Toto DUOFIT WT173M Installation instructions

Installation and Owner’s Manual /
Manuel D’Installation et D’Utilisation /
Manual de Instrucciones y del Propietrario /
Manual de instalação e do proprietário
Important Notice for Installers/
Remarque importante pour les installateurs/
Aviso importante para los instaladores/
Aviso importante para instaladores
The positions of the holes to drill in the wall vary depending on WASHLET being installed.
Please check page 8 for details. /
Les positions des trous à percer dans le mur varient en fonction du BIDET qui est installé.
Veuillez vérifier la page 22 pour obtenir plus de détails. /
Las ubicaciones de los orificios que se harán en la pared varían según el WASHLET que se instale.
Para obtener detalles, consulte la página 36. /
As posições dos orifícios a perfurar na parede variam, dependendo do WASHLET sendo instalado.
Verifique a página 50 para mais informações.
Sistema de depósito de parede DuoFit
DuoFit In Wall Tank System
Système de réservoir mural DuoFit
Sistema de tanque empotrado DuoFit
WT173M

2
• Hacksaw
• Flat File
• Drill
• 1/8” (3mm) Drill Bit
TABLE OF CONTENTS
THANKS FOR CHOOSING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and function
as a guiding principle. Congratulations on your choice.
INCLUDED PARTS
COMMON TOOLS NEEDED
• 3-1/2” (89mm) Hole Saw
• 7/16” (11mm) Open or Boxed-end Wrench
• Tape Measure
• Carpenter’s Level
Check to make sure you have all these parts from the package:
Parts in Bag 1 Parts in Bag 2
In Wall Tank
(Carrier)
Lag Screw
(8)
Threaded
Mounting Stud
(2)
Lower Bracket Anchor
(2)
Nut
(2)
Cap
(2)
Washer
(2)
Stud bolt Flange
(2)
Flange Pipe Inlet Pipe
Lubricated
sponge
ENGLISH
Push Plate Rough In
Installation
Manual
Installation
Template
Parts in Bag
Outlet Pipe
Mud Guard
Inlet Pipe
Mud Guard
Outlet Pipe Upper bracket
Thanks for Choosing TOTO!...........................................................................................2
Common Tools Needed..................................................................................................2
Included Parts................................................................................................................2
Before Installation........................................................................................................3-4
Installation Procedure................................................................................................5-13
Servicing Procedures..............................................................................................14-15
Warranty.......................................................................................................................16

3
BEFORE INSTALLATION
Read these instructions thoroughly before beginning work.
Please leave these instructions with the customer. They contain important mainte-
nance and warranty information.
If necessary, remove the existing toilet.
CAUTION! Be sure to properly bleed all air from the piping system prior to using
any TOTO products. Trapped/compressed air can cause damage to the flushing
system and toilet bowl.
Prepare the support for the carrier as shown. Consult with a building contractor and/or
local codes for any additional requirements. Add a double wall studs (king and jack)
and double header per the shown dimensions. Confirm that the opening is square.
Do not loosen or tamper with the copper fittings or joint connections.
Framing support be should capable of suporting 880 lb load without damage to the
wall. When metal framing studs are used, rigid, non-flexing bracing supports
should be added to create a rigidity of the base. This will serve to minimize any
flexing observed in the finished wall from sitting to standing and avoid cracks in
the wall.
■
■
■
■
■
■
King Studs
Header
(Double)
Trimmer
(Jack)Studs
Sole Plate
Sub-Floor
(plywood or concrete)
Finished Floor
2"(51)
16"
(406)
ENGLISH
16"
(406)
12- "
(309)
316
12- "
(309)
316
12"
(305)
Optional
GFCI
Electrical
Outlet 45- "
21 32 - 50- " 516
(1160-1278)
22- "(580)
1316

BEFORE INSTALLATION
ENGLISH
Table 1: Dimensions measured from Finished Floor
390
406
432
457
508
inch
1160
1176
1202
1227
1278
300
316
342
367
483 1253 393
418
Toilet Rim
Height (R)
mm
System
Height (H) Threaded Mounting
Stud Height (D)
Toilet Rim
Height (R) System Height (H) Threaded Mounting
Stud Height (D)
16"
17"
20"
15-11/32" 45-21/32" 11-13/16"
12-15/32"
13-15/32"
18" 14-15/32"
16-15/32"
19"
46-5/16"
47-5/16"
48-5/16"
50-5/16"
49-5/16" 15-15/32"
4
NPT
Water
Supply
dia.½"(Ø13)
Finished Floor
NPT
WASHLET
dia.½"(Ø13)
minimum ½"(13)
H
22- "(580)
1316 3- "(89)
12
1- "(35)
38
3- "
(100)
15 16
12- "
(320)
58
7- "
(180)
116
46- "
(1180)
716
39- "
(1000)
38
D"(22)
78
NPT
Water
Supply
dia.½"(Ø13)
inch (mm)
"
58-
(15-135)
3- "
(78)
116
R
6"(152)5- "(134)
14
3- " (86)
38
5- "
516

