Toshiba RAV-SM564 User manual

Indoor Unit
Model name:
4-way Cassette Type
RAV-SM564
RAV-SM804
RAV-SM1104
RAV-SM1404
RAV-SM1604
AIR CONDITIONER (SPLIT TYPE)
Owner’s Manual
English
For commercial use

–27–
1  
     ,   ,   
.
¡

•        .  
      .
•         .   
      (*1).  
       , : , 
 , ,  ,   .
•       ,   .  
        ,    
   ,    .
• ,        . (    
     .)
  
•         ,   
  .
•          .   ,
   .
•         ,   
    .      .
•        .  -  
,    .
•        .

•        
 (*1)     (*1).  
       ,   
      /  .
•      ,    .  
        OFF ()   
  .
•          ,      
        .   
    ,      . 
         - 
.
•     ,     . 
           
.
•     ,   ,  .
 ,    ,    , 
 ,     .     
.
•   ,    .
¦
•             
,   ,      OFF (). 
      OFF (),     
     .     ,
     ,    (*1) 
   (*1).
•    ,    ,   . -
            
 ,      .   ,  
   ,     
  .
•        .   
   ,         
  .
•     50        
      . -      
      .     
,    ,        
.
•       .      .
   ,    ,   
   .
•     -      .  
,            .
• -    ,     
    ,        .
•         ,  
  .     .
•          
.     .
•
              .
        .
•     -      .
    ,        .
•       (  )  
,     ,       
.        ,   
     (*1).
•       .
      ,      
 .

•   -     (,    ,
 ,   ,       ,  ),
   ,       
OFF ()      .  
      ,  
      (,   “ ”   
).        
         .
•
   ,     ,     
   OFF ()        . 
        ON ().
•      ,    ,   
   OFF ()       
   .        
 ON ().
•      ,    ,   
   OFF ()       
       .      
         ON ().
•
  .     ,      .
   
•       ,    , 
     .  
       /  .
53-RU 54-RU

–28–
£¤
     .
•             
   3 .
         « 
« ( ««   ).

•        .     
    .
•          ,
       .
•   ,      .      
     .
¦
•       ,   , 
,  ,  ,  ,  .
•       ,       
 .
•         ,   
      .
•         
     .      
     .
•        .     ,  
 .
•    .       .
•          
 .      ,       .
•            
     .  
.
•       .
      ,      
 .
•       .
        
,      ,       . 
       ,   ,   .
•       ,  .
    ,          
  .
•       .
         .
(*1) . “       ”.

£  ,    
   
£  £ 
     
   
 
(   
  
12 )
   
  
 
   
£¤
 .
 ,    ,    
   .
  ¬.
       
.
      10 .
11 cartons
55-RU 56-RU

–29–
2Part names

Indoor unit

Outdoor unit (The design varies depending on the outdoor unit.
The following illustration shows an example.)
Knob
Knob to open / close
the suction port. Provided in the electrical control
box.
Earth screw
Air filter
Removes dust or trash.
(Provided on the suction port.)
Change the direction of the air
to be discharged according to
cool / heat mode.
Discharge louver
of discharge port
The air in the room is sucked in
from this port.
Suction air port
Projection of
air filter
Air intake
(Side and rear)
Panel
There is an earth screw, valves,
and electric parts inside.
Air discharge
Piping panel
Wiring hole
Refrigerant pipe outlet
Fixing leg
3Wired remote controller
This remote controller can control the operation of up to 8 indoor units.

Display section
In the display illustration below all the icons are shown. When the unit is in operation,
only relevant icons will be displayed.
• When the leak breaker is turned on for the first time, flashes on the display
part of the remote controller.
• While this icon is flashing, the model is being automatically confirmed.
Wait till icon has disappeared to use the remote controller.
1Operation mode
The selected operation mode is displayed.
2Error display
Displayed while the protective device works or a error
occurs.
3SETTING display
Displayed during setup of the timer or other settings.
4TEST run display
Displayed during a test run.
5Timer display
When an error occurs, error code is displayed.
6Timer mode display
The selected timer mode is displayed.
7Louver position display
Displays louver position.
8Swing display
Displayed during up / down movement of the louver.
9Filter display
Reminder to clean the air filter.
10 Fan speed display
The selected fan speed mode is displayed.
11 Set temperature display
The selected set temperature is displayed.
12 Power saving mode display
Limits compressor speed (capacity) to save energy.
SET
TIME
TIMER SET
TEST
FILTER
RESET
TEMP.
CL
FAN
SAVE
SWING/FIX
VENT
MODE
ON / OFF
UNIT LOUVER
Display
section
Operation
section
19
21
22
1
6
2
5
9
10
43
15
17 16 20
11
14 13 12
18
87
(Auto)
(High)
(Med.)
(Low)
57-EN 58-EN

