This Installation Guide describes the hardware characteristics, installation methods and
the points that should be attended to during installation.
This Installation Guide is structured as follows:
Chapter 1 Introduction. This chapter describes the external components of the
Switch.
Chapter 2 Installation. This chapter illustrates how to install the Switch.
Chapter 3 Lightning Protection. This chapter illustrates how to prevent lightning
damage.
Chapter 4 Connection. This chapter illustrates how to do the physical connection of
the Switch.
Chapter 5 Configuration. This chapter instructs you to configure the Switch via Web
Interface and CLI commands.
Appendix A Troubleshooting.
Appendix B Hardware Specifications.
Appendix C Technical Support.

III

This Installation Guide is for:
Network Engineer
Network Administrator

Due to the similarity in structure of the L2 managed Switch series, in this Installation
Guide we take TL-SL3428 as an example to illustrate Chapter 2 Installation, Chapter 3
Lighting Protection, Chapter 4 Connection and Chapter 5 Configuration.
This guide uses the specific formats to highlight special messages. The following table
lists the notice icons that are used throughout this guide.
Remind to be careful. A caution indicates a potential which may
result in device damage.
Remind to take notice. The note contains the helpful
information for a better use of the product.
Audience

IV

Contents
Chapter 1 Introduction ———————————— 01
1.1 Product Overview.........................................01
1.2 Appearance .................................................01
Chapter 2 Installation ————————————— 04
2.1 Package Contents.........................................04
2.2 Safety Precautions........................................04
2.3 Installation Tools..........................................06
2.4 Product Installation ......................................06
Chapter 3 Lightning Protection ———————— 08
3.1 Cabling Reasonably ......................................08
3.2 Connect to Ground .......................................10
3.3 Equipotential Bonding...................................11
3.4 Use Lightning Arrester ..................................12
Chapter 4 Connection ————————————— 13
4.1 Ethernet Port ...............................................13
4.2 SFP Port ......................................................13
4.3 Console Port ................................................14
4.4 Verify Installation .........................................14
4.5 Power On ..................................................14
4.6 Initialization.................................................15
Chapter 5 Conguration———————————— 16
5.1 Congure the Switch via GUI ........................16
5.2 Congure the Switch Using CLI .....................17
Appendix A Troubleshooting—————————— 22
Appendix B Hardware Specications —————— 23
Appendix C Technical Support ————————— 24

01
L2 Managed Switch


TP-LINK JetStreamTM L2 Managed Switch, designed for workgroups and departments,
provides wire-speed performance and abundant layer 2 management features. It
provides a variety of service features and multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible
solutions for a variable scale of networks. ACL, 802.1x and Dynamic ARP Inspection
provide robust security strategies. QoS and IGMP snooping/filtering optimize voice and
video application. Link aggregation (LACP) increases aggregated bandwidth, optimizing
the transport of business critical data. SNMP, RMON, WEB/CLI/Telnet Log-in bring
abundant management policies. TP-LINK JetStreamTM L2 Managed Switch integrates
multiple functions with excellent performance, and is friendly to manage, which can
fully meet the need of the users demanding higher networking performance.

Front Panel
■
The front panel of TL-SL3428 is shown as the following figure.
Front Panel of TL-SL3428Figure 1-1
The front panel of TL-SL3452 is shown as the following figure.
Front Panel of TL-SL3452Figure 1-2
Introduction
L2 Managed Switch
TL-SL3428
LEDs
Console Port
10/100/1000Mbps RJ45 Port
SFP Port
10/100Mbps RJ45 Port
49
30 32 34 36 38 40 42 44 46 48
246810 12 14 16 18 20 22 24 26 28 29 31 33
35 37 39 41 43 45 47 25 271 3579
11 13 15 17 19 21 23
Console
PWR
SYS
50
49
50
51
52
51 52
5-4-
100Mbps
10Mbps
1000Mbps
10/100Mbps
1000Base-X
LEDs
Console Port
10/100/1000Mbps RJ45 Port
SFP Port
10/100Mbps RJ45 Port

