Ref: 09-12 Copyright, 2003. The Toro Company
Customer Service Bulletin
Commercial Business Group
Date: July 31, 2003
Workman® 1100, 2100 & 2110 MultiPro® 1200 & 1250
Model/Serial Range: Model Number: Serial Numbers:
07252 210000001-230000668
07252TC 210000101-230000240
07253 200000001-230000478
07253TC 200000101-230000235
07277 220000001-230000478
07277TC 220000101-230000351
41106 200000001-230000412
41107 200000001-230000307
Subject: Primary Drive Clutch Maintenance
The primary clutch is designed to provide long life with a minimum amount of maintenance.
Routine cleaning and servicing is needed to ensure longevity in the vehicle.
PRIMARY DRIVE CLUTCH SERVICING INSTRUCTIONS
Workman
®
1100, 2100 & 2110 MultiPro
®
1200 & 1250
1. Stop engine and engage parking brake.
2. Raise and latch cargo box. (As Required)
3. Remove three fasteners and separate cover from the clutch.
4. Clean the clutch and cover using dry methods (brush or cloth). If using compressed air, take
necessary precautions to avoid inhaling dust.
5. Lubricate the cam weights, pivots and roller pivots using Toro Dry Lubricant (104-7011) spray.
6. Install the clutch cover and torque the three fasteners to 75 to 150 in–lb (8.5 – 11 N-m).