–30–
13 UNIT No. display
Displays the number of the indoor unit selected.
Also displays error code of indoor and outdoor units.
14 Central control display
Displayed when the air conditioner is used under the
central control in combination with a central control
remote controller.
In case the remote controller is disabled by the central
control system, flashes.
The button operation is not accepted.
Even when ON / OFF, MODE, or TEMP. button is
pushed, and the button operation is not accepted.
(Settings made by the remote controller vary with the
central control mode. For details, refer to the Owner’s
Manual of the central control remote controller.)
15 Remote controller sensor display
Displayed while the sensor of the remote controller is
used.
16 Pre-heat display
Displayed when the heating mode is energized or
defrost cycle is initiated.
While this icon is displayed, the indoor fan stops.
17 No function display
Displayed when the function requested is not available
on that model.
18 Self clean operation display
Displayed during self clean operation to dry the indoor
heat exchanger.
19 Service display
20 Operation ready display
This display appears on some models.
21 Louver Number display.
(exapmle:01, 02, 03, 04)
22 Louver lock display
Displayed when there is a louver-locked unit in the
group (including 1 indoor unit by 1 outdoor unit).
1
6
2
3
5
9
15
17 16
11
14 13 12
20
18
87
19
21 22
4
10


Operation section
Push each button to select a desired operation.
• The control saves commands in memory and after the initial setting, there is no need for any additional
settings unless changes are desired. The air conditioner can be operated by pushing the button.
1 button (Temperature set button)
Adjusts the set point.
Select the desired set point by pushing TEMP.
or TEMP. .
2button (Timer set button)
Use to setup the timer.
3button (Filter reset button)
Resets “ ” display after cleaning filter.
4button (Test button)
Use only for service.
(During normal operation, do not use this button.)
5button
When the button is pushed, the operation starts, and it
stops by pushing the button again.
When the operation has stopped, the operation lamp and
all the displays disappear.
6Operation lamp
Green light illuminates when unit is on.
Although it flashes when operating the protection device
or an error occurs.
7 button (Operation mode button)
Selects desired operation mode.
8button (Fan speed button)
Selects the desired Fan speed.
9button (Ventilation button)
Use when a power ventilation kit (locally procured) is
connected.
• If “ ” is displayed on the remote controller when
this button is pushed, no vent kit connected.
10 button (Power save operation)
Use to initiate power saving mode.
11 button (Unit / Louver select button)
Selects a unit number (left) and louver number (right).
UNIT:
Selects an indoor unit when adjusting wind direction
multiple indoor units are controlled with one remote
controller.
LOUVER:
Selects a louver when setting wind direction
adjustment independently.
12 button (Swing / Louver direction
button)
Selects automatic swing or setting the louver
direction.
OPTION :
Remote controller sensor
Usually the temperature sensor of the indoor unit senses the
temperature. The temperature on the surrounding of the
remote controller can also be sensed.
For details, contact the dealer from which you have
purchased the air conditioner.
8
6
4
3
2
5
7
10
12
1
9
11
59-EN 60-EN

–31–
4Correct usage
When the air conditioner is used for the first time or when the setting is changed, follow the steps below. Settings are saved in
memory and are displayed anytime the unit is turned on by pushing the button.

Preparation
• When the circuit breaker is turned on, the partition lines are displayed on the remote controller.
* After the circuit breaker is turned on, the remote controller does not accept any commands for approx.
1 minute, this is not a failure.
REQUIREMENT
When the air conditioner is re-powered after it has not been used for a long period, turn on the circuit breaker at least 12 hours
before starting the air conditioner.
Start
1Push button.
The operation lamp illuminates, and the operation
starts.
2Select an operation mode with the “ ”
button.
One push of the button, and the display changes
in the order shown below.
3Select fan speed with “ ” button.
One push of the button, and the display changes
in the order shown below.
• When fan is in “ Auto”, fan speed is
adjusted based on difference between set point
and room temperature.
• In heating operation, if the room temperature is
not heated sufficiently with speed “ Low”
operation, select “ Med.” or “ High”
operation.
• The temperature sensor detects the return air
temperature at the indoor unit, which differs
from the room temperature depending on the
installation condition.
Set point is a target of room temperature.
( “Auto” is not selectable in the Fan
mode.)
4Select the set point temperature by pushing
the “TEMP. ” or “TEMP. ” buttons.
Stop
Push button.
The operation lamp goes off, and the operation stops.
In the Cool, Dry, or Auto (cooling) mode, the fan runs
for 10 minutes (or more) for self clean operation.
SET
TIME
TIMER SET
TEST
FILTER
RESET
TEMP.
CL
FAN
SAVE
SWING/FIX
VENT
MODE
ON / OFF
UNIT LOUVER
1
3 2
4
Auto Heat Dry FanCool
Auto High Med. Low
NOTE
Auto Changeover
• When in Auto Mode, the unit selects the operating mode (cooling, heating or fan only) based on the user set point
temperature.
• If the Auto mode is uncomfortable, you can select the desired conditions manually.
Cooling
• If there is a demand for cooling, unit will start approximately 1 minute after mode is selected.
Heating
• If there is a demand for heating, unit will start approximately 3 to 5 minutes after the mode is selected.
• After the heating operation has stopped, fan may continue to run for approx. 30 seconds.
• When the room temperature reaches the set temperature, the outdoor unit stops and the indoor unit fan runs at extremely
low speed.
During defrost operation, the fan stops so that cool air is not discharged. (“ ” Pre-heat is displayed.)
When restarting the operation after stop
When the unit is attempted to restart immediately after it was stopped, the unit can not start for approx. 3 minutes this is to
protect the compressor.


