Transition Networks SM12DP2XA User manual

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 1of 32
SM12DP2XA
Managed Gigabit Ethernet Fiber Switch
(12) 100/1000Base-X SFP Slots + (2) 1G/10G SFP+ slots +
(2) 10/100/1000Base-T




InstallGuide
33751Rev.C


TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 2of 32
Trademarks
Alltrademarksandregisteredtrademarksarethepropertyoftheirrespectiveowners.
Copyright Notice/Restrictions
Copyright©2018TransitionNetworks.Allrightsreserved.Nopartofthisworkmaybereproducedorusedinany
formorbyanymeans(graphic,electronicormechanical)withoutwrittenpermissionfromTransitionNetworks.
PrintedintheU.S.A.
SM12DP2XAManagedGigabitEthernetFiberSwitchInstallGuide33751Rev.B
Contact Information
TransitionNetworks
10900RedCircleDrive
Minnetonka,MN55343USA
tel:+1.952.941.7600|tollfree:1.800.526.9267|fax:952.941.2322
[email protected]|[email protected]|[email protected]
Revision History
RevDateDescription
A6/25/18InitialreleaseatFWv7.10.14232018‐05‐16.
B7/27/18UpdateDCInputterminalandcomplianceinformation.
C8/22/18CorrectthedefaultIPaddress.


TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 3of 32
CautionsandWarnings
Definitions
Cautionsindicatethatthereisthepossibilityofpoorequipmentperformanceorpotentialdamagetothe
equipment.Warningsindicatethatthereisthepossibilityofinjurytoperson.
CautionsandWarningsappearhereandmayappearthroughoutthismanualwhereappropriate.Failuretoread
andunderstandtheinformationidentifiedbythissymbolcouldresultinpoorequipmentperformance,damage
totheequipment,orinjurytopersons.
Cautions
Whileinstallingorservicingthepowermodule,wearagroundingdeviceandobserveallelectrostatic
dischargeprecautions.Failuretoobservethiscautioncouldresultindamageto,orfailureofthepower
module.
Warnings

Warning:Donotconnectthepowermoduletoanexternalpowersourcebeforeinstallingitintothechassis.
Failuretoobservethiswarningcouldresultinanelectricalshock,evendeath.
WARNING:Equipmentgroundingisvitaltoensuresafeoperation.Theinstallermustensurethatthepower
moduleisproperlygroundedduringandafterinstallation.Failuretoobservethiswarningcouldresultinan
electricshock,evendeath.
WARNING:Areadilyaccessible,suitableNationalElectricalCode(NEC)orlocalelectricalcodeapproved
disconnectdeviceandbranch‐circuitprotectormustbepartofthebuilding'sinstalledwiringtoaccommodate
permanentlyconnectedequipment.Failuretoobservethiswarningcouldresultinanelectricshock,evendeath.
WARNING:TurnanyexternalpowersourceOFFandensurethatthepowermoduleisdisconnectedfromthe
externalpowersourcebeforeperforminganymaintenance.Failuretoobservethiswarningcouldresultinan
electricalshock,evendeath.
WARNING:EnsurethatthedisconnectdevicefortheexternalpowersourceisOPEN(turnedOFF)before
disconnectingorconnectingthepowerleadstothepowermodule.Failuretoobservethiswarningcouldresultin
anelectricshock,evendeath.
See Electrical Safety Warnings on page 31 for Electrical Safety Warnings translated into multiple languages.


TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 4of 32
Contents
Introduction.................................................................................................................................................................6
SafetyStatements........................................................................................................................................................6
Features.......................................................................................................................................................................7
Benefits........................................................................................................................................................................7
Specifications...............................................................................................................................................................8
SwitchArchitecture....................................................................................................................................................12
NetworkManagementOptions.................................................................................................................................12
AboutThisManual.....................................................................................................................................................12
RelatedManuals........................................................................................................................................................13
ForMoreInformation................................................................................................................................................13
FrontPanel.................................................................................................................................................................14
1000BASE‐TPorts...................................................................................................................................................14
SFPandSFP+TransceiverSlots..............................................................................................................................14
CONSOLEPort........................................................................................................................................................14
FrontPanelLEDs....................................................................................................................................................15
PortStatusLEDs.....................................................................................................................................................15
SystemStatusLEDs................................................................................................................................................15
RST(Reset)Button.................................................................................................................................................16
PowerSupplyInputs..............................................................................................................................................16
Installation.................................................................................................................................................................17
SiteSelection..........................................................................................................................................................17
Unpacking...............................................................................................................................................................17
PackageContents...................................................................................................................................................18
Mounting................................................................................................................................................................18
RackMounting...................................................................................................................................................18
DesktoporShelfMounting................................................................................................................................19
EthernetCabling.....................................................................................................................................................20
InstallinganOptionalSFPTransceiver...................................................................................................................21
ToInstallanSFPtransceiver..............................................................................................................................22
ConnectingtoPower..............................................................................................................................................23
ConnectingtoanACPowerSource...................................................................................................................23
ConnectingtoaDCPowerSource.....................................................................................................................23
ConnectingtoBothACandDCPower...............................................................................................................23
InitialSwitchConfiguration........................................................................................................................................24
CLIConfiguration....................................................................................................................................................24
WebUIConfiguration............................................................................................................................................24
Troubleshooting,Warranty,SupportandCompliance..............................................................................................25
GeneralTroubleshooting.......................................................................................................................................25
LEDTroubleshooting..............................................................................................................................................26
DeviceLabelandPackagingLabel..........................................................................................................................26
RecordingDeviceandSystemInformation................................................................................................................27

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 5of 32
LimitedLifetimeWarranty.....................................................................................................................................28
ContactUs..............................................................................................................................................................28
TechnicalSupport...............................................................................................................................................28
ComplianceInformation............................................................................................................................................29
FCCRegulations......................................................................................................................................................29
CanadianRegulations.............................................................................................................................................29
DeclarationofConformity(DoC)...........................................................................................................................29
HighRiskActivitiesDisclaimer...............................................................................................................................30
ElectricalSafetyWarnings..........................................................................................................................................31
ElectricalSafety..................................................................................................................................................31
ElektrischeSicherheit.........................................................................................................................................31
Elektrisksikkerhed.............................................................................................................................................31
Elektrischeveiligheid..........................................................................................................................................31
Sécuritéélectrique.............................................................................................................................................31
Sähköturvallisuus...............................................................................................................................................31
Sicurezzaelettrica..............................................................................................................................................31
Elektrisksikkerhet..............................................................................................................................................31
Segurançaeléctrica............................................................................................................................................31
Seguridadeléctrica.............................................................................................................................................31
Elsäkerhet...........................................................................................................................................................31


TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 6of 32
Introduction
TheSM12DP2XAManagedGigabitEthernetFiberSwitchisanext‐generationFiberSwitchofferingfullsuiteofL2
featuresandadditional10GbEuplinkconnections.AdvancedL3featuressuchasStaticRoutedeliverbettercost
performanceandlowertotalcostofownershipinEnterprisenetworksorbackboneviafibberorcopper
connections.
TheSM12DP2XAprovides12GbESFPports,2RJ45ports,210GbESFP+portsandRJ45Consoleportwithbuilt‐in
ACandDCdualpowersupplies.SM12DP2XAprovidesfrontpanelaccesstoallpower,data,andmanagement
ports,inacompactformfactorfordesktop,wall‐mount,orrack‐mountinstallations.
TheSM12DP2XAdeliversmanagementsimplicity,betteruserexperience,andlowesttotalcostofownership.
Thebuilt‐inDeviceManagedSystem(DMS)isdesignedtobeextremelyeasytouse,manage,andinstallIPPhones,
IPCameras,orWifi‐APsforEnterpriseapplications.
SafetyStatements
CAUTION:Circuitdevicesaresensitivetostaticelectricity,whichcandamagetheirdelicateelectronics.
Dryweatherconditionsorwalkingacrossacarpetedfloormaycauseyoutoacquireastaticelectricalcharge.
Toprotectyourdevice:
Touchthemetalchassisofyourcomputertogroundthestaticelectricalchargebeforeyoupickupthe
circuitdevice.
Pickupthedevicebyholdingitontheleftandrightedgesonly.
Ifyouneedtouseanoutdoordeviceconnectedtothisdevicewithcablethenyoumustuseanarrester
onthecablebetweenoutdoordeviceandthisdevice.
NOTE:Theswitchisanindoordevice;ifitwillbeusedinanoutdoorenvironmentortoconnectwithan
outdoordevice,thenitmustusealightningarrestertoprotecttheswitch
WARNING:
•Self‐demolitionofthisproductisstrictlyprohibited.Damagecausedbyself‐demolitionwillbechargedfor
repairingfees.SeetheUSEPAElectronicsDonationandRecyclingwebsite.
•Donotplaceproductoutdoors.
•Beforeinstallation,makesureinputpowersupplyandproductspecificationsarecompatible.
•Toreducetheriskofelectricshock,disconnectallACorDCpowercordandPScablestocompletely
removepowerfromtheunit.
•Beforeimporting/exportingaconfigurationmakesurethefirmwareversionisthesame.
•Afterafirmwareupgrade,theswitchwillautomaticallysettheconfigurationtothelatestversion.
Notices:NotDesignedforUseinLifeSupportEquipmentorApplications:Theseproductsarenotdesignedforuse
inlifesupportequipmentorapplicationsthatwouldcausealife‐threateningsituationifanysuchproductfailed.
Donotusethisproductinthesetypesofequipmentorapplications.
ERN#:ERN#(EncryptionRegistrationNumber)R111839(self‐declaring).

