Tornado BR 47/35 ESC User manual

English 3
Français 19
Español 35
BR 47/35 ESC
5.961-740.0 01/09

2

English 3
To reduce the risk of fire, electric shock, or
injury:
– Do not leave appliance when plugged in.
Unplug from outlet when not in use and
before servicing.
– TO REDUCE THE RISK OF ELECTRIC
SHOCK-USE INDOORS ONLY
– Do not allow to be used as a toy. Close
attention is necessary when used by or
near children.
– Use only as discribed in this manual. Use
only manufacturer`s recommended
attachments.
– Do not use with damaged cord or plug. If
appliance is not working as it should, has
been dropped, damaged, left outdoors,
or dropprd into water, return it to a
service center.
– Do not pull or carry by cord, use cord as
a handle, close a door on cord, or pull
cord around sharp edges or corners. Do
not run appliance over cord. Keep cord
away from heated surfaces.
– Do not unplug by pulling on cord. To
unplug, grasp the plug, not the cord.
– Do not handle plug or appliance with wet
hands.
– Do not put any object into openings. Do
not use with any opening blocked; keep
free of dust, lint, hair, and anything that
may reduce air flow.
– Keep hair, loose clothing, fingers, and all
parts of body away from openings and
moving parts.
– Turn off all controls before unplugging.
– Use extra care when cleaning on stairs.
– Do not use to pick up flammable or
combustible liquids, such as gasoline, or
use in areas where they may be present.
– Connect to a properly grounded outlet
only. See Grounding Instruction.
This appliance must be grounded. If it
should malfunction or breakdown, ground-
ing provides a path of least resistance for
electric current to reduce the risk of electric
shock. This appliance is equipped with a
cord having an equipment-grounding con-
ductor and a grounding plug. The plug must
be inserted into an appropriate outlet that is
properly installed and grounded in accor-
dance with all local codes and ordinances.
Improper connection of the equipment
grounding conductor can result in a risk of
electric shock. Check with a qualified electri-
cian or service person if you are in doubt as
to whether the outlet is properly grounded.
Do not modify the plug provided with the ap-
pliance-if it will not fit the outlet, have a prop-
er outlet installed by a qualified electrician.
This appliance is for use on a nominal 120-
volt circuit and has a grounding attachment
plug that looks like the plug illustrated in
sketchpicture A. Make sure that the
appliance is connected to an outlet having
the same configuration as the plug. No
adaptor should be used with this appliance.
IMPORTANT SAFETY IN-
STRUCTIONS
READ ALL INSTRUCTIONS
BEFORE USING.
WARNING
WARNING
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
WARNING

4 English
1 Grounded outlet
2 Grounded outlet Box
3 Grounded Pin
Save operation is in the responsibility of the
operator.
The operator shall be familiar with the oper-
ation and function of all controls and instru-
ments before undertaking to operate the
unit.
Before operating the unit, operators shall
have read and be familiar with the operator’s
manual for the particular unit being operated
and they shall also abide by the safety rules
and practices in the following paragraphs.
Before operating any unit, the operator shall
be familiar with unusual operating conditions
which may require additional safety precau-
tions or special operating instructions.
Before starting to operate the unit be in op-
erating position.
Do not start or operate the unit, any of its
functions or attachments, from any place
other than from the designated operators
position.
Before leaving the operator’s position:
A bring the unit to a complete stop;
B if the unit must be on an incline, block the
wheels.
Maintain a safe distance from the edge of
ramps, platforms, and other similar working
surfaces.
Do not add to, or modify the unit.
Do not block access to fire aisles, stairways
or fire equipment.
Yield the right of way to pedestrians and
emergency vehicles such as ambulances
and fire trucks.
Cross railroad tracks at an angle wherever
possible. Do not park closer than 6 ft (1800
mm) to the nearest rail of a railroad track.
Keep a clear view of the path of travel and
observe for other traffic, personnel, and safe
clearances.
Under all travel conditions, operate the unit
at a speed that will pernit it to be brought to
a stop in a safe manner.
Do not indulge in stunt driving or horseplay.
Slow down for wet and slippery floors.
Before driving over a dockboard or bridge
plate, be sure that it is properly secured.
Drive carefully and slowly across the dock-
board or bridge plate, and never exceed its
rated capacity.
When negotiating turns, reduce speed to a
safe level consistent with the operating envi-
ronment. Make the turns smoothly.
If the unit is found to be in need of repair or
in any way unsafe, or contributes to an un-
safe condition, the matter shall be reported
immediately to the user’s designated author-
ity, and the unit shall not be operated until it
has been restored to safe operating condi-
tion.
If during operation the unit becomes unsafe
in any way, the matter shall be reported im-
mediately to the user’s designated authority,
and the unit shall not be operated until it has
been restored to safe operating condition.
Do not make repairs or adjustments unless
specifically authorized to do so.
CONNECT TO A PROPERLY
GROUNDED OUTLET ONLY
OPERATING SAFETY RULES
AND PRACTICES
Operator Responsibility
General
Travelling
Operator care of the unit

