Toro Workman MDX-D User manual

Part No. 13200SL
Service Manual
WorkmanRMDX--D
Preface
The purpose of this publication is to provide the service
technician with information for troubleshooting, testing
and repair of major systems and components on the
Workman MDX--D.
REFER TO THE OPERATOR’S MANUAL FOR OPER-
ATING, MAINTENANCE AND ADJUSTMENT IN-
STRUCTIONS. For reference, insert a copy of the
Operator’s Manual and Parts Catalog for your machine
into Chapter 2 of this service manual. Additional copies
of the Operator’s Manual and Parts Catalog are avail-
able on the internet at www.Toro.com.
The Toro Company reserves the right to change product
specifications or this publication without notice.
This safety symbol means DANGER, WARNING,
or CAUTION, PERSONAL SAFETY INSTRUC-
TION. When you see this symbol, carefully read
the instructions that follow. Failure to obey the
instructions may result in personal injury.
NOTE: ANOTE will give general information about the
correct operation, maintenance, service, testing or re-
pair of the machine.
IMPORTANT: The IMPORTANT notice will give im-
portant instructions which must be followed to pre-
vent damage to systems or components on the
machine.
EThe Toro Company -- 2013

Workman MDX--D
This page is intentionally blank.

Workman MDX--D
Table Of Contents
Chapter 1 -- Safety
Safety Instructions 1 -- 2..........................
Jacking and Other Instructions 1 -- 4...............
Safety and Instruction Decals 1 -- 6................
Chapter 2 -- Product Records and Maintenance
Product Records 2 -- 1...........................
Maintenance 2 -- 1...............................
Equivalents and Conversions 2 -- 2................
Torque Specifications 2 -- 3.......................
Chapter 3 -- Diesel Engine
Specifications 3 -- 2..............................
General Information 3 -- 3........................
Adjustments 3 -- 5...............................
Service and Repairs 3 -- 6........................
KUBOTA WORKSHOP MANUAL, DIESEL ENGINE,
SM--E3B SERIES
Chapter 4 -- Drive Train
Specifications 4 -- 2..............................
General Information 4 -- 3........................
Drive Train Operation 4 -- 4.......................
Special Tools 4 -- 7..............................
Troubleshooting 4 -- 8............................
Adjustments 4 -- 9...............................
Service and Repairs 4 -- 10.......................
Chapter 5 -- Electrical System
General Information 5 -- 2........................
Special Tools 5 -- 3..............................
Troubleshooting 5 -- 5............................
Electrical System Quick Checks 5 -- 7..............
Component Testing 5 -- 8.........................
Service and Repairs 5 -- 23.......................
Chapter 6 -- Chassis
Specifications 6 -- 2..............................
General Information 6 -- 3........................
Special Tools 6 -- 4..............................
Troubleshooting 6 -- 5............................
Adjustments 6 -- 8...............................
Service and Repairs 6 -- 11.......................
Chapter 7 -- Electrical Drawings
Electrical Schematic 7 -- 3........................
Circuit Diagrams 7 -- 4...........................
Electrical Harness Drawings 7 -- 8.................
SafetyProduct Records
and Maintenance
Diesel
Engine
Drive TrainElectrical
System
Electrical
Drawings Chassis

Workman MDX--D
This page is intentionally blank.

Workman MDX--D Page 1 -- 1 Safety
Chapter 1
Safety
Table of Contents
SAFETY INSTRUCTIONS 2......................
Supervisor’s Responsibilities 2.................
Before Operating 2............................
While Operating 3............................
Maintenance and Service 3....................
JACKING AND OTHER INSTRUCTIONS 4........
Jack Vehicle 4................................
Transport Vehicle 4...........................
Tow Vehicle 4................................
Transaxle Neutral Position 5...................
SAFETY AND INSTRUCTION DECALS 6..........
Safety