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 7of 32
Features
IPv6Management
SupportJumboFrameupto10200bytes
Authentication–RADIUS,TACACS+
IEEE802.1X:RADIUSauthentication,authorizationandaccounting,MD5hash,guestVLAN,
single/multiplehostmodeandsingle/multiplesessions
DHCPRelay,DHCPOption82,DHCPSnooping,DHCPServer,DHCPPerPort
L2/L3/L4ACLssupportMAC,VLANIDorIP,protocol,port,DSCP/IPprecedence/TCP.UDP,EtherType,
ICMP,TCPflag
LLDP(LinkLayerDiscoveryProtocol)
IPSourceGuard,PortSecurity
PortMirroring
FirmwareUpdateviaTFTP/HTTPandconsole
Syslog
1RUhigh,compactformfactor
Extendedoperatingtemperature:‐20°Cto+60°C
Benefits
Feature‐richEthernetSwitchforEnterprise‐class:TheswitchdeliversadvancedfunctionalityinL2+
managedswitchincludingLayer3staticroute,DHCPserver,IPv6support,LLDP,etc.Italsohas
comprehensivesecurityfeaturessuchasIPsourceguardandAccessControlListtoguardyournetwork
fromunauthorizedaccess.Itbuildsonthemarket‐leadingprice/performancewithL2+ManagedGbEfiber
switch,andprovidesecure,reliableandeaseofuseforenterpriseandSMBdeployments.
EasytoInstall,ConfigureandTroubleshootbyDMS:TheDMS(DeviceManagementSystem)provides
embeddedfunctionstofacilitatedevicemanagementanytimeandanywhere.Itsuser‐friendlyinterface
helpsyoumanagedevicesintuitively.ItsupportsvariousIPdevicetypes(e.g.IP‐phone,IP‐camera,
WiFi‐AP)forenduserstoenhancemanageabilityandsavetime/costduringinstallation/maintenance
stages.
LowerTotalCostofOwnership(TCO)withEnergy‐efficientDesign:Itisdesignedtohelpcustomersto
reducepowerconsumptionandlowertheTCObyEnergyEfficientEthernet(IEEE802.3az)features.Itcan
beusedtobuildagreenEthernetnetworkingenvironment.
AC/DCDualPowerSupply:Powerfailoverwhenpowersuppliesareconnectedtodifferentcircuitstohelp
reducenetworkoperatingrisk.



TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 8of 32
Specifications
PortConfiguration
TotalPortsSFP(100M/1G)Uplinks(100M/1G/10G)Console
16122SFP+(1G/10G)
2RJ45(100M/1G)RJ45
HardwarePerformance
Forwarding
Capacity SwitchingCapacityBackplaneMacTableJumboFrames
50.592Mpps68Gbps68Gbps3275610200Bytes
EnvironmentalRange
OperatingTemperatureStorageTemperatureAltitude
FahrenheitCentigradeFahrenheitCentigradeFeetMeters
‐4°to+140° ‐20°to+60° ‐4°to+158° ‐20°to+70° <10000<3000
Dimensions,Weights,Humidity
Dimensions(WxHxD)Weight
OperatingHumidity
MillimeterInchesKilogramsPounds
280x44x13411x1.73x5.281.02.210%to90%
non‐condensing
VoltageandFrequency
ModelNameACInputVoltageDCInputVoltagePowerConsumption
SM12DP2XA100‐240VAC,50‐60Hz24‐48VDC24Watts(max)
Certifications
ElectromagneticEmissions(EMC)
FCCClassA,CESafety:ULListed
MTBF
ModelMTBFEnvironment
SM12DP2XA270,787Hrs.GB,GC‐GroundBenign,Controlled.Temp:25.00deg.C.
SM12DP2XA58,838Hrs.GB,GC‐GroundBenign,Controlled.Temp:75.00deg.C.