02
L2 Managed Switch
LEDs
LED Status Indication
PWR
On The Switch is powered on
Off The Switch is powered off or power supply is abnormal
Flashing Power supply is abnormal
SYS Flashing The Switch works properly
On/Off The Switch works improperly
10/100Mbps
On A device is linked to the corresponding port, but no activity
Flashing Data is being transmitted or received
Green A 100Mbps device is connected to the corresponding port
Yellow A 10Mbps device is connected to the corresponding port
Off No device is connected to the corresponding port
1000Mbps
On A device is linked to the corresponding port, but no activity
Flashing Data is being transmitted or received
Green A 1000Mbps device is connected to the corresponding port
Yellow A 10/100Mbps device is connected to the corresponding port
Off No device is connected to the corresponding port
Note: TL-SL3428 features some “Combo”ports. A “Combo”port consists of a RJ45
port and a SFP port, and the two ports share the same LED.
Port Feature
Model 10/100Mbps RJ45
Port
10/100/1000Mbps
RJ45 Port SFP Port Console Port
TL-SL3428 24 4 2 1
TL-SL3452 48 2 2 1
10/100Mbps Port
Designed to connect to the device with a bandwidth of 10Mbps or 100Mbps. Each
has a corresponding 10/100Mbps LED.
10/100/1000Mbps Port
Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or
1000Mbps. Each has a corresponding 1000Mbps LED.
SFP Port
Designed to install the SFP module.
TL-SL3428 features some SFP transceiver slots that are shared with the associated
RJ45 ports. The associated two ports are referred as a “Combo” port, which means
they cannot be used simultaneously, otherwise only SFP port works.
Console Port
Designed to connect with the serial port of a computer or terminal for monitoring
and configuring the Switch.
Introduction

03
L2 Managed Switch
Note:
For TL-SL3428, when using the SFP port with a 100Mbps module or a gigabit module,
■
you need log on to the GUI (Graphical User Interface) of the Switch and configure its
corresponding Speed and Duplex mode on Switching→Port→Port Config page.
For 100Mbps module, please select 100MFD while select 1000MFD for gigabit module.
By default, the Speed and Duplex mode of SFP port is 1000MFD.
For TL-SL3452, the SFP port can be only used with a gigabit module.
■
Rear Panel
■
The rear panel of TL-SL3428 is shown as the following figure.
Grounding Terminal
Power Socket
Rear Panel of TL-SFigure 1-3 L3428
The rear panel of TL-SL3452 is shown as the following figure.
Grounding Terminal
Power Socket
Rear Panel of TL-SL3452Figure 1-4
Grounding Terminal
The Switch already comes with lightning protection mechanism. You can also ground
the Switch through the PE (Protecting Earth) cable of AC cord or with Ground Cable.
For detailed information, please refer to Chapter 3 Lightning Protection.
Power Socket
Connect the female connector of the power cord here, and the male connector to
the AC power outlet. Please make sure the voltage of the power supply meets the
requirement of the input voltage (100-240V~ 50/60Hz).
Caution: Please use the provided power cord.
Introduction

04
L2 Managed Switch


Make sure that the package contains the following items. If any of the listed items is
damaged or missing, please contact your distributor.
One Resource CD
One Switch One Power Cord, one Console
Cable and one Ground Cable
This Installation Guide
Two mounting brackets and
the ttings
L2Managed Swi tch
TL-SL3428

To avoid any device damage and bodily injury caused by improper use, please observe
the following rules.
Safety Precautions
■
Keep the power off during the installation.
■
Wear an ESD-preventive wrist strap, and make sure that the wrist strap has a good
■
skin contact and is well grounded.
Use only the power cord provided with the Switch.
■
Make sure that the supply voltage matches the specifications indicated on the rear
■
panel of the Switch.
Ensure the vent hole is well ventilated and unblocked.
■
Do not open or remove the cover of the Switch.
■
Before cleaning the device, cut off the power supply. Do not clean it by the waterish
■
cloth, and never use any other liquid cleaning method.
Site Requirements
■
To ensure normal operation and long service life of the device, please install it in an
environment that meets the requirements described in the following subsection.
Temperature/Humidity
ȭ
ȭ
L2Managed Switc h
TL-SL3428
Installation

