Transition Networks StackMaster SMHB-E-FL-12 User manual

StackMaster™
Manageable Hub
#7332.H
SMHB-E-TBT-16, SMHB-E-TBT-24, SMHB-E-FL-6, SMHB-E-FL-12,
SMME-E, SMMC-E
For assistance in installing, using, or
maintaining the TRANSITION Networks
StackMaster™ Manageable Hub, contact
TRANSITION Networks Technical
Support at:
[phone]
or contact your local distributor.

CAUTION: RJ connectors are NOT INTENDED FOR
CONNECTION TO THE PUBLIC TELEPHONE NETWORK.
Failure to observe this caution could result in damage to the
public telephone network.
Compliance Information
UL Listed
C-UL Listed (Canada)
CISPR/EN55022 Class A
FCC Regulations
This equipment has been tested and found to comply with the limits for a class
A digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case the user
will be required to correct the interference at the user’s own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for
digital apparatus set out on the radio interference regulations of the Canadian
Department of Communications.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
Copyright Restrictions
© 1995, 1997 TRANSITION Networks.
All rights reserved. No part of this work may be reproduced or used in any
form or by any means – graphic, electronic, or mechanical – without written
permission from TRANSITION Networks.
Trademark Notice
All registered trademarks and trademarks are the property of their respective
owners.
Der Anschluss dieses Gerätes an ein öffentlickes
Telekommunikationsnetz in den EG-Mitgliedstaaten verstösst gegen die
jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie
91/263/EWG zur Angleichung der Rechtsvorschriften der
Mitgliedstaaten über Telekommunikationsendeinrichtungen
einschliesslich der gegenseitigen Anerkennung ihrer Konformität.

Table of Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1
1.1 24-Port 10BaseT Repeater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
1.2 16-Port 10BaseT Repeater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–4
1.3 6-Port 10BaseFL Repeater. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6
1.4 12-Port 10BaseFL Repeater. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
1.5 StackMaster™ SNMP Management Unit . . . . . . . . . . . . . . . . . . . . . 1–10
1.6 SNMP Configuration Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–12
1.6.1 StackMaster™ Configuration Main Menu. . . . . . . . . . . . . . . . . 1–13
1.6.2 IP Parameters Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–15
1.6.3 SNMP Parameters Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–16
1.6.4 Serial Port Parameters Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 1–17
1.6.5 Bootp Parameters Menu (Currently Not Available). . . . . . . . . . 1–18
1.6.6 Miscellaneous Configuration Options Menu . . . . . . . . . . . . . . 1–19
2. SITE PLANNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
2.1 Site Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1
2.2 Ethernet Network Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . .2–1
2.3 Network Parameters Data Sheetss . . . . . . . . . . . . . . . . . . . . . . . . . . .2–2
TCP/IP Network Parameters Data Sheet . . . . . . . . . . . . . . . . . . . . 2-2
SNMP Network Parameters Data Sheet. . . . . . . . . . . . . . . . . . . . . 2-3
Serial Port Parameters Data Sheet. . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Bootp Parameters Data Sheet (Bootp Currently Not Available) . . . 2-5
3. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–1
3.1 Unpacking StackMaster™ Equipment . . . . . . . . . . . . . . . . . . . . . . . . .3–1
6-Port 10BaseFL Unit Packing Contents . . . . . . . . . . . . . . . . . . . .3–2
12-Port 10BaseFL Unit Packing Contents . . . . . . . . . . . . . . . . . . .3–2
24-Port 10BaseT Unit Packing Contents . . . . . . . . . . . . . . . . . . . .3–2
SNMP Management Unit Packing Contents (EXTERNAL UNIT) . .3–3
SNMP Management Board Packing Contents (INTERNAL UNIT) .3–3
3.2 Installing Units in Rack or on Table . . . . . . . . . . . . . . . . . . . . . . . . . .3–4
3.3.1 Standard 19-Inch Rack Installation . . . . . . . . . . . . . . . . . . . . . . .3–4
3.3.2 Table-Top Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–5
3.3 Cascading StackMaster™ Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–6
3.3.1 Cascading Units that Use SNMP Management . . . . . . . . . . . . . .3–6
Stack with EXTERNAL SNMP Management . . . . . . . . . . . . . . . . .3–6
i
USER’S GUIDE