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 9of 32
SoftwareFeatures
Layer2Switching
SpanningTree
Protocol(STP)
StandardSpanningTree802.1d
RapidSpanningTree(RSTP)802.1w
MultipleSpanningTree(MSTP)802.1s
Trunking
LinkAggregationControlProtocol(LACP)IEEE802.3ad
Upto8groups
Upto8portspergroup
VLAN
Supportsupto4KVLANssimultaneously(outof4096VLANIDs)
Port‐basedVLAN
802.1Qtag‐basedVLAN
MAC‐basedVLAN
ManagementVLAN
PrivateVLANEdge(PVE)
Q‐in‐Q(doubletag)VLAN
VoiceVLAN
GARPVLANRegistrationProtocol(GVRP)
DHCPRelay RelayofDHCPtraffictoDHCPserverindifferentVLAN.
WorkswithDHCPOption82
IGMPv1/v2/v3
Snooping
IGMPlimitsbandwidth‐intensivemulticasttraffictoonlytherequesters.Supports
1024multicastgroups
IGMPQuerierIGMPquerierisusedtosupportaLayer2multicastdomainofsnoopingswitchesin
theabsenceofamulticastrouter
IGMPProxyIGMPsnoopingwithproxyreportingorreportsuppressionactivelyfiltersIGMP
packetsinordertoreduceloadonthemulticastrouter
MLDv1/v2SnoopingDeliversIPv6multicastpacketsonlytotherequiredreceivers
DeviceManagementSystem(DMS)
DMSTopologyView,FloorView,MapView,Dashboard,TrafficMonitoring,Cable
Diagnostics,GoogleMapAPIKey
Graphical
Monitoring
Topologyview:Supportintuitivewaytoconfigureandmanageswitchesand
deviceswithvisualrelations
Floorview:It’seasytodraganddropdevicesandtohelpbuildsmartworkforces
Mapview:Enhanceefficiencytodraganddropdevicesandmonitorsurroundings
onGoogleMaps
FindmySwitchSearchyourrealswitchesquicklyandmanagedirectly.
TrafficMonitoringDisplayvisualchartofnetworktrafficofalldevicesandmonitoreveryportatanytime
fromswitches
Troubleshooting
Networkdiagnosticbetweenmasterswitchanddevices
Supportprotectionmechanism,suchasrate‐limitingtoprotectyourdevicesfrom
brute‐forcedownloading


TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 10 of 32
Layer3Switching
IPv4StaticRoutingIPv4Unicast:Staticrouting
IPv6StaticRoutingIPv6Unicast:Staticrouting
Security
SecureShell(SSH)SSHsecuresTelnettrafficinoroutoftheswitch,SSHv1andv2aresupported
SecureSocketsLayer
(SSL)
SSLencryptsthehttptraffic,allowingadvancedsecureaccesstothebrowser‐based
managementGUIintheswitch
IEEE802.1X
IEEE802.1X:RADIUSauthentication,authorizationandaccounting,MD5hash,
guestVLAN,single/multiplehostmodeandsingle/multiplesessions
SupportsIGMP‐RADIUSbased802.1X
DynamicVLANassignment
Layer2Isolation
(PrivateVLANEdge)
PVE(aka“protectedports”)providesL2isolationbetweenclientsinthesameVLAN.
Supportsmultipleuplinks.Layer2Isolationpreventscommunicationbetweenwired
andwirelessclientsinthenetwork.Itpreventsanywirelessorwiredsubscriberfrom
beingabletocommunicatetoeachotherevenwhentheyarewithinthesame
subnet,makingitagoodsolutionforhotspotsecurity.
PortSecurityLocksMACaddressestoports,andlimitsthenumberoflearnedMACaddress
IPSourceGuardPreventsillegalIPaddressfromaccessingtospecificportintheswitch
RADIUS/TACACS+ SupportsRADIUSandTACACS+authentication(switchasaclient).
StormControlPreventstrafficonaLANfrombeingdisruptedbyabroadcast,multicast,orunicast
stormonaport
DHCPSnoopingAfeatureactsasafirewallbetweenuntrustedhostsandtrustedDHCPservers
DHCPperPortTheswitch’sDHCPserverassignsIPaddresses.ClientsgetIPaddressesinsequence
andtheswitchassignsIPaddressesonaper‐portbasisfromtheconfiguredIPrange.
ACLs
L2/L3/L4.IPv6support.Upto512entries.Droporratelimitationbasedon:
SourceanddestinationMAC,VLANIDorIPaddress,protocol,port,
Differentiatedservicescodepoint(DSCP)/IPprecedence
TCP/UDPsourceanddestinationports
802.1ppriority
Ethernettype
InternetControlMessageProtocol(ICMP)packets
TCPflag
QualityofService(QoS)
HardwareQueue Supports8hardwarequeues
SchedulingStrictpriorityandweightedround‐robin(WRR)
QueueassignmentbasedonDSCPandclassofservice
Classification
Portbased
802.1pVLANprioritybased
IPv4/IPv6precedence/DSCPbased
DifferentiatedServices(DiffServ)
Classificationandre‐markingACLs
RateLimitingIngresspolicer

