TrailFX 2123131 Instruction manual

www . T r a il F X . c om
Page 1of 2 Rev 030816
120 min
PARTS LIST:
Qty
Part Description
Qty
Part Description
1
Block Light*
2
M6 x 16mm Bolt*
1
Wiring Harness
1
M8 X 25mm Bolt*
1
Switch
2
M6 Lock Nut*
1
U Bracket*
1
M8 Hex Nut*
1
Lock Washer*
*Part quantity doubles for the paired kits
LIGHT INSTALLATION:
1. Install supplied bracket to block light using M6 x 16mm bolts and M6 Lock Nuts. Insert bracket into vents on back of block light
and then, insert M6 lock nuts into the open cavities next to inserted bracket. Once both have been placed, insert m6 x 16mm
bolt into hole on side of block light. Repeat on opposite side of light.
2. Identify the desired mounting location for the lights on the vehicle. Place block light and mark bracket hole locations on vehicle
(If mounting hole requires drilling).
3. If mounting hole requires drilling, drill a 5/16" hole in locations marked.
4. Mount using M8 x 25mm bolt, lock washer, and M8 hex nut. Once Light bar is in desired location tighten all hardware.
3” LED 18W Cube Light
Part No: 2123131, 2123131P, 2123141, 2123141P
tools may be required
1 866 638 4870
REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE
PRESENT.
[e-mail]
READ INSTRUCTIONS CAREFULLY BEFORE STARTING
INSTALLATION.
BLOCK LIGHT
WIRING HARNESS
SWITCH
MOUNTING KIT
To Harness

www . T r a il F X . c om
Page 2of 2 Rev 030816
LIGHT COVERS SOLD SEPARATELY
Check out these other TrailFX Products!! www.TrailFX.com
WIRING INSTALLATION:
!!! Paired kits will have 2 Deutsch connectors on harness:
1. Remove wiring harness and switch from kit.
2. Route wiring harness so that the red and black power cables are
routed to the 12V battery, the three switch wires are routed to
your desired switch location, and the Deutsch plug(s) is routed to
the light. (Keep wiring away from anything that will get hot).
3. Mount relay with desired hardware in a position under hood or in
cab that is limited to water exposure.
4. Plug male (on the wiring harness) and female (on light) Deutsch
plug(s) connectors together.
5. Drill ¾” hole in desired switch mounting location. Verify there will
be enough clearance behind switch to plug in the wires. Notch a
small slit in the side of the hole using a file. This will keep the
switch from turning.
6. Press switch into hole; verify that the notch made in step 5 lines
up with the notch on the switch.
7. Plug wires into switch. Prongs on switch will be marked 1
through 3. Red wire goes to prong 1, Blue wire goes to Prong
2, and the Black wire goes to prong 3 (gold prong).
8. Attach power cable to the battery. Red goes to positive and
black goes to negative.
Do periodic inspections to the installation to make sure that all hardware is secure and tight.
Never use a caustic or petroleum based cleaner on any surface of the light.
For best cleaning results, always use household glass cleaner or mild soap with a soft lint free rag.