8 °C operation (For object pre-heating)
(SDI 4series and DI 4series (RAV-SP***4AT / RAV-SM***4AT) only)
The air conditioner can control the heating temperature to about 8 °C in the heating mode.
The 8 °C heating operation requires settings with the wired remote controller. Ask the installer or dealer for the settings
according to the installation manual of the indoor unit.
Start
1Set the displayed temperature to 18 °C in the heating mode by pushing TEMP. button.
2Set the displayed temperature to 8 °C by pushing TEMP. button for at least four seconds.
Stop
1Set the displayed temperature to 18 °C by pushing TEMP. button.
• The air conditioner returns to the normal Heat mode. Select a desired temperature and operation mode.
NOTE
• The discharged air temperature is lower than that in the normal heating operation.
• The room temperature may not be heated evenly depending on the remote controller installation location.
• The room temperature may not reach 8 °C depending on the room size or the installation conditions.
• Setting for fan speed is available during the 8 °C heating operation.
The 8 °C heating operation is cancelled in the following cases.
•When operation is stopped with button
•When another operation mode is selected with button
•When temperature setting or operation mode is changed or operation is started / stopped by the wireless remote controller
or the central control remote controller.
• When this operation mode is used, observe proper operating hours and periodic maintenance by service staff is
recommended.
61-EN 62-EN

–32–
5Timer operation
• Three timer modes are available: (Setting of up to 168 hours is enabled.)
Set
1Push button.
The timer mode changes with every push of the button.
• and timer display flashes.
2Push to select “set time”.
• With every push of button, the set time increases
by 0.5 hr (30 minutes).
When setting a time more than 24 hours for timer
operation, timer can be set in increments of 1 hr.
The maximum set time is 168 hr (7 days).
The remote control displays the set time with time
(between 0.5 and 23.5 hours) (*1) or number of days
and time (24 hours or more) (*2) as shown below.
• With every push of button, the set time decreases
by 0.5 hr (30 minutes) (0.5 - 23.5 hours) or 1 hr (24 -
168 hours).
Example of remote control display
• 23.5 hours (*1)
• 34 hours (*2)
3Push button.
• icon disappears and time display goes on,
and or icon flashes.
(When On timer is activated, time and On timer
are icons and other icons disappear.)
4Cancel timer operation
Push button.
Timer icon disappears.
NOTE
• When the operation stops after the timer reached the preset
time, the Repeat Off timer resumes the operation by
pushing button and stops the operation after the
time of the timer has reached the set time.
• When is pushed while the Off timer function of the
air conditioner is active, the indication of the timer function
disappears and then appears again after about 5
seconds.
This is due to normal processing of the remote controller.
Off timer : The unit stops when the set time is reached.
Repeat Off timer : The unit stops daily when the set time is reached.
On timer : The unit starts when the set time is reached.
1
3
2
4
shows 1 day (24 hours).
shows 10 hours. (Total 34 hours)
(Off timer) (On timer)(Repeat Off timer)
No display
Off Off On
Number of days Time
6Adjustment of wind direction
For best cooling and heating performance, adjust the louvers (adjustment plates of up / down wind direction)
appropriately. Cold air descends and warm air rises, so to heat a room tilt the louvers downward, and to cool a
room tilt them horizontally.
CAUTION
Direct the louvers horizontally for cooling.
If the louvers stay pointed downward when cooling, condensation may form on the discharge port and / then drops from
the louvers.
NOTE
If the louvers stay pointed straight out horizontally when heating, the room temperature may be unevenly
distributed.
• When the air conditioner is not working, the louvers are directed horizontally automatically.
• The louvers are directed horizontally when heating begins, during defrost operation, or during the minimum
operation after reaching the set temperature.
When a swing or louver direction setting is made at this time, the remote controller display varies with the setting,
but the louvers stay pointed straight out horizontally.
When the air conditioner starts heating, the louvers are directed to the set direction.
For cooling (COOL)
Direct the louvers horizontally.
For heating (HEAT)
Direct the louvers downward.
63-EN 64-EN