English 5
Operation of the unit may be hazardous if
maintenance is neglected or repairs, re-
builds, or adjustments are not performed in
accordance with the manufacturer’s design
criteria. Therefore, maintenance facilities
(on or off premises), trained personnel, and
detailed procedures shall be provided.
Maintenance and inspection of the unit shall
be performed in conformance with the fol-
lowing practices:
A a schedules planned maintenance, lubri-
cation, and inspection system shall be
followed; consult the manufacturer’s rec-
ommendations.
B only tranined and authorized personnel
shall be permitted to maintain, repair, ad-
just, and inspect the unit, and in accord-
ance with manufacturer’s specifications.
Avoid fire hazards and have fire protection
equipment present in the work area. Do not
use open pans of fuel or flammable cleaning
fluids for cleaning parts.
Any unit not in safe operating condition shall
be removed from service.
Repairs shall not be made in Class I, Class
II, and Class III locations.
Fire Prevention: The unit shall be kept in a
clean condition and reasonably free of lint,
excess oil, and grease. Noncombustible
agents are preferred for cleaning the unit.
Flammable liquids [those having flash points
at or above 100°F (37,8°C)] are not allowed.
Precautions regarding toxicity, ventilation,
and fire hazard shall be appropriate for the
agent or solvent used.
Nameplate Visibility: The unit type designa-
tions as shown on the nameplate and the
type markers shall not be covered over with
paint so that their identification information is
obscured.
The unit shall not be used in classified are-
as.
MAINTENANCE ANDREBUILD
PRACTICES
FIRE SAFETY STANDARD

6 English
Please read and comply with
these instructions prior to the
initial operation of your appliance. Retain
these operating instructions for future refer-
ence or for subsequent possessors.
Safety instructions 6
Function 6
Proper use 6
Environmental Protection, Disposal 7
Operating and Functional Elements 8
Before Startup 9
Start up 9
Operation 10
Shutting down 12
Maintenance and care 12
Transport 15
Troubleshooting 16
Specifications 16
Warranty 16
Accessories and Spare Parts 16
For operator:
Please ensure that all users of the machine
have read and understood the contents of
this Operating Instructions Manual and are
familiar with the local regulations about work
safety. The users must have been techni-
cally trained to use this appliance.
For users:
Before using the appliance for the first time,
read and observe these operating instruc-
tions and the accompanying brochure: Safe-
ty information for brush cleaning units and
spray-extraction units, No. 5.956-251.
Safety devices serve to protect the user and
must not be rendered inoperational or their
functions bypassed.
The appliance can only be started when you
press the foot pedal fully downwards. The
machine stops when you release the foot
pedal.
From he stationary escalator cleaner, deter-
gent fluid (from the fresh water tank) is ap-
plied to the running travellator/ escalator.
The rolling brushes brush the detergent
againt the running direction into the ridges of
the travellator/ escalator. In the same work-
ing step, the dirty detergent is sucked into
the dirt water tank of the machine via the in-
take brushes.
Use this appliance only as directed in these
operating instructions.
– The appliance may only be used to clean
the stepping areas of travellators/ esca-
lators.
– The running or movement direction of
the unit to be cleaned must be adjusted
in such a way that the travellator/ escala-
tor moves away from the machine.
– To clean the escalator, place the ma-
chine only at the lower end of the escala-
tor.
– The appliance may only be equipped
with original accessories and spare
parts.
Contents
Safety instructions
Safety Devices
Foot pedal
Function
Proper use

