Travis Industries 564 TRV 25K User manual

Gas Fireplace
Framing Guide
NOTE: FOR GENERAL REFERENCE ONLY.
Always consult the appliance and accessory installation
manuals for detailed installation information.
Manuals are found at
www.fireplacex.com
or
by scanning the
QR codes on the following pages
Copyright © 2021 - 17602168

Page 2
17602168 - 9/23/21
Why are there multiple framing specifications for the same unit?
...............................................................................................3
564 TRV 25K .........................................................................4
564 TRV 25K - Fireplace Dimensions................................4
564 TRV 25K - Framing Dimensions - Standard................5
564 TRV 25K - Framing Dimension - With CoolSmart Kit..6
564 TRV 25K - Framing Dimension - With CoolSmart Side
Vent Kit ..............................................................................7
564 TRV 25K CleanFace.......................................................8
564 TRV 25K CF - Fireplace Dimensions ..........................8
564 TRV 25K CF - Framing Dimensions - Standard..........9
564 TRV 25K CF - Framing Dimension - With CoolSmart Kit
.........................................................................................10
564 TRV 25K CF - Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................11
564 TV 35K..........................................................................12
564 TV 35K - Fireplace Dimensions.................................12
564 TV 35K - Framing Dimensions - Standard ................13
564 TV 35K - Framing Dimension - With CoolSmart Kit...14
564 TV 35K - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................15
564 TV 35K CleanFace........................................................16
564 TV 35K CF - Fireplace Dimensions...........................16
564 TV 35K CF - Framing Dimensions - Standard...........17
564 TV 35K CF - Framing Dimension - With CoolSmart Kit18
564 TV 35K CF - Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................19
864 TRV 31K .......................................................................20
864 TRV 31K - Fireplace Dimensions..............................20
864 TRV 31K - Framing Dimensions - Standard..............21
864 TRV 31K - Framing Dimension - With CoolSmart Kit22
864 TRV 31K - Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................23
864 TRV 31K CleanFace.....................................................24
864 TRV 31K CF - Fireplace Dimensions ........................24
864 TRV 31K CF - Framing Dimensions - Standard........25
864 TRV 31K CF - Framing Dimension - With CoolSmart Kit
.........................................................................................26
864 TRV 31K CF -Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................27
864 TV 40K..........................................................................28
864 TV 40K - Fireplace Dimensions.................................28
864 TV 40K - Framing Dimensions - Standard ................29
864 TV 40K - Framing Dimension - With CoolSmart Kit...30
864 TV 40K - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................31
864 TV 40K CleanFace........................................................32
864 TV 40K CF - Fireplace Dimensions...........................32
864 TV 40K CF - Framing Dimensions - Standard...........33
864 TV 40K CF - Framing Dimension - With CoolSmart Kit34
864 TV 40K CF - Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................35
4237 EG...............................................................................36
4237 TV - Fireplace Dimensions......................................36
4237 TV - Framing Dimensions - Standard......................37
4237 EG - Framing Dimension - With CoolSmart Kit .......38
4237 EG - Framing Dimension - With CoolSmart Side Vent Kit
.........................................................................................39
3615 HO Linear ...................................................................40
3615 HO - Fireplace Dimensions.....................................40
3615 HO - Framing Dimensions - Standard.....................41
3615 HO - Framing Dimension - With CoolSmart Kit.......42
3615 HO - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................43
4415 HO Linear ...................................................................44
4415 HO - Fireplace Dimensions.....................................44
4415 HO - Framing Dimensions - Standard.....................45
4415 HO - Framing Dimension - With CoolSmart Kit.......46
4415 HO - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................47
4415 HO See-Through Linear .............................................48
4415 HO ST - Fireplace Dimensions ...............................48
4415 HO ST - Framing Dimensions - Standard ...............49
6015 HO Linear ...................................................................50
6015 HO - Fireplace Dimensions.....................................50
6015 HO - Framing Dimensions - Standard.....................51
6015 HO - Framing Dimension - With CoolSmart Kit.......52
6015 HO - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................53
ProBuilder™ 42 Linear ........................................................54
PB 42 Linear - Fireplace Dimensions...............................54
PB 42 Linear - Framing Dimensions - Standard...............55
PB 42 Linear - Framing Dimension - With CoolSmart Kit.56
PB 42 Linear - Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................57
ProBuilder™ 54 Linear ........................................................58
PB 54 Linear - Fireplace Dimensions...............................58
PB 54 Linear - Framing Dimensions - Standard...............59
PB 54 Linear - Framing Dimension - With CoolSmart Kit.60
PB 54 Linear - Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................61
ProBuilder™ 72 Linear ........................................................62
PB 72 Linear - Fireplace Dimensions...............................62
PB 72 Linear - Framing Dimensions - Standard...............63
PB 72 Linear - Framing Dimension - With CoolSmart Kit.64
PB 72 Linear - Framing Dimension - With CoolSmart Side
Vent Kit ............................................................................65
ProBuilder 24CF..................................................................66
PB 24CF - Fireplace Dimensions.....................................66
PB 24CF - Framing Dimensions - Standard.....................67
PB 24CF - Framing Dimension - With CoolSmart Kit.......68
PB 24CF - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................69
ProBuilder 36CF..................................................................70
PB 36CF - Fireplace Dimensions.....................................70
PB 36CF - Framing Dimensions - Standard.....................71
PB 36CF - Framing Dimension - With CoolSmart Kit.......72
PB 36CF - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................73
ProBuilder 42CF..................................................................74
PB 42CF - Fireplace Dimensions.....................................74
PB 42CF - Framing Dimensions - Standard.....................75
PB 42CF - Framing Dimension - With CoolSmart Kit.......76
PB 42CF - Framing Dimension - With CoolSmart Side Vent
Kit.....................................................................................77
Gas Fireplace Installation Worksheet ..................................78