Workman MDX--DPage 1 -- 2Safety
Safety Instructions
Workman MDX--D vehicles are designed and tested to
offer safe service when operated and maintained pro-
perly. Although hazard control and accident prevention
partially are dependent upon the design and configura-
tion of the machine, these factors are also dependent
upon the awareness, concern and proper training of the
personnel involved in the operation, transport, mainte-
nance and storage of the machine. Improper use or
maintenance of the machine can result in injury or
death.
Read and understand the contents of the Operator’s
Manual before starting and operating the machine. Be-
come familiar with all controls and know how to stop it
quickly. Additional copies of the Operator’s Manual are
available on the internet at www.Toro.com.
The safety alert symbol means
CAUTION, WARNING or DANGER —
“personal safety instruction”. Read
and understand the instruction because it has to
do with safety. Failure to comply with the instruc-
tion may result in personal injury.
WARNING
To reduce the potential for injury or death, com-
ply with the following safety instructions.
WARNING
The Workman is an off--highway vehicle only. It is
not designed, equipped or manufactured for use
on public streets, roads or highways.
Supervisor’s Responsibilities
1. Make sure operators are thoroughly trained and fa-
miliar with the Operator’s Manual and all labels on the
vehicle.
2. Be sure to establish your own special procedures
and work rules for unusual operating conditions (e.g.
slopes too steep for vehicle operation).
Before Operating
1. Read and understand the contents of the Operator’s
Manual and Operator’s DVD before starting and operat-
ing the vehicle. Become familiar with the controls and
know how to stop the vehicle and engine quickly. Addi-
tional copies of the Operator’s Manual are available on
the internet at www.Toro.com.
2. Keep all shields, safety devices and decals in place.
If a shield, safety device or decal is defective, illegible or
damaged, repair or replace it before operating the ve-
hicle. Also, tighten any loose nuts, bolts or screws to en-
sure vehicle is in safe operating condition.
3. Since diesel fuel used in your Workman MDX--D
vehicle is flammable, handle it carefully:
A. Store fuel in containers specifically designed for
this purpose.
B. Do not remove vehicle fuel tank cap while engine
is hot or running.
C. Do not smoke while handling fuel.
D. Fill fuel tank outdoors and only to within an inch of
the top of the tank, not the filler neck. Do not overfill
the fuel tank.
E. Cleanupanyspilledfuel.

Workman MDX--D Page 1 -- 3 Safety
While Operating
1. Sit on the operator seat when starting and operating
the vehicle.
2. Before starting the engine:
A. Sit on operator’s seat and depress the brake ped-
al. Make sure that the parking brake is released.
B. Turn ignition switch to the ON position. When the
glow plug indicator goes off, the engine is ready to
start.
C. Turn ignition switch to the START position. Re-
lease switch to the ON position once the engine
starts.
3. Do not run engine in a confined area without ade-
quate ventilation. Exhaust fumes are hazardous and
could possibly be deadly.
4. Do not touch engine, radiator, exhaust system or
transaxle while engine is running or soon after it is
stopped. These areas could be hot enough to cause
burns.
5. Before getting off the seat:
A. Stop movement of the vehicle.
B. Turn ignition switch to OFF and wait for all move-
ment to stop.
C. Apply parking brake.
D. Remove key from ignition switch.
E. Do not park on slopes unless wheels are chocked
or blocked.
Maintenance and Service
1. Before servicing or making adjustments, turn all ac-
cessories off, stop the engine, set parking brake and re-
move key from the ignition switch.
2. Make sure vehicle is in safe operating condition by
keeping all nuts, bolts and screws tight.
3. Never work under a raised bed without placing the
bed on the fully extended prop rod.
4. Never store the vehicle or fuel container inside
where there is an open flame, such as near a water heat-
er or furnace.
5. To reduce potential fire hazard, keep engine area
free of excessive grease, grass, leaves and dirt.
6. If engine must be running to perform maintenance or
an adjustment, keep clothing, hands, feet and other
parts of the body away from moving parts. Keep by-
standers away.
7. Do not overspeed the engine by changing governor
setting. To assure safety and accuracy, check maximum
engine speed. Maximum engine speed is 3470 RPM.
8. Shut engine off before checking or adding oil to the
engine crankcase.
9. Disconnect battery before servicing the vehicle. Dis-
connect negative (--) battery cable first and positive (+)
cable last. If battery voltage is required for troubleshoot-
ing or test procedures, temporarily connect the battery.
Attach positive (+) cable first and negative (--) cable last.
10.Battery acid is poisonous and can cause burns.
Avoid contact with skin, eyes and clothing. Protect your
face, eyes and clothing when working with a battery.
11. Battery gases can explode. Keep cigarettes, sparks
and flames away from the battery.
12.If major repairs are ever needed or assistance is de-
sired, contact an Authorized Toro Distributor.
13.To assure optimum performance and continued
safety of the vehicle, use genuine Toro replacement
parts and accessories. Replacement parts and acces-
sories made by other manufacturers may result in non-
conformance with safety standards, and the warranty
may be voided.
14.When raising the vehicle to change tires or to per-
form other service, use correct blocks, hoists and jacks.
Make sure vehicle is parked on a solid level surface such
as a concrete floor. Prior to raising the vehicle, remove
any attachments that may interfere with the safe and
proper raising of the vehicle. Always chock or block
wheels. Use appropriate jack stands to support the
raised vehicle. If the vehicle is not properly supported by
jack stands, the vehicle may move or fall, which may re-
sult in personal injury (see Jack Vehicle in this section).
15.Make sure to dispose of potentially harmful waste
(e.g. fuel, oil, engine coolant, filters, battery) in an envir-
onmentally safe manner. Follow all local codes and reg-
ulations when recycling or disposing of waste.
Safety