Stack with INTERNAL SNMP Management . . . . . . . . . . . . . . . . .3–7
3.3.2 Cascading Units that do NOT Use SNMP Management . . . . . . .3–8
STACKED Unmanaged Units . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–8
SINGLE Unmanaged Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–9
3.4 Verifying Correct Inter-repeater Bus Termination . . . . . . . . . . . . . .3–10
Stack with EXTERNAL SNMP Management . . . . . . . . . . . . . . . .3–10
Stack with INTERNAL SNMP Management . . . . . . . . . . . . . . . .3–10
STACKED Unmanaged Units . . . . . . . . . . . . . . . . . . . . . . . . . . .3–11
SINGLE Unmanaged Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–11
3.5 Connecting StackMaster™ to Network . . . . . . . . . . . . . . . . . . . . . . .3–12
3.5.1 Five-Segment Rule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–12
3.5.2 Connecting to10BaseT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–14
RJ-45 Pin Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–15
3.5.3 Connecting to10BaseFL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–15
3.6 Connecting Units to Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–16
3.7 Resetting StackMaster™ Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–17
Managed Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–17
Unmanaged Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–17
3.8 Optionally Configuring SNMP Management at Attached Terminal .3–18
3.8.1 Connecting to ASCII Terminal . . . . . . . . . . . . . . . . . . . . . . . . .3–18
3.8.2 Bringing Up Configuration Software . . . . . . . . . . . . . . . . . . . .3–19
3.8.3 Resetting the StackMaster . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–20
3.8.4 Setting Network and SNMP Parameters . . . . . . . . . . . . . . . . . .3–21
Network Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–21
SNMP Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3–22
4. OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4–1
4.1 Power On/Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4–1
5. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–1
5.1 Fault Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–1
5.2 Recovery Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–4
5.2.1 Installing a Cascade Terminator . . . . . . . . . . . . . . . . . . . . . . . . .5–4
If External SNMP Management Unit is NOT used: . . . . . . . . . . . .5–4
For ALL Stacks of Two or More Units . . . . . . . . . . . . . . . . . . . . . .5–4
5.2.2 Resetting the StackMaster™ Stack . . . . . . . . . . . . . . . . . . . . . . .5–5
Managed Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–5
Unmanaged Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–5
5.3 Replacement Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–6
5.3.1 Replacing StackMaster™ Unit Fuses . . . . . . . . . . . . . . . . . . . . .5–6
5.4 StackMaster™ Field Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–7
ii StackMaster™

5.4.1 Installing SNMP Management Board in 24-Port 10BaseT Unit . .5–7
5.4.2 Installing SNMP Management Board in 6-Port or12-Port 10BaseFL
Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-10
5.4.3 Installing SNMP Management Board in 16-Port 10BaseT Unit .5-13
5.5 Software Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–16
5.5.1 Software Upgrade at Attached ASCII Terminal . . . . . . . . . . . . .5–16
Obtaining Updated StackMaster™ Software. . . . . . . . . . . . . . . .5–16
Connecting to ASCII Terminal . . . . . . . . . . . . . . . . . . . . . . . . . .5–16
Resetting the StackMaster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–17
Transferring the File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5–17
APPENDIX
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A–1
Cable Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B–1
Segment Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .C–1
Approved European Power Cord Set . . . . . . . . . . . . . . . . . . . . . . . . . . . .D–1
Regulation and Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .E–1
Policy and Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F–1
iii
USER’S GUIDE

iv StackMaster™

Preface
This guide is intended for the system or network administrator responsible
for installing, configuring, using, and maintaining a Transition Networks
StackMaster™ unit or stacked set of units. A working knowledge of local
area network (LAN) operations, including familiarity with communications
protocols used on interconnected LANs, is assumed.
v
USER’S GUIDE

