Read Me First
SM24DPA Packing List:
Before you start installing SM24DPA Managed Switch, please verify that the package
contains the following items:
16-Port 100/1000 Dual speed SFP + 8-Port RJ-45/SFP (100/1000) L2 Managed
Switch
AC Power Cord
Mounting Accessory (for 19” Rack Shelf)
User’s Guide CD-ROM
RS-232 Null Modem Cable
Please notify your sales representative immediately if any of the aforementioned items is
missing or damaged.
Power Requirements:
Voltage : 100240 VAC
Frequency : 5060 Hz
Consumption : 30W
Quick Installation:
1. Install the switch in the rack with mounting accessory.
2. Connect the SM24DPA switch to an AC power source.
3. The port 9–24 connector is (100/1000) SFP port on the switch. Use Fiber cable to
connect between SM24DPAand end station.
4. The port 1– 8 includes two types of media --- TP and (100/1000M) SFP fiber module;
they support TP or fiber with auto-detected function.
5. Use RS-232 interface to pre-configure SM24DPAfor network management.
For example: IP address, VLAN, Port Trunk, STP, etc.
SM24DPA switch’s serial port default settings are listed as follows:
Baud rate 115200
Stop bits 1
Data bits 8
Parity N
Flow control none
The default values of SM24DPA switch are as follows:
IPAddress : 192.168.1.77
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.1.254
Username : admin
Password : admin
User also can use telnet or web to pre-configure SM24DPA with the default IP address
and username/password in the first configuration. Please refer to User’s Guide contained
in CD-ROM for details on the setting of parameters. SM24DPA user’s manual is filed

under the path: \manual of the CD-ROM.
Warning:
Self-demolition on Product is strictly prohibited. Damage caused by self-demolition will
be charged for repairing fees.
Do not place product at outdoor or sandstorm.
Before installation, please make sure input power supply and product specifications are
compatible to each other.
Before importing / exporting configuration please make sure the firmware version is
always the same.
After firmware upgrade, the switch will remove the configuration automatically to latest
firmware version.