Workman MDX--DPage 1 -- 4Safety
Jacking and Other Instructions
Jack Vehicle
DANGER
POTENTIAL HAZARD
A vehicle that is not properly supported
may become unstable.
WHAT CAN HAPPEN
The vehicle may move or fall. Personal
injury or damage to the machine may result.
HOW TO AVOID THE HAZARD
Make sure vehicle is parked on a solid level
surface, such as a concrete floor.
Make sure engine is off and key is removed
from the ignition switch before getting off
the vehicle.
Before raising the vehicle, remove any
attachments that may interfere with the safe
and proper raising of the vehicle.
Always chock or block wheels to prevent
the vehicle from rolling.
Do not start vehicle while it is on jack
stands without placing transaxle in neutral.
Make sure proper hoists, jacks and jack
stands are used to raise and support the
vehicle.
Jacking Locations
1. Jack front of the vehicle on the front of the frame and
behind the towing tongue (Fig. 1).
2. Jack rear of the vehicle under each rear axle tube. Do
not jack vehicle below the transaxle case (Fig. 2).
1. Front frame 2. Towing tongue
Figure 1
12
1. Transaxle case 2. Axle tube
Figure 2
2
1
Transport Vehicle
When moving the vehicle long distances, use a trailer or
flatbed truck. Make sure vehicle is secured to the trailer
properly. Refer to Operator’s Manual for transport infor-
mation.
Tow Vehicle
IMPORTANT: Frequent or long distance towing of
the Workman MDX--D is not recommended.
In case of emergency, the vehicle can be towed for a
short distance. Refer to Operator’s Manual for towing
information.
IMPORTANT: If vehicle is towed, make sure that
ignition switch is in the OFF position and key is re-
moved from switch.

Workman MDX--D Page 1 -- 5 Safety
Transaxle Neutral Position
When performing routine maintenance and/or engine
testing, the transaxle must be shifted into the neutral
position.
1. Park machine on a level surface, stop engine, set
parking brake and remove key from the ignition switch.
2. Move shift lever to the neutral position (Fig. 3).
3. Make sure transaxle is in the neutral position by ro-
tating the driven clutch. The tires should not rotate when
the transaxle is in the neutral position. If tire rotation
does occur, see Adjust Shift Cables in the Adjustments
section of Chapter 4 -- Drive Train.
1. Shift lever (in neutral)
2. Forward position
3. Reverse position
Figure 3
1
3
2
Safety

Workman MDX--DPage 1 -- 6Safety
Safety and Instruction Decals
Numerous safety and instruction decals are affixed to
your Workman. If any decal becomes illegible or dam-
aged, install a new decal. Part numbers are listed in the
Parts Catalog. Order replacement decals from your Au-
thorized Toro Distributor.

Workman MDX--D Page 2 -- 1 Product Records and Maintenance
Chapter 2
Product Records and Maintenance
Table of Contents
PRODUCT RECORDS 1.........................
MAINTENANCE 1..............................
EQUIVALENTS AND CONVERSIONS 2...........
Decimal and Millimeter Equivalents 2............
U.S. to Metric Conversions 2...................
TORQUE SPECIFICATIONS 3...................
Fastener Identification 3.......................
Standard Torque for Dry, Zinc Plated and
Steel Fasteners (Inch Series). 4...............
Standard Torque for Dry, Zinc Plated and
Steel Fasteners (Metric Fasteners). 5..........
Other Torque Specifications 6..................
Conversion Factors 6.........................
Product Records
Insert Operator’s Manual and Parts Catalog for your
Workman at the end of this chapter. Additionally, if any
optional equipment or accessories have been installed
to your machine, insert the Installation Instructions, Op-
erator’s Manuals and Parts Catalogs for those options
at the end of this chapter.
Maintenance
Maintenance procedures and recommended service in-
tervals for your Workman are covered in the Operator’s
Manual. Refer to that publication when performing regu-
lar equipment maintenance.
Product Records
and Maintenance