05
L2 Managed Switch
Please keep a proper temperature and humidity in the equipment room. Too high/low
humidity may lead to bad insulation, electricity leakage, mechanical property changes
and corrosions. Too high temperature may accelerate aging of the insulation materials
and can thus significantly shorten the service life of the device. For normal temperature
and humidity of the device, please check the following table.
Environment Temperature Humidity
Operating 0℃~ 40℃10% ~ 90%RH Non-condensing
Storage -40℃~ 70℃5% ~ 90%RH Non-condensing
Clearness
L2 Managed Switch
TL-SL3428
The dust accumulated on the Switch can be absorbed by static electricity and result
in poor contact of metal contact points. Some measures have been taken for the
device to prevent static electricity, but too strong static electricity can cause deadly
damage to the electronic elements on the internal circuit board. To avoid the effect of
static electricity on the operation of the Switch, please attach much importance to the
following items:
Dust the device regularly, and keep the indoor air clean.
■
Keep the device well grounded and ensure static electricity has been transferred.
■
Electromagnetic Interference
L2 Managed Switch
TL-SL3428
Electronic elements including capacitance and inductance on the device can be affected
by external interferences, such as conducted emission by capacitance coupling,
inductance coupling, and impedance coupling. To decrease the interferences, please
make sure to take the following measures:
Use the power supply that can effectively filter interference from the power grid.
■
Keep the device far from high-frequency, strong-current devices, such as radio
■
transmitting station.
Use electromagnetic shielding when necessary.
■
Lightening Protection
L2 Managed Switch
TL-SL3428
Extremely high voltage currents can be produced instantly when lightning occurs and
the air in the electric discharge path can be instantly heated up to 20,000℃. As this
instant current is strong enough to damage electronic devices, more effective lightning
Installation

06
L2 Managed Switch
protection measures should be taken.
Ensure the rack and device are well earthed.
■
Make sure the power socket has a good contact with the ground.
■
Keep a reasonable cabling system and avoid induced lightning.
■
Use the signal SPD (Surge Protective Device) when wiring outdoor.
■
Note: For detailed lightning protection measures, please refer to Chapter 3
Lightning Protection.
Installation Site
S
L2 Lite Managed Switch
TL-SL3428
L2 Managed Switch
TL-SL3428
When installing the device on a rack or a flat workbench, please note the following
items:
The rack or workbench is flat and stable, and sturdy enough to support the weight of
■
5.5kg at least.
The rack or workbench has a good ventilation system. The equipment room is well
■
ventilated.
The rack is well grounded. Keep the power socket less than 1.5 meters away from the
■
device.

Phillips screwdriver
■
ESD-preventive wrist wrap
■
C a b l e s
■
Note: These tools are not provided with our product. If needed, please self purchase
them.

Desktop Installation
■
To install the device on the desktop, please follow the steps below:
Set the device on a flat surface strong enough to support the entire weight of the1.
device with all fittings.
Remove the adhesive backing papers from the rubber feet.2.
Installation

07
L2 Managed Switch
Turnover the device and attach the supplied rubber feet to the recessed areas on3.
the bottom at each corner of the device.
L2 Managed Switch
TL-SL3428
Feet
Bottom of the
Device
Notch
Desktop InstallationFigure 2-1
Rack Installation
■
To install the device in an EIA standard-sized, 19-inch rack, follow the instructions
described below:
Check the grounding and stability of the rack.1.
Secure the supplied rack-mounting brackets to each side of the device with supplied2.
screws, as illustrated in the following figure.
L2 Managed Switch
TL-SL3428
Rack-
mounting
Bracket
Screw
Bracket InstallationFigure 2-2
After the brackets are attached to the device, use suitable screws (not provided) to3.
secure the brackets to the rack, as illustrated in the following figure.
L2 Managed Switch
TL-SL3428
Rack
Rack InstallationFigure 2-3
Caution:
Please set 5~10cm gaps around the device for air circulation.
■
Please avoid any heavy thing placed on the device.
■
Please mount devices in sequence from the bottom to top of the rack and ensure a
■
certain clearance between devices for the purpose of heat dissipation.
Installation