English 7
Environmental protection
The packaging material can be
recycled. Please do not throw
the packaging material into
household waste; please send
it for recycling.
Old appliances contain valua-
ble materials that can be recy-
cled; these should be sent for
recycling. Batteries, oil, and
similar substances must not
enter the environment. Please
dispose of your old appliances
using appropriate collection
systems.

8 English
1 Push handle
2 Drainage hose for fresh water
3 Dirt water discharge hose
4 Mains plug
5 Strain relief clamp
6 Foot pedal
7 Rear wheels with stopping lever
8 Cover dirt water reservoir
9 Front wheels
10 Dirt water reservoir
11 Fresh water reservoir filler neck
12 Pedal for raising/ lowering the brush
head
13 Lever to lock the brush head
1 Operating hour counter
2 Display pump pressure
3 Power switch
4 Indicator lamp "Dirt water tank full"
5 Indicator lamp "Brush motor overload"
Operating and Functional Elements
Operator console

English 9
ÎRemove all packaging material except
the wooden palette.
ÎInsert the pushing handle in the grooves
on the appliance.
ÎFasten the pushing handle with the 4
screws enclosed in the packet.
ÎFasten the covering flaps.
ÎHang in the strain relief clamp at the
pushing handle.
ÎLock the rear wheels; remove the wood-
en blocks used for stopping the wheels.
ÎFour indicated floor boards of the pallet
are fastened with screws. Unscrew
these boards.
ÎPlace the boards on the edge of the pal-
let. Place the boards in such a way that
they lie in front of the four wheels of the
machine. Fasten the boards with screws.
ÎSlowly push the machine down from the
ramp.
Note
At the time of manufacturing the appliance,
it has already been flused using an anti-frost
agent. Before starting the machine for the
first time, you need to first remove the anti-
frost agent.
ÎFill in 10 litres of fresh water in the fresh
water reservoir.
ÎPress the foot pedal.
ÎSet the machine switch to basic clean-
ing.
ÎKeep the machine running until the pres-
sure on the manometer falls.
Danger
Risk of injury! The appliance can get stuck
and be dragged away by the travellator/ es-
calator. Before starting cleaning, check the
stepping areas and the ridge profile to see
that there are no deformations or any ob-
jects stuck therein. To be on the safer side,
make sure that you know where the emer-
gency switch-off button of the travellator/ es-
calator is located.
ÎCordon off the travellator/ escalator as
long as cleaning operations are on and
the stepping areas are still wet.
ÎSwitch on the travellator/ escalator.
ÎEnsure that the running direction of the
travellator/ escalator is away from the
machine.
ÎCheck whether the combs and the guide
rails of the machine match the make of
the travellator/ escalator. Replace the
combs and the guide rails, if required.
Before Startup
Installing the pushing handle
Unloading
Removing anti-frost agents
Start up
Preparing the travellator/ escalator
Preparing the appliance