0.09375
Workman MDX--DPage 2 -- 2Product Records and Maintenance
Equivalents and Conversions

Workman MDX--D Page 2 -- 3 Product Records and Maintenance
Torque Specifications
Recommended fastener torque values are listed in the
following tables. For critical applications, as determined
by Toro, either the recommended torque or a torque that
is unique to the application is clearly identified and spe-
cified in this Service Manual.
These Torque Specifications for the installation and
tightening of fasteners shall apply to all fasteners which
do not have a specific requirement identified in this Ser-
vice Manual. The following factors shall be considered
when applying torque: cleanliness of the fastener, use
of a thread sealant (e.g. Loctite), degree of lubrication
on the fastener, presence of a prevailing torque feature,
hardness of the surface underneath the fastener’s head
or similar condition which affects the installation.
As noted in the following tables, torque values should be
reduced by 25% for lubricated fasteners to achieve
the similar stress as a dry fastener. Torque values may
also have to be reduced when the fastener is threaded
into aluminum or brass. The specific torque value
should be determined based on the aluminum or brass
material strength, fastener size, length of thread en-
gagement, etc.
The standard method of verifying torque shall be per-
formed by marking a line on the fastener (head or nut)
and mating part, then back off fastener 1/4 of a turn.
Measure the torque required to tighten the fastener until
thelinesmatchup.
Fastener Identification
Figure 1
Grade 1 Grade 5 Grade 8
Inch Series Bolts and Screws
Figure 2
Class 8.8 Class 10.9
Metric Bolts and Screws
Product Records
and Maintenance

Workman MDX--DPage 2 -- 4Product Records and Maintenance
Standard Torque for Dry, Zinc Plated and Steel Fasteners (Inch Series)
Thread Size
Grade 1, 5 &
8withThin
Height Nuts
SAE Grade 1 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 2 or Stronger Nuts)
SAE Grade 5 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 2 or Stronger Nuts)
SAE Grade 8 Bolts, Screws, Studs &
Sems with Regular Height Nuts
(SAE J995 Grade 5 or Stronger Nuts)
in--lb in--lb N--cm in--lb N--cm in--lb N--cm
#6--32UNC
10 + 213 + 2147 + 23
15 + 2169 + 23 23 + 3262 + 34
#6--40UNF 17 + 2192 + 23 25 + 3282 + 34
#8--32UNC
13 + 225 + 5282 + 30
29 + 3328 + 34 41 + 5463 + 56
#8--36UNF 31 + 4350 + 45 43 + 5486 + 56
#10--24UNC
18 + 230 + 5339 + 56
42 + 5475 + 56 60 + 6678 + 68
#10--32UNF 48 + 5542 + 56 68 + 7768 + 79
1/4 -- 20 UNC 48 + 753 + 7599 + 79 100 + 10 1130 + 113 140 + 15 1582 + 169
1/4 -- 28 UNF 53 + 765 + 10 734 + 113 115 + 12 1299 + 136 160 + 17 1808 + 192
5/16 -- 18 UNC 115 + 15 105 + 15 1186 + 169 200 + 25 2260 + 282 300 + 30 3390 + 339
5/16 -- 24 UNF 138 + 17 128 + 17 1446 + 192 225 + 25 2542 + 282 325 + 33 3672 + 373
ft--lb ft--lb N--m ft--lb N--m ft--lb N--m
3/8 -- 16 UNC 16 + 216 + 222 + 330 + 341 + 443 + 558 + 7
3/8 -- 24 UNF 17 + 218 + 224 + 335 + 447 + 550 + 668 + 8
7/16 -- 14 UNC 27 + 327 + 337 + 450 + 568 + 770 + 795 + 9
7/16 -- 20 UNF 29 + 329 + 339 + 455 + 675 + 877 + 8104 + 11
1/2 -- 13 UNC 30 + 348 + 765 + 975 + 8102 + 11 105 + 11 142 + 15
1/2 -- 20 UNF 32 + 453 + 772 + 985 + 9115 + 12 120 + 12 163 + 16
5/8 -- 11 UNC 65 + 10 88 + 12 119 + 16 150 + 15 203 + 20 210 + 21 285 + 28
5/8 -- 18 UNF 75 + 10 95 + 15 129 + 20 170 + 18 230 + 24 240 + 24 325 + 33
3/4 -- 10 UNC 93 + 12 140 + 20 190 + 27 265 + 27 359 + 37 375 + 38 508 + 52
3/4 -- 16 UNF 115 + 15 165 + 25 224 + 34 300 + 30 407 + 41 420 + 43 569 + 58
7/8 -- 9 UNC 140 + 20 225 + 25 305 + 34 430 + 45 583 + 61 600 + 60 813 + 81
7/8 -- 14 UNF 155 + 25 260 + 30 353 + 41 475 + 48 644 + 65 667 + 66 904 + 89
NOTE: Reduce torque values listed in the table above
by 25% for lubricated fasteners. Lubricated fasteners
are defined as threads coated with a lubricant such as
engine oil or thread sealant such as Loctite.
NOTE: Torque values may have to be reduced when
installing fasteners into threaded aluminum or brass.
The specific torque value should be determined based
on the fastener size, the aluminum or base material
strength, length of thread engagement, etc.
NOTE: The nominal torque values listed above for
Grade 5 and 8 fasteners are based on 75% of the mini-
mum proof load specified in SAE J429. The tolerance is
approximately + 10% of the nominal torque value. Thin
height nuts include jam nuts.