–33–
How to set up the louver direction
1Push during operation.
The louver direction changes for every push of the
button.
In HEAT operation
Direct the louver (adjustment plate of up / down wind
direction) downward. If directing at horizontally, hot air
may not come to the foot.
In COOL / DRY operation
Direct the louver (adjustment plate of up / down wind
direction) horizontally. If directing it downward, the dew
may form on the surface of the air discharge port and
may drop down.
In FAN operation
Select a desired louver direction.
How to start swinging
1Push , set the louver (adjustment plate
of up / down wind direction) direction to the
lowest position, and then push again.
SWING is displayed and the up / down louver
direction is automatically selected.
Display during swinging
How to stop swinging
1Push at a desired position while the
louver is swinging.
• When is pushed after that, wind
direction can be set again from the highest
position.
Display when swinging is stopped
In this case, push again two seconds later.
• In Cool / Dry operation, the louver does not stop
as it directs downward. If stopping the louver as
it directs downward during swing operation, it
stops after moving to the third position from the
highest position.
Display when stopping the swing
1
Unit select button
Initial setup
Initial setup
Initial setup
* However, even if is pushed while the
louver is swinging, the louver position is
displayed as follows and highest position of the
louver may not be selected.
Repeat
Fan / Heat
operation Cool / Dry operation
Fan / Heat
operation Cool / Dry operation
Unit select button
• When multiple indoor units are controlled with one
remote controller, louver direction can be set for
each indoor unit by selecting individually.
• To set louver direction individually, push
button to display an indoor unit number in the control
group. Then set the wind direction of the displayed
indoor unit.
• When no indoor unit number is displayed, all indoor
units in the control group can be controlled
simultaneously.
• Each time button is pushed, the display
changes as follows:


How to set louver wind
direction individually
1Select an indoor unit to be set by pushing
(left side of the button) during
operation.
• The indoor unit number changes each time you
push the button.
* When no unit number is displayed, all indoor units
are selected.
2Select a louver you want to adjust change by
pushing (right side of the button).
• Each time you push the button, the display on
the left of the remote controller changes as
follows:
* When no louver number is displayed, all four louvers
are selected.
3Determine wind direction of the selected
louver by pushing .
• Each time you push the button, the display
changes as follows:
* During COOL (DRY) mode, (4) and (5) are not
displayed.
Not
display
UNIT No.
1-1 UNIT No. 1-2 UNIT No. 1-3
UNIT No.
1-4
Not
display
UnitNo.
1-1 UnitNo. 1-2 UnitNo. 1-3
UnitNo.
1-4
Not
display
Louver No.
03
01
0204
Refrigerant
pipe
Drain pipe
Electrical control box
(1) (2) (3) (4)
(7) (6) (5)
65-EN 66-EN

–34–
7Power saving mode
The power saving mode saves energy by limiting the maximum current which will effect cooling capacity that the unit can
generate.
Push button during operation.
• The air conditioner enters power saving mode.
•appears on the display.
Power saving mode will stay in effect until it is
cancelled.
To cancel the power saving mode, push
button again.
•disappears.

To configure the power saving mode settings
1Push button for at least four seconds when the air conditioner is not working.
• , symbol, and numbers flash.
2Push (left side of the button) to select an indoor unit to be set.
• Each time the button is pushed, UNIT No. change as follows:
3Push TIME buttons, to adjust the
power saving mode setting.
• Each push of the button changes the power level by
1 % within the range from 100 % to 50 %.
• The factory default is 75 %.
4Push button.
5Push button to complete the setting.
NOTE
• When other electric appliances are used at the same time, to avoid triggering the circuit breaker, power saving mode is
recommended. Of course power saving mode can be used to save energy as well.
• Power saving mode consumes less energy, but may not cool the room as much as normal mode. (The maximum current is
limited to approximately 75 % (factory default) of the normal mode.)
• Even when operation start / stop, operation mode change, or power reset is performed during the power saving mode, the
power saving mode is retained until the next operation.
4
3
1
52
UNIT No.
1-1 UNIT No. 2-1 UNIT No. 3-1
UNIT No.
4-1
The fan of the selected unit runs.
Setting of power level in
power saving mode
8Self clean mode
This function is provided to dry the inside of the indoor unit by the FAN operation after running the cooling
/ dry / AUTO (cooling) mode to keep the indoor unit clean.
• The self clean time varies with the cooling / dry /Auto (cooling) operation time as follows.
• “ ” is displayed on the remote controller during self clean operation.
To stop self clean forcibly, push button twice in succession.
CAUTION
• The fan continues to run even after button is pushed to stop operation in some modes.
This is normal because the self clean mode is in progress.
• The louvers open slightly and are directed horizontally during self clean, and they close when the self clean is
completed.
• The operation lamp (LED) does not light during the self clean mode (function).
• The self clean mode (function) cannot clean the room or remove the already existing mold and dust inside the indoor
unit.
• To cancel the self clean function, consult the dealer.
Cooling / dry / Auto (cooling) operation time self clean time
Less than 10 minutes No self clean operation
10 minutes to less than 1 hour 1 hour
More than 1 hour 2 hours
67-EN 68-EN

