Interior, Shell - Almond
98500670
Page 1 of 2 Printed 1/13/04 © Travis Industries, Inc.
Compatibility
• 21 DV Fireplace
• Sweet Dreams Stove
Packing List
Firebox Interior
Important Warnings
• Turn off gas to the appliance and make sure it has fully cooled prior to conducting service.
• The firebox liner is very heavy (46 Lbs.) take care to prevent damage.
Installation
1 Remove the face, glass, embers, and burner (see the owner’s manual for details).
2 Follow the directions below to remove and discard the steel liner.
Lift the back of the liner so the
tab disengages from this slot
on the niche shelf.
a
b
c
Push the
bottom edge
of the liner to
the back of
the firebox.




Steel Liner Liner
Liner Shelf
Tilt the steel liner forward and pull it out of
the firebox (pull the top edge out first).

Interior, Shell - Almond
98500670
Page 2 of 2 Printed 1/13/04 © Travis Industries, Inc.
3 Install the interior following the directions below.
(a) Tilt the interior
forward and at a
slight angle as you
insert it into the
firebox.
Place the bottom
right corner into
the firebox first.
Note how it fits
behind the pilot
assembly.
(b) Rotate the
interior behind the
pilot assembly –
you may need to
tilt the interior
slightly so it fits
into the firebox.
(c) While
positioning the
interior, you may
wish to push it
upwards.
(d) Once in
position pull the
interior forward so
it is against the
front flanges of the
firebox. Center
the liner from side
to side.
4 Replace the burner, logs, embers, glass, and face.
