Toto TBW05401 User manual

©TOTO Ltd. All rights reserved.
©
TOTO Ltd. Alle Rechte vorbehalten.
© TOTO Ltd. Todos los derechos reservados.
© TOTO Ltd. Tous droits réservés.
© TOTO Ltd. Tutti i diritti riservati.
Tel / Tél:
2019.10
0000135
Printed in Japan.
Gedruckt in Japan.
Impreso en Japón.
Imprimé au Japon.
Stampato in Giappone.
You are advised to record the following information to allow quick service.
Halten Sie bitte folgende Informationen fest, damit ein schneller Kundenservice möglich ist.
Le recomendamos que registre la siguiente información para permitir un servicio rápido.
Il est recommandé de conserver les informations suivantes pour permettre un service rapide.
Si prega di registrare i seguenti dati per accelerare gli interventi di assistenza.
Head Office
Firmensitz
Oficina principalOficina principal
Siège social
SedSede centrale
Name of shop :
Name des Verkaufsstelle:
Nombre de la tienda:
Nom du magasin :
Nome del negoziante:
Date of purchase:
Kaufdatum:
Fecha de compra:
Date d'achat :
Data di acquisto:
Date : year month day
Warranty period: 2 years from the date of purchase
Datum: Jahr Monat Tag
Gewährleistungsfrist: 2 Jahre ab dem Kaufdatum
Fecha: año mes día
Periodo de garantía: 2 años a partir de la fecha de compra
Date : année mois jour
Période de garantie: 2 ans à compter de la date d'achat
Data: anno mese giorno
Periodo di garanzia: 2 anni dalla data di acquisto
TOTO Europe GmbH
Zollhof 2, 40221 Düsseldorf Germany
Phone : [phone]
TBW05401
TBW05402
EN Operation Manual
Thermostat Shower Column (Shelf Type)
DE Bedienungshandbuch
Wandmontierte thermostatische Misch-Armatur
ES Manual de operaciones
Columna de ducha con monomando termostático
FR Mode d'emploi
Mitigeur thermostatique mural
IT Manuale operativo
Miscelatore termostatico a parete
EN
Thank you for choosing TOTO's Thermostat Shower Column (Shelf Type).
For the best performance, please read this manual carefully.
DE
Wir danken Ihnen dafür, dass Sie sich für die Wandmontierte thermostatische Misch-
Armatur von TOTO entschieden haben.
Lesen Sie bitte für beste Leistung dieses Handbuch sorgfältig durch.
ES
Gracias por haber elegido el Columna de ducha con monomando termostático TOTO .
Para obtener el mejor rendimiento, lea atentamente este manual.
FR
Nous vous remercions pour avoir choisi le Mitigeur thermostatique mural de TOTO.
Pour la meilleure performance, veuillez bien lire ce manuel.
IT
Grazie per aver scelto Miscelatore termostatico a parete della TOTO.
Per prestazioni ottimali, si raccomanda di leggere questo manuale attentamente.

1
Actions that you must NOT do are indicated as “Prohibited”.
The left gure signies that “Disassembly is Prohibited”.
Actions that you must do without fail are indicated as “Mandatory".
The left gure signies that it is “Mandatory”.
Please read the “Safety Precautions” section thoroughly to ensure safe use.
zRead this manual carefully and keep it for future reference.
zThis manual employs various symbols in order to indicate safe and proper use of the
product and to prevent injuries to people or property damage.
The symbols and meanings are as follows:

The actions you must observe are classied into the following symbols; their meanings
are explained.
Symbol Meaning
WARNING This symbol means that if the action indicated by the
symbol is ignored or mishandled, death or serious
injury may occur.
CAUTION This symbol means that if the action indicated by the
symbol is ignored or mishandled, injury or property
damage may occur.
WARNING
Prohibition
Do not use hot water at temperatures higher than 80°C.
If water hotter than 80°C is used, the water may scald you and may shorten
the life of the product or damage the product and cause leakage resulting in
water damage to property.
Do not modify the product using parts other than those
that constitute this product or by mounting other parts or
dismounting original parts.
Improper modications to the product may not perform to expectations and
may result in injuries such as scalding and cause leakage resulting in water
damage to property.
Safety Precautions
EN
Follow all precautions
carefully to ensure
safe operation.
Please read the “Safety Precautions” section thoroughly to ensure safe use.