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 11 of 32
Egressshapingandratecontrol
Perport

Management
DHCPServerSupportDHCPservertoassignIPtoDHCPclients
ZeroTouchUpgradeUpgradesingleswitchautomaticallywhenyougetnotification
RemoteMonitoring
(RMON)
EmbeddedRMONagentsupportsRMONgroups1,2,3,9(history,statistics,alarms,
andevents)forenhancedtrafficmanagement,monitoringandanalysis
PortMirroring
Trafficonaportcanbemirroredtoanotherportforanalysiswithanetworkanalyzer
orRMONprobe.UptoN‐1(NisSwitch’sPorts)portscanbemirroredtosingle
destinationport.Asinglesessionissupported.
UPnP
UPnPwaspromotedbytheUPnPForumtoenablesimplerobustconnectivityto
stand‐alonedevicesandPCsfromover800vendorsofconsumerelectronics,network
computing,etc.UPnPhasbeenmanagedbytheOpenConnectivityFoundation(OCF)
since2016.
s‐Flow
Theindustrystandardformonitoringhighspeedswitchednetworks.Itgivescomplete
visibilityintotheuseofnetworksenablingperformanceoptimization,
accounting/billingforusage,anddefenseagainstsecuritythreats
IEEE802.1ab(LLDP)
Usedbynetworkdevicesforadvertisingtheiridentities,capabilities,and
neighborsonanIEEE802ablocalareanetwork
SupportsLLDP‐MEDextensions(IEEE802.1AB)
WebGUIInterfaceBuilt‐inswitchconfigurationutilityforbrowser‐baseddeviceconfiguration
CLILetsyouconfigure/manageswitchesinCommandLineInterfacemodes
DualImageIndependentprimaryandsecondaryimagesforbackupwhileupgrading
SNMP SNMPversion1,2cand3withsupportfortraps,andSNMPversion3user‐based
securitymodel(USM)
FirmwareUpgradeWebbrowserupgrade(HTTP/HTTPs)andTFTP
Upgradethroughconsoleport
NTPNetworkTimeProtocol(NTP)isanetworkingprotocolforclocksynchronization
betweencomputersystemsoverpacket‐switched
OtherManagement
HTTP/HTTPs;SSH
DHCPClient/DHCPv6Client
CableDiagnostics
Ping
Syslog
TelnetClient
IPv6Management
SwitchingBandwidth68Gbps
MACAddressesTable32756MACAddresses