–35–
9Advanced settings

How to set up swing type
1Push for at least four seconds when
the air conditioner is not working.
• , symbol, and numbers flash.
2Select an indoor unit to be set by pushing
(left side of the button).
• Each time you push the button, unit numbers
change as follows:
The fan of the selected unit runs and the louvers
start swinging.
3Select a swing type by pushing TIME
buttons.
CAUTION
Do not set the swing setup code to “0000”.
(This setting may cause a failure of the louvers.)
4Push the button.
5Push the button to finish the setting.
2145
3
Swing setup code Swing of louvers
0001 Standard swing
(Factory default)
0002 Dual swing
0003 Cycle swing
Not
display
Unit No.
1-1 Unit No. 2-1 UnitNo. 3-1
UnitNo.
4-1
Swing setup code
▼Standard swing
All four louvers swing simultaneously at the same
angle.
▼Dual swing
Adjoining louver alternately swing horizontally and
downward.
▼Cyclic swing (Recommended for cooling)
All four louvers swing at different times like waves.
Swing
Horizontal
Downward
Downward
Horizontal
Downward Downward
Horizontal
Horizontal
69-EN 70-EN

–36–

Setting the louver lock
1Push and hold the button (right side of
the button) for at least 4 seconds while
running is stopped.
blinks.
• When no unit number is displayed, all units are
selected.
2Push the button (left side of the button)
to select a unit.
The unit number changes each time you push the
button.
The fan of the selected unit runs, and the louver
swings.
3Push the “TEMP. ” buttons to
display the number of the louver to fix its
direction.
The selected louver swings.
4Push the buttons to select the
direction of the louver you do not want to
swing.
* If (4) or (5) is selected, condensation may occur
during cooling.
5Push the button to confirm the setting.
When the setting is confirmed, the mark lights
up.
(To set the louver lock of another unit, repeat from
Step 2. To set another louver lock of the same unit,
repeat from Step 3.)
6Push the button to finish the setting.
* F1 appears in the CODE No. section on the
remote controller. This indicates that the louver
01 shown in the following figure is selected.
NOTE
Even in louver lock mode, the louver temporarily
moves in the following cases:
• When the air conditioner is stopped
UNIT LOUVER
Unit No.
1-1 Unit No. 2-1 Unit No. 3-1
Unit No.
4-1
(1)
0001
(2)
0002
(3)
0003
(5)
0005
(4)
0004
0001 - 0005
(Louver position
code) Louver No.
03
01
0204
Refrigerant
pipe
Drain pipe
Electrical control box


Releasing the louver lock
Set “0000” in Step 4 of “Setting the louver lock”.
The mark disappears.
* Steps 1 - 3 and 5, 6 of “Setting
the louver lock” also apply to
releasing the lock.
◆Adjusting the horizontal direction
1Push and hold the and “TEMP. ”
buttons for at least 4 seconds while running
is stopped.
blinks.
“01” appears in CODE No.
2Push the button (left side of the button)
to select a unit
The unit number changes each time you push the
button.
The fan of the selected unit runs, and the louver
swings.
3Push the “TEMP. ” buttons to
change the CODE No. to “45”.
4Push the “TIME ”buttons to select a
direction.
5Push the button to check the settings.
The indicator stops blinking and stays lit, and the
settings are confirmed.
6Push button to finish the setting.
* If the cold draft position is selected, the ceiling
smudging reduction effect will be reduced.
Direction SET
DATA Direction setting
“0000” Smudging reduction position
(reduces ceiling smudging)
“0002”
Cold draft position
(Less directly expose your body to
cool air)
(factory default)
0000
SET DATA
Unit No.
1-1 Unit No.
2-1 Unit No.
3-1
Unit No.
4-1
No
display
71-EN 72-EN

