TRENDnet TEW-755AP2KAC V1 User manual

TEW-755AP2KAC (V1) / TEW-821DAP2KAC (V1)
Quick Installation Guide

Table of Content
1 English
1. Before You Start
2. Hardware Installation and Configuration
3. Connect your wireless access points

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
1
1. Before You Start
Package Contents
Ÿ1 x TEW-WLC100 wireless LAN controller
Ÿ 2 x TEW-755AP N300 PoE access points or TEW-821DAP AC1200 dual band PoE access
points
Ÿ2 x TPE-113GI 802.3af Gigabit PoE injectors
Ÿ2 x Network cables (1.5 m / 5 ft.)
ŸTEW-WLC100 power adapter (12V DC, 1A)
ŸQuick Installation Guide
ŸCD-ROM (User's Guide)
ŸController rack mount kit
ŸAccess point mounting plates
Minimum Requirements
ŸComputer with an Ethernet port and web browser
Ÿ Network cable for computer connection to controller
Ÿ Network cables for access point connections to PoE injectors
Important Note: Make sure your existing network is using a DHCP server to distribute IP
addresses to the access points. By default, TRENDnet access points listed below will obtain an IP
address automatically through DHCP or otherwise default back to 192.168.10.100 /
255.255.255.0 if a DHCP server is not available on your network. Each access point must be
assigned a unique IP address on the same network. The wireless controller and access points
must be connected to the same IP subnet on your network (e.g. 192.168.10.x / 255.255.255.0).
Optional Equipment
Ÿ EIA standard 19” rack
Ÿ Power drill/drill bits and Phillips bit or screwdriver for mounting

2
Access Point Model Description Controller Compatible
Firmware Version
TEW-755AP N300 PoE Access Point 1.03 or above
TEW-821DAP AC1200 Dual Band PoE Access Point 1.05 or above
TEW-825DAP AC1750 Dual Band PoE Access Point 1.01 or above
Access Point Compatibility
By default, the access points included in this kit are controller ready. For any additional access
points, please refer to the access point model compatibility list below and controller compatible
firmware version. You can download the access point's firmware from
http://www.trendnet.com/support which include instructions on how to upgrade the firmware.
Before any additional access points are added to the wireless controller, make sure to reset the
access points to factory default.

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
3
2. Initial Controller Setup
3. Assign a Static IP address to your computer's network adapter in the subnet of 192.168.10.x
(e.g. 192.168.10.25) and a subnet mask of 255.255.255.0.
4. Open your web browser, type the default IP address of the wireless controller in the address
bar, and then press Enter. The default IP address is 192.168.10.200.
Note: Before connecting the wireless controller to the network and connecting other devices
such as PoE injectors or access points, follow the steps to set up your controller IP address
settings and administrator password first.
1
Power
2

4
6. Click Management and click on LAN.
5. Enter the User name and Password, and then click Login. By default:
User Name: admin
Password: admin
LAN
Management
Login

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
5
8. To change the controller administrator password, click Account Settings and click Edit.
Edit
Account Settings
7. Configure the wireless controller IP address settings to match the requirements of your
network and click Apply.
IP Address
Netmask
Gateway
DNS1
DNS2
192.168.10.200
255.255.255.0
192.168.10.1
192.168.10.1
Apply
Network Settings
LAN Settings TEW-WLC100

6
10. Using an Ethernet cable, connect one of the five Gigabit Ethernet ports located on the back of
the wireless controller to your network (e.g. router, switch, etc.)
Network
9. In the New Password and Confirm Password fields, enter the new administrator password
and click OK to save the new password settings. You will be prompted immediately
afterwards to login to the controller management page with the new password.
OK
Confirm Password
New Password