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 12 of 32
Event/ErrorLog Syslog,SMTP(RFC821)
ManagementAccess
FilteringSNMP,Web,Telnet,SSH
CDPAwareYes(CiscoDiscoveryProtocol)
EdgePortBPDU
Filtering
ControlwhetheraportexplicitlyconfiguredasEdgewilltransmitandreceive
BPDUs.
EdgePortBPDUGuard
ControlwhetheraportexplicitlyconfiguredasEdgewilldisableitselfupon
receptionofaBPDU.Theportwillentertheerror‐disabledstate,andwillbe
removedfromtheactivetopology.
SwitchArchitecture
Theswitchincorporatesawire‐speed,non‐blockingswitchingfabric.Thisallowswire‐speedtransportofmultiple
packetsatlowlatencyonallportssimultaneously.Theswitchalsofeaturesfull‐duplexcapabilityonallports,
whicheffectivelydoublesthebandwidthofeachconnection.Thisswitchusesstore‐and‐forwardtechnologyto
ensuremaximumdataintegrity.Withthistechnology,theentirepacketmustbereceivedintoabufferand
checkedforvaliditybeforebeingforwarded.Thispreventserrorsfrombeingpropagatedthroughoutthe
network.
NetworkManagementOptions
TheswitchcanalsobemanagedoverthenetworkwithawebbrowserorTelnetapplication.Theswitchincludes
abuilt‐innetworkmanagementagentthatallowsittobemanagedin‐bandusingSNMPorRMON(Groups1,2,3,
9)protocols.SeetheWebUserGuideforadetaileddescriptionofthemanagementfeatures.
AboutThisManual
Thismanualdescribeshowtoinstall,configure,andtroubleshoottheSM12DP2XAswitch,includinghowto:
Installtheswitch.
CheckswitchstatusbyreadingtheLEDs.
Resettheswitchorrestoretheswitchtofactorydefaults.
Troubleshootswitchinstallation.
Thismanualisintendedforusebynetworkadministratorswhoareresponsibleforoperatingandmaintaining
networkequipment;consequently,itassumesabasicworkingknowledgeofgeneralswitchfunctions,the
InternetProtocol(IP),andSimpleNetworkManagementProtocol(SNMP).

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 13 of 32
Theseconventionsareusedthroughoutthisguidetoshowinformation:
Note:Emphasizesimportantinformationorcallsyourattentiontorelatedfeaturesorinstructions.
Warning:Alertsyoutoapotentialhazardthatcouldcausepersonalinjury.
Caution:Alertsyoutoapotentialhazardthatcouldcauselossofdataordamagetothesystemor
equipment.
RelatedManuals
SM12DP2XAQuickStartGuide,33750
SM12DP2XAInstallGuide,33751(thismanual)
SM12DP2XAWebUserGuide,33752
SM12DP2XACLIReference,33753
ForMoreInformation
AprintedQuickStartGuideisshippedwitheachunit.
ForTransitionNetworksDrivers,Firmware,etc.gototheProductSupportwebpage(logonrequired).
ForTransitionNetworksManuals,Brochures,DataSheets,etc.gototheSupportLibrary(nologonrequired).
ForSFPinformationseeTransitionNetworksSFPwebpage.
ForSFP+informationseeTransitionNetworksSFP+webpage.
Note:Informationinthisdocumentissubjecttochangewithoutnotice.Notethatthismanualprovideslinksto
thirdpartywebsitesforwhichTransitionNetworksisnotresponsible.

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 14 of 32
FrontPanel
Theswitchfrontpanelcontainsthepowerinputs,ports,LEDsandRESETbuttonasshownanddescribedbelow.

1000BASE‐TPorts
Theswitchcontains10/100/1000BASE‐TRJ‐45ports.AllRJ‐45portssupportautomaticMDI/MDI‐Xoperation,
auto‐negotiationandIEEE802.3xauto‐negotiationofflowcontrol,sotheoptimumdatarateandtransmission
canbeselectedautomatically.
SFPandSFP+TransceiverSlots
TheswitchsupportsSmallFormFactorPluggable(SFP)transceiverslotsport1toport12,andport15toport16
are10GSFP+.Inthedefaultconfiguration,ifanSFPtransceiver(purchasedseparately)isinstalledinaslotand
hasavalidlinkontheport,theassociatedRJ‐45portisdisabled.
CONSOLEPort
TheswitchhasoneRJ‐45CONSOLEportforCLIaccessviatheprovidedRS232DB9toRJ45Cable.
NotethatCross‐overcablingtotheCONSOLEportisnotsupported.

