Toshiba nv Series User manual

6F8C1220
Unified Controller
nv Series
Controller Unit
Instruction Manual

Notes
(1) The technical information provided herein describes typical operations and applications of the product and does not
guarantee the intellectual property rights or other rights of Toshiba or third parties nor allows license of its use.
(2) No part or the whole of this document may be reproduced without prior consent.
(3) The information herein may be changed in the future without notice.
(4) All possible measures have been taken to prepare the information herein. If you have any question, comment, or find
any error, please contact us.
TC-net, PROSEC, TOSLINE, TOSDIC, CIEMAC are trademarks or registered trademarks of Toshiba Corporation.
IBM is a registered trademark of International Business Machines Corporation.
Device Net is a registered trademark of Open DeviceNet Vendor Association Inc.
Microsoft, Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.
© TOSHIBA CORPORATION 2017
All right reserved

Unified Controller nv series Controller Unit Instruction Manual
Safety Precautions
i
The product and the instruction manual describe important information to prevent possible harm
to users and damage to the property and to use the product safely.
Understand the following description (signs and symbols), read the text and observe
descriptions.
Description of signs
Sign Meaning of the sign
DANGER This indicates an immediate danger that may result in death or
serious injury if not avoided.
WARNING This indicates a danger that may result in death or serious injury*1 if
not avoided.
CAUTION This indicates a danger that may result in minor or moderate injury*2
or only a physical damage if not avoided.
*1: A serious injury indicates loss of sight, injury, burns (high/low temperature), electric shock,
broken bones, or intoxication that will have aftereffects and require hospitalization or long-term
hospital visits for healing.
*2: An injury indicates an injury, burn, or electric shock that does not need hospitalization or long-term
hospital visits for healing.
*3: Aproperty damage indicates consequential damage in terms of breakage of properties or materials.
Description of symbols
Symbol Meaning of the symbol
Prohibited
Indicates “Prohibition” or “You must not do”.
Specific details are indicated near the symbol with pictures and text.
Mandatory
Indicates “Mandatory Action” or “Do as indicated”.
Specific details are indicated near the symbol with pictures and text.
Warning
Indicates Warning.
Specific details are indicated near the symbol with pictures and text.
(Note) Descriptions of Prohibition, Mandatory Action, and Warning vary depending on the display on the
main unit.

6F8C1220
ii
1. Safety Precautions in Installation
WARNING
Ground
Ground the device.
Otherwise, it may cause an electric shock or
fire.
CAUTION
Prohibited
Do not install, store, or use it in the
following environments.
・A place with a lot of dust
・A place with corrosive gases (SO2, H2S)
ore flammable gases
・A place with vibrations and shocks
exceeding the allowed values
・A place with condensations due to rapid
temperature changes
・A place with low or high temperature
outside of the installation condition
・A place with high humidity outside of the
installation condition
・A place with direct sunlight
・A place near equipment generating
strong radio waves or magnetic fields
It may cause accidents.
Mandatory
Install the device in a place where
maintenance and inspection can be
done easily.
Otherwise, it may cause accidents.
Prohibited
Do not block the ventilation hole or air
inlet/outlet.
It may cause fire or failure due to overheat.
Prohibited
Do not insert any foreign object such as
wasted lines into the module or unit.
It may cause fire, failure, or malfunction.
Mandatory
Install the power module, controller
module, station bus module, and
TC-net I/O module to the base unit.
Otherwise, it may cause an electric shock,
injury, or failure.
Do not use it alone or for other purposes.
Mandatory
Install the power module, controller
module, and I/O module to the base
unit for the nv series because they are
dedicated to the nv series.
Otherwise, it may cause an electric shock,
injury, or failure.
Do not use it alone or for other purposes.
Mandatory
Install or remove the module, base unit,
and terminal block while the power is
off.
Otherwise, it may cause an electric shock,
malfunction, or failure.
Mandatory
When connecting the connectors and
cables or installing the module to the
base unit, press them fully until they
clicks, and secure them with screws
tightly.
Insufficient tightening may cause failure
or malfunction due to vibrations.