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
7
3. Connect your wireless access points
Note: Before mounting the access points to the desired locations, connect the access point
locally directly to the wireless controller first for initial configuration. The access points are
standard IEEE 802.3af PoE compliant and may also be connected to a PoE/PoE+ switch for data
and power, however, for the purposes of this installation guide we will reference installation
using the supplied PoE injectors.
1. Connect the included PoE injector power adapters to the supplied PoE injectors DC IN power
ports. Connect the adapters to available power outlets to power on the PoE injectors.
2. Using the included Ethernet cables, connect the wireless controller to the DATA IN ports of
the PoE injectors.
3. Using additional Ethernet cables, connect the access points to the PWR+DATA OUT ports
of the PoE injectors.
Access Point
Power
Access Point
PWR+ DATA
OUT
DATA
IN
PoE Injector
Power
PWR+ DATA
OUT
DATA
IN
PoE Injector
Network

8
4. Initial Wireless Setup
1. Using your computer and web browser, access the wireless controller management page
using the newly assigned IP address settings (configured in Section 2) and login.
Note: If the IP address settings were not changed in Section 2, the IP address settings for the
controller are 192.168.10.200 / 255.255.255.0.
2. Click Monitor and click Devices.
3. The access points will be discovered automatically and appear in the Device List.
Note: If the access points do not appear, make sure access points are powered by checking the
physical LEDs and physical cable connections and refresh the page.
Login
Devices
Monitor

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
9
4. After the access points are discovered and appear in the Device List, under the Action
column, click on each access point to add them to the wireless controller.
5. Once the access points have been added to the wireless controller, the Status will change
from NEW to RUN.
6. Click Configuration and click Wireless Groups/Profiles.
Device Name Mac Address Address Wifi Group Status Client DOWN UP History Channel Type Action
D8:EB:97:31:5A:31
00:18:E7:95:92:45
192.168.10.21
192.168.10.22
NEW
NEW
Accept
Accept
Device Name Mac Address Address Wireless Group Status Client DOWN UP History Channel Type Action
192.168.10.26
192.168.10.25
RUN
RUN
Edt
TEW-821DAP
TEW-821DAP
00:18:E7:95:92:45
D8:EB:97:31:5A:31
1(2.4G)/1(5G)
1(2.4G)/1(5G)
0
0
0B
0B
0B
0B
AP
AP Edt
Accept
Configuration
Wireless Groups/Profiles

10
8. In the Edit Wireless Group window, enter the wireless network name/SSID for the wireless
network. (e.g. TRENDnet-WiFi)
Note: The SSID is the wireless network name used to broadcast and be discovered by your
wireless client devices to connect to your wireless network.
9. For Roaming options, select 802.11k and OKC wireless roaming protocols to ensure
fast transition wireless connectivity for client devices when roaming between multiple access
points.
10. For Authentication method, select WPA/WPA2-PSK. For the WPA Cipher, select AES and
enter the Pre-Shared Key required to connect to your wireless network. Click OK.
Note: The pre-shared key is the key/password (8-63 alphanumeric characters) client devices
will be required to enter in order to connect to your wireless network.
11. The initial wireless settings are complete. You can use the included hardware to mount the
access points to the desired locations.
Note: The access points must be connected to the same IP subnet as your wireless controller.
(e.g. 192.168.10.x / 255.255.255.0)
7. In the list below, click Create to create a new wireless profile.
Roaming 802.11k 802.11r OKC
SSID TRENDnet-WiFi

ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
11
12. To mount the access points, install the mounting plates first to the desired wall or ceiling
using the included drywall anchors and screws. Install the mounting plates with the clips
facing away from the wall. If wall mounting, install the mounting plates with the correct
orientation. After the mounting plates are properly installed, align the access point mounting
holes with the mounting plate clips and slide in access point to lock into place.
For detailed information regarding advanced settings, please refer to the User's Guide found on
the included CD.
Clip
Mounting Plate
( for wall mounting)Orientation
Ceiling
Access Point
Drywall Anchors
ClipClip
Clip
Clip Clip Mounting Plate
Drywall Screws
This side up
