Toshiba TC-net 100 User manual

Unified Controller
nv Series
TC-net 100 (TN8) Module
Instruction Manual

Notes
(1) The technical information provided herein describes typical operations and applications of the product and does
not guarantee the intellectual property rights or other rights of Toshiba or third parties nor allows license of its use.
(2) No part or the whole of this document may be reproduced without prior consent.
(3) The information herein may be changed in the future without notice.
(4) All possible measures have been taken to prepare the information herein. If you have any question, comment, or
find any error, please contact us.
PROSEC, TOSLINE, TOSDIC, CIEMAC are trademarks or registered trademarks of Toshiba Corporation.
Microsoft, Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.
DeviceNet is a registered trademark of Open DeviceNet Vender Association Inc.
©TOSHIBA CORPORATION 2016
All rights reserved

Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
i
Safety Precautions
On the product and this operation manual, important information for safe and correct
use to prevent danger to the user and other people as well as property damage is
described.
Understand the following information (signs and symbols) before reading the text, and
follow the described items.
Description of signs
Sign
Description
DANGER Indicates that failure to avoid it will result in an immediate risk of
death or serious injury(*1).
WARNING
Indicates that failure to avoid it will result in a risk of death or
serious injury(*1).
CAUTION Indicates that failure to avoid it will result in a risk of light or
medium injury(*2) or only property damage(*3).
*1: A serious injury indicates loss of sight, injury, burns (high/low temperature), electric shock, broken bones, or intoxation that will have aftereffects
and require hospitalization or long-term hospital visits for healing.
*2: An injury indicates an injury, burn, or electric shock that does not need hospitalization or long-term hospital visits for healing.
*3: A property damage indicates consequential damage in terms of breakage of properties or materials.
Description of symbols
Symbol
Meaning
Prohibited
Indicates “Prohibition” or “You must not do”.
Specific details are indicated near the symbol with pictures and text.
Mandatory
Indicates “Mandatory Action” or “Do as indicated”.
Specific details are indicated near the symbol with pictures and text.
Warning
Indicates Warning.
Specific details are indicated near the symbol with pictures and text.
(Note) Descriptions of Prohibition, Mandatory Action, and Warning vary depending on the display on the main unit.

6F8C1360
ii
1. Safety Precautions on Installation
WARNING
Ground
Ground the device.
Otherwise, it may cause an electric
shock or fire.
Mandatory
Construct the emergency stop
circuit and interlock circuit
outside
the nv series.
Otherwise, it may cause an injury
accident or damage to the machine if
failure or malfunction occurs in the
nv
series.
CAUTION
Prohibited
Do not install, store, or use it in
the following environments.
・A place with a lot of dust
・A place with corrosive gases (SO2,
H2S) ore flammable gases
・A place with vibrations and shocks
exceeding the allowed values
・A place with condensations due to
rapid temperature changes
・A place with low or high
temperature outside of the
installation condition
・A place with high humidity outside
of the installation condition
・A place with direct sunlight
・A place near equipment
generating strong radio waves or
magnetic fields
It may cause accidents.
Mandatory
Install the device in a place where
maintenance and inspection can
be done easily.
Otherwise, it may cause accidents.

Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
iii
Prohibited
Do not block the ventilation hole
or air inlet/outlet.
It may cause fire or failure due to
overheat.
Mandatory
For installation and wiring of the
system, observe the installation
conditions and methods
described in this document.
Otherwise, it may cause a fall, fire,
failure, or malfunction.

6F8C1360
iv
2. Safety Precautions on Maintenance and Inspection
WARNING
Mandatory
When installing or removing the
module after wiring, make sure
that the external power supply is
off.
Otherwise, there will be live electric
poles on the back of the external
terminal block of the module,
causing an electric shock.
CAUTION
Prohibited
Do not drop, crush, or apply
strong shocks to the device or
board.
It may cause failure.
Mandatory
Before touching the device or
board, touch a grounded metal
to discharge the static electricity
of your body.
Otherwise, it may cause malfunction
or failure due to static electricity.
Mandatory
Wipe off stain on the device,
module, or board with a soft
cloth.
For severe stain, use a wet cloth
wrung tightly.
Leaving them stained may cause
wrong decision or malfunction.
Mandatory
Place a board or module
removed from the unit or base
unit on a conductive mat or
conductive bag (used for a
backup board) on a grounded
table.
Otherwise, parts may be
damaged due to static electricity.
Prohibited
Do not use benzene or thinner to
remove stain on device, module,
or board.
It may cause deformation or
discoloration of the device panel,
module, or board.

Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
v
3. Safety Precautions on Replacement of Life Limited Parts
WARNING
Mandatory
If the device has power fuses or
alarm fuses, when replacing
them, turn off the switch of the
device.
Otherwise, it may cause an electric
shock or fire.
4. Safety Precautions on Daily Use
WARNING
No touch
Do not touch the terminals of the
module and unit during
energization.
It may cause an electric shock.
Prohibited
Do not modify, repair,
disassemble, or adjust the device,
module, or board.
It may cause an electric shock, fire,
injury, or failure.
Upon faulty operation or failure,
contact Toshiba's branch office or
service offices.
Mandatory
Before using, check that the
power capacity, frequency,
voltage, and regulation comply
with the device specifications.
If not, it may cause damage of the
device, or fire due to overheat, as
well as not obtaining the original
performance of the device.
Mandatory
When the ambient or internal
temperature of the device rises
abnormally or failure occurs in
the device, stop using the device,
turn off the power, and contact
one of Toshiba's service
representatives.
Using it as it is may cause fire due to
overheat.
No touch
Do not touch the terminals of the
module and unit during
energization.
It may cause an electric shock.
The power supply module is for the nv
series only. Do not use it alone for
any other purposes.

6F8C1360
vi
CAUTION
Prohibited
Do not touch anything other than
the operation part (setting
switches inside the module), such
as the IC parts and terminals,
connectors, and soldered
surfaces inside the module.
Doing so may result in electrostatic
breakdown of the ICs and LSIs,
causing failure. Also, an injury may
occur due to the ends of the part lead
wires, or burns may occur due to hot
parts.
Prohibited
Do not disassemble or modify
the device or module.
It may cause malfunction or failure as
well as loss of safety of the device.
Prohibited
Do not forcefully bend, pull, or
twist the power cord and cables.
It may cause breaks or heating.
Prohibited
Do not insert any metal into the
gaps of the device main body.
It may cause fire.
5. Safety Precautions on Transportation, Storage, and Disposal
CAUTION
Mandatory
Observe ordinances and rules.
When destroying the product,
observe the ordinances and rules of
the local government.
Prohibited
For transportation and storage of
the product, use a conductive
bag and packaging box.
Otherwise it will cause failure.

6F8C1360
vii
Restrictions on Application
This product is not developed/manufactured for use in systems involving devices that
directly affect human life (Note 1). Do not use them for such applications.
To use this product for systems that involve devices that significantly affect human
safety or maintenance of public functions (Note 2), special considerations (Note 3)
are required in system operation, maintenance, and management. In this case,
contact one of Toshiba's sales representatives.
(Note 1) Devices that directly affect human life include the following.
•Medical devices such as life supporting devices and devices for surgical
units.
(Note 2) Systems that involve devices that significantly affect human safety or
maintenance of public functions include the following.
•Main unit control systems of nuclear power plants, safety protection
systems of nuclear facilities, and other systems that are critical for safety
•Operation control systems of mass transportation systems and air traffic
control systems
(Note 3) Special considerations indicate sufficient discussions with Toshiba's
engineers to construct a safe system (e.g. employing fool-proof design,
fail-safe design, or redundant design).
Disclaimer
Toshiba shall not be responsible for any damage caused by fire or earthquake, acts of
a third party, other accidents, the user's willful acts or negligence, misuse, or use in
abnormal conditions.
Toshiba shall not be responsible for any incidental damage (loss of business profits,
interruption of business, change or loss of stored memory) caused by use of or being
unable to use this product.
Toshiba shall not be responsible for any damage caused by failure to observe the
information described in the operation manual.
Toshiba shall not be responsible for any damage caused by malfunctions due to
combination with any connected device.
Toshiba shall not be responsible for any damage caused by malfunctions due to
combination with any application program created by the customer.
Note
Use your cellular phone or PHS 1 meter or more away from the product main unit in operation,
various transmission cables, and I/O bus cable. Otherwise, the system may malfunction.

