1 - 7Oct. 1995 © TOSHIBA CORP. 1550 ADJUSTMENT
1.2.2 Output check mode (Test mode 03/04)
In the 03 or 04 test mode, you can check the status of each of the output signals by entering the
following corresponding code.
Code Function Code Function Group
1 Main motor
2 Feed roller clutch (copier)
3 Aligning roller clutch (copier)
6 Toner motor
7 Optics fan
8 Exit fan
9 Pick-up roller clutch (copier)
11 Main motor
12 Feed roller clutch (copier)
13 Aligning roller clutch (copier)
16 Toner motor
17 Optics fan
18 Exit fan
19 Pick-up roller clutch (copier)
10 Total counter Increases at each “P” key press.
*1 20 Scanning motor At 1st “P” key press, scans forward and backward at 2nd press.
21 Lens motor At 1st “P” key press, moves to 50% position and to 200%
position at 2nd press.
22 Mirror motor At 1st “P” key press, moves to 50% position and to 200%
position at 2nd press.
1
30 HVT-M
31 HVT-TR
32 HVT-AC
33 Exposure lamp If forced on for 5 sec., it goes off.
64444474444448
64444474444448
ON OFF
61 PFU motor (PFU)
62 Pick-up roller clutch (PFU)
63 Feed roller clutch (PFU)
64 Aligning roller clutch (PFU)
80 DF independent aging At 1st “P” key press, starts and stops at 2nd press.
71 PFU motor (PFU)
72 Pick-up roller clutch (PFU)
73 Feed roller clutch (PFU)
74 Aligning roller clutch (PFU)
64748 64474448
At 1st “P” key press, comes on and goes off at 2nd press.
ON
64474448
OFF
2
3
1
92 Sorter aging without paper At 1st “P” key press, starts and goes off at 2nd press.
644444444474444444448
82 DF pick-up roller rotation
83 DF aligning roller
84 DF transport belt rotation
85 DF pick-up roller rotation/Weight solenoid
86 DF weight solenoid
87 DF clutch
90 Sorter transport motor
91 Sorter bin motor
3
*1: Scanning motor rotates at the preset reproduction ratio.
At 1st “P” key press, comes on and stops at
2nd press.