Unified Controller nv series Controller Unit Instruction Manual iii
Mandatory
For installation and wiring of the
system, observe the installation
conditions and methods described in
this document.
Otherwise, it may cause a fall, fire,
failure, or malfunction.
Prohibited
Do not install or store the relay output
module in the following places:
・Silicon gases are present.
・Silicon products are used.
It may cause contact failure.
No touch
Do not touch the card parts, contacts,
connectors, or soldered surface in the
module.
Ends of the lead wire of the parts may cause
an injury, or electrostatic breakdown of the
ICs or LSIs may occur, resulting in failure.
2. Safety Precautions on Wiring
WARNING
Mandatory
Connect the cables while the power is
off.
Otherwise, it may cause an electric shock or
failure.
Mandatory
When wiring the module, use crimp
contacts with sheath, or cover it with
tape.
Otherwise, exposed conductors may cause
an electric shock.
Mandatory
Install the terminal block cover securely
to the terminal block.
Exposed conducting parts may cause an
electric shock.
CAUTION
Mandatory
Connect an external power supply
that matches the rating.
Otherwise, it may cause an explosion
or fire.
Mandatory
Wiring work must be done by
qualified experts.
Wrong wiring may cause a fire, electric
shock, or failure.
Mandatory
Install a fuse that matches the
current capacity to the external
circuit for overload protection of the
relay output module.
Otherwise, a load short-circuit may
cause an accident or damage to the
machine.
Mandatory
Construct the emergency stop
circuit and interlock circuit outside
the nv series.
Otherwise, it may cause an injury
accident or damage to the machine if
failure or malfunction occurs in the nv
series.

6F8C1220
iv
3. Safety Precautions in Daily Use
WARNING
No touch
Do not touch the terminals of the
module and unit during energization.
It may cause an electric shock.
Prohibited
Do not modify, repair, disassemble, or
adjust the device, module, or board.
It may cause an electric shock, fire, injury, or
failure.
Upon faulty operation or failure, contact
Toshiba's branch office or service offices.
Mandatory
Before using, check that the power
capacity, frequency, voltage, and
regulation comply with the device
specifications.
If not, it may cause damage of the device, or
fire due to overheat, as well as not obtaining
the original performance of the device.
Prohibited
When the ambient or internal
temperature of the device rises
abnormally or failure occurs in the
device, stop using the device, turn off
the power, and contact one of Toshiba's
service representatives.
Using it as it is may cause fire due to
overheat.
No touch
Do not touch the terminals of the
module and unit during energization.
It may cause an electric shock.
The power supply module is for the nv
series only. Do not use it alone for any
other purposes.
CAUTION
Mandatory
When performing program changes
during operation, forced output, run, or
halt operations, ensure safety.
Wrong operations or failure to ensure safety
may cause an accident or damage to the
machine.
Mandatory
When there is any smoke or strange
odor, turn off the power.
Otherwise, it may cause a fire or electric
shock.
Contact one of our branch offices or service
agencies.
Prohibited
Do not forcefully bend, pull, or twist the
power cord and cables.
It may cause breaks or heating.
Prohibited
Do not insert any metal into the gaps of
the device main body.
It may cause fire.
Mandatory
When using the contact relay used for
relay output, check the contact life.
If the contact life of the relay is expired, an
output error may occur due to a defective
contact, resulting in an accident or damage
to the machine.
Contact relays have a life due to wearing of
the contact. If the life is expired, replace it
with a new one.