–37–
10Maintenance
WARNING
Cleaning the air filter and other parts of the air filter involves dangerous work in high places, so be sure
to have a qualified installer or qualified service person to do it.
Do not attempt it by yourself.
After the cooling or dry auto (cooling) operation has finished, the dry operation is performed and the fan
starts running. When cleaning the unit, stop the drying operation forcibly and turn off the circuit breaker
to avoid electric shock.
Cleaning air filters
Clogged air filters will reduce the cooling and heating performance.
(1) If “ ” is displayed on the remote controller, clean the air filters.
(2) When the cleaning of air filters has been completed, push button.
“”disappears.
When the unit will not be used for a long time
1. Perform the fan operation for a couple of hours to dry inside.
2. Press on the remote controller to stop running, and turn off the circuit breaker.
3. Clean the air filters and reinstall them.
Before the cooling season
Clean the drain pan
• Contact the dealer where you purchased the product.
(Drain does not work if the drain pan or vent is clogged. In some cases the drain may overflow and wet the wall or floor. Be
sure to clean the drain pan before the cooling season.)
(1)
(2)
Check periodically
• If the unit is used for a long time, parts may deteriorate and cause malfunction or bad drainage of dehumidified water
depending on the heat, humidity, or dust.
• In addition to the usual maintenance, it is recommended that you have the unit checked and maintained by the dealer where
you purchased it.
NOTE
For environmental conservation, it is strongly recommended that the indoor and outdoor units of the air conditioner in
use be cleaned and maintained regularly to ensure efficient operation of the air conditioner.
When the air conditioner is operated for a long time, periodic maintenance (once a year) is recommended.
Furthermore, regularly check the outdoor unit for rust and scratches, and remove them or apply rustproof treatment, if
necessary.
As a general rule, when an indoor unit is operated for 8 hours or more daily, clean the indoor unit and outdoor unit at
least once every 3 months. Ask a professional for this cleaning / maintenance work.
Such maintenance can extend the life of the product though it involves the owner’s expense.
Failure to clean the indoor and outdoor units regularly will result in poor performance, freezing, water leakage, and even
compressor failure.
Maintenance List
Part Unit Check (visual / auditory) Maintenance
Heat exchanger Indoor / outdoor Dust / dirt clogging, scratches Wash the heat exchanger when it is clogged.
Fan motor Indoor / outdoor Sound Take appropriate measures when abnormal sound
is generated.
Filter Indoor Dust / dirt, breakage • Wash the filter with water when it is contaminated.
• Replace it when it is damaged.
Fan Indoor • Vibration, balance
• Dust / dirt, appearance
• Replace the fan when vibration or balance is
terrible.
• Brush or wash the fan when it is contaminated.
Air intake / discharge
grilles Indoor / outdoor Dust / dirt, scratches Fix or replace them when they are deformed or damaged.
Drain pan Indoor Dust / dirt clogging, drain
contamination Clean the drain pan and check the downward slope for smooth drainage.
Ornamental panel,
louvers Indoor Dust / dirt, scratches Wash them when they are contaminated or apply repair coating.
Exterior Outdoor • Rust, peeling of insulator
• Peeling / lift of coat Apply repair coating.
73-EN 74-EN

–38–
11Troubleshooting
Check the points described below before requesting repair.
If there is something unusual even after checking the above, stop running the unit, turn off the circuit breaker, and inform the
dealer where you purchased the product of the product number and symptom. Do not attempt to repair the unit by yourself as
doing so is dangerous. If the check indicator ( , , , etc.) is displayed on the remote controller LCD, inform the dealer
of its content as well.
If any of the following occur, stop running the unit immediately, turn off the circuit breaker, and contact the dealer where you
purchased the product.
• The switch does not work properly.
• The circuit breaker often blows out.
• You unintentionally put a foreign object or water inside.
• The unit cannot be run even after the cause of the protective device activation is removed.
• Other unusual conditions are found.
Symptom Cause
It is not a malfunction.
Outdoor unit
• White, misty, cold air or water comes out
• Sometimes the noise of air leaking is heard.
• A noise is heard when the power is turned
on.
• The fan of the outdoor unit is automatically stopped and
defrosting is performed.
• The solenoid valve works when defrosting starts or stops.
• The outdoor unit is preparing for running.
Indoor unit
• Sometimes a swishing is heard.
• A clacking sound is heard.
• Discharged air smells unusual.
• The fan continues running even after the
unit operation is stopped.
• When the unit starts running, during operation, or
immediately after the unit stops running, a sound such as
water flowing may be heard, or the operation sound may
become louder for a couple of minutes immediately after
the unit starts running. This is the sound of the refrigerant
flowing or the dehumidifier draining.
• This is a sound generated when the heat exchanger, etc.
expands and contracts slightly due to temperature
change.
• Various smells from the walls, carpet, clothes, cigarette,
cosmetics, etc. adhere to the air conditioner.
• The fan keeps running to self clean operation the heat
exchanger during drying.
• The unit does not run • Has a blackout occurred?
• Has the circuit breaker blown?
• Has the protective device been activated? (The operation
indicator and on the remote controller are blinking.)
Check again.
The room does not cool down or warm up.
• Is the air intake or discharge of the outdoor unit clogged?
• Is a door or window open?
• Is the air filter clogged with dust?
• Is the air volume set to “Low”? Or is the operation mode
set to “Fan”?
• Is the setup temperature appropriate?