1. Introduction
The StackMaster™ Ethernet Repeater Stack is an expandable stack of
repeater hubs, connected to various media, that functions through an
inter-repeater bus as a single Ethernet repeater. The minimum
StackMaster™ configuration consists of a single unit: the 16-Port 10BaseT
hub, the 24-Port 10BaseT hub, the 6-Port 10BaseFL hub, or the 12-Port
10BaseFL hub.
The StackMaster™ configuration is expanded by adding up to five
additional StackMaster™ repeaters selected from among the 24-Port
10BaseT hub, the 6-Port 10BaseFL hub, and/or the 12-Port 10BaseFL hub.
Inter-repeater bus connectors, located on the back of the StackMaster™
hubs, are used for cascading the six hubs into a single repeater.
Optional SNMP Management of a StackMaster™ stack is provided either
by an external SNMP Management hub or by an optional SNMP
Management circuit board installed in the 16-Port 10BaseT hub, the
StackMaster™ 24-Port 10BaseT hub, the 6-Port 10BaseFL hub or the 12-
Port 10BaseFL hub. The SNMP Management hub and SNMP management
circuit boards provide SNMP formatted information to external network
management platforms.
Fully configured StackMaster™ stacks can be connected to each other in a
network. (Each stack must have separate SNMP network management.)
Standard Ethernet network conventions regarding cable distances and
segment numbers must be followed.
Selectable hubs used in the StackMaster™ stack include:
• 16-Port 10BaseT hub (with optional SNMP management board)
• 24-Port 10BaseT hub (with optional SNMP management board)
• 6-Port 10BaseFL hub (with optional SNMP management board)
• 12-Port 10BaseFL hub (with optional SNMP management board)
• SNMP Management hub
1-1
MANAGEABLE HUB

1.1 24-Port 10BaseT Repeater
The StackMaster™ 24-Port 10BaseT hub supports twenty-four RJ-45
10BaseT connections to either shielded or unshielded twisted pair.
Additionally, the StackMaster™ 24-Port 10BaseT hub supports installation
of an SNMP Management Board that allows the StackMaster™ 24-Port
10BaseT hub to manage the entire StackMaster™ Stack.
Connectors
Twenty-four (24) RJ-45 connectors are provided at the front of the 24-Port
10BaseT hub.
NOTE: A power connector, DB9 serial port connector, AUI port
connector, and Cascade (bus) connector are provided at the back of the
24-Port 10BaseT hub.
Indicators
When the StackMaster™ 24-Port 10BaseT hub is powered, the Power
indicator is illuminated. Combination Link/Partition LEDs above each of
the twenty-four RJ-45 connectors indicate link and partition status for each
of the twenty-four 10BaseT connections:
green LED: good link
red LED: partition
1-2 StackMaster™
Power Reset
12345678 910111213141516 1718192021222324
1234
567 8
Expansion Card
Indicators
Enable Status
StackMaster™ 24 Port Manageable 10BaseT Hub
Link/Partition
TRANSITION
networks
Power Reset
12345678 910111213141516 1718192021222324
1234
567 8
Expansion Card
Indicators
Enable Status
StackMaster™24 Port Manageable 10BaseT Hub
Link/Partition
Power
21 22 23
TRANSITION
networks

