTEGRAL PART OF THE ACTUATOR
AND MUST BE PRESERVED FOR FUTURE REFERENCE
UNTIL DEMOLITION OF THE SAME.
C20 TECHNICAL DESCRIPTION -3
13
VER.0.0
REV.09.13 INSTALLATION AND USE ISTRUCTIONS
AB
C
Ø3.8
Ø3.8
Ø3.8 Ø3.8
Ø3.8 Ø3.8
Ø3.8
Ø3.8
Ø3.8
Ø3.8
Ø3.8
Ø3.8
Ø3.8
Ø3.8
Ø3.8
Ø3.8
ASSEDIATTACCO AL SERRAMENTO
ACHSEDERPLASTIKFLUEGELBOECKCHEN
WINDOWCASING'SAXIS
AXEDEATTELAGEA LA FENETRE
INTERNALLINE OFWINDOW'S FIXEDPART
LIGNE INTERIEURE DEFENETRE FIXEE
INNENLINIE DESFESTGESETZEN FENSTERS
LINEAINTERNA SERRAMENTO PARTEFISSA
INTERNALLINE OFWINDOW'S MOVINGPART
LIGNE INTERIEURE DE FENETRE MOBILE
INNENLINIE DESBEWEGLICHEN FENSTERS
LINEAINTERNASERRAMENTOPARTE MOBILE
GABARITADHESIF POUR FENETRE APROJECTION
ADHESIVE TEMPLATETOTOPHINGED WINDOW
KLEBSCHABLONEFUER FENSTER MIT UNTENOEFFNUNG
DIMAADESIVAPERSERRAMENTO A SPORGERE
GABARITADHESIF POUR FENETREA SOUFFLET
ADHESIVE TEMPLATETOBOTTOMHINGED WINDOW
DIMAADESIVA PER SERRAMENTO AVASISTAS
KLEBSCHABLONE FUERKIPPFENSTER
UNTEREGRENZEDES FENSTERS
LIMITEINFERIORDELAVENTANA
WINDOW FRAME'S INFERIORLIMIT
LIMITE INFERIORE DELSERRAMENTO
POSITIONAMIENTO DE LA ESTAFA PARAVENTANAA RESALTAR
POSITIONDER MONTAGEKONSOLENFÜRKLAPPFENSTER
BRACKETS POSITION TOTOP HINGED WINDOW MOUNTING
POSIZIONE STAFFEPER MONTAGGIO A SPORGERE
POSITIONAMIENTO DE LAESTAFAPARAMONTAJE VERTICAL
KONSOLENPOSITIONFÜR SENKRECHTE MONTAGE
BRACKETS POSITION FORVERTICALMOUNTING
POSIZIONE STAFFEPER MONTAGGIO VERTICALE
PLANTILLAADHESIVAPARAVENTANAARESALTAR
PLANTILLAADHESIVA PARAVENTANADE FUELLE ALTA
LINEAINTERIORDE LAVENTANAPARTE MOBIL
LINEAINTERIOR DE LA VENTANAPARTEFIJA
LIMITE INFERIEURE DU BÂTI
EJE DEFISAJEALA VENTANA
KLEBSCHABLONE FUER SENKRECHTEMONTAGE
ADHESIVETEMPLATEFOR VERTICAL MOUNTING
GABARITADHESIF POURMONTAGEVERTICAL
DIMAADESIVAPER MONTAGGIO VERTICALE
PLANTILLAADHESIVA PARAMONTAJEVERTICAL
POSITIONAMIENTO DE LA ESTAFAPARAVENTANADE FUELLEALTA
POSITION DER MONTAGEKONSOLENFÜRKIPPFENSTER
BRACKETS POSITIONTO BOTTOMHINGEDWINDOW MOUNTING
POSIZIONE STAFFEPERMONTAGGIOA VASISTAS
POSITIONDES ETRIERS POUR FENETREA SOUFFLET POSITIONDES ETRIERS POURFENETRE A PROJECTIONPOSITION DES ETRIERS POUR MONTAGE VERTICAL
Ø3.8 Ø3.8
Ø3.8
Fig. 5
D E
A
2