08
L2 Managed Switch


In the actual network environment, you may need cable outdoors and indoors, and
the requirements for cabling outdoors and indoors are different. A reasonable cabling
system can decrease the damage of induced lightning to devices.
Note: It’s not recommended using Ethernet cables outdoors. When cabling outdoors,
please use a signal lightning arrester.
Requirements for Cabling Outdoors
■
Aerial cabling without safeguard is not allowed.
■
It’s not allowed cabling down the building to connect network devices in different
■
floors.
Outdoor cables should be buried and paved to the indoor through basement. A piece
■
of steel wire should be paved underground along the pipe and connected to the
lightning protection terminal of the building for shielding. Before connecting the cable
to the device, install a signal lightning arrester on the corresponding port.
When an aerial cable is set up, the cable should be through a metal pipe (15m long
■
at least) before coming into the building. The two ends of this metal pipe should be
grounded. Before connecting the cable to the device, install a signal lightning arrester
on the corresponding port.
It’s not necessary to pave STP cables through pipes. The shielded layer of STP cable
■
should be well grounded. Before connecting the cable to the device, install a signal
lightning arrester on the corresponding port.
Requirements for Cabling Indoors
■
When cabling indoors, keep a certain distance away from the devices that may cause
high-frequency interferences, such as down-conductor cable, powerline, power
transformer and electromotor.
The main cable should be paved in the metal raceway of the access shaft. When
■
cabling, keep the loop area formed by the cable itself as small as possible.
Lightning Protection

09
L2 Managed Switch
Requirements for the distance between Ethernet cable and other pipelines are shown
■
in the table.
Other Pipelines
Ethernet Cable
Min Parallel Net Length
L (mm)
Min Parallel-overlapping Net Height
H (mm)
Down-conductor 1000 300
PE 50 20
Service pipe 150 20
Compressed air pipe 150 20
Thermal pipe (not wrapped) 500 500
Thermal pipe (wrapped) 300 300
Gas pipe 300 20
The two diagrams below demonstrate parallel net length and parallel-overlapping net
height.
Note: The above minimum net length/height is required when metal raceway is not
used. If any requirements cannot be met, you can add a steel tube or metal raceway
for shielding.
Requirements for the distance between Ethernet cable and high-power electric
■
devices are in following tables.
Cable Pave Way Min Parallel
Length (mm)
<2kVA
powerline
Parallel cabling 130
One is in the grounded metal raceway or metal pipe 70
The both are in the grounded metal raceway or metal pipe 10
2~5kVA
powerline
Parallel cabling 300
One is in the grounded metal raceway or metal pipe 150
The both are in the grounded metal raceway or metal pipe 80
>5kVA
powerline
Parallel cabling 600
One is in the grounded metal raceway or metal pipe 300
The both are in the grounded metal raceway or metal pipe 150
Device Min Distance (m)
Switch case 1.00
Transformer room 2.00
Elevator tower 2.00
Air-conditioner room 2.00
Lightning Protection

10
L2 Managed Switch

Connecting the device to ground is to quickly release the lightning over-voltage and
over-current of the device, which is also a necessary measure to protect the body from
electric shock.
In different environments, the device may be grounded differently. The following
will instruct you to connect the device to the ground in two ways, connecting to the
grounding bar or connecting to the ground via the power cord. Please connect the
device to ground in the optimum way according to your specific operation environment.
Connecting to the Grounding Bar
■
If the device is installed in the Equipment Room, where a grounding bar is available,
you are recommended to connect the device to the Grounding Bar as shown in the
following figure.
Switch (Rear Panel)
Ground Cable
Grounding Te rminal
Grounding Bar
Connecting to the Grounding BarFigure 3-1
Note: The grounding bar is not provided with our product. If needed, please self
purchase it.
Connecting to the Ground via the Power Supply
■
If the device is installed in the normal environment, the device can be grounded via the
PE (Protecting Earth) cable of the AC power supply as shown in the following figure.
Connecting to the GroundFigure 3-2
Lightning Protection

11
L2 Managed Switch
Note:
The figure is to illustrate the application and principle. The power cord you get from
■
the package and the socket in your situation will comply with the regulation in your
country, so they may differ from the figure above.
If you intend to connect the device to the ground via the PE (Protecting Earth) cable
■
of AC power cord, please make sure the PE (Protecting Earth) cable in the electrical
outlet is well grounded in advance.