Page 3
17602168 - 9/23/21
Why are there multiple framing specifications for the same unit?
You will notice the there are multiple framing diagrams and specifications for many of the units included in this
framing guide. Travis Industries has developed a means to reduce the amount of heat that is exhausted from
the front of the fireplace by relocating that heat to another location. This optional accessory is referred to as
the CoolSmart TV Wall™ Kit.
Relocating the heat to a location higher on the wall (or to the sides of the fireplace enclosure) allows for
reduced clearances, lower television installations above the fireplace, and allows for more flexible wall finish
parameters for some fireplaces. Sometimes the dimensions of the enclosure are dictated by the size of the
appliance and required clearances for the fireplace, other times the dimensions are dictated by the dimensions
of the CoolSmart TV Wall kit if it is used. Make sure to thoroughly plan your installation and decided if you will
be using one of the CoolSmart TV Wall kits before beginning framing.
Travis Industries offers two different styles of CoolSmart kits:
The original front-facing CoolSmart TV Wall kit that vents the heat from the fireplace directly above the
opening of the fireplace but higher up on the wall. This kit exhausts the heat into the room through one long,
narrow manifold, allowing it to blend into the finish of the wall.
The new Side Vent CoolSmart TV Wall kit. This new kit works on the same principles as the original
CoolSmart kit but uses two manifolds to move the air into the room rather than the single manifold in the
original CoolSmart kit. These Side Vent manifolds are shorter in width but taller than the original CoolSmart
manifold to allow for the equivalent amount of airflow but also allow for placement in a variety of locations. The
Side Vent manifolds may be placed on the front, sides, or rear of the enclosure as long as it is in the same
conditioned space as the fireplace.
CoolSmart TV Wall Kit CoolSmart Side Vent Kit

Page 4
17602168 - 9/23/21
564 TRV 25K
 Heating Capacity: Up to 1,250 square feet
 BTU Input Per Hour: 7,500 (NG) 6,500 (LP)
to 25,000 (NG/LP)
 Glass Viewing Area: Tempered Glass, 29-
3/8″W x 16 3/8″H, 479.8 Sq. In.
Scan for
Installation Manual
564 TRV 25K - Fireplace Dimensions
37-1/4"*
947mm
17-1/4"*
439mm
28-1/2"*
724mm
30-1/4"
768mm
1"
25mm
28-3/4"
730mm
18-7/8"
480mm
31-3/4"
794mm
Top Vent Configuration
8" (203mm) Diameter Vent 4-3/4"
121mm
32-3/4"
832mm
* Includes 1/2"
(
13mm
)
clearance - see "Clearances" and "Framin
g
Dimensions" for details
.
37"
940mm
Lifting Handle
Rear Vent
C
on
f
iguration
8" (203mm) Diameter Vent
BackofFireplace
24-1/4"
616mm

