Tradinco TRAQC-2 Series User manual

TRAQC-2 PC
Portable pressure calibrator
with a pressure control valve
User manual

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 2 van 15
Content
1. General.....................................................................................................................................................................3
1.1 Introduction....................................................................................................................................................3
1.2 Warranty.........................................................................................................................................................3
1.3 Service of Tradinco Instruments.....................................................................................................................4
1.4 Calibration services.........................................................................................................................................4
1.5 Accreditation ..................................................................................................................................................4
1.6 Packaging for shipment ..................................................................................................................................4
2. Safety symbols, notices and warnings .....................................................................................................................5
2.1 Responsible use of the Traqc-2 PC .................................................................................................................5
2.2 General safety instructions.............................................................................................................................5
2.3 Warnings and caution notices ........................................................................................................................5
3. About the Traqc-2 PC ...............................................................................................................................................7
3.1 Functions of the Traqc-2 PC............................................................................................................................7
3.2 Terms of use ...................................................................................................................................................7
Control panel and layout............................................................................................................................7
Display terms..............................................................................................................................................8
Terms of the manual ..................................................................................................................................8
3.3 A closer look at the instrument ......................................................................................................................8
4. Operation of the Traqc-2 PC ....................................................................................................................................9
4.1 On/off switch..................................................................................................................................................9
4.2 Zero/unit switch .............................................................................................................................................9
4.3 Display ..........................................................................................................................................................10
4.4 Two-way switch ............................................................................................................................................10
5. Using the Traqc-2 ...................................................................................................................................................11
5.1 Applying supply pressure to the UUT ...........................................................................................................11
5.2 Performing a comparative measurement ....................................................................................................11
5.3 Performing a leak test ..................................................................................................................................11
5.4 Measuring external pressure........................................................................................................................11
5.5 Charging the battery.....................................................................................................................................11
6. Maintenance ..........................................................................................................................................................12
6.1 Maintenance.................................................................................................................................................12
6.2 Calibration ....................................................................................................................................................12
7. Specifications .........................................................................................................................................................13
8. Declaration of conformity ......................................................................................................................................14

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 3 van 15
1. General
1.1 Introduction
The Traqc-2 PC is a portable calibration instrument to perform calibrations on site:
•by reducing pressure from an external circuit, by means of a connected pressure supply (max. 10 bar). After this,
the applied pressure can be read on the display.
•by directly measuring the pressure of a connected external circuit (max. 10 bar).
Also a leak test can be performed with the Traqc-2 PC. The built-in pressure cell has been calibrated to confirm that
the measured value is within the accuracy described in the specifications.
1.2 Warranty
During the design and manufacturing of this instrument the at most attention has been given to quality and
durability. This manual contains information needed for the safe and effective use of the capabilities of the
instrument.
Please read the manual carefully before operating the instrument. By doing so, possible damage to the instrument
or damage caused by incorrect use of the instrument can be avoided. Tradinco Instruments warrantees the
instrument in accordance with the Standard Terms and Conditions 2020 of the Instrument Trade as issued by the
Association bearing the name "Federation Het Instrument" (The Instrument Federation, filed with the Chamber of
Commerce of Gooi-, Eem- and Flevoland under number 4050754. You can find and download a copy of the terms
and conditions from our website https://tradinco.com/.
Tradinco Instruments warrantees that this product will be free from defects in materials and workmanship for a
period of 1 year from the date of shipment. If any such product proves defective during this warranty period,
Tradinco Instruments, at its option, will either repair the defective product without charge for parts or labor, or will
provide a replacement in exchange for the defective product.
In order to obtain service under this warranty, the customer must notify Tradinco Instruments of the defect before
the expiration of the warranty period and make suitable arrangements for the performance of the service.
The customer is responsible for packaging and shipping of the defective product to the service center designated by
Tradinco Instruments, with shipping charges prepaid. If no defect can be found Customer may be charged for costs
of the investigation. This warranty does not apply to any defect, failure or damage caused by:
•Improper use of the instrument;
•Battery leakage;
•Normal wear of the product;
•Modification or repair carried out by or on behalf of the owner or by a third party;
•Implementation of modifications to the product that are not supplied or implemented by Tradinco Instruments.
Tradinco Instruments and its vendors will not be liable for any indirect, special, incidental or consequential damages
irrespective of whether Tradinco Instruments or the vendor has advance notice of the possibility of such damages.
The type number of the product, as listed on the instrument tag plate, should always be mentioned in any
correspondence concerning the product.
Tradinco Instrumenten-Apparaten B.V.
Radonstraat 250
2718 TB Zoetermeer
The Netherlands
[phone]
www.tradinco.com
[email protected]