Equipotential Bonding is the practice of intentionally electrically connecting all earthed
systems to the same grounding grid or connecting the grounding grids of all the
earthed systems together through the ground or overground metal so as to create
an earthed equipotential zone. When lightning occurs, the high voltage produced by
lightning current in all systems will meanwhile exist in their ground cables, and thus
all ground cables have the same electrical potential and basically eliminate the electric
strikes between the systems.
The figure below illustrates how to practice equipotential bonding in a network.
Grounding T e rminal Equipotential Bonding Cable
Grounding BarGround Cable
Equipotential BondingFigure 3-3
When equipotential bonding, please note that the cable should be copper wrapped Kelly
with its area being 6mm2at least. The shorter cable the better, and use a grounding
bar to establish an equipotential bonding point.
Note: The equipotential bonding cable is not provided with our product. If needed,
please self purchase it.
Lightning Protection

12
L2 Managed Switch

Power lightning arrester and signal lightning arrester are used for lighting protection.
Power lightning arrester is used for limiting the voltage surge due to a lightning. If an
outdoor AC power cord should be directly connected to the device, please use a power
lightning arrester.
Note: Power lightning arrester is not provided with our product. If needed, please self
purchase it.
Signal lightning arrester is used to protect RJ45 ports of the device from lightning.
When cabling outdoors, please install a signal lightning arrester before connecting the
cable to the device.
When purchasing or using a signal lightning arrester, please observe the following
rules:
The port rate of the signal lightning arrester should match the rate of the desired port
■
on the device. If it is not matched, this signal lighting arrester will not work. Purchase
a standard lightning arrester.
Install signal lightning arrester near the protected device and connect it to the
■
ground via a shorter ground cable.
Ethernet CableEquipotential Bonding CableGrounding T e rminal
Signal Lightning Arrester Device
L2 Managed Switch
TL-SL3428
Lightning Arrester ConnectionFigure 3-4
Note: Signal lightning arrester is not provided with our product. If needed, please self
purchase it.
Lightning Protection

13
L2 Managed Switch
Connection


Connect the Ethernet ports of the Switch to the network devices by RJ45 cable as the
following figure shown.
L2 Managed Switch
TL-SL3428
RJ45 Cable
RJ45 Port
Connecting the RJ45 PortFigure 4-1

Connect the SFP port to a SFP module.
For TL-SL3428, if an SFP transceiver (purchased separately) is installed in a slot and has
a valid link on the port, the associated RJ45 port will be disabled and cannot be used.
L2 Managed Switch
TL-SL3428
SFP Port
Inserting the SFP ModuleFigure 4-2
Note:
TL-SL3428 supports 100/1000Base-FX SFP module at full-duplex mode. When
■
using a SFP module, you need log on to the GUI of the Switch and configure the
corresponding Speed and Duplex mode on Switching→Port→Port Config page.
TL-SL3452 only supports 1000Base-X SFP module at full-duplex mode.
■
SFP Module

14
L2 Managed Switch
Connection

CLI (Command Line Interface) enables you to manage the Switch, thus you can load
the CLI after connecting the PCs or Terminals to the console port on the Switch via the
provided cable.
Connect the console port of the device with your computer by the console cable as the
following figure shown.
L2Managed Switch
TL-SL3428
Connecting the Console PortFigure 4-3
You can also manage the device through the console port, for details please refer to the
CLI Reference Guide on the resource CD.
Note:
The console port is the first port on the right of the front panel.
■
Please keep the device power off when plugging the console cable.
■
Do not connect the console port with other ports by RJ45 cable.
■

After completing the installation, please verify the following items:
There are 5~10cm of clearance around the sides of the device for ventilation and the
■
air flow is adequate.
The voltage of the power supply meets the requirement of the input voltage of the
■
device.
The power socket, device and rack are well grounded.
■
The device is correctly connected to other network devices.
■

Plug the female connector of the provided power cord into the power socket of the
device, and the male connector into a power outlet as the following figure shown.

15
L2 Managed Switch
Connecting to Power SupplyFigure 4-4
Note: The gure is to illustrate the application and principle. The power cord you get
from the package and the socket in your situation will comply with the regulation in
your country, so they may differ from the gure above.

After the device is powered on, it begins the Power-On Self-Test. A series of tests
run automatically to ensure the device functions properly. During this time, its LED
indicators will respond as follows.
The Power LED indicator will light on all the time.
■
After keeping off for several seconds, the LED indicators of all the ports will light up
■
momentarily and then turn off again after the initialization.
The System LED indicator will flash, which represents a successful initialization.
■
Connection