Workman MDX--D Page 2 -- 5 Product Records and Maintenance
Standard Torque for Dry, Zinc Plated and Steel Fasteners (Metric Series)
Thread Size
Class 8.8 Bolts, Screws and Studs with
Regular Height Nuts
(Class 8 or Stronger Nuts)
Class 10.9 Bolts, Screws and Studs with
Regular Height Nuts
(Class 10 or Stronger Nuts)
M5 X 0.8 57 + 6in--lb 644 + 68 N--cm 78 + 8in--lb 881 + 90 N--cm
M6 X 1.0 96 + 10 in--lb 1085 + 113 N--cm 133 + 14 in--lb 1503 + 158 N--cm
M8 X 1.25 19 + 2ft--lb 26 + 3N--m 28 + 3ft--lb 38 + 4N--m
M10 X 1.5 38 + 4ft--lb 52 + 5N--m 54 + 6ft--lb 73 + 8N--m
M12 X 1.75 66 + 7ft--lb 90 + 10 N--m 93 + 10 ft--lb 126 + 14 N--m
M16 X 2.0 166 + 17 ft--lb 225 + 23 N--m 229 + 23 ft--lb 310 + 31 N--m
M20 X 2.5 325 + 33 ft--lb 440 + 45 N--m 450 + 46 ft--lb 610 + 62 N--m
NOTE: Reduce torque values listed in the table above
by 25% for lubricated fasteners. Lubricated fasteners
are defined as threads coated with a lubricant such as
engine oil or thread sealant such as Loctite.
NOTE: Torque values may have to be reduced when
installing fasteners into threaded aluminum or brass.
The specific torque value should be determined based
on the fastener size, the aluminum or base material
strength, length of thread engagement, etc.
NOTE: The nominal torque values listed above are
based on 75% of the minimum proof load specified in
SAE J1199. The tolerance is approximately + 10% of the
nominal torque value.
Product Records
and Maintenance