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 4 van 15
1.3 Service of Tradinco Instruments
Tradinco Instruments has made a concerted effort to provide complete and current information for the proper use
of the equipment. If there are questions regarding this manual, proper use of the equipment, or if you have
problems using your Traqc-2 PC and you don’t find the answer in this manual, contact either Tradinco Instruments
for personal assistance. We are ready to help.
1.4 Calibration services
In addition to servicing our own products, Tradinco Instruments provides complete pressure calibration services for
many pressure instruments. This service includes a Certificate of Compliance and Calibration and a record of
traceability to the pressure standards of the Dutch Accreditation Council RvA.
1.5 Accreditation
Tradinco Instruments is registered to ISO 9001:2015. The calibration program at Tradinco Instruments is accredited
by Dutch Accreditation Council RvA, as complying with EN ISO/IEC 17025:2017.
1.6 Packaging for shipment
If the product must be shipped to a different location or returned for any reason through a common carrier it must
be packaged properly to minimize the risk of damage. The recommended method of packing is to place the
instrument in a container, surrounded on all sides with at least four inches of shock attenuation material such as
styrofoam peanuts.

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 5 van 15
2. Safety symbols, notices and warnings
This warning symbol indicates danger for the system and material if the respective safety precautions are
not taken, or indicates that danger of injury for persons and the environment and/or considerable material
damage (mortal danger, danger of injury) will occur if the respective safety precautions are not taken.
This warning symbol indicates danger by explosion for the system and material and the operator and
bystanders if the respective safety precautions are not taken.
This notice symbol does not indicate safety notices but information for a better understanding of the facts.
2.1 Responsible use of the Traqc-2 PC
To ensure safety, the operator must make sure that the following conditions are met:
•The system is used properly, no dangerous media are used and that all technical specifications are observed;
•The system is in perfect operating condition;
•The operation manual is legible and accessible to the user at the system’s location;
•The system is operated, serviced and repaired only by authorized and qualified personnel;
•The user receives instruction on industrial safety and environmental protection, and is knowledgeable of all
operating instructions and safety notices relevant to the current procedure.
2.2 General safety instructions
The system should be operated only by trained personnel who are familiar with this manual and the
operation of the instrument.
The battery of the Traqc-2 PC should be charged regularly. Only use the supplied USB cable for this, which
may be connected to a USB charging point that delivers a maximum of 500 mA/hr in order to prevent
overloading the internal electronics.
A condition for trouble-free and safe operation of this system is proper transport, proper storage,
installation, assembly and proper use as well as careful operation and maintenance.
Any operation not described in the following instructions should be prohibited. The system must be
handled with care required for an electronic precision instrument (protect from humidity, impacts, strong
magnetic fields, static electricity and extreme temperatures). Do not insert any objects into the instrument.
2.3 Warnings and caution notices
WARNING: PRESSURE! Pressure gases are potentially hazardous. Energy stored in these gases can be
released suddenly and with extreme force. Pressure systems should be assembled and operated only by
personnel who have been trained in proper safety practices.
Do not disconnect any pressure connection of the Traqc-2 PC when a measurement of any kind is in
progress. Physical injury may exceed when process connections will be disconnected, caused by the
expanding gas.
CAUTION: Pressure testing with compressed gases can lead to additional risks due to release of stored
energy (e.g. burst of system, flying objects). Please take appropriate measures (e.g. shielding, use of
personal protective equipment (PPE)) to prevent hazardous situations which could result in human injuries.
CAUTION: Use proper pressure medium. Use only clean, dry air or nitrogen gas. This instrument is not
designed for oxygen use.