10 English
ÎOpen the cover of the fresh water reser-
voir.
ÎFill in fresh water.
ÎPour in detergent.
Use only those detergents approved by
the manufacturer of the appliance.
ÎClose the cover of the fresh water reser-
voir.
ÎDrive the machine in front of the travella-
tor/ escalator platform.
Danger
Risk of injury!
–Press the foot lever with only one foot.
The other foot must be placed firmly on
the ground.
–Hold the pushing handle firmly with at
least one hand.
–Loose fitting clothes and jewellery can
get entangled in the moving parts of the
travellator/ escalator. Hence, remove
jewellery and wear clothes fitting well on
the body and safety shoes.
The cleaning time depends on the level of
dirt and is divided into three cleaning types.
Use dry vacuum clean on the travellators/
escalators that have already been cleaned.
Cleaning slighly dirty travellators/ escalators
(normally, at short regular intervals). At this
setting, the appliance works with reduced
quantity of water. The water pump works
with regular strokes.
Cleaning very dirty travellators/ escalators
(normally done when the escalator has not
been cleaned for a long time). Areas with
heavy dirt and stains should ideally be
cleaned manually.
– First clear off loose, coarse dust manual-
ly.
– Remove hard objects (such as stones)
from the ridges of the steps.
– Clean the front side of the escalator
steps manually.
– Clean the stepping areas in overlapping
strips. To do that, first move the appli-
ance from the working position and place
it on the side.
– Observe the steps while cleaning. They
should be moist but not wet. There
should not be any foam residue.
– First do moist cleaning (with detergent
liquid) and then dry (by setting the appli-
ance to dry vacuum cleaning).
– Then clean using clear water so as to re-
move detergent residues.
Danger
Risk of injury and electrical shock! Always
lay the extension cable in such a way that it
does not get jammed or crushed and also
does not cause somebody to stumble over it.
ÎPlug in the main plug.
Operation
Cleaning types
Dry vacuum cleaning
Regular cleaning
Basic cleaning
Tips for cleaning
Cleaning operations

English 11
ÎInsert the end of the extension cable as
a loop in the strain relief clamp.
ÎLock the rear wheels.
ÎPlace the machine on the platform in
such a way that the front wheels do not
touch the first step of the moving travel-
lator/ escalator.
ÎPress pedal for lowering the brush head.
The brush head will be lowered and the
lock lever will arrest in its position.
ÎPress the foot pedal with one foot and
while doing so move the machine a little
back and forth towards the side. The ma-
chine will position itself centrally in the
grooves of the steps; you will then hear a
rustling sound.
Danger
Risk of injury! Do not push the appliance
onto the escalator any further than the indi-
cations given below. Otherwise, the ma-
chine will get dragged off by the escalator.
In case of danger, immediately press the
emergency stop switch of the escalator.
The cleaning head must lie flat on the esca-
lator.
ÎSet the appliance switch to regular or ba-
sic cleaning.
The machine is started.
Note
The machine switches off when the dirt wa-
ter reservoir is full. To restart the machine,
empty the dirt water reservoir and briefly set
the appliance switch to "0".
ÎContinue cleaning until the travellator/
escalator has completed 1 or 2 rounds.
Then move the machine towards the
side and start a new cleaning process.
ÎSet the appliance switch to 'dry vacuum
cleaning' position. Dry vacuum cleaning
is activated.
ÎLet the pump pressure fall to 0 bar.
ÎSet the appliance switch to "0".
ÎRelease the foot pedal.
ÎPress pedal for raising the brush head.
Brush head is raised.
ÎMove the appliance to the side.
ÎPress pedal for lowering the brush head.
The brush head will be lowered and the
lock lever will arrest in its position.
ÎPress the foot pedal and place the ma-
chine centrally in the ridges of the steps.
ÎSet the appliance switch to regular or ba-
sic cleaning.
ÎThen clean using clear water so as to re-
move detergent residues.
Danger
Risk of injury! To refill detergent, always
move out the machine first from the working
position.
Moving the appliance to the side