Confirmation and check
When an error occurred in the air conditioner, an error code
and indoor UNIT No. appear on the display part of the remote
controller.
The error code is only displayed during the operation.
If the display disappears, operate the air conditioner
according to the following “Confirmation of error log” for
confirmation.

Confirmation of error log
When an error occurred on the air conditioner, the error log
can be confirmed with the following procedure. (The error log
is stored in memory up to 4 errors.)
The log can be confirmed from both operating status and stop
status.
1When and buttons are pushed at the
same time for 4 seconds or more, the
following display appears.
If is displayed, the mode enters in the
error log mode.
•[01: Order of error log] is displayed in CODE No..
• [Error code] is displayed in CHECK.
• [Indoor unit address in which an error occurred] is
displayed in Unit No.
.
2Every pushing of button used to set
temperature, the error log stored in memory
is displayed in order.
The numbers in CODE No. indicate CODE
No. [01] (latest) →[04] (oldest).
REQUIREMENT
Do not push button because all the error log of the indoor
unit will be deleted.
3After confirmation, push button to return
to the usual display.
Error code Indoor UNIT No. in
which an error occurred
3
2
1
75-EN 76-EN

–39–
12Operations and performance
▼Check before running
• Check whether the earth wire is cut or disconnected.
• Check whether the air filter is installed.
• Turn on the circuit breaker 12 hours or more before starting
operation.
▼3 minutes protection function
3-minutes protection function prevents the air conditioner
from starting for initial 3 minutes after the main power switch
/ circuit breaker is turned on for re-starting the air conditioner.
▼Power failure
Power failure during operation will stop the unit completely.
• To restart the operation, push the ON / OFF button on the
remote controller.
• Lightning or a wireless car telephone operating nearby
may cause the unit to malfunction. Turn off the main power
switch or circuit breaker and then turn them on again. Push
the ON / OFF button on the remote controller to restart.
▼Defrosting operation
If the outdoor unit is frosted during the heating operation,
defrosting starts automatically (for approximately 2 to 10
minutes) to maintain the heating capacity.
• The fans in both indoor and outdoor units will stop during
the defrosting operation.
• During the defrosting operation, the defrosted water will be
drained from the bottom plate of the outdoor unit.
▼Heating capacity
In the heating operation, the heat is absorbed from the
outside and brought into the room. This way of heating is
called heat pump system. When the outside temperature is
too low, it is recommended to use another heating apparatus
in combination with the air conditioner.
▼Protective device
• Stops operation when the air-conditioner is overloaded.
• If the protective device is activated, the unit stops running,
and the operation indicator and check indicator on the
remote controller blink.
▼If the protective device is activated
• Turn off the circuit breaker and perform a checkup.
Continued running may cause a malfunction.
• Check whether the air filter is installed. If not, the heat
exchanger may be clogged with dust and water leakage
may occur.
▼During cooling
• The air intake or discharge of the outdoor unit is clogged.
• Strong wind continuously blows against the discharge of
the outdoor unit.
▼During heating
• The air filter is clogged with a large amount of dust.
• The air intake or discharge of the indoor unit is clogged.
▼Do not turn off the circuit breaker
During the air-conditioning season, leave the circuit breaker
turned on, and use the ON / OFF key on the remote
controller.
▼Attention to snowfall and freeze on the
outdoor unit
• In snowy areas, the air intake and air discharge of the
outdoor unit are often covered with snow or frozen up.
If snow or freeze on the outdoor unit is left as it is, it may
cause machine failure or poor warming.
• In cold areas, pay attention to the drain hose so that it
perfectly drains water without water remaining inside for
freeze prevention. If water freezes in the drain hose or
inside the outdoor unit, it may cause machine failure or
poor warming.
▼Air conditioner operating conditions
For proper performance, operate the air conditioner under the following temperature conditions:
If air conditioner is used outside of the above conditions, safety protection may work.
Cooling operation
Outdoor temperature : –15 °C to 43 °C (Dry bulb temp.)
Room temperature : 21 °C to 32 °C (Dry bulb temp.), 15 °C to 24 °C (Wet bulb temp.)
[CAUTION] Room relative humidity – less than 80 %. If the air conditioner operates in excess of this
figure, the surface of the air conditioner may cause dewing.
Heating operation Outdoor temperature : –15 °C to 15 °C (Wet bulb temp.)
Room temperature : 15 °C to 28 °C (Dry bulb temp.)
13Installation
Do not install the air conditioner in the following places
• Do not install the air conditioner in any place within 1 m from a TV, stereo, or radio set. If the unit is installed in such place,
noise transmitted from the air conditioner affects the operation of these appliances.
• Do not install the air conditioner near a high frequency appliance (sewing machine or massager for business use, etc.),
otherwise the air conditioner may malfunction.
• Do not install the air conditioner in locations where iron or other metal dust is present. If iron or other metal dust adheres to
or collects on the interior of the air conditioner, it may spontaneously combust and start a fire.
• Do not install the air conditioner in a humid or oily place, or in a place where steam, soot, or corrosive gas is generated.
• Do not install the air conditioner in a salty place such as seaside area.
• Do not install the air conditioner in a place where a great deal of machine oil is used.
• Do not install the air conditioner in a place where it is usually exposed to strong wind such as in seaside area.
• Do not install the air conditioner in a place where sulfureous gas generated such as in a spa.
• Do not install the air conditioner in a vessel or mobile crane.
• Do not install the air conditioner in an acidic or alkaline atmosphere (in a hot-spring area or near a chemicals factory, or in a
place subject to combustion emissions). Corrosion may be generated on the aluminum fin and copper pipe of the heat
exchanger.
• Do not install the air conditioner near an obstacle (air vent, lighting equipment, etc.) that disturbs discharge air. (Turbulent
airflow may reduce the performance or disable devices.)
• Do not use the air conditioner for special purposes such as preserving food, precision instruments, or art objects, or where
breeding animals or growing plants are kept.
(This may degrade the quality of preserved materials.)
• Do not install the air conditioner over an object that must not get wet. (Condensation may drop from the indoor unit at a
humidity of 80 % or more or when the drain port is clogged.)
• Do not install the air conditioner in a place where an organic solvent is used.
• Do not install the air conditioner near a door or window subject to humid outside air.
Condensation may form on the air conditioner.
• Do not install the air conditioner in a place where special spray is used frequently.
Be careful with noise or vibrations
• Do not install the air conditioner in a place where noise by outdoor unit or hot air from its air discharge annoys your neighbors.
• Install the air conditioner on a solid and stable foundation so that it prevents transmission of resonating, operation noise and
vibration.
• If one indoor unit is operating, some sound may be audible from other indoor units that are not operating.
77-EN 78-EN