4.1-
4.2-
4.2.1- PROTECTIONAGAINST ELECTRIC HAZARD
The actuator is protected against electric hazard due to direct and indirect contacts.
The protection measures against direct contacts aim at protecting people against
hazards due to contact with active parts, usually live parts; while the protection
measures against indirect contacts aim at protecting people against hazards due to
conducing part, which are usually insulated, but could become live in case of failure
(insulation failure).
The adopted protection measures are the following:
1) Insulation of live parts by means of a plastic material body;
2) Enclosure with suitable protection degree;
GENERAL INSTRUCTIONS
THIS APPLIANCE MAY NOT BE USED BY PERSONS (CHILDREN INCLUDED) WITH
REDUCED PHYSICAL, SENSORIAL OR MENTAL CAPACITIES, OR INEXPERT PEOPLE,
UNLESS THEY ARE SUPERVISED AND TAUGHT HOW TO USE IT BY A PERSON
RESPONSIBLE FOR THEIR SAFETY. CHILDREN MUST BE CONTROLLED TO MAKE
SURE THEY DO NOT PLAY WITH THE APPLIANCE.
OPERATORS MUST BE INFORMED OF ACCIDENT RISKS, SAFETY DEVICES AND THE
GENERAL ACCIDENT PREVENTION REGULATIONS ESTABLISHED BY INTERNATIONAL
DIRECTIVESAND BY THE LAW IN FORCE IN THE COUNTRYOF USE.
ALL OPERATORS MUST STRICTLY COMPLY WITH THE ACCIDENT PREVENTION
REGULATIONS IN FORCE IN THE COUNTRY OF USE.
DO NOT REMOVE OR ALTER THE PLATES PLACED ON THE ACTUATOR BY THE
MANUFACTURER.
IF THE WINDOW FRAME IS ACCESSIBLE FROM OR INSTALLED AT A HEIGHT OF LESS
THAN 2.5 m FROM THE GROUND, AND IF IT CAN BE COMMANDED BY AN UNTRAINED
USER OR WITH A REMOTE CONTROL DEVICE, FIT AN EMERGENCY STOP SYSTEM
WHICH AUTOMATICALLY CUTS IN TO PREVENT THE RISK OF CRUSHING OR
DRAGGING PARTS OF THE BODY INSERTED BETWEEN THE MOVINGAND FIXED PARTS
OF THE WINDOW FRAME.
ANY TAMPERING WITH OR UNAUTHORISED REPLACEMENT OF ONE OR MORE PARTS
OR COMPONENTS OF THE ACTUATOR, OR THE USE OF UNORIGINAL ACCESSORIES
AND CONSUMABLES, MAY INCREASE THE RISK OF ACCIDENT AND THUS RELIEVES
THE MANUFACTURER OF ALL CIVILAND PENAL LIABILITY.
EXTRAORDINARYAND ROUTINE MAINTENANCE OPERATIONS INVOLVING THE TOTAL
OR PARTIAL DISMOUNTING OF THE ACTUATOR MAY ONLY BE PERFORMED AFTER
DISCONNECTING IT FROM THE POWER SUPPLY.
SAFETY DEVICES
4- SAFETY
14 INSTALLATION AND USE ISTRUCTIONS
C20
VER.0.0
REV.09.13

3) Only for Mod. C20/230 V equipped with double insulation: Protection of passive
type given by the use of components with double insulation, also called components of
class II or with equivalent insulation. (It is forbidden to connect the actuators equipped
with double insulation to the earth plant.
4.3-
4.4- RESIDUAL RISKS
The installer and the user are herewith informed that after the actuator has been
installed on the window, the actuator drive can accidentally generate the following
residual risk:
Residual risk: Hazard of squashing or dragging of body parts inserted between the
movable and the fix part of the window frame.
Exposure frequency: Accidental and when the installer or the user decides to perform
a wrong voluntary action.
Severity of the damage: Light lesions (usually reversible).
Adopted measures: Before enabling the device, it is compulsory to verify that near the
window there are not persons, animals or things whose safety may be accidentally
jeopardized. During actuator operation, it is compulsory to be in a safe control position
assuring visual control on the window movement (see par.6.1).
SAFETY PLATES
IT IS FORBIDDEN TO REMOVE, MOVE, SPOIL OR IN ANYWAY REDUCE THE VISIBILITY
OF THE SAFETY PLATES. FAILURE TO OBSERVE THE ABOVE MAY CAUSE SERIOUS
HARM TO PEOPLE AND DAMAGE TO PROPERTY. THE MANUFACTURER DECLINES ALL
LIABILITY FOR ANY DAMAGE CAUSED BY THE FAILURE TO OBSERVE THE ABOVE
REQUIREMENT.
Fig. 6 illustrates the safety plate: this must applied directly to the outside of the actuator
or near it and always in a position where it can be seen by the installer and/or operator.
Fig. 6
SAFETY -4
C20
15
VER.0.0
REV.09.13 INSTALLATION AND USE ISTRUCTIONS
MACCHINA AD AVVIAMENTO AUTOMATICO
AUTOMATIC MACHINE
PRIMA DI INSTALLARE E UTILIZZARE L'ATTUATORE È OBBLIGATORIO CHE L'INSTALLATORE E L'UTILIZZATORE
LEGGANO E COMPRENDANO IN TUTTE LE SUE PARTI IL MANUALE
THE INSTALLER AND USER MUST READ AND UNDERSTAND ALL PARTS OF THIS MANUAL BEFORE INSTALLING
AND USING THE ACTUATOR.
PERICOLO ATTENZIONE ALLE MANI
BEWARE OF YOUR HANDS
ATTENZIONE MACCHINAADAVVIAMENTO AUTOMATICO CON COMANDO ADISTANZA
ATTENTION! AUTOMATIC MACHINE WITH REMOTE CONTROL DEVICE
IT
EN