12 English
ÎSet the appliance switch to 'dry vacuum
cleaning' position. Dry vacuum cleaning
is activated.
ÎLet the pump pressure fall to 0 bar.
ÎSet the appliance switch to "0".
ÎRelease the foot pedal.
ÎActivate the lever to lock and the pedal to
raise the brush head. Brush head is
raised.
ÎRelease the rear wheels.
ÎDrive out the machine from the working
position and the podium until it is on firm
ground.
ÎPull out the mains plug.
ÎDrain off and disose the remaining deter-
gent fluid.
ÎDrain out the dirt water and dispose it off.
ÎClean the inside and outside of the ma-
chine. Rinse the tanks with clear water.
ÎStore the machine in a frost-free room on
an even and clean floor.
ÎLock the rear wheels.
ÎRemove the cordon from the travellator/
escalator only when the entire working
area is dry again. There is risk of acci-
dent on account of slipping even if the
travellator/ escalator is slightly moist.
Danger
Risk of injury! Before doing any work on the
machine:
ÎSet the appliance switch to "0".
ÎPull out the mains plug.
ÎLock the rear wheels.
ÎDrain off and disose the remaining deter-
gent fluid.
ÎDrain out the dirt water and dispose it off.
몇Warning
Risk of damage! Do not wash down the ap-
pliance with water and do not use aggres-
sive detergents.
ÎClean the outside of the appliance with a
damp cloth which has been soaked in
mild detergent.
ÎWipe the insides of the dirt water reser-
voir.
ÎClean the fluff filter.
The escalator cleaner must be accessible
from the bottom side to perform any testing
or maintenance jobs on the machine.
ÎTake the help of another person to tilt the
machine forward until it stands on the
front casing.
ÎCheck spray pattern of the nozzles.
ÎCheck if suction nozzles are dirty.
Shutting down
Complete cleaning
Turn off device
Maintenance and care
Cleaning the device
Maintenance intervals
Tilt the machine in the maintenance po-
sition.
Daily before use

English 13
ÎCheck emergency stop function of the
foot pedal.
Press the foot pedal, set the appliance
switch to 'dry vacuum cleaning', the ap-
pliance must run. Release the foot ped-
al; the appliance must stop.
Get the machine repaired only by author-
ised customer service agents.
ÎCheck the locking of the rear wheels.
Get the machine repaired only by author-
ised customer service agents.
ÎCheck for wear and tear:
Roller brushes, intake brushes, combs,
guide rails, hoses, stopper and front
wheels. Replace stopper and front
wheels, if required, only through author-
ised customer service agents.
ÎCheck mains cable and plug for damage
or breakage. Get them replaced only
through customer service agent or an
electrician.
ÎCheck if all fasteners are fastened tight-
ly.
ÎCheck the drive belt for tension and wear
(Customer Service).
ÎUnscrew the tin cover plate using a torx
spanner.
Note
You will find a torx spanner in the holder of
the drainage hose of the dirt water reservoir.
ÎClean the fluff filter.
ÎReplace the tin plate.
ÎLoosen all the four screws and remove
the bearing lid.
ÎRemove the roller brushes (large) and in-
take brushes (small) and replace them
(pay attention to the hexagonal intake of
the brushes!).
Also check simultaneously the combs
and the guide rails and replace or clean
them as required.
After 100 operating hours
Maintenance Works
Clean the fluff filter
1
Replacing the roller brushes and the in-
take brushes
2

14 English
ÎRemove the combs and replace them.
To do this, slide the inlet combs on the
narrow rails and the outlet combs on the
wider rails.
ÎPull out all dirt particles from the suction
nozzles; do not push them in.
ÎLoosen the fastening screws of the hold-
er for the guide rails.
ÎDismantle the guide rails.
ÎInsert the guide rails in reverse se-
quence. Ensure that they sit properly.
ÎLoosen the union joint. Remove nozzle,
washer and sieve.
ÎClean the nozzle or insert a new nozzle
in the union joint.
ÎInsert washer and sieve and tighten the
union joint by hand.
ÎUnscrew the pad with a screw-driver and
replace it.
Danger
Risk of injury! Do not drive over slopes great-
er than 5°. Never transport the machine over
the travellator/ escalator.
ÎLock the rear wheels.
ÎSecure the machine with clamping belts
and ropes so that it doesn't slip off.
Replacing the combs
Cleaning the suction nozzles
Replacing the guide rails
Check nozzles and filters for detergents
Replacing the pad
Transport