6F8C1360
viii
This manual describes the functions, methods of installation and setting, and
maintenance and inspection of the TC-net 100 (TN8) module ("TN8 module" hereafter)
for connecting the information/control network TC-net 100 to the Unified Controller nv
series.
To use this device correctly, read "Safety precautions" first.
The manuals related to the TN8 module are as follows.
•Unified Controller nv series Main Unit Operation Manual (6F8C1220)
Describes the main unit hardware of the nv series controller.
•Unified Controller nv series Type 1 Function Manual (6F8C1221)
Describes the functions and basic use of the nv series Type 1.
•Unified Controller nv series Type 2 Function Manual (6F8C1362)
Describes the functions and basic use of the nv series Type 2.
•Unified Controller nv series/Integrated Controller V series Command Manual
(6F8C1226)
Describes the detailed specifications of the instruction words of the program
languages (LD, FBD, and SFC) supported by the nv series and Integrated Controller
V series.
•Unified Controller nv series/Integrated Controller V series nV-Tool (Basic)
Operation Manual (6F8C1290)
Describes how to create, debug, print, and save programs using nV-Tool.
•Unified Controller nv series TC-net 100 Module Manual (6F8C1360)
(This document)
Describes the TC-net 100 (TN8) module, which is common to Type 1 and Type 2
of the nv series.
After reading the manual, place it in a location that can be accessed easily when
necessary.
Introduction

Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
ix
●
Notational conventions
The following are the notational conventions for better understanding of this
document.
Important:
Describes what the user should be particularly aware of to handle the product correctly.
Note:
Describes what the user should observe to handle the product correctly.
Remark:
Describes a remark.
●
Reading this document
This document consists of the following chapters.
•Chapter 1 Introducing the TN8 module
Describes the functions, characteristics, and names and functions of the
parts.
•Chapter 2 Installation and wiring
Describes how to install it to the basic unit and how to connect cables.
•Chapter 3 Setting
Describes how to set the switches and parameters to use the module
correctly.
•Chapter 4 Operation
Describes the operations such as checking before operation, startup, and
shutdown.
•Chapter 5 Troubleshooting
Describes troubleshooting such as what to do when failure occurs.
•Chapter 6 Maintenance and inspection
Describes troubleshooting regarding daily inspection and periodical
inspection and how to perform inspections.
•Chapter 7 Application interface
Describes the user application interface and usage constraints.

6F8C1360
x
Chapter 1
Introducing the
TN8
Module
...1
1.1 Functions and Characteristics of the TN8 Module······ 2
1.2 Names and Functions of the Parts··························· 4
1.2.1 Names of the parts ·············································· 4
1.2.2 Functions of the parts··········································· 5
Chapter 2
Installation and
W
iring
...7
2.1 Installation (Installation to the Basic Unit)················· 8
2.2 Connecting the TC-net 100 Cable ·························· 10
2.3
Connecting the Serial Communication Port (RS-232C)
Cable
································································ 12
2.4 Replacing the Module·········································· 13
Chapter 3
Setting
...15
3.1 Switch Setting ·················································· 16
3.1.1 Station address setting switch
(STN-H, STN-L)················································ 16
3.1.2 Operation mode setting switch (MODE) ·················· 17
3.2 Network Parameter Setting··································· 18
3.2.1 Network ID and subnet mask ······························· 18
3.2.2 Station address················································· 19
3.2.3 Overview of multicast address······························ 19
3.3 Setting with the Engineering Tool·························· 21
3.3.1 Network parameter setting··································· 22
3.3.2 Setting the scan sending blocks···························· 32
3.3.3 Setting the state change notification······················· 35
3.4 Network Information ··········································· 38
3.4.1 Referring to LAN transmission map ······················· 38
3.4.2 Accessing the scan data ····································· 39
3.4.3 Clearing the scan unhealthy state·························· 39
3.4.4 Clearing the overlapping sending SA ····················· 39
3.4.5 LAN control information ······································ 40
3.4.6 Detailed explanation of LAN management information 41
3.4.7 MIB information················································· 42
3.4.8 Reception system switching································· 43
3.4.9 Viewing the in-ring map······································· 44
3.5 Option Functions················································ 45
3.5.1 Setting the self healthy mode parameters················ 45
3.6 Setting the RAS Information Block in Scan
Transmission····················································· 47
CONTENTS