5.1- GENERAL INSTRUCTIONS
THE ACTUATOR INSTALLATION CAN BE PERFORMED EXCLUSIVELY BY COMPETENT
AND QUALIFIED TECHNICAL PERSONNEL SATISFYING THE PROFESSIONAL AND
TECHNICAL REQUIREMENTS FORESEEN BY THE LAWS IN FORCE IN THE COUNTRY OF
INSTALLATION.
THE ACTUATOR PERFORMANCE MUST BE SUFFICIENT TO ASSURE THE CORRECT
MOVEMENT OF THE WINDOW. IT IS COMPULSORY TO VERIFY THE THRUST OR
TRACTIVE FORCE ACCORDING TO THE TYPE AND WEIGHT OF THE WINDOW (PAR. 3.4).
IT IS FORBIDDEN TO EXCEED THE LIMITS SET IN TAB. 1 CONCERNING TECHNICAL
DATA(PAR. 3.3).
THE ACTUATOR INSTALLATION MUST BE PERFORMED EXCLUSIVELY WITH CLOSED
WINDOW OR SKYLIGHT.
BEFORE PERFORMING THE INSTALLATION OF THE ACTUATOR ON BOTTOM HUNG
WINDOWS, VERIFY THAT ON BOTH SIDES OF THE WINDOW TWO COMPASS STROKE
LIMIT DEVICES ARE INSTALLED IN ORDER TO AVOID THE ACCIDENTAL FALL OF THE
WINDOW.
FOR CORRECT OPERATION OF THE ACTUATOR, THE WINDOW FRAME MUST HAVE A
MINIMUM HEIGHT VALUE INCLUDED IN THE RANGE STATED IN TABLE FIG. 7a FOR TOP
HUNGASSEMBLY, IN TABLE FIG. 7b FOR BOTTOM HUNGASSEMBLY,AND IN TABLE FIG.
7c FOR THE DOMEASSEMBLY.
THE STROKE SELECTION HAS TO BE CARRIED OUT WITH SWITCHED OFF ACTUATOR
ONLY BY COMPETENT AND QUALIFIED TECHNICAL PERSONNEL.
VERIFY THAT THE POSITIONS OF THE LABELS LOCATED ON THE QUICK COUPLING
CORRESPOND TO THE LABELS ON THE ACTUATOR: RED LABEL WITH LETTER “A”
FOR THE TOP HUNG ASSEMBLY, GREEN LABEL WITH LETTER “B” FOR VERTICAL
ASSEMBLY.
VERIFY THAT DISTANCE “D” BETWEEN THE ACTUATOR SHELL AND THE CHAIN END
(FIG. 7a/7b/7c) IS GREATER THAN 5 mm.
IF THE WING AND THE FRAME ARE COPLANAR PROCEED WITH THE ASSEMBLY
ACCORDING TO FIG. 7.
THE FITTING SURFACE FOR THE ARS RAPID COUPLING DEVICE MUST BE PERFECTLY
FLAT AND/OR SMOOTH.
16
C20
VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
5- INSTALLATION