Unified Controller nv series Controller Unit Instruction Manual v
Mandatory
Install the battery before use.
If the RAM is operated without any battery,
memory data or programs may be lost,
causing an accident or damage to the
machine due to malfunction.
Replace the battery according to the battery
replacement cycle guideline.
Mandatory
Turn on the power in the following order:
Turn on the power of the nv series, and then
turn on the I/O module supply external
power and external load power.
If this order is not followed, it may cause an
accident or damage to the machine due to
malfunction.
Mandatory
For system safety, turn off the load
power before the power of the nv
series.
If this order is not followed, it may cause an
accident or damage to the machine.
Share the external power supply for the I/O
module with the load power supply
whenever possible. If this is not possible,
construct the system so that the external
power supply and load power supply are
turned off simultaneously.
4. Safety Precautions in Maintenance and Inspection
WARNING
Mandatory
When installing or removing the
module, unit, terminal block, or wiring
cable, make sure that the external
power supply is off.
Otherwise, there will be live electric poles on
the back of the external terminal block of the
module, causing an electric shock.
Prohibited
Do not connect the battery in reverse,
charge, disassemble, overheat it, throw
it into fire, or short-circuit it.
It may cause an explosion or fire.
Mandatory
When replacing the power fuse or alarm
fuse of the device, turn off the device.
Otherwise, it may cause an electric shock or
fire.
Mandatory
Replace fuses or batteries with
specified items.
Using anything other than specified may
cause a fire or failure.
Mandatory
Be extremely careful when measuring
the power supply voltage at the power
terminal part of the module during an
inspection.
Otherwise, it may cause an electric shock.

6F8C1220
vi
CAUTION
Mandatory
Replace the battery every 5 years.
If the battery is worn, the data or programs
saved in the controller module may be lost,
causing an accident or damage to the
machine due to malfunction.
Mandatory
Replace the shutdown capacitor every
8 years.
If the shutdown capacitor is worn, the data
or programs saved in the controller module
may be lost, causing an accident or
damage to the machine due to malfunction.
5. Safety Precautions in Disposal
WARNING
Prohibited
Do not throw the lithium battery into a
fire.
The battery may explode.
CAUTION
Mandatory
When disposing of the lithium battery or
Ni-Cd battery, follow the ordinances or
rules of the local government.
Otherwise, it may cause environmental
damage.
Mandatory
Dispose of the unit and module of the
nv series as industrial waste.
Otherwise, it may cause environmental
damage.

Unified Controller nv series Controller Unit Instruction Manual vii
6. Checking the Warning Label on the Main Body
Check that warning label is attached on the main body.
If the label is missing or hard to read due to stain, contact our service department.
[Warning symbols on the nv series main body]
This symbol is a warning symbol for dangerous parts. It is attached on places
where there is a risk of an electric shock or a risk of damage to the main body due
to wrong wiring.
Note the following where this symbol is present.
●Touching the power input terminal of the power supply module while the power is on
causes an electric shock and is very dangerous.
Do not touch the power input terminal.
●For safety, turn off the power before wiring or performing maintenance and inspection.
●Wire the power input terminal correctly, and avoid applying any voltage exceeding the
specified voltage range. It may cause failure or damage.
●Perform connector connection of the nV-Tool port after turning off the power of the nV-Tool
(such as the PC).
Turn on the power of the nV-Tool after connection.
Be careful not to short-circuit the connector pins with the connector cover.
[Warning stickers]
The warning sticker as shown in the left
figure is attached to the power terminal
of the nv series (except for power
supplies below 24V).
Remove the sticker from the mount,
and attach it on the main body of the
nv series, or on a location near the nv
series where it can be seen easily.
There are stickers in both Japanese
and English. Use the one that suits
your need.
When wiring, remove the sticker
mount.
If the sticker is damaged, contact your
distributor.

6F8C1220
viii
Restrictions on Application
■This product is not developed/manufactured for use in systems involving devices that
directly affect human life (Note 1). Do not use them for such applications.
■To use this product for systems that involve devices that significantly affect human safety or
maintenance of public functions (Note 2), special considerations (Note 3) are required in
system operation, maintenance, and management. In this case, contact one of Toshiba's
sales representatives.
(Note 1) Devices that directly affect human life include the following.
Medical devices such as life supporting devices and devices for surgical units.
(Note 2) Systems that involve devices that significantly affect human safety or
maintenance of public functions include the following.
Main unit control systems of nuclear power plants, safety protection systems of
nuclear facilities, and other systems that are critical for safety
Operation control systems of mass transportation systems and air traffic control
systems
(Note 3) Special considerations indicate sufficient discussions with Toshiba's engineers to
construct a safe system (e.g. employing fool-proof design, fail-safe design, or
redundant design).
Disclaimer
■Toshiba shall not be responsible for any damage caused by an earthquake, lightning and
wind, fire for which Toshiba is not responsible for, acts of a third party, other accidents, the
user's willful acts or negligence, misuse, or use in abnormal conditions.
■Toshiba shall not be responsible for any incidental damage (loss of business profits,
interruption of business, change or loss of stored memory) caused by use of or unable to
use of this product.
■Toshiba shall not be responsible for any damage caused by failure to observe the
information described in the operation manual.
■Toshiba shall not be responsible for any damage caused by malfunctions due to
combination with any connected device.
■Toshiba shall not be responsible for any damage caused by malfunctions due to
combination with any application program created by the customer.

