Toshiba TPS0A0700AXA User manual

UNINTERRUPTIBLE POWER SYSTEM (UPS)
TPX Series
INSTALLATION AND
OPERATION MANUAL
LINE INTERACTIVE
700VA/420W 120V UPS
Document: 97673-000
Date: June 2017
© Copyright 2017 TOSHIBA International Corporation
All rights reserved.

This Page Left Intentionally Blank

TPX Series UPS 700VA Operational Manual –97673-000 i
PRODUCT USE AND WARRANTY RESTRICTION
The Toshiba products listed in this document are intended for usage in general electronics
applications (computer, personal equipment, office equipment, etc.). These Toshiba
products are neither intended nor warranted for usage in equipment that requires
extraordinarily high quality and/or reliability or where a malfunction or failure may cause
loss of human life or bodily injury (Unintended Usage). Unintended Usage includes atomic
energy control instruments, airplane or spaceship instruments, transportation instruments,
traffic signal instruments, combustion control instruments, life-support equipment, all types
of safety devices, etc. Unintended Usage of Toshiba products listed in this document shall
be made at the customer’s own risk.
NOTICE
PLEASE INFORM A TOSHIBA INTERNATIONAL CORPORATION
REPRESENTATIVE IN CASE OF INCONSISTENCIES, OMISSIONS, OR QUESTIONS
The instructions contained in this manual are not intended to cover all of the details or
variations in equipment, or to provide for every possible contingency concerning
installation, operation, or maintenance. Should further information be required or if
problems arise which are not covered sufficiently, contact the TIC customer support center.
The contents of this instruction manual shall not become a part of or modify any prior or
existing agreement, commitment, or relationship. The sales contract contains the entire
obligation of Toshiba International Corporation's UPS Division. The warranty contained in
the contract between the parties is the sole warranty of Toshiba International Corporation's
UPS Division and any statements contained herein do not create new warranties or modify
the existing warranty.
Any electrical or mechanical modifications to this equipment without prior written consent of
Toshiba UPS will void all warranties and may void the UL/CUL listing. Unauthorized
modifications can also result in personal injury, loss of life, or destruction of the equipment.
QUALIFIED PERSONNEL ONLY
Qualified Personnel are those who have the skills and knowledge relating to the
construction, installation, operation, and maintenance of the electrical equipment and
have received safety training on the hazards involved (Refer to the latest edition of
NFPA 70E for additional safety requirements).

TPX Series UPS 700VA Operational Manual –97673-000 ii
UNINTERRUPTIBLE POWER SUPPLY (UPS)
Please complete the following information and retain for your records.
Unless otherwise specified, the warranty period for the UPS or UPS part is 36 months from
the shipment date (see Toshiba International Corporation bill of lading).
Unless otherwise specified, the warranty period for a UPS battery is 24 months from the
shipment date (see Toshiba International Corporation bill of lading).
Please complete the following information and retain for your records.
Job Number: _____________________________________________________________
Model Number: ___________________________________________________________
Serial Number: ___________________________________________________________
Application: ______________________________________________________________
Shipment Date: ___________________________________________________________
Installation Date: __________________________________________________________
Inspected By: _____________________________________________________________

TPX Series UPS 700VA Operational Manual –97673-000 iii
PURPOSE AND SCOPE OF MANUAL
This manual provides information on how to safely install your Toshiba International
Corporation power electronics product. This manual includes a section of general safety
instructions that describes the warning labels and symbols that are used throughout the
manual. Read the manual completely before installing, operating, or performing
maintenance on this equipment.
This manual and the accompanying drawings should be considered a permanent part of
the equipment and should be readily available for reference and review. Dimensions
shown in the manual are in metric and/or the English customary equivalent.
Toshiba International Corporation reserves the right, without prior notice, to update
information, make product changes, or discontinue any product or service identified in this
publication.
Toshiba is a registered trademark of the Toshiba Corporation. All other product or trade
references appearing in this manual are registered trademarks of their respective owners.
Toshiba International Corporation shall not be liable for direct, indirect, special, or
consequential damages resulting from the use of the information contained within this
manual.
This manual is copyrighted. No part of this manual may be photocopied or reproduced in
any form without the prior written consent of Toshiba International Corporation.
© Copyright 2017 TOSHIBA International Corporation
All rights reserved
Printed in Taiwan