English 15
Danger
Risk of injury! Before doing any work on the
machine:
ÎSet the appliance switch to "0".
ÎPull out the mains plug.
ÎLock the rear wheels.
ÎDrain off and disose the remaining deter-
gent fluid.
ÎDrain out the dirt water and dispose it off.
Troubleshooting
Fault Remedy
Motor/pump do not start or
switch off automatically when the
machine is on.
Dirt water reservoir is full; empty it.
Press the foot pedal.
Indicator lamp "Dirt water tank
full" is glowing.
Dirt water reservoir is full; empty it.
Working pressure of min. 3 bar is
not building up.
If fresh water reservoir is empty, then fill it up (35 litres).
Check pipes to see if there are any leaks. If required, get
it sealed by customer service.
Check the nozzles.
Get customer service to clean the pump.
Cleaned steps are too wet. Check the combs for wear, replace if required.
Check the condition of the seal of the dirt water reservoir
for damages, replace if required.
Check the intake brushes for wear, replace if required.
Check suction nozzles and hose for blockages; clean if
required.
Check whether the wastewater reservoir lid is completely
closed.
Check whether the correct combs have been installed.
Washed steps are not clean. Check detergent nozzles to see if they are blocked; clean
or replace if required.
Check the condition of the seal of the dirt water reservoir
for damages, replace if required.
Check the brush rollers and intake brushes for wear, re-
place if required.
Check detergent. Check the concentration of the deter-
gent solution.
Check the intake brushes for wear, replace if required.
Check whether the wastewater reservoir lid is completely
closed.
Check whether the correct combs have been installed.
Indicator lamp "Brush motor
overload" is glowing.
Set appliance switch to "0", then turn it back to the de-
sired operating position. If the fault recurs often, call cus-
tomer service.
Remove belts or cords from brushes.

16 English
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre. Please
submit the proof of purchase.
Danger
Risk of injury and electrical shock! Repair
works may only be performed by the author-
ised customer service.
– Only use accessories and spare parts
which have been approved by the manu-
facturer. The exclusive use of original ac-
cessories and original spare parts
ensures that the appliance can be oper-
ated safely and troublefree.
– At the end of the operating instructions
you will find a selected list of spare parts
that are often required.
– For additional information about spare
parts, please go to the Service section at
www.kaercher.com.
Specifications
1.310-105
Nominal voltage V 120
Frequency Hz 60
Control voltage V 12
Rated power (max.) W 1360
Suction engine output W 800
Brush engine output W 650
Pump pressure bar 3-4
Water Consumption l/h 25-50
Speed of roller brushes 1/min 870
Speed of intake brushes 1/min 1090
Working width mm 470
Width mm 480
Length mm 1150
Height with pushing
handle
mm 1050
Height without pushing
handle
mm 760
Fresh/dirt water reser-
voir volume
l 35/35
Unladen weight kg approx.
90
Operating weight kg approx.
125
Sound pressure level
(EN 60704-1)
dB(A) <75
Vibration total value
(ISO 5349)
m/s20,43
Warranty
Accessories and Spare Parts