Unified Controller nv series Controller Unit Instruction Manual ix
Precautions on Usage
●Installation
Use your cellular phone or PHS one meter or more away from the product main unit in
operation, various transmission cables, and I/O cable. Otherwise, the system may
malfunction.
When connecting the connectors and cables or installing the module to the base unit,
secure them with screws tightly.
Insufficient tightening may cause failure or malfunction due to vibrations.
●Power wiring
Keep the cables from other lines as much as possible. Especially, keep them away
200mm or more from power lines.
The terminal screw size is M4. As applicable crimp contacts, use the one for M4 screws
whose width is 8.5mm or less.
Do not connect anything to the NC part.
●Use of sample programs
Use the sample programs described in the operation manual after performing an operation
check.
Make sure to perform an operation check before actual operation to avoid an accident due
to malfunction.
Do not drop, bump, or apply strong shocks to the device or module. It may cause failure.
●Battery replacement
Battery replacement can be done while the unit is energized or not energized. When
replacing the battery while the unit is not energized, complete the replacement within 3
minutes. If the unit is left without a battery for a long time, the content of the RAM memory
may be lost.
The Battery Normal LED (BAT) may illuminate during battery replacement. This is not an
error.
If the voltage decreases with the battery installed, the state will be detected normally and
the LED goes off.
The battery voltage is not compatible with manganese batteries or alkaline batteries. Do
not mix them.
Do not use a battery when 3 years or more have passed since the production date.
●Maintenance
Place a module removed from the unit on a conductive mat or conductive bag (used for a
backup board) on a grounded table.
Otherwise, parts may be damaged due to static electricity.
Before touching the device or module, touch a grounded metal to discharge the static
electricity of your body. Otherwise, it may cause malfunction or failure due to static
electricity.

6F8C1220
x
Wipe off stain on the device or module with a soft cloth.
For severe stain, use a wet cloth wrung tightly.
Leaving them stained may cause wrong decision or operational mistake.
Do not use benzene or thinner to remove stain on device or module.
It may cause deformation or discoloration of the device panel or module.
To keep the system normal and avoid unnecessary troubles, perform daily inspections,
regular inspections, and cleaning.
●Please observe the following
To assure safety of the operator and normal operation of the device when the device is used,
please observe the following.
1. Before installation, operation, maintenance, or inspection, read this operation manual and
all the related manuals thoroughly to obtain device information, safety information, and
other considerations. Use the device after reading the operation manual thoroughly.
2. Do not install or store it in the following environments.
(1) A place with a lot of dust
(2) A place with corrosive gases (SO2, H2S)
(3) A place with vibrations and shocks
(4) A place with low or high temperature outside of the installation condition described in
this manual
(5) A place with high humidity
3. When the ambient or internal temperature of the device rises abnormally or failure occurs
in the device, stop using the device, turn off the power, and contact one of Toshiba's
service representatives.
4. Do not open the case of the device during operation for any purpose other than switch
setting.
5. Do not modify the device.
6. Be careful not to drop the product during transportation.
7. The device is intended for people with general knowledge on handling of control devices
in terms of installation, wiring, usage, and maintenance. Wrong handling may cause an
electric shock, fire, failure, or malfunction. Those who have insufficient knowledge on
handling of control devices or electric devices should avoid performing installation, wiring,
usage, and maintenance, and delegate the task to someone with expertise.
8. This document and related materials are intended for people with general knowledge on
handling of control devices.
If you have any question, please do not hesitate to ask us.