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 15 of 32
FrontPanelLEDs
TheswitchincludesaLEDpanelforsystemandportindicationsthatsimplifyinstallationandnetwork
troubleshooting.TheLEDsarelocatedonleftsideofthefrontpanelforeasyviewing.TheLEDsareshownand
describedinthetablesbelow.
PortStatusLEDs
LED(Color)ViewStatus
P1‐P12SFP
Link/Act/Speed
(Green/Amber)

LightswhenFiberconnectionwithremotedeviceisgood.
Blinkswhenanytrafficispresent.
TheLEDisgreenwhenlinkingup1Gbps.
TheLEDisAmberwhenlinkingup100Mbps.
P13‐P14TP
Link/Act/Speed
(Green/Amber)

Blinkswhenanytrafficispresent.
TheLEDisgreenwhenlinkingup1Gbps.
TheLEDisAmberwhenlinkingup10/100Mbps.
P15‐P161GSFP
10GSFP+
Link/Act/Speed
Blinkswhenanytrafficispresent.
Thegreen10GLEDislitwhenlinkedat10Gbps.
Thegreen1GLEDislitwhenlinkedat1Gbps.
SystemStatusLEDs
LED(Color)ViewStatus
ACPWR
(Green)
LightswhenACpowerison.
DCPWR
(Green)LightswhenDCpowerison.
SYSSystem
(Green)
Blinkswhensystemisbooting;
Litwhensystemiscomingup.
ALMAlarm
(Red)Usuallyoff;lightswhenasystemerrorconditionexists.


TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 16 of 32
RST(Reset)Button
ThefrontpanelRST(Reset)buttonisrecessedforaccessusingapapercliporsomethingsimilar.
PressandholdtheRST(Reset)buttonfor2‐7secondstoresetor7‐12secondstorestoreto
factorydefaults;theLEDsblinkandthefanspeedsupmomentarily.
PresstheResetbuttonforacertainperiodoftimetoperformthesetasks:
ResettheSwitch:torebootandgettheswitchbacktothepreviousconfigurationsettingssaved.
RestoretheSwitchtoFactoryDefaults:torestoretheoriginalfactorydefaultsettingsbacktothe
switch.
Note:Basedonthetablebelow,youcantellwhichtaskisbeingperformedbyreadingtheLEDbehaviorswhile
pressingtheRST(Reset)button.OncetheLEDbehaviorsarecorrectlydisplayed,youcanjustreleasethe
button.
Task PressRSTbuttonforSYSLEDBehaviorPortStatusLEDBehavior
ResettheSwitch2~7secondsBlinkingGreenAllLEDsOFF
RestoretoDefaults8~12secondsBlinkingGreenAllLEDsStayON
PowerSupplyInputs
TheSM12DP2XAfrontpanelhastwofrontpanelpowerinputsforpowerredundancy;theswitchhasa100~240
VACpowersocketforACpowerInputanda24/48VDCpowerinputviatheterminalblock.ConnectingtobothAC
andDCpowerprovidesredundancy(ACwithpriority).
AnACPowerCordisincluded.Toorderthecorrespondingcountry‐specificpowercord,addtheextensionfrom
totheendoftheSKU.ForexampleSM24TBT2DPA‐NA=NorthAmerica,‐LA=LatinAmerica,‐EU=Europe,‐UK=
UnitedKingdom,‐SA=SouthAfrica,‐JP=Japan,‐OZ=Australia,‐BR=Brazil.
SeeConnectingtoPoweronpage24.

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 17 of 32
Installation
SiteSelection
TheSwitchcanbemountedinastandard19‐inchequipmentrack(ViaRackmountKit).Besuretofollowthe
guidelinesbelowwhenchoosingalocation.Thesiteshould:
•Beatthecenterofallthedevicesyouwanttolinkandnearapoweroutlet.
•Beabletomaintainitstemperaturewithin‐20to+60°Canditshumiditywithin5%to95%,
non‐condensing.
•Beaccessibleforinstalling,cablingandmaintainingthedevices.
•AllowthestatusLEDstobeclearlyvisible.
Makesurethetwisted‐pairEthernetcableisalwaysroutedawayfrompowerlines,radios,transmittersorany
otherelectricalinterference.
MakesurethattheSwitchisconnectedtoaseparategroundedpoweroutlet.
Unpacking
1. CarefullyunpackallSM12DP2XAcontents.
2. VerifyreceiptofallSM12DP2XAcomponents.Contactyoursalesrepresentativeifanyitemsaremissing.
3. PlacetheSM12DP2XAandrelatedmaterialsneartheinstalllocation.
4. SavetheSM12DP2XAshippingcartonandpackingmaterialsforpossiblefutureuse.

