GREAT Things Come in Small Packages:
• Low cost with smallest hybrid footprint
• FAST Monochrome or ColorPOS®Two-Color thermal receipt
• Drop validation impact print station with superior paper handling
• Built in MICR reader
• Imaging Module option available
• Multiple communication interfaces
The Next Evolution in Teller
Validation/Receipt Printers
From the company that brought you the first
thermal/impact hybrid transaction printer with
integrated MICR, and the first clam shell drop-in
paper loading design. TPG announces another
first – the model B780 offers the market the
first fully featured two-color/monochrome hybrid
printer with a footprint under 72.8 sq. in.
Performance in a
Small Package!
TPG’s B780 printer has been designed for maximum
flexibility, performance, reliability, and lowest cost. It
opens a new world of possibilities in banking with its lightning
fast (200 mm/s) thermal receipt station. The B780 printer is capable
of printing watermarks, logos, coupons and other “attention grabbing”
features on monochrome or two-color thermal paper. Using TPG’s innovative and
industry leading ColorPOS technology and ReceiptWare™ Receipt Marketing Software,
the B780 is sure to deliver your message every time.
Premier Technology
Still need to print on forms and validate checks? The B780 impact slip station allows drop-
in validation with top, front or side insertion of checks or other forms. It also reads MICR
information from checks, general ledger tickets, etc.
But, it doesn’t end there. The B780 offers a paper low indicator and exhaust sensor, a positive
slip position sensor and indicator, multiple resident emulations, and it is available with
several popular communications interfaces, including USB. The B780’s ribbon cassette has
been designed for a snap-on/ snap-off, “clean fingers” installation and can be used with any
new or recycled bond paper.
Simply Reliable
No preventative maintenance is required during regular work cycles. The B780’s industry
leading design is backed by a 2-Year warranty.
B780
Check Imaging Hybrid
Two-Color Hybrid Receipt/Validation Printer with Slip Station,
Integrated MICR, and Upgradable Imaging Module
Teller Printing Application
Receipt Marketing Application
With Upgradable Imaging Module

Transaction Printer Group – Headquarters, 25 Tri-State International, Suite 200, Lincolnshire, IL 60069 • Tel: [phone] • 847 383 7900 Fax: [phone] • www.TPGprinters.com
©2006 Transaction Printer Group (TPG). All Rights Reserved. Patents pending. All trademarks or registered trademarks are the property of their respective owners.
Printed in U.S.A. Product specifications are subject to change in order for TPG to continue to meet the needs of the market.
Distributed by:
105-304-01 8/07
Imaging Capability
TPG’s B780 two-color/monochrome hybrid thermal/impact receipt
printer is designed with imaging in mind. The innovative imaging
module is designed as an upgrade kit. You can add imaging capability
anytime you like.
This imaging module is field upgradable (the printer does not need to
be shipped out for an upgrade) by a certified technician.
Check 21 Compliant:
• One pass scans both sides of the check
• Archives check images in printer memory
• Optimized to handle wrinkled and folded checks
Scans laminated ID cards
TPG's B780 Hybrid printer has an upgradable Imaging Module option.
The Imaging Module allows you to scan checks and ID's right at the
point-of-sale. The option can be purchased as a field upgrade or as a
standard option.
Multiple Communication Interfaces:
Serial, USB, and Ethernet.
Harsh Environment
With the Harsh Environment kit, you can expect the same technical
specifications as the standard printer. The only difference – the
printer is ready for your harsh conditions.
Check Imaging Hybrid
B780
Technical Specifications
Receipt Station Slip Station
Print Method Direct Thermal, 203 DPI 9-Pin Impact
Character Cell Size 13 X 24, 10 X 24 7 X 7, 12 X 7, 5 X 9
CPI 15, 6, 20.3 13.9 & 16.8
Print Columns 44 & 56 42 & 51
Print Line Width 2.8 in. (72 mm) 3.02 in. (76.8 mm)
Character Sets Page 437, 737, 850, 852, 858 (with Eurosymbol), 860, 862, 863,
865, 866, and 1252. Contact your TPG representative for expanded
character sets.
Bar Codes UPC-A, UPC-E, Code 39, Code 93, Code 128, JAN8 and JAN13
(EAN), Interleaved 2 of 5, Codabar, PDF 417 (receipt station only)
Printing Speed Monochrome 56.3 LPS (200 mm/s) 4.8 LPS (16 mm/s)
Two-color 27 LPS (100 mm/s)
Auto Cutter Partial Cut
Emulations Available Application compatible escape commands, TPG A756/A758,
ColorPOS
Data Buffer 8K
User Memory 2 to 8 MB: shared for graphics, logos, user defined characters
and user data storage
Communication Board Architecture supports:
Dual 9-Pin RS-232/USB, 25-pin RS-232, Ethernet, USB, and
Powered USB
MICR Reader:
Character sets/fonts E-13B and CMC-7, auto discriminate (Integrated in slip station)
Check Read Rate 99% minimum
Parsing Formats E-13B only. Programmable to any format
Thermal Paper Requirements:
Paper Type Direct Thermal, POS Grade(s), special paper for color printing
Paper Roll (W X Dia.) 3.15 in. X 3.27 in. (80 mm X 83 mm)
Impact Slip Forms:
Size 2.75 in. X 5.00 in. (69.85 mm x 127.00 mm) minimum front & side
Max. Form Length 11.00 in. (279.4 mm)
Number of Plies 1 - 4 ply multipart
Paper Thickness 0.014 in. maximum (0.35 mm)
Power 24 VDC
Certifications EMC emissions: EN55022:1998 Class B ITE emission requirements
(EU); FCC 47 CFR Part 15, Class B emissions requirements (USA),
VCCI Class B ITE emissions requirements (Japan); AS/NZS
3548:2002/CISPR22 Class B ITE emission requirements (Australia);
EMC Immunity: EN55024:1998/A1:2001 Information technology
equipment (EU)
Reliability Thermal Print Mechanism - 200 KM paper (59 M lines)
monochrome, 200 KM
two-color (53 M lines), Auto Knife Cutter - 1.5 M cuts, Impact Print
Mechanism - 15 M lines, Impact Printhead - 200 M characters, and
MICR reader - 200,000 Reads
Dimensions (W X D X H) 6.5 in. X 11.4 in. X 6.6 in. (165.10 mm X 289.56 mm X 167.64 mm)
Weight Approximately 8 lbs., depending on options
Options MICR Reader, Expanded flash memory
Printer Drivers OLE POS for Windows compatible and Windows/Windows NT and
Windows 2000, Java POS, USB, and Powered USB
* TPG’s native mode
6.5"
11.4"
6.6"
www.colorpos.com
Two-Color Hybrid Receipt/Validation Printer with Slip Station,
Integrated MICR, and Upgradable Imaging Module