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 6 van 15
WARNING: NOT EXPLOSION PROOF! Using this instrument in an area where devices with intrinsically safe
classification is recommended, is prohibited!
WARNING: Detachable main power supply cord with inadequate ratings should not be used.
WARNING: It is the responsibility of the operator to ensure that pressure in circuits connected to the
Traqc-2 PC will never exceed their safe working pressure. In the event that the maximum safe working
pressure of a circuit / system to be tested is lower than the maximum obtainable output pressure of the
Traqc-2 PC, the operator who will perform the tests must be instructed in advance regarding the maximum
safe working pressure of the external circuit.
Depending on the volume and pressure in the Traqc-2 PC, the risks for humans and material can be very
high. For that reason the end user must ensure that maximum pressure levels for each circuit are
established as set forth by law. (European directive 2014/68/EU or similar guidelines/obligations are
specified and applicable in the country of use.)
Because of the potential risk for human beings in the vicinity of systems/circuits under pressure, the end
user must ensure that risks are kept to the minimum by fencing, warning, forbidding passage or access to
the area for as long as the risk exists.
Do not connect the voltages higher than specified in the specifications to the instrument. If higher voltages
are connected, the interface control may be damaged.
This instrument is equipped with an overpressure protection, which protects the pressure sensor against
overpressure. As soon as the pressure on the pressure sensor increases to 1 bar above the measuring range
specified for the instrument, the supply to the pressure sensor will be cut off to protect the pressure sensor
from damage.

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 7 van 15
3. About the Traqc-2 PC
3.1 Functions of the Traqc-2 PC
The Traqc-2 PC is a portable pressure calibrator to perform a calibration, a simple pressure measurement or a leak
test. The Traqc-2 PC is not suitable for generating pressure. However, an UUT can be pressurized by means of a
supply pressure, which can be regulated with the pressure control valve if desired. This pressure will appear in the
display. The display can be set to psi, bar or kPa by briefly pressing the push button. The pressure indication on the
display can be zeroed by pressing the push button for a longer period of time.
3.2 Terms of use
Control panel and layout
ID Function Description
SC Connection point For the purpose of connecting the external pressure supply
PCV Pressure control valve For the purpose of controlling the pressure to test
connection 1 & 2
PS Selector switch May or may not allow reduced pressure to
test connection 1 & leak test function
TEST 1 Test connection 1 Test point to which an UUT can be connected
TEST 2 Test connection 2 Test point to which an UUT can be connected
OFF / ON On / off switch Switching the Traqc-2 PC on or off
ZERO / UNIT Push button For the purpose of zeroing the display or changing
the measuring unit
PT Pressure reference sensor Measuring the pressure
PSS Pressure limiting valve Protecting the pressure sensor against overpressure
Underlined components are visible

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 8 van 15
Display terms
Term Description
P test [bar/psi/kPa] Pressure test
Terms of the manual
Term Description Meaning
CW Clock Wise
CCW Counter Clock Wise
UUT User under test (the object that is being
tested)
3.3 A closer look at the instrument
Charging
connector USB B
under swivel flap
Pressure control valve
Two-way switch
Test terminal
On/off switch
Zero/unit switch
Display
Test point

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 9 van 15
4. Operation of the Traqc-2 PC
The supply pressure which must be connected should not exceed 10 bar.
The pressure to the test terminals, test 1 and test 2, should never exceed the maximum pressure in
accordance with the type label.
4.1 On/off switch
To turn the instrument on and off.
4.2 Zero/unit switch
The instrument is equipped with a push button that can be used to:
•Changing the unit shown on the display. To do this, briefly press the push button.
•Zeroing the reading. To do this, press the push button for at least 3 seconds.
Storage compartment