Unified Controller nv series Controller Unit Instruction Manual xi
●nv series operation manuals
In addition to this manual, there are the following related manuals for the nv series.
Unified Controller nv series Type 1 Function Manual (6F8C1221)
Describes the functions and use of type 1 and information necessary to create user
programs.
Unified Controller nv series Type 2 Function Manual (6F8C1362)
Describes the functions and use of type 2 and information necessary to create user
programs.
Unified Controller nv series/Integrated Controller V series Command Manual (6F8C1226)
Describes the detailed specifications of the instruction words of the program languages
(LD, FBD, SFC and ST) supported by the nv series and V series.
Unified Controller nv series/Integrated Controller V series Engineering Tool 4 (Basic)
Operation Manual (6F8C1290)
Describes how to create, debug, print, and save programs using nV-Tool.
Unified Controller nv series/Integrated Controller V series Engineering Tool 4 (Setup)
Operation Manual (6F8C1291)
Describes how to set up nV-Tool.
High-speed Serial I/O System TC-net I/O Instruction Manual (6F8C1240)
This describes the specification, handling method and maintenance on nv series I/O and
TC-net I/O system.
TC-net100 Module Instruction Manual（6F8C1360）
This describes the specification and handling method on TC-net 100 module of nv series.
Ethernet Module Instruction Manual（6F8C1358）
This describes the specification and handling method on Ethernet module of nv series.

6F8C1220
xii
This manual describes the overview, storage, handling, and maintenance/inspection of the
following modules of the Unified Controller nv series.
To use the device correctly, read "Safety precautions" before use.
Repairs and replacements due to depletion or wear are offered at cost even within the warranty
period of this product.
Introduction

Unified Controller nv series Controller Unit Instruction Manual xiii
●Notational conventions
The following are the notational conventions for better understanding of this document.
Important Describes what the user should be particularly aware of to handle the product correctly.
Note Describes what the user should observe to handle the product correctly.
Remark Describes a remark.
●Reading this document
This document consists of the following chapters.
Chapter 1 On installing type1/type2 controllers
This chapter describes the system configuration installing the unified controller
nv series type1 and type2.
Chapter 2 Installing/Uninstalling
This chapter describes how to install and uninstall modules comprising the
controller unit.
Chapter 3 Connecting devices
This chapter describes how to connect cables connecting to the controller
unit.
Chapter 4 Starting and stopping
This chapter describes how to start and stop the controller unit.
Chapter 5 Downloading a program
This chapter describes how to download a program from nV-Tool to the
controller unit.
Chapter 6 Operation
This chapter describes operation of the controller and what is displayed during
operation.
Chapter 7 Troubleshooting
This chapter describes troubleshooting to deal with a trouble.
Chapter 8 Maintenance and inspection
This chapter describes daily inspection, the detail and the method of
periodical inspection and how to replace parts including batteries.

6F8C1220
xiv
Chapter 1
On Installing
type1/type2
Controllers
…1
1.1 Functions and Characteristics of the Controller ·········2
1.2 Names and Functions of Parts of the Controller ············· 4
1.3 Names and Functions of the Parts of the Power Supply
················································································································ 6
1.4 System Configuration ································································ 10
1.5 Installation Condition ································································· 16
1.6 Grounding of the Controller ···················································· 20
Chapter 2
Installing/
Uninstalling
…23
2.1 Base Unit / Fan Unit ····································································· 25
2.2 Installing / Uninstalling the Module ······································ 28
2.3 Implementation to the Body ···················································· 31
Chapter 3
Connecting
Devices
…33
3.1 Connection of the External Line I/O ····································· 34
3.2 Connection of TC-net I/O Loop Cable ································ 36
3.3 Connection with the nV-Tool Cable ······································ 38
Chapter 4
Starting and
Stopping
…39
4.1 Checking the Switch before Starting ··································· 40
4.2 Installing the Battery to the Controller Module ··············· 41
4.3 How to Start the Controller ······················································ 42
4.4 The Status of LED when the Controller is Started ········· 43
4.5 How to Stop the Controller ······················································ 44
Chapter 5
Downloading a
Program
…45
Chapter 6
Operation
…51
CONTENTS