TPX Series UPS 700VA Operational Manual –97673-000 iv
TOSHIBA INTERNATIONAL CORPORATION
CUSTOMER SUPPORT CENTER
Toshiba International Corporation’s Customer Support Center can be contacted to obtain
help in resolving any Uninterruptible Power System (UPS) problems that you may
experience or to provide application information.
Customer Support Center
8 a.m. to 5 p.m. (CST) –Monday through Friday
USA Toll Free [phone] –Field Service Tech Support
USA Toll Free [phone] –Pre-sales Application Support
You may also contact Toshiba International Corporation by writing to:
Toshiba International Corporation
Power Electronics Division - UPS
13131 West Little York Road
Houston, Texas 77041-9990
Attn: UPS Product Manager
For further information on Toshiba International Corporation’s products and services,
please visit our website at www.ToshibaUPS.com.

TPX Series UPS 700VA Operational Manual –97673-000 v
TABLE OF CONTENTS
1. GENERAL SAFETY INSTRUCTIONS....................................... 1
2. SAFETY ALERT SYMBOL........................................................ 1
3. IMPORTANT SAFETY INSTRUCTIONS.................................... 4
4. INTRODUCTION...................................................................... 10
5. PRODUCT DESCRIPTION ...................................................... 10
6. INSTALLATION....................................................................... 10
6.1 PLACEMENT ..................................................................................10
6.2 CONNECT COMPUTER INTERFACE (OPTIONAL)......................11
6.3 CONNECT TO UTILITY..................................................................11
6.4 CHARGE THE BATTERY...............................................................11
6.5 CONNECT THE LOADS (DEVICES)..............................................11
6.6 FRONT PANEL VIEW.....................................................................12
6.7 REAR PANEL VIEW .......................................................................13
7. OPERATION............................................................................ 15
7.1 TURN ON........................................................................................15
7.2 TURN OFF ......................................................................................15
7.3 SILENCE/ALARM OFF ...................................................................15
7.4 SELF-TEST.....................................................................................15
7.5 LOAD LEVEL / BATTERY CAPACITY BAR GRAPH .....................16
7.6 SHUTDOWN MODE .......................................................................16
7.7 COLD START..................................................................................16

TPX Series UPS 700VA Operational Manual –97673-000 vi
8. ALARMS.................................................................................. 17
8.1 BACKUP MODE..............................................................................17
8.2 LOW BATTERY...............................................................................17
8.3 OVERLOAD ....................................................................................17
9. SOFTWARE INSTALLATION AND USB PORT...................... 18
9.1 MONITORING SOFTWARE OVERVIEW.......................................18
9.2 INSTALLING SOFTWARE..............................................................18
9.3 FEATURES FOR MONITORING SOFTWARE...............................18
9.4 HOW TO START MONITORING SOFTWARE...............................19
10. TROUBLESHOOTING............................................................. 20
11. SPECIFICATIONS ................................................................... 21
12. INSPECTION/STORAGE/DISPOSAL...................................... 23
12.1 INSPECTION ..................................................................................23
12.2 UNPACKING...................................................................................23
12.3 STORAGE CONDITIONS...............................................................23
13. INSTALLATION PRECAUTIONS ............................................ 25
14. OPERATING PRECAUTIONS................................................. 26
15. MAINTENANCE....................................................................... 27
15.1 REPLACING BATTERIES...............................................................29
16. SERVICE AND WARRANTY ................................................... 30
16.1 SERVICE.........................................................................................30
16.2 LIMITED WARRANTY.....................................................................31