When the SNMP Management circuit board is installed and managing the
StackMaster™ Stack, the Expansion Card Indicators (SNMP Management
circuit board indicators) are active. The Enable indicator is illuminated
when the SNMP Management circuit board is installed. When the
StackMaster™ Stack is functioning normally, the eight Status indicators
cycle in a steady roll.
Switches
The reset switch reinitializes the StackMaster™ 24-Port 10BaseT hub.
NOTE: If the SNMP Management Board is installed in the StackMaster™
24-Port 10BaseT hub and the StackMaster™ 24-Port 10BaseT hub is
installed at the top of a Stack, the reset switch resets the entire Stack.
1. INTRODUCTION
1-3
MANAGEABLE HUB
Power Reset
12345678 910111213141516 1718192021222324
1234
567 8
Expansion Card
Indicators
Enable Status
StackMaster™24 Port Manageable 10BaseT Hub
Link/Partition
Reset
TRANSITION
networks
Power Reset
12345678 910111213141516 1718192021222324
1234
567 8
Expansion Card
Indicators
Enable Status
StackMaster™24 Port Manageable 10BaseT Hub
Link/Partition
1 2 3 4
Expansion Card
Indicators
Status
5 6 7 8
Enable
TRANSITION
networks

1.2 16-Port 10BaseT Repeater
The StackMaster™ 16-Port 10BaseT Repeater hub supports sixteen RJ-45
10BaseT connections to either shielded or unshielded twisted pair.
Additionally, the StackMaster™ 16-Port 10BaseT hub supports installation
of an SNMP Management Board that allows the StackMaster™ 16-Port
10BaseT hub to manage the entire StackMaster™ Stack.
Connectors
Sixteen (16) RJ-45 connectors are provided at the front of the 16-Port
10BaseT Repeater hub.
A power connector, DB9 serial port connector, AUI port connector, and
Cascade (bus) connector are provided at the back of the 16-Port 10BaseT
hub.
Indicators
When the StackMaster™ 16-Port 10BaseT Repeater hub is powered, the
Power indicator is illuminated. Combination Link/Partition LEDs above
each of the sixteen RJ-45 connectors indicate link and partition status for
each of the sixteen 10BaseT connections:
green LED: good link
red LED: partition
1-4 StackMaster™
Power
Reset
12 3 45 6 78 910 111213 1415 16
Link/Partition
12 3 4
567 8
Expansion Card
Expansion Enable
Status
StackMaster™16 Port Manageable 10BaseT Hub
TRANSITION
networks
110-120
220-240
Caution : For continued protection
against risk of fire, replace only with same
type and rating of fuse : 250V 2A.
Caution : Disconnect power before replacing fuse.
ATTENTION: Couper le courant avant de replacer
le fusible.
2A, 250V
Input Power: 100-240 V
50/60 Hz
0.5 A
Model#: SMHB-E-TBT-16
7090 Shady Oak Road
Mpls, MN 55344
AUXSERIAL AUI
B
A
CASCADE CONNECTORS
E N G I N E E R I N G , I N C .
TRANSITION
Power
Reset
12 3 45 6 78 910 111213 1415 16
Link/Partition
12 3 4
567 8
Expansion Card
Expansion Enable
Status
StackMaster™16 Port Manageable 10BaseT Hub
11 12 13
Power
TRANSITION
networks

When the SNMP Management circuit board is installed and managing the
StackMaster™ Stack, the Expansion Enable and Expansion Card Status
Indicators (SNMP Management circuit board indicators) are active. The
Expansion Enable indicator is illuminated when the SNMP Management
circuit board is installed. When the StackMaster™ Stack is functioning
normally, the eight Expansion Card Status indicators cycle in a steady
roll.
Switches
The Reset switch reinitializes the StackMaster™ 16-Port 10BaseT
Repeater.
NOTE: If the SNMP Management Board is installed in the StackMaster™
16-Port 10BaseT Repeater hub and the StackMaster™ 16-Port 10BaseT
Repeater hub is installed at the top of a Stack, setting the reset switch
resets the entire Stack.
1. INTRODUCTION
1-5
MANAGEABLE HUB
Power
Reset
12 3 45 6 78 910 111213 1415 16
Link/Partition
12 3 4
567 8
Expansion Card
Expansion Enable
Status
StackMaster™16 Port Manageable 10BaseT Hub
Reset
TRANSITION
networks
Power
Reset
12 3 45 6 78 910 111213 1415 16
Link/Partition
12 3 4
567 8
Expansion Card
Expansion Enable
Status
StackMaster™16 Port Manageable 10BaseT Hub
1 2 3 4
Expansion Card
Status
Status
5 6 7 8
Expansion Enable
TRANSITION
networks