Unified Controller nv series Controller Unit Instruction Manual xv
Chapter 7
Troubleshooting
…55
7.1 If a Trouble is Suspected ·························································· 56
7.2 Trouble Details Checks ······························································ 62
7.3 Version Checks ············································································· 70
Chapter 8
Maintenance and
Inspection
…71
8.1 Daily Inspections ·········································································· 72
8.2 Periodic Inspections ··································································· 73
8.3 Service Parts ·················································································· 74
8.4 Replacing the Battery ································································· 75
8.5 Replacing the Shutdown Capacitor ····································· 77
8.6 Replacing and Cleaning the Filter ········································ 79
8.7 Disposing of the Module ··························································· 82
Appendix A
Specification
…83
A.1 General Specification ································································· 84
A.2 Power Module Specification ···················································· 86
A.3 Controller Module Specification ············································ 88
A.4 Life-time Components ································································ 89
A.5 List of TC-net I/O Modules and Other Related Modules
·············································································································· 90
A.6 List of Current Consumptions and Weights by Module
·············································································································· 91
Appendix B
Outline Drawing
…93
B.1 Base and Fan Units ····································································· 94
B.2 Power Module PS891 ·································································· 98
B.3 Controller Modules PU811 and PU812 ································ 99
Appendix C
Notes on
Applying the I/O
Modules
…101
C.1 DC Input Modules ······································································ 102
C.2 AC Input Modules ······································································ 107
C.3 DC Output Modules ·································································· 110
C.4 AC Output Modules ·································································· 113
C.5 Contact Output Modules ························································ 114
C.6 Analog Input Modules ····························································· 115
C.7 Analog Output Modules ························································· 116

6F8C1220
xvi

1
Chapter 1
On Installing type1/type2
Controllers
Unified controller nv series have two types; type1 and type2.
The type1 controller is mainly used for high-speed sequence control as a successor of S
model of the integrated controller V series.
The type2 controller is mainly used for loop control as a successor of L model of the
integrated controller V series.
1.1 Functions and Characteristics of the Controller ··2
1.2 Names and Functions of Parts of the Controller ··4
1.3 Names and Functions of the Parts of the Power Supply
······································································6
1.4 System Configuration ···································· 10
1.5 Installation Condition·····································16
1.6 Grounding of the Controller···························· 20

Chapter 1 On Installing type1/type2 Controllers
6F8C1220
2
1.1 Functions and Characteristics of the Controller
Unified controller nv series inherit functions of the conventional integrated
controller V series and have the following features.
Computing performance has been improved by directly executing
IEC language by the hardware.
As it is designed to execute international standard language IEC 61131-3
instructions with ASIC directly on the hardware, you can set the execution time of
sequence instruction word to 20ns (1/2 compared to our product) at maximum
and the control cycle to 0.5ms at minimum.
High reliability has been achieved by the redundant structure of
modules and application of ECC circuit of the internal memory.
You can build a duplexed system having two sets of the power, CPU and
transmission modules. Furthermore, you can not only detect errors but also
correct them by applying ECC circuit to the internal memory of each module. The
complex circuit is highly integrated by ASIC to reduce the number of parts and
the failure rate.
It is equipped with the fastest serial I/O system “TC-net I/O” first
time in the industry.
The field I/O system that provides 100Mbps transmission rate and allows loop
duplexed structure has been achieved first time in the industry. You can collect
fast I/O data and set the minimum time of collection cycle to 100μs. The
transmission channel is normally duplexed loop (sending and receiving) structure
that can be further duplexed.
High reliability has been achieved by introducing Gigabit and
redundant supervisory control network.
The supervisory control network employs Ethernet whose transmission rate
is1Gbps and can further duplex the transmission channel. It allows you to use the
international standard Real-Time Ethernet “TC-net 100” as a network between
controllers. It is designed to be connected with conventional devices via a
switching hub and gateway.