Page 5
17602168 - 9/23/21
564 TRV 25K - Framing Dimensions - Standard
37-3/4"
959mm 17-1/2"
445mm
37-1/4"
947mm
MIn. Enclosure
39-1/2" 1004mm
Max. 3"
77mm

Page 6
17602168 - 9/23/21
564 TRV 25K - Framing Dimension - With CoolSmart Kit
564 25K Standard
a 37-3/4” (959mm)
b 17-1/2” (445mm)
c 37-1/4” (947mm)
Max. 120"
3048mm
Min. 70-7/8"
1801mm
3-3/4"
96mm
Upper Manifold Framing
Lower Manifold Framing
8-1/2"
216mm
Bottom of Upper
Manifold Framing
Braces for Manifold
Support Brackets
26-1/2" 674mm
ab
c

Page 7
17602168 - 9/23/21
564 TRV 25K - Framing Dimension - With CoolSmart Side Vent Kit
564 25K
a 37-3/4” (959mm)
b 17-1/2” (445mm)
c 37-1/4” (947mm)

Page 8
17602168 - 9/23/21
564 TRV 25K CleanFace
 Heating Capacity: Up to 1,250 square feet
 BTU Input Per Hour: 7,500 (NG) 6,500 (LP) to
25,000 (NG/LP)
 Glass Viewing Area: Tempered Glass, 29-3/8″
W x 16 3/8″H, 479.8 Sq. In.
Scan for
Installation Manual
564 TRV 25K CF - Fireplace Dimensions
* See "Clearances" and "Framing Dimensions" for details.
31-3/4"
807mm
38-1/4"
972mm
4-3/4"
121mm
Top Vent Configuration
8" (203mm) Ø Vent
Framing Opening
Left
a'gauche
Front
avant
Right
droit
Rear
arrie're
Baseplate
The bottom of the face is
1/8" (4mm) above the
baseplate.
5-3/4"
147mm
19-3/4"
502mm
37"
940mm
7-5/8"
194mm
33-1/8"
842mm
32-5/8"
829mm
19-1/8" *
486mm
28-1/2"*
724mm
Rear Vent
C
on
f
iguration
8" (203mm) Diameter Vent
BackofFireplace
24-1/4"
616mm

Page 9
17602168 - 9/23/21
564 TRV 25K CF - Framing Dimensions - Standard
38-3/4"
985mm 19-3/8" 493mm Flush Install
18-7/8" 480mm Extended (Tile Over) Install
37-1/4"
947mm
MIn. Enclosure
39-1/2" 1004mm



Max. 3"
77mm

Page 10
17602168 - 9/23/21
564 TRV 25K CF - Framing Dimension - With CoolSmart Kit
564 25K CleanFace
a 38-3/4” (985mm)
b 19-3/8” (493mm) Flush
18-7/8” (480mm) Extended
c 37-1/4” (947mm)
Max. 120"
3048mm
Min. 70-7/8"
1801mm
3-3/4"
96mm
Upper Manifold Framing
Lower Manifold Framing
8-1/2"
216mm
Bottom of Upper
Manifold Framing
Braces for Manifold
Support Brackets
26-1/2" 674mm
ab
c

Page 11
17602168 - 9/23/21
564 TRV 25K CF - Framing Dimension - With CoolSmart Side Vent Kit
564 25K CleanFace
a 38-3/4” (985mm)
b 19-3/8” (493mm) Flush
18-7/8” (480mm) Extended
c 37-1/4” (947mm)

Page 12
17602168 - 9/23/21
564 TV 35K
 Heating Capacity: Up to 1,700 square feet
 BTU Input Per Hour: 12,000 (NG) 7,500 (LP)
to 35,000 (NG/LP)
 Glass Viewing Area: Ceramic Glass, 29-3/8″
W x 16 3/8″H, 479.8 Sq. In.
Scan for
Installation Manual
564 TV 35K - Fireplace Dimensions