1-6 StackMaster™
1.3 6-Port 10BaseFL Repeater
The StackMaster™ 6-Port 10BaseFL Repeater hub supports six 10BaseFL
port connections. Additionally, the StackMaster™ 6-Port 10BaseFL hub
supports installation of an SNMP Management Board that allows the
StackMaster™ 6-Port 10BaseFL hub to manage the entire Stack.
Connectors
Six (6) 10BaseFL port connections through transmit (TX) and receive (RX)
ST connectors are provided at the front of the 6-Port 10BaseFL Repeater.
NOTE: A power connector, DB9 serial port connector, AUI port
connector, and Cascade (bus) connector are provided at the back of the 6-
Port 10BaseFL hub.
Indicators
When the StackMaster™ 6-Port 10BaseFL hub is powered, the Power
indicator is illuminated. Port Status LEDs above each of the six 10BaseFL
TX/RX port connector pairs indicate link status for each of the six
connections:
green LED: good link
Power
Reset
12345 6
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX
1234
567 8
Mgmt
Enable
Management
Status
6 Port StackMaster™FL
TRANSITION
networks
Power
Reset
12345 6
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX
1234
567 8
Mgmt
Enable
Management
Status
6 Port StackMaster™FL
12
Power
TRANSITION
networks

1. INTRODUCTION
1-7
MANAGEABLE HUB
When the SNMP Management circuit board is installed and managing the
StackMaster™ Stack, the SNMP Management circuit board indicators are
active. The Management(Mgmt) Enable indicator is illuminated when the
SNMP Management circuit board is installed. When the StackMaster™
Stack is functioning normally, the eight Management Status indicators
cycle in a steady roll.
Switches
The reset switch reinitializes the StackMaster™ 6-Port 10BaseFL hub.
NOTE: If the SNMP Management Board is installed in the StackMaster™
6-Port 10BaseFL hub and the StackMaster™ 6-Port 10BaseFL hub is
installed at the top of a Stack, the reset switch resets the entire Stack.
Power
Reset
12345 6
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX
1234
567 8
Mgmt
Enable
Management
Status
6 Port StackMaster™FL
Mgmt
Enable
1 2 3 4
5 6 7 8
Management
Status
TRANSITION
networks
Power
Reset
12345 6
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX
1234
567 8
Mgmt
Enable
Management
Status
6 Port StackMaster™FL
Reset
TRANSITION
networks

1.4 12-Port 10BaseFL Repeater
The StackMaster™ 12-Port 10BaseFL hub supports twelve 10BaseFL port
connections. Additionally, the StackMaster™ 12-Port 10BaseFL hub
supports installation of an SNMP Management Board that allows the
StackMaster™ 12-Port 10BaseFL hub to manage the entire Stack.
Connectors
Twelve (12) 10BaseFL port connections through transmit (TX) and receive
(RX) ST connectors are provided at the front of the 12-Port 10BaseFL hub.
NOTE: A power connector, DB9 serial port connector, AUI port
connector, and Cascade (bus) connector are provided at the back of the
12-Port 10BaseFL hub.
Indicators
When the StackMaster™ 12-Port 10BaseFL hub is powered, the Power
indicator is illuminated. Port Status LEDs above each of the twelve
10BaseFL TX/RX port connector pairs indicate link status for each of the
twelve input/output connections.
green LED: good link
1-8 StackMaster™
Power
Reset
12345 6 7 8 910 11
12
1234
567 8
Mgmt
Enable
Management
Status
StackMaster™FL
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX
TRANSITION
networks
Power
Reset
12345 6 7 8 910 11
12
1234
567 8
Mgmt
Enable
Management
Status
StackMaster™FL
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX
78
Power
TRANSITION
networks