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 10 van 15
4.3 Display
The display shows the following information:
•The battery status
•The test pressure
4.4 Two-way switch
The instrument is equipped with a two-way pneumatic switch that has two functions:
•The pressure from the pressure control valve is passed to the pressure sensor and to the test terminal
(test 1 or test 2).
•The test terminals (test 1 and test 2) and the pressure sensor are disconnected from the source.

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 11 van 15
5. Using the Traqc-2
5.1 Applying supply pressure to the UUT
•Turn on the instrument
•Press short the zero/unit button to set the desired unit (barg, psig or kPag)
•Turn the selector switch in the forward direction
•Turn the PCV all the way counterclockwise
No pressure will build up to the pressure control valve
•Connect the supply pressure to the connection point (SC)
With a maximum pressure of 10 bar!
•Connect the UUT to the test terminals (test 1 or test 2)
Using a polyflo connector
•Zero the pressure reading with the zero/unit button
Press and hold the zero/unit button for 3 seconds
5.2 Performing a comparative measurement
•Operate the instrument as described in section 5.1
•Turn the PCV clockwise to apply the correct pressure to the UUT
Read the pressure on the display
•Turn the selector switch in the blocking direction
•Wait for the pressure to stabilize
Depending on the environmental conditions, this may take some time
•Read the difference in pressure between the Traqc-2 PC and the UUT
5.3 Performing a leak test
•Operate the instrument as described in section 5.1
•Turn the PCV clockwise to apply the correct pressure to the UUT
Read the pressure on the display
•Turn the selector switch in the blocking direction
The internal circuit of the Traqc-2 that is part of the leak test is as short as possible
•Wait for the pressure to stabilize
Depending on the environmental conditions, this may take some time
•Zero the pressure reading with the zero/unit button
Press and hold the zero/unit button for at least 3 seconds
•Read off the pressure history from the display
5.4 Measuring external pressure
If no pressure has to be generated, the pressure of an UUT can be measured with the Traqc-2 PC. The pressure can
be read off directly from the display. The test circuit and the Traqc-2 PC is as short as possible:
•Zero the pressure reading with the zero/unit button
Press and hold the zero/unit button for at least 3 seconds
•Connect the UUT to the test terminal (test 1 or test 2)
•Apply the pressure with the UUT
•Read off the pressure from the display
5.5 Charging the battery
The Traqc-2 PC is equipped with a Lithium-Ion battery, which must be charged regularly. When the instrument is
switched on, the status of the battery is visible on the display. The USB cable and the USB charging port are
provided. Always use the supplied cable or a similar cable with a maximum length of 0.8 meters.
The charging specifications are:
•Maximum 500mA
•5 VDC

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 12 van 15
6. Maintenance
6.1 Maintenance
Depending on the number of operating hours, the Traqc-2 PC should be maintained on a regular basis. We
recommend to contact our service department for tailor-made advice.
6.2 Calibration
The Traqc-2 PC is equipped with a pressure measuring cell, whose measurement accuracy decreases over time. This
is a natural process. To ensure that your Traqc-2 PC always displays the correct reading on the display, the Traqc-2
must be calibrated regularly at Tradinco Instruments. The recommended frequency of the recalibration (annually,
every two years or else) depends, among other things, on the number of operating hours and the required
measurement accuracy. Please contact our service department for tailor-made advice.

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 13 van 15
7. Specifications

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 14 van 15
8. Declaration of conformity

User manual Traqc-2 PC
User manual Traqc-2 PC rev.0
Pagina 15 van 15
Tradinco Instrumenten-Apparaten b.v.
Radonstraat 250
2718 TB Zoetermeer
The Netherlands
[phone]
www.tradinco.com
[email protected]