Page 13
17602168 - 9/23/21
564 TV 35K - Framing Dimensions - Standard
37-3/4"
(959mm)
17-1/2" (445mm)
Minimum
Enclosure
Height
58-1/4"
70-1/4"
NG
LP
(1480mm)
(1784mm)
37-1/4"
(947mm)
Max. Header Depth
3” (77mm)

Page 14
17602168 - 9/23/21
564 TV 35K - Framing Dimension - With CoolSmart Kit
564 35K Standard
a 37-3/4” (959mm)
b 17-1/2” (445mm)
c 37-1/4” (947mm)
3-3/4"
UpperManifoldFraming
LowerManifoldFraming
8-1/2"
Bottom of Upper
Manifold Framing
Braces for Manifold
Support Brackets
26-1/2" (674mm)
(216mm)
(96mm)
Max. 120"
(3048mm)
Min. 76-7/8"
(1953mm)
a
b
c

Page 15
17602168 - 9/23/21
564 TV 35K - Framing Dimension - With CoolSmart Side Vent Kit
564 35K
a 37-3/4” (959mm)
b 17-1/2” (445mm)
c 37-1/4” (947mm)

Page 16
17602168 - 9/23/21
564 TV 35K CleanFace
 Heating Capacity: Up to 1,700 square feet
 BTU Input Per Hour: 12,000 (NG) 7,500 (LP)
to 35,000 (NG/LP)
 Glass Viewing Area: Ceramic Glass, 29-3/8″
W x 16 3/8″H, 479.8 Sq. In.
Scan for
Installation Manual
564 TV 35K CF - Fireplace Dimensions

Page 17
17602168 - 9/23/21
564 TV 35K CF - Framing Dimensions - Standard
38-3/4"
(985mm)
37-1/4"
(947mm)
Max. Header Depth
3” (77mm)
Minimum
Enclosure
Height
58-1/4"
70-1/4"
NG
LP
(1480mm)
(1784mm)
19-3/8” (493mm) Flush Install
18-7-8” (480mm) Extended (Tile Over) Install

Page 18
17602168 - 9/23/21
564 TV 35K CF - Framing Dimension - With CoolSmart Kit
564 35K CleanFace
a 38-3/4” (985mm)
b 19-3/8” (493mm) Flush
18-7/8” (480mm) Extended
c 37-1/4” (947mm)
3-3/4"
UpperManifoldFraming
LowerManifoldFraming
8-1/2"
Bottom of Upper
Manifold Framing
Braces for Manifold
Support Brackets
26-1/2" (674mm)
(216mm)
(96mm)
Max. 120"
(3048mm)
Min. 76-7/8"
(1953mm)
a
b
c

Page 19
17602168 - 9/23/21
564 TV 35K CF - Framing Dimension - With CoolSmart Side Vent Kit
564 35K CleanFace
a 38-3/4” (985mm)
b 19-3/8” (493mm) Flush
18-7/8” (480mm) Extended
c 37-1/4” (947mm)

Page 20
17602168 - 9/23/21
864 TRV 31K
 Heating Capacity: Up to 1,400 square feet
 BTU Input Per Hour: 10,000 (NG) 8,000 (LP) to
31,000 (NG/LP)
 Glass Viewing Area: Tempered Glass, 34-1/4″W x
22-1/4″H, 758.8 Sq. In.
Scan for
Installation Manual
864 TRV 31K - Fireplace Dimensions
T
op Vent Configuration
8" (203mm) Ø Vent
38-1/4"
972mm
36-3/4"
933mm
41"
1041mm
20-3/4"*
528mm*
38-1/4"
972mm
28-5/8"*
728mm*
37"
940mm
35-1/4"
895mm
7-1/4"
184mm
1"
25mm
* See "Clearances" and "Framing Dimensions" for details.
Optional "CoolSmart TV" or
"Power Heat Duct" Connection
30-3/4"
781mm
BackofFireplace
Rear Vent
C
on
f
iguration
8" (203mm) Ø Vent