–40–
14Specifications
* Under 70 dBA
Model Sound power level (dBA) Weight (Kg)
Main unit (Ceiling panel)
Cooling Heating
RAV-SM564UTP-E * * 20 (4.2)
RAV-SM804UTP-E * * 20 (4.2)
RAV-SM1104UTP-E * * 24 (4.2)
RAV-SM1404UTP-E * * 24 (4.2)
RAV-SM1604UTP-E * * 24 (4.2)
Declaration of Conformity
NOTE
This declaration becomes invalid if technical or operational modifications are introduced without the manufacturer’s
consent.
Manufacturer: TOSHIBA CARRIER (THAILAND) CO., LTD.
144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road,
Amphur Muang, Pathumthani 12000, Thailand
Authorized
Representative /
TCF holder:
Nick Ball
Toshiba EMEA Engineering Director
Toshiba Carrier UK Ltd.
Porsham Close, Belliver Industrial Estate,
PLYMOUTH, Devon, PL6 7DB.
United Kingdom
Hereby declares that the machinery described below:
Generic Denomination: Air Conditioner
Model / type: RAV-SM564UTP-E
RAV-SM804UTP-E
RAV-SM1104UTP-E
RAV-SM1404UTP-E
RAV-SM1604UTP-E
Commercial name: Digital Inverter Series Super Digital Inverter Series Air Conditioner
Complies with the provisions of the “Machinery” Directive (Directive 2006 / 42 / EC) and the regulations
transposing into national law
Complies with the provisions of the following harmonized standard:
EN 378-2: 2008+A2:2012
79-EN 80-EN

1114119601
Information according to EMC Directive 2004 / 108 / EC
(Name of the manufacturer) TOSHIBA CARRIER (THAILAND) CO., LTD.
(Address, city, country) 144 / 9 Moo 5, Bangkadi Industrial Park, Tivanon Road,
Amphur Muang, Pathumthani 12000, Thailand
(Name of the Importer / Distributor in EU) Toshiba Carrier UK Ltd.
(Address, city, country) Porsham Close, Belliver Industrial Estate, PLYMOUTH,
Devon, PL6 7DB. United Kingdom
TOSHIBA CARRIER (THAILAND) CO.,LTD.
144/9 MOO 5, BANGKADI INDUSTRIAL PARK, TIVANON ROAD, TAMBOL BANGKADI,
AMPHUR MUANG, PATHUMTHANI 12000, THAILAND.