English 17
Accessories
Accessories Type Part no.: Description
Roller brushes, soft
(standard)
5.762-266 Roller brushes for regular cleaning
(appliance needs 2 pieces).
Roller brushes, hard 5.762-267 Roller brushes for regular cleaning,
for removing stubborn dirt (appli-
ance needs 2 pieces).
Intake brushes 5.762-268 For transporting the dirt water trans-
port from the travellator/ escalator to
the suction nozzles (appliance re-
quires 2 pieces).
Inlet combs, blue Kone 6.369-509 Combs for adjusting the appliance to
the respective travellator/ escalator
brand (set with 2 pieces).
Outlet combs, blue Kone 6.369-519
Inlet combs, black OTIS 6.369-510
Outlet combs, black OTIS 6.369-520
Inlet combs, green Schindler 6.369-511
Outlet combs, green Schindler 6.369-521
Inlet combs, white CNIM 6.369-512
Outlet combs, white CNIM 6.369-522
Groove scraper Kone und
Schindler
6.369-507 For manual pre-cleaning (removing
stones, chewing gum and other
sticky dirt).
OTIS und
Thyssen
6.369-508
Set Handpads Kone 6.369-513 For manually cleaning the front side
of the steps (set with 5 green pads).
OTIS 6.369-514
Schindler 6.369-515
Thyssen 6.369-516
Detergent RM 758 For cleaning by machine.
Detergent RM 759 For basic cleaning (30 kg). For man-
ually cleaning very dirty spots.

5950-583.book Seite 98 Donnerstag, 13. Februar 2003 3:55 15

Français 19
Pour réduire les risques d'incendie, de chok
électrique ou de blessure:
– Ne pas laisser l'appareil sans
surveillance lorsqu'il est branché.
Débrancher lorsque l'appareil n'est pas
utilisé et avant l'entretien.
– Pour réquire les risques de choc
électrique, utiliser à l'interieur seulement.
– Ne pas permettre aux enfants de jouer
avec l'appareil. Une attention particulière
est nécessaire lorsque l'appareil est
utilisé par des enfants ou à proximité de
ces derniers.
– N'utiliser que conformément à cette
notice avec les accessoires
recommandés par le fabricant.
– Ne pas utiliser si le cordon ou la fiche est
endommagé. Retourner l'appareil à un
atelier de réparation s'il ne fonctionne
pas bien, s'il est tombé ou s'il a été
endommagé, oublie à l'extérieur ou
immergé.
– Ne pas tirer soulever ni traîner l'appareil
par le cordon. Ne pas utiliser le cordon
comme une poignée, le coincer dans
l'embrasure d'une porte ou l'appuyer
contre des arêtes vives ou des coins. Ne
pas faire rouler l'appareil sur le cordon.
Garder le cordon à l'écart des surfaces
chaudes.
– Ne pas débrancher en tirant sur le
cordon. Tirer plutôt la fiche.
– Ne pas toucher la fiche ni l'appareil
lorsque vos mains sont humides.
– N'insérer aucun objet dans les
ouvertures. Ne pas utiliser l'appareil
lorsqu'une ouverture est bloquée.
S'assurer que de la poussière, de la
peluche, des cheveux ou d'autres
matières ne réduisent pas le debit d'air.
– Maintenir les cheveux, les vêtements
amples, les doigts et toutes les parties
du corps à l'écart des ouvertures et des
pièces mobiles.
– Mettre toutes les commandes à la
position ARRÊT avant de débrancher
l'appareil.
– User de prudence lors du nettoyage des
escaliers.
– Ne pas aspirer des liquides
inflammables ou combustibles, comme
de l'essence, et ne pas faire functionner
dans des endroits où peuvent se trouver
de tels liquides.
– Ne brancher qu'à une prise de courant
avec mise à la terre. Voir les instructions
la mise à la terre.
Cet appareil doit être mis à la terre. En cas
de défaillance ou de panne, la mise à la terre
fournit au courant un chemin de moindre ré-
sistance qui réduit le risque de choc élec-
trique. Cet appareil est pourvu d'un cordon
muni d'un conducteur de terre et d'une fiche
avec broche de terre. La fiche doit être
branchée dans une prise appropriée correct-
ement installée et mise à la terre conformé-
ment aux règlements et ordonnances
municipaux.
Un conducteur de terre mal raccordé peut
entraîner un risque de choc électrique. Con-
sulter un électricien ou un technicien d'entre-
tien qualifié si vous n'êtes pas certain que la
prise est correctement mise à la terre. Ne
INSTRUCTIONS IMPORTAN-
TES EN MATIÈRE DE SÉCU-
RITÉ
LIRE TOUTES LES INSTRUC-
TIONS AVANT DE FAIRE
FONKTIONNER
Attention
Attention
CONSERVER CES INSTRUC-
TIONS
INSTRUCTIONS VISANT LA
MISE À LA TERRE
Attention