Unpacking

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 18 of 32
PackageContents
Afterunpackingtheswitch,pleasecheckthecontentstobesureyouhavereceivedallthecomponents.
Beforebeginningtheinstallation,besureyouhaveallothernecessaryinstallationequipment.
•OneSM12DP2XAGbEFiberManagedSwitch
•Fouradhesiverubberfeet
•MountingAccessory(for19”RackShelf)
•OneprintedQuickStartGuide
•OneACPowerCord
•OneRS232DB9toRJ45Cable
Notifyyoursalesrepresentativeimmediatelyifanyoftheaboveitemsismissingordamaged.
Mounting
Theswitchcanbemountedinastandard19‐inchequipmentrackoronadesktoporshelfasfollows.
Rack Mounting
Beforerackmountingtheswitch,verifythesefactors:
•Temperature:Sincethetemperaturewithinarackassemblymaybehigherthantheambientroom
temperature,checkthattherack‐environmenttemperatureiswithinthespecifiedoperating
temperaturerange(‐20°to+60°C).
•MechanicalLoading:Donotplaceanyequipmentontopofarack‐mountedunit.
•CircuitOverloading:Besurethatthesupplycircuittotherackassemblyisnotoverloaded.
•Grounding:Rack‐mountedequipmentshouldbeproperlygrounded.
ToRack‐mountDevices:(Optional)
1. AttachthebracketstothedeviceusingthescrewsprovidedintheMountingAccessory.
 
2. Mountthedeviceintherack(viaRack‐Mountkit),usingfourrack‐mountingscrews(notprovided).Besureto
securethelowerrack‐mountingscrewsfirsttopreventthebracketsbeingbentbytheweightoftheswitch.
3. Ifinstallingasingleswitchonly,turnto“ConnectiontoaPowerSource”attheendofthischapter.
4. Ifinstallingmultipleswitches,mountthemintherack,onebelowtheother,inanyorder.

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 19 of 32
Desktop or Shelf Mounting
1. Attachthefouradhesiverubberfeettothebottomofthefirstswitch.

2. SetthedeviceonaflatsurfacenearanACpowersource,makingsurethereareatleasttwoinchesofspace
onallsidesforproperairflow.
3. Ifinstallingasingleswitchonly,goto“ConnectingtoaPowerSource”attheendofthisChapter.
4. Ifinstallingmultipleswitches,attachfouradhesivefeettoeachone.Placeeachdevicesquarelyontopofthe
onebelow,inanyorder.

TransitionNetworks SM12DP2XAInstallGuide
33751 Rev. C https://www.transition.com Page 20 of 32
EthernetCabling
Toensureproperoperationwheninstallingtheswitchintoanetwork,makesurethatthecurrentcablesare
suitableforyouroperatingenvironment.Checkthefollowingcriteriaagainstthecurrentinstallationofyour
network:
•Protectionfromradiofrequencyinterferenceemissions.
•Electricalsurgesuppression.
•Separationofelectricalwiresanddatabasednetworkwiring.
•Safeconnectionswithnodamagedcables,connectorsorshields.
WARNING:Themini‐GBICsareClass1laserdevices.Avoiddirecteyeexposuretothebeamcomingfrom
thetransmitport.
  
RJ‐45Connections  SFPTransceiver
Forfiberopticconnections,youmayuse50/125or62.5/125micronmultimodefiberor9/125micron
single‐modefiber.
Forcopperconnections,youmayuseunshieldedtwisted‐pair(UTP)forRJ‐45connections.For1Gbps
connectionsuseCategory5,5e,6,or6A.For10Gbpsconnectionsseethetablebelow.
TheIEEE802.3an‐2006,Table55‐12,CablingTypesandDistancesprovidesdistancedescriptionsasfollows:
CablingCategoryMaxLinkSegmentDistanceCablingreference(s)
ClassE/Category655mto100m*ISO/IECTR‐24750/TIA/EIATSB‐155
ClassE/Category6:unscreened55mISO/IECTR‐24750/TIA/EIATSB‐155
ClassE/Category6:screened100mISO/IECTR‐24750/TIA/EIATSB‐155
ClassF/(Category7)100mISO/IECTR‐24750
ClassEA/Category6A100mISO/IEC11801Ed2.1/TIA/EIA‐568‐B.2‐10
Formoreinformationseehttps://www.bicsi.org/double.aspx?l=3382.