Unified Controller nv series TC-net 100 (TN8) Module Operation Manual
xi
Chapter 4
Operation
...49
Chapter 5
Troubleshooting
...51
Chapter 6
Maintenance and
I
nspection
...53
6.1 Inspection ························································· 54
6.1.1 Daily inspection················································· 54
6.1.2 Periodical inspection ·········································· 55
6.2 Life Limited Parts ··············································· 55
Chapter 7
Application
I
nterface
...57
7.1 Information by Socket ········································· 59
7.1.1 Configuration of information by socket ······················ 59
7.1.2 Referring to information by socket ························· 60
7.1.3 Timing of generation of information by socket··········· 61
7.2 Transmission Path Diagnosis Information ·············· 63
7.2.1 Configuration of the scan data healthy map ············· 63
7.2.2 Configuration of the scan data unhealthy map·········· 64
7.2.3 Configuration of the scan data talker map················ 65
7.2.4 Configuration of RAS information ·························· 66
7.2.5 Configuration of in-ring map···································· 68
7.3 Usage Constraints ·············································· 69
7.4 Restriction on Station Redundant Configuration······ 70
Appendix A
Specifications
...71
A.1 General Specifications ········································ 72
A.2 TC-net 100 Transmission Specifications················· 73
A.3 Function Specifications······································· 74
A.4 Serial Communication Port (RS-232C) Transmission
Specifications ···················································· 75

6F8C1360
xii
Appendix B
Outside
D
imensions
...77
Appendix C
Related Products
...79
Appendix D
Decimal-hexadecimal
C
onversion Table
...81

1
Chapter 1
Introducing the TN8
Module
This chapter describes the functions, characteristics, and names and
functions of the TN8 module
1.1 Functions and Characteristics of the TN8 Module ···2
1.2 Names and Functions of the Parts ·····················4
1.2.1 Names of the parts ··································4
1.2.2 Functions of the parts·······························5

Chapter 1 Introducing the TN8 Module
6F8C1360
2
1.1 Functions and Characteristics of the TN8 Module
The TN8 module is a device to connect the controller main unit of
the Unified Controller nv series to the information and monitoring
control network TC-net 100. For the interface of the TN8 module,
optical fiber cables are provided: One for single bus and one for
dual-redundant bus.
・TN821: Optical fiber cable single bus module
・TN821A: Optical fiber cable single bus module
・TN822: Optical fiber cable dual-redundant bus module
・TN822A: Optical fiber cable dual-redundant bus module
Up to 4 TN8 modules can be installed to the basic unit.
Remark
•TN821A/TN822A are successor machine for TN821/TN822. Thus, TN821A/TN822A are
compatible with TN821/TN822.
Characteristics of the TN8 module
•Openness
The TN8 module is a network for monitoring control that
maintains the openness of the 100 Mbps Ethernet and has the
collision avoidance function and deterministic real time
responsiveness.
•Communication services
The communication services include scan transmission (cyclic
broadcast transmission) that transmits control data periodically,
and normal message transmission.
Scan transmission has 3 modes; high, medium and low, which can
be assigned according to the data update cycle to ensure
deterministic real time responsiveness.
Message transmission supports Toshiba's standard protocol
PCMP as well as TCP, UDP, and IP.
Remark
•
PCMP: Process Control Message Protocol
•High reliability
Highly reliable system configuration is available with redundancy
of the transmission path.