20 Français
pas modifier la fiche fournie avec l'appareil -
si elle ne peut être insérée dans la prise, fair
installer une prise adéquate par un élec-
tricien qualifié.
Cet appareil est destiné à un circuit de 120
V et est muni d'une fiche de mise à la terre
semblable à celle illustrée par le croqui A.
S'assurer que l'appareil est branché à une
prise de courant ayant la même configura-
tion que la fiche. Aucun adaptreur nr devrait
être utilisé avec cet appareil.
1 Sortie avec mise à la terre
2 Boîte avec mise à la terre
3 Fiche avec mise à la terre
Un fonctionnement sûr est la responsabilité
de l'opérateur.
L'opérateur doit être au courant du fonction-
nement et des fonctions de toutes les com-
mandes et de tous les instruments avant
d'entreprendre de faire fonctionner l'unité.
Avant de faire fonctionner l'unité, les opéra-
teurs doivent avoir lu et bien connaître le
manuel d'utilisation pour l'unité particulière
en fonctionnement et ils doivent également
obéir aux règles et pratiques de sécurité
énoncées dans les paragraphes suivants.
Avant de faire fonctionner l'unité, l'opérateur
doit bien connaître les conditions de fonc-
tionnement inhabituelles qui peuvent néces-
siter des précautions de sécurité
supplémentaires ou des instructions de
fonctionnement spéciales.
Avant de commencer à faire fonctionner
l'unité, soyez dans une position d'opération.
Ne démarrez pas ou n'opérez pas l'unité,
l'une quelconque de ses fonctions ou acces-
soires, depuis tout endroit autre que la posi-
tion désignée pour les opérateurs.
Avant de quitter la position de l'opérateur :
A arrêtez complètement l'unité ;
B si l'unité doit se trouver sur un plan incli-
né, bloquez les roues.
Conservez une distance de sécurité depuis
le bord des rampes, plate-formes et autres
surfaces de travail similaires.
N'effectuez aucun ajout ou aucune modifica-
tion à l'unité.
Ne bloquez pas l'accès aux couloirs à incen-
die, escaliers ou équipement de lutte contre
les incendies.
Donnez la priorité aux piétons et véhicules
d'urgence tels que les ambulances et les ca-
mions de pompiers.
Traversez les voies ferrées de manière an-
gulaire si possible. Ne vous garez pas à
moins de 1800 mm du rail le plus proche
d'une voie ferrée.
Conservez une vision claire du chemin de
déplacement et prenez garde au reste de la
circulation, au personnel et aux dégage-
ments sûrs.
Opérez l'unité à une vitesse qui lui permettra
d'être arrêtée de manière sûre dans toutes
les conditions de déplacement.
Ne vous adonnez pas aux cascades ou à la
brutalité.
Ralentissez en cas de sols mouillés et glis-
sants.
Avant de passer sur un bord de quai ou sur
la chaussée d'un pont, assurez-vous qu'il/
NE BRANCHER QU'À UNE
PRISE DE COURANT AVEC
MISE À LA TERRE
REGLES ET PRATIQUES DE
SECURITE DE FONCTION-
NEMENT
Responsabilité de l'opérateur
Généralités
Déplacements