INSTALLATION PROCEDURE
Installation procedure
Symbols and their meanings
Visual confirmation required.
Loosen the bolts on the adjustable
legs and adjust the carrier to the
desired height with reference to
the Finished Floor (see Table 1
for guide).
Place the carrier so that the front
of the carrier frame is flush with
the front of the supporting wall
frame.
Tighten the two bolts on the
legs to secure the height of the
carrier.
1. Install the discharge pipe
2. Adjust the tank legs
H
Horizontal confirmation
required.
Horizontal
Vertical confirmation
required.
Attach sealing tape
Vertical
Seal
Drill a 3-3/4"(95mm) hole on the
subfloor 1-3/4" (45mm) from the
front of studs.
Mark the location.
Mark
39-3/8”
(1000mm)
1-3/4”(45mm)
FFL
5
ENGLISH

3. Install the upper bracket
4. Drill pilot holes in the wood frame
A
2
dia.1/8"
(Ø 3mm)
1
1
B
2
dia.1/8"
(Ø 3mm)
Mark the location for drilling pilot holes for the screws to secure the carrier to the
wood frame.
There are six (6) screws for the side (3 on each side) and two on the feet. Make
sure the carrier is flush with the wood frame before placing the markings.
Remove the carrier from the wood frame, drill six (6) 1/8"(3mm) holes on the wall
stud (Trimmer/Jack) and two (2) on the subfloor (plywood); for concrete, drill 3/8"
(10mm) holes for anchors.
For vertical drain installation, clip the
upper bracket to the front slot of the
frame as shown.
For left or right drain installation, clip
the upper bracket to the back slot of
the frame as shown.
Mark
A
A
A
A
A
B
B
A
45° 45°
Front Slot Back Slot
6
ENGLISH

5. Set the tank to the wood frame
1
Use the lower bracket to lock the outlet pipe to the Carrier.
Place the carrier into the wood frame, make sure the carrier is horizontally leveled
and flush when placed in the front face of the stud frame.
Use the screws provided for securing the System. Install the outlet pipe to the sewer
pipe.
2
Horizontal
Vertical
6. Plumb the water supply line and check for leak.
CAUTION
Required
This indicates that misoperation could result in injury or
physical damage.
It is important to reconfirm that there is
no water leakage at all connections.
Incomplete connection could cause foul odor
or water to leak.
Do not loosen or tamper with the copper
fittings or joint connections.
The symbol indicates something that must be done.
Seal
3
7
ENGLISH
1
3
1
1
2

7. Confirm water supply
Before connecting the flexible hose
to the fill valve, open shutoff valve
to let water run for a minute or two.
After that, shut off the valve and the
main supply valve.
8. Attach the mud guard, push plate rough-in, and mounting
studs
Insert the mud guard for the inlet and
outlet, the push plate rough-in for the
push plate and the two (2) Threaded
Mounting Stud for the mounting bowl
on the inner holes.
8
ENGLISH

The positions of the holes to drill in the wall vary depending on
WASHLET being installed.
9. Cutting Out the Wall Location
For WASHLET with the above
plug attached, proceed to page
10.
For WASHLET with an attached
outlet plug, proceed to page 9.
Power plug shape may vary
by country. Please confirm
which Power plug shape you
have for correct installation.
9
ENGLISH

9. Cutting Out the Wall Location
Recommended minimum 1/2” (13mm) drywall installation.
Refer to the dimensions to locate the cuts on the wall.
Inlet Drain
mud guard
Outlet Drain
Mud Guard
Push Plate
Rough-In
Threaded
Mounting
Stud
WASHLET Water
Supply Hole
Push Plate
8-7/8”(226mm)
5-9/16”(140mm)
Outlet Drain Hole
Inlet Drain Hole
Wall Panel (min.1/2”(13mm))
24” (610mm)
Installation
Template
Electrical
Box Hole
12-5/8”(320mm)
7-1/16”(180mm)
FFL
Toilet
Mounting
Holes
Toilet
Mounting
Holes
Refer to page 58 for more
detail dimensions.
Cut a 4-1/2” (114mm) diameter hole for the outlet drain.
Cut a 2-1/2” (64mm) diameter hole for the water inlet.
Cut two 3/4” (19mm) diameter holes for the threaded mounting stud.
Cut a 8-7/8” (226mm) x 5-9/16” (140mm) hole for the push plate.
Dimensions are based on toilet rim height 16-1/8" (410mm)
Mark
10
ENGLISH