2
WARNING
Prohibition
Do not let children use the product unattended.
Children may scald or injure themselves.
Do not place heavy things on the product
There is a risk that this may cause damage, injury or property damage due to
water leakage wetting household belongings. The weight that can be put on
the shelf is up to 10 kg.
Do not use scalding hot-water (60°C or higher) in the shower
head.
Scalding water can break the shower head cause scalding or injury.
During your shower, use a temperature lower than 45°C to ensure safety.
Disassembly
Prohibited
Do not disassemble or remodel the product in any way other than
what is described in this manual.
Improper modications may cause scalding water that can injure you and
may damage the product and cause leakage resulting in water damage to
property.
Do Not
Touch
When using hot water at high temperatures, do not directly touch
the spout and faucet main body.
The spout and faucet main body can become hot enough to scald you when
touched.
Mandatory
Check the temperature handle before turning on the water.
If you turn on the water when it is set to the hottest setting, the water may be
hot enough to scald you. When using hot water, start with cold water rst and
then adjust the water temperature slowly to the desired temperature.
After using hot water, turn on the cold water for a while.
Hot water could remain in the faucet and come out at your next use and may
scald you.

3
EN
WARNING
Mandatory
Periodically (more than twice a year) check around the piping for
water leakage and loose connections.
Parts may get damaged from deterioration and wear and may cause leakage
resulting in water damage to property or cause injuries such as scalding.
Set the cold water supply pressure higher than or equal to the
hot water supply pressure.
In order to prevent scalding due to unsafe operation, the cold water supply
pressure must be set higher than or equal to the hot water supply pressure.
If increasing pressure on the hot water side, make sure the hot water supply
pressure side is set lower than the cold water side.
Before using the hot water, be sure to check the temperature with
your hands.
There is a risk that hot water at a high temperature may come out and
you may get burned. Also, please note that the temperature may rise after
you switch between spout and shower or change the state of the shower
discharge.
Before using, check the water discharge mode and then press
the Open/Close button.
If you make a mistake, then you might suddenly be splashed with water or get
burned.
After using hot water at a high temperature, be sure to return the
safety button on the temperature control handle back to “40” or less.
This is because there is a risk that when you use it next time, hot water at a
high temperature may suddenly come out and burn you.
Turn the temperature control handle slowly.
Turning the temperature control handle suddenly may result in a sudden rise
in temperature and there is a risk that you may get burned.
When cleaning the lter, be sure to close the stopcock to the
piping before loosening the lid. Also, check that the hot water
side stop valve part is not hot. (See page 31)
Hot water at a high temperature may come out and scald you or cause
damage to your property due to water leakage.

4
WARNING
Mandatory
Pay careful attention when adjusting the ow rate on the hot
water side.
There is a risk that hot water at a high temperature may come out and you
may get burned.
If freezing has occurred, set the safety button of the temperature
control handle to “40” and check if it matches the discharge
temperature.
When there is freezing, there is a risk that the set temperature may shift and
you may get burned.
CAUTION
Prohibition
Do not subject the product to strong force or impact.
Strong forces or impacts may damage the product and cause leakage
resulting in water damage to property.
Do not ignore abnormally loose parts.
If abnormally loose parts are ignored, parts may break or plated surfaces
may crack and cause personal injury. If you detect any damaged parts or
cracked plated surfaces, immediately call for repair or replacement.
Do not strike or use the plated parts with undue force.
The plated surface may crack and injure you. If the plated surface cracks,
immediately ask for repair.
Do not use cleaning agents other than neutral detergent.
(See page 32)
If you use cleaning agents other than neutral detergent, they may discolor or
damage the faucet.
Do not submerge the showerhead in the bathtub or washbowl
and do not wash the showerhead by soaking it in detergent.
If you submerge the showerhead in the water, debris, hair and detergent
in the water will enter the shower head and may clog it so that it cannot
function.