17
C20
Fig. 7a
IF THE WINDOW FRAME IS COPLANAR, REMOVE THE ACTUATOR FROM THE WINDOW
FRAME USING THE APPLICATIONS OF THE ABOVE GIVEN TABLE.
USE ONLY A SCREW IN POSITION “A” OR “B”.
THE RELEASE SIDE INDICATOR (REF. 3) IN THIS ASSEMBLY TYPE HAS TO BE ON THE
RIGHT.
-10 mm
-5 mm
B
B
A
1
2
1
240
360
250
360
55°
60°
VER.0.0
REV.09.13 INSTALLATION AND USE ISTRUCTIONS
INSTALLATION -5
Dimensions in mm
POS. ROTATION
AXIS
POS. FROM THE
WINDOW FRAME
COPLANAR
STROKE (mm) MIN. WINDOW
GAP (mm) OPENING
ANGLE
TOP HUNG OPENING
50
18.3
10
72.5
38.5
D>5
A B
12
3
-10-10
-5
Pos.
A1
Pos.
B2
Pos.
B1
Pos.
B1
WING
FRAME
Flat and/or
smooth surface

18
C20
Fig. 7b
VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
Dimensions in mm
5- INSTALLATION
BOTTOM HUNG OPENING
240 33.6
360 31.6
500
900
26°
22°
"B" MOTOR OVERALL
DIMENSIONS (mm)
STROKE (mm) MIN. WINDOW
GAP (mm) OPENING
ANGLE
USE ONLY A SCREW IN POSITION “A”.
26.6 31 ±1
15.4
D>552.5
5.4
1
80
50
25
15
B
A
FRAME
WING

19
C20
Fig. 7c
USE ONLY A SCREW IN POSITION “A”.
A
11.7
72
60
D>5
10.5
35.5
30
WING
FRAME
MIN. 33
50
50
B
1
VER.0.0
REV.09.13 INSTALLATION AND USE ISTRUCTIONS
Dimensions in mm
DOME OPENING
THE RELEASE SIDE INDICATOR (REF. 1) IN THIS ASSEMBLY TYPE HAS TO BE ON
THE LEFT.
240 40
360 43
300
400
48°
55°
"B" MOTOR OVERALL
DIMENSIONS (mm)
STROKE (mm) MIN. WINDOW
GAP (mm) OPENING
ANGLE
INSTALLATION -5

5.2- TOP HUNG WINDOWS
(Fig. 8 and Fig. 19 ÷ 27)
1) Open the package (par. 3.7) and extract the various
components;
2) Fig. 19- With a pencil draw the centre line “X” of the
window frame;
3) Fig. 20-Apply the adhesive template (Ref. 1) on the
window frame aligning it with the previously drawn
centre line “X”;
CAUTION: FOR NON-COPLANAR WINDOW FRAMES, IT IS NECESSARY TO CUT THE
ADHESIVE TEMPLATE CONCERNED PART AND TO APPLY IT ON THE WINDOW FRAME
PAYING ATTENTION TO KEEP IT IN THE SAME REFERENCE POSITION.
4) Fig. 21- With a suitable drill, create on the window frame holes having the related
diameter, given on the adhesive template;
5) Fig. 22÷24- With the suitable screws tighten the brackets for window frame
connection (right - left) and the quick coupling;
6) Fig. 25/26- After having connected the electric connector in the actuator, perform the
electric connections according to the provisions of par. 5.5, as well as with reference
to the wiring diagram. Let the chain come out for at least 5 cm of stroke, then
disconnect the connector;
7) Fig. 26- Connect the chain end to the quick coupling;
8) Fig. 27- Fasten the actuator to the brackets for connection to the window frame using
the suitable screws;
VERIFY IN Fig. 7a THE CORRECT FASTENING POSITIONING OF THE ACTUATOR.
MAKE SURE THAT THE RED LABEL LOCATED ON THE QUICK COUPLING
CORRESPONDS TO THE SAME LABEL ON THE ACTUATOR.
VERIFY THAT AFTER THE TIGHTENING THE CONNECTION BRACKETS TO THE WINDOW
FRAMEADHERE TO THEACTUATOR IN ORDER TOASSURE ACORRECT APPLICATION.
9) Fig. 27- Select the wished stroke (I= 240 mm - II= 360 mm) using the switch (Ref. 1)
located on one side of the actuator. The actuator is supplied with the stroke set on 240
mm.
10) Fig. 25- Insert the electric connector;
TO CHANGE THE PRE-SET STROKE, USE A SCREWDRIVER (FIG. 27) WITH SUITABLE
TIP. MAKE SURE TO INSERT THE TIP UP TO THE MICROSWITCH BASE AND TO SHIFT IT
COMPLETELY. AN INCORRECT IN-BETWEEN POSITION STALLS THE ACTUATOR.
Fig. 8
20
C20
VER.0.0
REV.09.13
INSTALLATION AND USE INSTRUCTIONS
5- INSTALLATION