TPX Series UPS 700VA Operational Manual –97673-000 1
1. GENERAL SAFETY INSTRUCTIONS
DO NOT attempt to install, operate, maintain, or dispose of this equipment until this entire
instruction manual has been read and all product warnings and user instructions are
understood.
2. SAFETY ALERT SYMBOL
The Safety Alert Symbol indicates that a potential personal injury hazard exists. The
symbol is comprised of an equilateral triangle enclosing an exclamation mark.
Signal Words
Listed below are the signal words that are used throughout this manual followed by their
descriptions and associated symbols. When the words DANGER, WARNING and
CAUTION are used in this manual they will be followed by important safety information that
must be carefully adhered to.
The word DANGER preceded by the safety alert symbol indicates that an imminently
hazardous situation exists that, if not avoided, will result in death or serious injury to
personnel.
DANGER

TPX Series UPS 700VA Operational Manual –97673-000 2
The word WARNING in capital letters preceded by the safety alert symbol
indicates that a potentially hazardous situation exists that, if not avoided, could
result in death or serious injury to personnel.
The words CAUTION and ATTENTION in capital letters preceded by the safety alert
symbol indicate a potentially hazardous situation exists which, if not avoided, may result in
minor or moderate injury.
The word CAUTION in capital letters without the safety alert symbol indicates that a
potentially hazardous situation exists which, if not avoided, may result in equipment or
property damage.
Special Symbols
To identify special hazards, other symbols may appear in conjunction with the DANGER,
WARNING and CAUTION signal words. These symbols indicate areas that require special
and/or strict adherence to the procedures to prevent serious injury to personnel or death.
Electrical Hazard Symbol
A symbol which indicates a hazard of injury from electrical shock or burn. It is comprised of
an equilateral triangle enclosing a lightning bolt.
WARNING
CAUTION/ATTENTION
CAUTION

TPX Series UPS 700VA Operational Manual –97673-000 3
Explosion Hazard Symbol
A symbol which indicates a hazard of injury from exploding parts. It is comprised of an
equilateral triangle enclosing an explosion image.
Equipment Warning Labels
DO NOT attempt to install, operate, maintain, or dispose of this equipment until this entire
instruction manual has been read and all product warnings and user instructions are
understood.
Labels attached to the equipment are there to provide useful information or to indicate an
imminently hazardous situation that may result in serious injury, severe property and
equipment damage, or death if the instructions are not followed.

TPX Series UPS 700VA Operational Manual –97673-000 4
3. IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that should be followed during the installation,
maintenance, and operation of the UPS and its batteries to assure safe and proper
operation.
Qualified Personnel ONLY!
Qualified Personnel refer to individuals that have the skills and knowledge relating to the
construction, installation, operation, and maintenance of the electrical equipment and have
received safety training on the hazards involved (Refer to the latest edition of NFPA 70E
for additional safety requirements).
For further information on workplace safety visit www.osha.gov.
Qualified Personnel shall:
1) Have read the entire operation manual.
2) Be trained and authorized to safely energize, de-energize, ground,
lockout and tag circuits and equipment, and clear faults in accordance
with established safety practices.
3) Be trained in the proper care and use of protective equipment such as
safety shoes, rubber gloves, hard hats, safety glasses, face shields, flash
clothing, etc., in accordance with established safety practices.
4) Be trained in rendering first aid.
5) Be knowledgeable of batteries and the required handling and
maintenance precautions.

TPX Series UPS 700VA Operational Manual –97673-000 5
Misuse of this equipment could result in injury and equipment damage. In no event will
Toshiba Corporation be responsible or liable for either indirect or consequential damage
or injury that may result from the misuse of this equipment.
Do not dispose of the batteries in a fire. The batteries may explode.
Do not open or mutilate the batteries. Released electrolyte is harmful to the eyes and skin
and could also be toxic.
A battery can present a risk of electrical shock and high short circuit current.
Contact with any part of a grounded battery can result in electrical shock.
The likelihood of shock will be reduced if such grounds are removed prior to installation
or maintenance.
WARNING
CAUTION
CAUTION
DANGER
WARNING