Workman MDX--DPage 2 -- 6Product Records and Maintenance
Other Torque Specifications
SAE Grade 8 Steel Set Screws
Thread Size
Recommended Torque
Square Head Hex Socket
1/4 -- 20 UNC 140 + 20 in--lb 73 + 12 in--lb
5/16 -- 18 UNC 215 + 35 in--lb 145 + 20 in--lb
3/8 -- 16 UNC 35 + 10 ft--lb 18 + 3ft--lb
1/2 -- 13 UNC 75 + 15 ft--lb 50 + 10 ft--lb
Thread Cutting Screws
(Zinc Plated Steel)
Type 1, Type 23 or Type F
Thread Size Baseline Torque*
No. 6 -- 32 UNC 20 + 5in--lb
No. 8 -- 32 UNC 30 + 5in--lb
No. 10 -- 24 UNC 38 + 7in--lb
1/4 -- 20 UNC 85 + 15 in--lb
5/16 -- 18 UNC 110 + 20 in--lb
3/8 -- 16 UNC 200 + 100 in--lb
Wheel Bolts and Lug Nuts
Thread Size Recommended Torque**
7/16 -- 20 UNF
Grade 5
65 + 10 ft--lb 88 + 14 N--m
1/2 -- 20 UNF
Grade 5
80 + 10 ft--lb 108 + 14 N--m
M12 X 1.25
Class 8.8
80 + 10 ft--lb 108 + 14 N--m
M12 X 1.5
Class 8.8
80 + 10 ft--lb 108 + 14 N--m
** For steel wheels and non--lubricated fasteners.
Thread Cutting Screws
(Zinc Plated Steel)
Thread
Size
Threads per Inch
Baseline Torque*
Type A Type B
No. 6 18 20 20 + 5in--lb
No. 8 15 18 30 + 5in--lb
No. 10 12 16 38 + 7in--lb
No. 12 11 14 85 + 15 in--lb
* Hole size, material strength, material thickness and fin-
ish must be considered when determining specific
torque values. All torque values are based on non--lubri-
cated fasteners.
Conversion Factors
in--lb X 11.2985 = N--cm N--cm X 0.08851 = in--lb
ft--lb X 1.3558 = N--m N--m X 0.7376 = ft--lb

Workman MDX--D Page 3 -- 1 Diesel Engine
Chapter 3
Diesel Engine
Table of Contents
SPECIFICATIONS 2............................
GENERAL INFORMATION 3.....................
Operator’s Manual 3..........................
ADJUSTMENTS 5..............................
Adjust Throttle Cable 5........................
SERVICE AND REPAIRS 6......................
Air Cleaner 6.................................
Exhaust System 8............................
Fuel Tank 10.................................
Radiator 12..................................
Engine 14....................................
Engine Removal 15..........................
Engine Installation 16........................
Engine Clutch Adapter 18......................
KUBOTA WORKSHOP MANUAL, DIESEL ENGINE,
SM--E3B SERIES
Diesel
Engine

Workman MDX--DPage 3 -- 2Diesel Engine
Specifications
Item Description
Make / Designation Kubota water--cooled, Diesel,
Model Z602--E3B
Number of Cylinders 2
Bore x Stroke 2.83” x 2.9” (72mm x 73.6mm)
Total Displacement 36.55 in3(599 cc)
Compression Ratio 24.0:1
Firing Order 1 (closest to gear case end) -- 2 (closest to flywheel end)
Direction of Rotation Counterclockwise (viewed from flywheel)
Fuel Diesel Fuel with Low or
Ultra Low Sulfur Content
Fuel Injector Pump Bosch MD Type Mini
Fuel Injection Nozzle Bosch Throttle Type
Fuel Capacity 6.5 U.S. gallons (24.6 liters)
Governor Mechanical
Low Idle (no load) 1300 + 70 RPM
High Idle (no load) 3470 + 50 RPM
Engine Oil API CH--4, CI--4, CJ--4 or higher
Engine Oil Viscosity See Operator’s Manual
Oil Pump Gear Driven Trochoid Type
Crankcase Oil Capacity 2.6 U.S. quarts (2.5 liters) with filter
Cooling System Capacity (including reserve tank) 3.0 U.S. quarts (2.8 liters)
Starter 12 VDC 0.95 KW
Alternator/Regulator 12 VDC 40 AMP
Dry Weight (approximate) 132 lbs (60 kg)

Workman MDX--D Page 3 -- 3 Diesel Engine
General Information
This Chapter gives information about specifications,
maintenance, troubleshooting, testing and repair of the
dieselengineusedintheWorkmanMDX--D.
Most repairs and adjustments require tools which are
commonly available in many service shops. Special
tools are described in the Kubota Workshop Manual,
Diesel Engine, SM--E3B Series. The use of some spe-
cialized test equipment is explained. However, the cost
of the test equipment and the specialized nature of
some repairs may dictate that the work be done at an en-
gine repair facility.
Service and repair parts for the Kubota engine in your
Workman are supplied through your local Toro distribu-
tor. If no parts list is available, be sure to provide your
distributor with the Toro model and serial number.
Operator’s Manual
The Operator’s Manual provides information regarding
the operation, general maintenance and maintenance
intervals for your Workman MDX--D vehicle. Refer to the
Operator’s Manual for additional information when ser-
vicing the machine.
Diesel
Engine

Workman MDX--DPage 3 -- 4Diesel Engine
This page is intentionally blank.
