Tracmaster BCS615L Instruction Manual

No liability will be accepted for any damage
caused to persons or property through failure
to observe the operating and safety instructions.
CRUSADER
POWER SCYTHES
Tracmaster Ltd, Teknol House, Victoria Road, Burgess Hill RH15 9LH
Tel: [phone] Fax: [phone]
Website: www.tracmaster.co.uk E-mail: [e-mail]
© Tracmaster Ltd 2008.
Specifications are subject to change without prior notice.
OP/PS/615L-630/0208
BCS
Wheel speed lever
Throttle lever
Locking
clip
Clutch
lever
Cutter
drive lever
Fuel tap
Choke lever
Grease nipple
Grease nipple (remove rubber bung)
Height adjustment skids
BCS615L/620/630
VIBRATION & SOUND LEVELS
Machine Cutter Bar RPM Vibration
2
m/sec - 3 Axis Level dB(A)
BCS 615L Power Scythe 40” (100cm) 2000 8.0 88.0
BCS 620 Power Scythe 40” (100cm) 2000 8.0 88.0
BCS 620 Power Scythe 44” (115cm) 2000 9.3 88.0
BCS 630 Power Scythe 40” (100cm) 2000 6.8 91.0
BCS 630 Power Scythe 44” (115cm) 2000 7.1 91.0
Sound
OPERATING
INSTRUCTIONS
&
SAFETY NOTES
WEAR EAR
PROTECTION
WEAR SAFETY
FOOTWEAR
WEAR EYE
PROTECTION
READ CAREFULLY
IMPORTANT
Engine stop lever
Forward/reverse lever

S A F E T Y
TO START ENGINE
ALWAYS start the engine in the open air
DO NOT smoke when refuelling
DO NOT mix OIL with the fuel
ALWAYS stop the engine before making any adjustments,
refuelling, moving or cleaning, or when the unit is
unattended
USE ONLY unleaded petrol from fuel containers designed for
this purpose - refuel outdoors only and replace the tank cap
securely
IN CASE of petrol spillage move the machines away from the
area of spillage and allow the petrol vapours to dissipate
before starting the engine
DO NOT remove any safety guards that are fitted
DO NOT touch any moving parts or attempt any maintenance
whilst the machine is running - KEEP HANDS AND FEET
AWAY
BEFORE starting work clear the work area of any objects that
could damage the machine
DO NOT allow children or anyone uninstructed to operate the
machine - KEEP ANIMALS AWAY
o
DO NOT use on slopes or banks of more than 20
ALWAYS wear suitable clothing to give personal protection
including footwear that offers a good grip
AVOID wearing loose garments that may catch in moving parts
KNOW how to stop the machine in an emergency
NEVER interfere with any control settings on the engine
NEVER select reverse gear with your back to a wall or other
immovable object
IF A FAULT develops DO NOT attempt any repair - immediately
contact the supplier from whom the machine was obtained
VISUALLY INSPECT the machine before use - ensure all teeth,
nuts and bolts are tight and not worn or damaged and
replace teeth if necessary
KEEP IN MIND the operator is responsible for accidents or
hazards occurring to people or property
Check the engine oil level. Top up with 10w/40 oil if necessary.
Check fuel level. Only use unleaded petrol from a clean container.
Never re-fuel when the engine is hot or running. Leave 1” air space in
the fuel tank.
Depress the engine stop lever (the red lever on the left handlebar)
then pull up the clutch lever and secure with locking clip.
Ensure the wheel speed lever is in neutral ‘O’ position.
Apply half throttle (the lever on the right handlebar).
Turn the fuel tap to ‘ON’ position, if the engine is cold set the choke
lever to ‘ON’ position.
Pull the recoil start handle gently until it engages then give it a good
strong pull to start the engine.
When the engine has started, release the choke lever after a few
seconds and return the throttle lever to idle position.
OPERATION
TO STOP ENGINE
OPERATING HINTS
MAINTENANCE GUIDE
Use handlebar adjuster to set handlebar height.
Pull up clutch lever (located on left handlebar). This will automatically
release stop lever locking clip.
Ensure the red forward/reverse lever is in the forward position.
st
Select 1 gear by using the wheel speed lever.
Engage the cutter bar by using the cutter bar drive lever.
Raise the throttle slightly, release the clutch lever gently and fully,
keeping the red engine stop lever depressed as engine will stop if
released.
Commence work.
Close the throttle.
Pull up the clutch lever.
Locate the wheel speed lever in neutral position.
Disengage drive to the cutter bar.
Release clutch lever.
Release engine stop lever completely.
WARNING: THE EXHAUST COVER MAY BE HOT - DO NOT
TOUCH
After every hour of operation stop the engine and remove the spark
plug cap. Check engine oil level (recommended oil SAE 10w/40).
Wash down and re-oil the sliding parts after each day of use.
Lubricate grease nipples every day (where fitted).
Use an old paintbrush to smear grease over the cutter blades.
Replace the spark plug cap.
Do not turn the machine on its side for cleaning.
When the machine is not in use always leave the clutch lever pulled in
and secured with locking clip.
NEVER USE MORE THAN ¼
THROTTLE WHEN THE BAR
IS OPERATING
Best results are obtained with the engine at a low throttle setting,
which enables the bar to cut cleanly and gives less wear and tear on
the reciprocating parts, which in turn reduces maintenance.
NB: If you are working on a slope, always work across the slope -
never up or down.
On rough terrain, the bar should be raised by the height adjuster skids
to prevent the blades from digging into the ground.
Always wear gloves.
WARNING: If any abnormal vibrations or sounds occur, STOP the
engine immediately and check the machine and the cutter bar. If you
have any concerns contact your supplier.
For engine maintenance please refer to engine manufacturers
manual.