TPX Series UPS 700VA Operational Manual –97673-000 6
Risk of electric shock –Refer to cautionary markings at top, or rear, or bottom of UPS.
Risk of electric shock –Heat-sinks are live. Disconnect unit before servicing.
(UPS has internal batteries): Risk of electric shock –Hazardous live parts inside this
unit is energized from the battery supply even when the input AC power is
disconnected.
(No user serviceable parts): Risk of electric shock –do not remove cover, no user
serviceable parts inside. Refer service to qualified service personnel.
(Non-isolated battery supply): Risk of electric shock –battery circuit is not isolated
from AC input. Hazardous voltage may exist between battery terminals and ground.
Test before touching.
When replacing batteries, replace with the same type and number of batteries: One
Sealed lead acid battery, rated 12V, 9AH maximum.
To reduce risk of fire, use only No. 26 AWG or larger telecommunication line cable.
With the installation of this equipment it should be prevented, that the sum of the
leakage current of the UPS and connected consumer does not exceed 3.5 mA.
Transformer core is not grounded. It may present risk of electric shock. Test before
touching.
A battery can present a risk of electric shock and high short circuit current. The
following precaution should be observed when working on batteries
oRemove watches, rings or other metal objects.
oUse only tools with insulated handles.
oWear rubber gloves and boots.
CAUTION

TPX Series UPS 700VA Operational Manual –97673-000 7
oDo not lay tools or metal parts on top of batteries.
oDisconnect charging source prior to connecting or
disconnecting battery terminals.
To reduce risk of electric shock, disconnect the UPS from the mains supply before
installing a computer interface signal cable. Reconnect the power cord only after
signaling interconnections have been made.
Servicing of batteries should be performed or supervised by personnel with knowledge
of batteries and the required precautions. Keep unauthorized personnel away from
batteries.
The instructions contained within this safety manual are deemed important and should be
closely followed at all times during installation and follow-up maintenance of the UPS and
batteries.
To reduce the risk of fire. Connect only to a circuit provided with 20 amperes
maximum branch circuit overcurrent protection in accordance with the National
Electric Code, ANSI/NFPA 70”.
Attention –afin de réduire les risques d’incendie, ne raccordez qu’à un circuit
muni d’une protection de surintensité du circuit de dérivation maximum de 20
ampères conformément au Code Électrique National (National Electrical Code)
des états-unis, ANSI/NFPA 70.
CAUTION

TPX Series UPS 700VA Operational Manual –97673-000 8
CAUTION
The unit has a dangerous amount of voltage. If the UPS indicator is on, the unit’s
outlets may have a dangerous amount of voltage even when not plugged into the
wall outlet because the battery may continue to supply power.
Ensure installation is indoors, free from electrically-conductive particles,
temperature and humidity controlled in order to reduce the risk of electric shock.
It is best to disconnect the device using the power supply cord. Ensure that the
equipment is placed in a position near the outlet where easily accessible.
Except when replacing the batteries, all service on this equipment must be
carried out by qualified service personnel.
Before conducting any maintenance, repair or shipment, first ensure that all
components turned off completely and disconnected.
ATTENTION
Hazardous through electrical shock. Also with disconnection of this unit from the
mains, hazardous voltage still may be accessible through supply from the batteries.
The battery supply should therefore be disconnected in the plus and the minus pole
when maintenance or service work inside the battery cabinet or UPS is considered.
To reduce risk of fire, replace only with the same type and rating of fuse.
Intended for installation in a controlled, indoor environment free of conductive
contaminants. Maximum ambient temperature 40°C.
WARNING

TPX Series UPS 700VA Operational Manual –97673-000 9
Special Symbols
The following are examples of symbols used on the UPS to alert nearby personnel to
important information:
RISK OF ELECTRIC SHOCK –Please observe the warning that a risk of
electric shock is present.
CAUTION: REFER TO OPERATOR’S MANUAL – Refer to the operator’s
manual for additional information, such as important operating and maintenance
instructions.
SAFE GROUNDING TERMINAL - Indicates primary safe ground.
LOAD ON/OFF - Pressing this button turns on/off the output receptacles and
the Indicator light.
RJ-45 RECEPTACLE –The receptacle provides network interface
connections and telephone or telecommunications equipment should not be
plugged into it.
Please do not discard the UPS or UPS batteries as the UPS may have valve
regulated, lead–acid batteries. Please recycle batteries.