1.1 Functions and Characteristics of the TN8 Module
Unified Controller nv series TC-net100 (TN8) Module Operation Manual
3
Example of system configuration
Figure 1-1 System configuration example (Optical transmission path)
Host system network
Unified Controller nv series
TC-net I/O system
TC-Net 100
Monitoring control newwork

Chapter 1 Introducing the TN8 Module
6F8C1360
4
1.2 Names and Functions of the Parts
1.2.1 Names of the parts
Figure 1-2 Names of the parts of the TN8 module (TN821/TN821A, TN822/TN822A)
(Note) Front panel name is difference between TN821A/TN822A and TN821/TN822.
State display LED
(B system)
・RUN
・ERR
・
L-
A
・SCAN
Station address setting switch
・
STN H
・STN L
Operation mode setting switch
・
MODE
Serial communication port
・
TOOL
State display LED(Asystem)
・
LNK-
A
・
ACT-
A
TC
-net 100 modular connector for A system
RUN
ERR
L
-A
SCAN
MODE
UN
H
L
STN
TOOL
TN822
L
-
B
TN
-
A
LNK
-
A
ACT
-
A
TN
-
B
LNK
-
B
ACT
-
B
Optical fiber cable
RUN
ERR
L
-
A
SCAN
MODE
UN
H
L
STN
TOOL
TN821
TN
-
A
LNK
-
A
ACT
-
A
Optical fiber cable
For single bus
State display LED
・RUN
・ERR
・
L-
A
・
L-
B
・
S
CAN
・
LNK-
A
・
ACT-
A
TC
-net 100 modular connector
State display LED
for B
System
TN
821/TN821A TN822/TN822A
For dual
-
redundant bus

1.2 Names and Functions of the Parts
Unified Controller nv series TC-net100 (TN8) Module Operation Manual
5
1.2.2 Functions of the parts
The major functions of the parts are as shown below.
State display LED
Table 1-1 Display details on the state display LED and normal display
Name Display
Normal
display
RUN
(green)
Displays the hardware operation state.
ON: Running
OFF: Down
ON
ERR
(red)
Displays the hardware operation state.
ON: Down
OFF: Running
OFF
SCAN
(green)
Displays the scan transmission state.
ON: SCAN transmission is in execution.
OFF: SCAN transmission is under suspension.
SCAN
ON during
transmission
L-A (green)
Displays the TC-net 100 A system state.
ON: TC-net 100 transmission is in execution.
OFF: TC-net 100 transmission is under suspension.
ON
L-B (green)
Displays the TC-net 100 B system state (TN822 only).
ON: TC-net 100 transmission is in execution.
OFF: TC-net 100 transmission is under suspension.
ON
LNK-A
(green)
Displays the TC-net 100 A system link state.
ON: Connected to the hub successfully.
OFF: Not connected to the hub.
ON
ACT-A
(green)
Displays the TC-net 100 A system frame transmission
state.
Blinking: TC-net 100 frame transmission is in execution.
OFF: TC-net 100 transmission is under suspension.
Blinking
LNK-B
(green)
Displays the TC-net 100 B system link state (TN822
only).
ON: Connected to the hub successfully.
OFF: Not connected to the hub.
ON
ACT-B
(green)
Displays the TC-net 100 B system frame transmission
state (TN822 only).
Blinking: TC-net 100 frame transmission is in execution.
OFF: TC-net 100 transmission is under suspension.
Blinking
(Note) 1.Check the LED states from the front.
2.Refer to “Table 5-1 Diagnosis using the LEDs.”

Chapter 1 Introducing the TN8 Module
6F8C1360
6
Station address setting switch (STN-H, STN-L)
Switches to set the station address in hexadecimal. For setting method,
refer to "Chapter 3 Setting."
Operation mode setting switch (MODE)
Switches to set the operation mode. For setting method, refer to
"Chapter 3 Setting."
Serial communication port RS-232C (TOOL)
A RS-232C port for maintenance. The connector is a 9-pin D-sub
connector (socket).
TC-net 100MT-RJ connectors (TN-A and TN-B)
A communication port for the TC-net 100. The optical fiber cord with
the MT-RJ connector is connected to it.