When the SNMP Management circuit board is installed and managing the
StackMaster™ Stack, the SNMP Management circuit board indicators are
active. The Management(Mgmt) Enable indicator is illuminated when the
SNMP Management circuit board is installed. When the StackMaster™
Stack is functioning normally, the eight Management Status indicators
cycle in a steady roll.
Switches
The reset switch reinitializes the StackMaster™ 12-Port 10BaseFL hub.
NOTE: If the SNMP Management Board is installed in the StackMaster™
12-Port 10BaseFL hub and the StackMaster™ 12-Port 10BaseFL hub is
installed at the top of a Stack, the reset switch resets the entire Stack.
1. INTRODUCTION
1-9
MANAGEABLE HUB
Mgmt
Enable
Power
Reset
12345 6 7 8 910 11
12
1234
567 8
Mgmt
Enable
Management
Status
StackMaster™FL
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX
1 2 3 4
5 6 7 8
Management
Status
TRANSITION
networks
Power
Reset
12345 6 7 8 910 11
12
1234
567 8
Mgmt
Enable
Management
Status
StackMaster™FL
Port
Status
RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX RX TX
Reset
TRANSITION
networks

1.5 StackMaster™ SNMP Management Unit
The optional StackMaster™ SNMP Management unit can be installed at
the top of the StackMaster™ stack to provide SNMP formatted information
to external network management platforms.
NOTE: SNMP management also can be provided by an optional SNMP
management circuit board installed in one of the StackMaster™ units.
Connectors
A Management Interface (bus) connector, DB9 Serial Port connector, and
power connector are provided at the back of the SNMP Management hub.
Indicators
When the StackMaster™ SNMP Management hub is powered, the Power
indicator is illuminated. When the StackMaster™ Stack is functioning
normally, the eight Status indicators cycle in a steady roll.
1-10 StackMaster™
Serial Port Management Interface
110-120
220-240
Power
Serial Port
Management Interface
StackMaster™
Network Management Unit
Ethernet
Power
Reset
Status
Status
Power
networks
TRANSITION
StackMaster™
Network Management Unit
Ethernet
Power
Reset
Status
networks
TRANSITION

Switches
The reset switch on the StackMaster™SNMP Management hub
reinitializes the entire stack.
NOTE: The StackMaster™SNMP Management hub uses “flash ROM”,
which allows firmware upgrades over the network.
1. INTRODUCTION
1-11
MANAGEABLE HUB
StackMaster™
Network Management Unit
Ethernet
Power
Reset
Status
Reset
networks
TRANSITION

1.6 SNMP Configuration Software
The StackMaster™comes with software configuration parameters set to
standard default values. Through a set of configuration menus displayed at
an ASCII terminal or terminal emulation attached to the SNMP
Management hub or to a StackMaster™hub which has the SNMP
management board installed , users are guided through modifying SNMP
management configuration parameters.
1-12 StackMaster™
Serial Port Parameters Menu
baud = data bits =
stop bits = parity =
SERIAL >
SNMP Parameters Menu
commwrite = commread =
auth = trap =
sysname = contact =
location =
SNMP >
Parameters Menus
StackMaster Configuration Main Menu
MAIN >
main serial
ip bootp
snmp misc
Miscellaneous Options Menu
Bootp Menu
Bootp Parameters Menu
bootserver = file =
dir = mode =
BOOTP >
Misc. Configuration Options Menu
restart =
factory =
save =
keys =
MISC >
read =
quit =
Configuration Main Menu
Network Parameters Menu
name =
domain =
nameserver =
IP>
ipaddr =
submask =
router =