TPX Series UPS 700VA Operational Manual –97673-000 10
4. INTRODUCTION
The information provided in this manual covers single phase 700 VA, uninterruptible power
supplies, their basic functions, operating procedures, and emergency situations, also
including information on how to ship, store, handle and install the equipment. Only detailed
requirements of the UPS units are described herein, and installation must be carried out in
accordance with this manual. Electrical installations must also carefully follow local
legislation and regulations. Only qualified personnel should conduct these installations as
failure to acknowledge electrical hazards could prove to be fatal.
5. PRODUCT DESCRIPTION
Toshiba’s TPX Series, line-interactive pure sine wave UPS system protects computers,
servers, networking accessories and telecommunication equipment from blackouts, voltage
fluctuations and transient surges. It includes 6 protected NEMA 5-15R output receptacles
total, 3 of which offer surge suppression only for less critical desktop accessories.
6. INSTALLATION
Inspect the UPS upon receipt. The packaging is recyclable; keep it for reuse or be disposed
of properly.
6.1 PLACEMENT
Install the UPS in a protected area with adequate flowing air and free of excessive dust.
Do not operate the UPS where the temperature and humidity is out of the specified limits

TPX Series UPS 700VA Operational Manual –97673-000 11
6.2 CONNECT COMPUTER INTERFACE (OPTIONAL)
This UPS is supplied with local monitoring software. If used, connect the computer
interface port and the USB port of the UPS using the supplied cable.
Note: Computer interface connection is optional. The UPS works properly without a
computer interface connection.
CAUTION: Use only factory supplied or authorized UPS monitoring cable!
6.3 CONNECT TO UTILITY
Connect the power cord on the UPS to a properly grounded AC power outlet. Do not use
surge protectors or extension cords. Please notice the voltage of utility power should match
with the UPS. For example, the rating voltage of UPS is 120V, the input utility power
should be the same as 120V.
6.4 CHARGE THE BATTERY
The UPS charges its battery whenever it is connected to utility power. For best results,
charge the battery for 8 hours in the initial use.
6.5 CONNECT THE LOADS (DEVICES)
The employed equipment’s power cords (such as computer) are plugged into the sockets
on the rear panel.
CAUTION: Do not plug high-draw equipment such as laser printer or plotter to the “UPS
outlets”. A laser printer or plotter periodically draws significantly more power than when it
is in idle status, and may overload the UPS.
Note: The Toshiba UPS is designed to support electronic equipment only. The UPS will be overloaded
if the total VA rating for all equipment connected through the battery backup/surge protection outlets
exceeds the UPS's Output Capacity.

TPX Series UPS 700VA Operational Manual –97673-000 12
6.6 FRONT PANEL VIEW
“OFF” button: Press the OFF button to turn off the UPS and the loads.
“ON/TEST” button: With the UPS plugged in, press the ON/TEST button to turn on the
UPS and power the loads. ON/TEST button also activates the UPS‘s self-test function and
silences the buzzer when working at backup mode.
“BOOST AVR (VOLTAGE BOOST)” indicator (YELLOW LED): The LED illuminates
when the UPS is correcting a lower utility voltage input. The loads will continue to receive
clean power from the UPS.
“BUCK AVR (VOLTAGE REDUCTION)” indicator (YELLOW LED): The LED
illuminates when the UPS is correcting a higher utility voltage input. The loads will continue
to receive clean power from UPS.
“OVERLOAD / REPLACE BATTERY” indicator (RED LED): The LED flashes when
the loads connected to the UPS exceed the UPS‘s capacity. The LED will be lit steadily
when the UPS‘s battery is no longer useful and must be replaced.
“BACK UP” indicator (YELLOW LED): The LED illuminates when the UPS is
supplying battery power to the loads








